Brickcom MD-500Ap Series Manuel utilisateur

Micro SD/SDHC Card

RJ45 Connector (for Ethernet and

PoE:802.3.af)

M12 Connector(*)

DC12V Connector (*)

*Cable Connector Variants*

Profile

Management

POE

Micro

SD/ SDHC Card

DDNS Server

5 Megapixel

Mini Dome Network Camera

▪Most Intelligent and Professional 5M Outdoor Mini Dome Camera

▪HDTV Quality (Full HD 1080p @ 30fps Streaming)

▪Wide Camera Angle Adjustment with Pan 35°, Tilt 0-90°, Rotation 180°

▪Intelligent Multi-Profile Sensor Management®for Different Environments

▪Weather-proof (IP67) and Vandal-proof(IK10) with Stylish Design

▪Wide Angle of View and Easy to Adjust Focus

▪EN50155 Certify with Anti Vibration and Shock

▪Built-In Micro SD slot/ TV out Connector Supported

▪PoE(802.3af) / M12 Connector / DC12V Supported

Photo Indication & Dimension Diagram

Full HD

30fps

Low Lux

MD-500Ap HDTV 1080p/720p ●5M/4M/3M/2M/1.3M Resolution Supported

Microphone Hole

Security Screws

Screw Hole

PAL/ NTSC Switch

TV out Connector

LED Indicators

Reset Button Slot

Hardware System CPU: 533 MHz

Flash: 32M

RAM: 256M DDR

Image Sensor Sensor Type : 1/2.5” CMOS Sensor

Sensor Resolution : 2592 x 1944 pixel

Camera Angle

Adjustment

Pan ± 35°/ Tilt 0-90° / Rotation ± 180°

Minimum

Illumination

1 lux (F1.6 , 1/5s , BW)

2Lux (F1.6 , 1/5s , Color)

Local Storage Built-in Micro SD/SDHC Memory Card Slot

Audio Streaming 1-way Audio Support

Audio Compression G.711, AMR (8 kHz, Mono, PCM)

Audio

Input/ Output

Built-in MIC

Communication Ethernet : one 10/100Mbps RJ-45

Supported Protocols : TCP/IP, UDP, ICMP,

DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP,

Samba, PPPoE, UPnP, RTP, RTSP, RTCP, IPv6

Connectors

Cables with different Options

A. RJ45,DC12V

B. M12

Power Input PoE 802.3af/ M12/ DC12V

Max. Power

Consumption

5.5 watts

Environment Operating Temperature

-20°C ~ 50°C (-4°F ~122°F),

Operating Humidity :

10% ~ 80%

Dimension 110(L) X110(W) X 53.7(H) mm

Weight 460g/1.02lb

Housing Weather-proof (IP67)

Vandal-proof (IK10)

Certification FCC, CE, EN50155, IK10

Viewing System

Requirements

OS: Microsoft Windows 7/Vista/XP/2000

Browser: Mozilla Firefox, Internet Explorer 6/7 or

above, Safari, Google Chrome

Cell Phone: 3GPP player

Real Player: 10.5 or above

Quick Time: 6.6 or above

VLC

Warranty Limited 2-year warranty

Compression

Streaming

H.264 / MPEG4 / MJPEG

Simultaneous multiple streams

Video Setting Multi-Profile Image Management:

Day/ Night/ Sunset/ User 1/ User 2

Auto Exposure/ Gain/ White Balance Control

Manual Exposure Control: 1/20000~1/5s

Manual Gain Control: 1X ~ 32X

Manual White Balance Control:2000K~7000K

S/N Ratio 38.1dB

Image Resolution 5M : 2592x1944 @ 10fps

(5M supports MJPEG only)

4M : 2304x1728 @ 15fps

3M : 2048x1536 @ 18fps

2M (Full HD): 1920x1080 @ 30fps

1M (HDTV): 1280x720 @ 30fps

Lens Spec

MD-500Ap f=4mm f=3.6mm

Lens Type Board Lens Board Lens

F Number F=1.6 F=1.6

FOV(H/V/D) 90°/67°/112° 92°/68°/115°

Events Motion Detection

Schedule

Audio Detection

Alarm Stream/Snapshot to

FTP/Email/Samba/SD-Card

HTTP/Email Notification

Camera

General

Audio

Video

Events and Alarm Management

Product Distinction

M12 mount Lens

BNCMD-01

TV out Connector Line

PS-588I

8-port 10/100M PoE Fast Ethernet Switch

PS-7242IL-AF

24-port 10/100M PoE Web Smart Ethernet

Switch

Work Best With

Camera Accessories Options Network Equipment Options

names and products are trademarks or registered trademarks of their respective

companies. We reserve the right to introduce modifications without notice. in

brickcom.com
