Brickcom OB-E200Af Instructions d'utilisation

Hardware User’s Manual

Megapixel Day & Night

Bullet Network Camera

OB-E200Af / OB-E200Nf

Product name:

Network Camera (OB-E200Af / OB-E200Nf)

Release Date:

2014/9

Version:

V1.0

Web site:

www.brickcom.com

Email:

support@brickcom.com

[email protected]

Editor:

Tracy Cho

Table of Contents

Before You Use This Product .......................................................................................1

FCC Warning..................................................................................................................2

Regulatory Information .................................................................................................3

Chapter 1 - Package Contents......................................................................................4

Chapter 2 - Megapixel Day & Night Bullet Network Camera Overview .....................5

Chapter 3 - Device Appearance Description ...............................................................6

Chapter 4 - LED Behavior .............................................................................................7

Chapter 5 - Hardware Reset..........................................................................................8

Chapter 6 - System Requirements ...............................................................................9

Chapter 7 - Installation................................................................................................10

7.1 Hardware Installation .....................................................................................10

7.2 Camera Connection........................................................................................10

7.3 Software Installation.......................................................................................12

7.4 Launch EasyConfig........................................................................................15

Chapter 8 - Accessing the Network Camera..............................................................24

8.1 Check Network Settings ................................................................................24

8.2 Add the Password to Prevent Unauthorized Access...................................24

8.3 Viewing Video Streams with Internet Explorer.............................................25

Chapter 9 - Viewing Video Streams with BRC64.......................................................26

Before You Use This Product

In many countries, there are laws prohibiting or restricting the use of surveillance

devices. This Network Camera is a high-performance, web-ready camera which can be

part of a flexible surveillance system. It is the user’s responsibility to ensure that the

operation of this camera is legal before installing this unit for its intended use.

Upon opening the product’s package, verify that all the accessories listed on the

“Package Contents” are included. Before installing the Network Camera, read the

warnings in the “Quick Installation Guide” to avoid misuse. When installing the Network

Camera, carefully read and follow the instructions in the “Installation” chapters to avoid

damages due to faulty assembly or installation.

FCC Warning

This device complies with Part 15 of FCC rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference that may

cause undesired operations.

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance 20cm between the radiator & your body.

This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.

The availability of some specific channels and/or operational frequency bands are

country dependent and are firmware programmed at the factory to match the

intended destination. The firmware setting is not accessible by the end user.

Chapter 1 - Package Contents

1. Network Camera

2. Screw Bag

3. Power Adapter(*)

4. Product CD

5. POE Injector(*)

NOTE - (*) These are optional features.

Chapter 2 - Megapixel Day & Night Bullet

Network Camera Overview

The Brickcom OB-E200Af / OB-E200Nf outdoor bullet network camera adopts the

two-megapixel sensor which allows the camera to deliver extremely clear and detailed

images that CCTV cameras cannot offer. To optimize use of the megapixel resolution,

the OB-E200Af / OB-E200Nf use efficient H.264/ MJPEG codec compression to deliver

dual configurable video streams simultaneously. These features make OB-E200Af /

OB-E200Nf the perfect outdoor camera for neighborhood, school campus, and parking

lot surveillance.

The OB-E200Af / OB-E200Nf supports Power over Ethernet and enables the camera to

use the same cable for power and data transmission, eliminating the need to install an

external power supply. With an IP66 certified outdoor enclosure, the OB-E200Af /

OB-E200Nf is not only weather proof, but also dust and rust resistant.

The OB-E200Af / OB-E200Nf supports the removable IR cut filter, the camera can

automatically switch into the day mode or night mode, which allows the users to enjoy

the best quality of images in the different circumstances. The megapixel day and night

bullet network camera is the best choice for the outdoor application.

Chapter 3 - Device Appearance Description

Lens

IR Leds

Light Sensor

RJ45 Ethernet Port

DC12V Power Input

Chapter 4 - LED Behavior

Function

LED Behavior

Description

Ethernet Link

Continuous illumination (Green)

Ethernet Connected

Data Link

Blinking (Orange)

Data Transmitting

Chapter 5 - Hardware Reset

The Reset Button can be used to restore the camera to factory default settings. If the

camera experiences a problem, rebooting the camera may correct the problem. If the

problem remains, please restore the camera to factory default settings and reinstall the

software.

To Reset

Press and hold the Reset Button for more than 10 seconds using a paper clip or thin

object. Wait for the camera to reset to default.

NOTE - By resetting the camera, all settings will be restored to the factory default

settings.

Reset Button
