Security Systems D220

User’s Guide

National Security Systems Inc (800)457-1999

Table of Contents

About This User’s Guide .......................................................................... 3

Introduction .................................................................................................. 3

Security System Basics ............................................................................ 4

Controlled Points ....................................................................................... 5

24-Hour Points ........................................................................................... 6

Keypad Keys................................................................................................ 6

Keypad Lights ............................................................................................. 7

Keypad Tones ............................................................................................. 8

System Events ............................................................................................ 9

Silencing Alarms ......................................................................................... 10

Turning the System Off ............................................................................. 11

Turning the System All On ....................................................................... 12

Turning the System All On, with No Delay........................................... 13

Turning On Part of the System (Part On) ............................................ 14

Turning the System Part On, with No Delay........................................ 15

Turning the System On, With Points Open (Bypassing Points) .... 16

Viewing Alarm Memory ............................................................................. 17

Resetting the System ................................................................................ 18

Selecting Watch Tone .............................................................................. 19

Selecting Watch Points............................................................................ 20

Checking System Troubles...................................................................... 21

Changing Passcodes ................................................................................ 22

Step Outside ............................................................................................... 23

Exit Only........................................................................................................ 24

Silencing the Trouble Tone ...................................................................... 25

Show Passcode Types ............................................................................. 26

Change Passcode Type ........................................................................... 27

Change Other Users’ Passcodes .......................................................... 28

System Test ................................................................................................. 29

Security System Limitations .................................................................... 30

Fire Safety and Evacuation ...................................................................... 31

Security System Glossary ........................................................................ 32

Maintenance and Service ......................................................................... 33

How to Clean the keypad ........................................................................ 33

About This User’s Guide

This user’s guide shows you how to use and maintain your security

system.It covers basic system functions, such as turning the system on

and off.

The functions described in this guide are programmed by your security

company. Some of them may not be included in your system.Some of

the functions covered may require you to enter your personal passcode.

Introduction

Your system helps to secure life,property,and investments against fire,

theft,and bodily harm. It consists of a keypad (or keypads), sensors

(such as motion detectors or devices located on doors and windows),

and other sensing devices designed to detect the presence of smoke or

combustion. Each of these devices is connected to a sophisticated

electronic“brain,”which processes all events registered by the system.

Control of your security system is achieved through the keypad, which

offers a variety of basic and advanced features.Its function, versatility,

and ease of operation make it ideal for home or office.The keypad is

tailored to meet your individual needs.Moreover,it has been designed

with you,the user, in mind.

Security System Basics

What is a Point?

A“point”is a detection device, or group of devices connected to your

security system. The keypad shows point status through the lights

numbered 1 to 8 on the keypad display.Each point can represent a

single door, window, motion sensor, smoke detector, or other detection

device.

What is a “Faulted” Point?

When a point (such as a door or window) is closed,it is said to be

“normal.”When the door or window is open,the point is said to be

“faulted,”or not normal. When you turn your system on, you will

usually want all of the points in your system to be normal.You can turn

your system on with faulted points by using the Bypassing Points (on

page 16) procedure.

The keypad shows faulted points by lighting the point status display

(numbered one through eight).

Are All Points the Same?

No. There are two basic types of points, Controlled and 24-hour.

321

564

897

SOUNDER

SYSTEM STATUS LIGHTS POINT STATUS FUNCTION KEYS

0CLEAR

12345678

On No Delay

ALL

PART

OK TEST RESET

CHECK

WATCH

PART ON

ALL ON

Controlled Points

Controlled points respond to alarm conditions depending upon whether

the system is turned on or turned off. They are programmed to either

respond instantly to alarm conditions or to provide a delay for you to

reach the keypad and turn the system off.Various controlled points may

be located throughout your house.When you turn your system on,you

can turn on all controlled points (All On) or just some of the controlled

points (Part On).

All On

When you turn your systemAll On, you are turning on all controlled

points, both interior (motion detectors) and exterior (doors and

windows of the building).

Part On

When you turn your system Part On,you are turning on a portion of the

controlled points.The particular points included in this portion are

determined by your alarm company. Part points may include only the

exterior (doors and windows) of your system, or the points on the first

floor of a two-story house.Check with your security company to learn

which points are Part points.

24-Hour Points

24-hour points are always on,even when the system is turned off.There

are two types of 24-hour points: Fire and Non-Fire points.

Fire Points

Fire points only monitor fire detection devices, such as smoke detectors.

They are always on and cannot be turned off.

Non-Fire 24-Hour Points

Non-fire points are always on and cannot be turned off.

Keypad Keys

Your keypad has fifteen keys.These keys perform various functions, as

described below.

1,2,3,4,5,6,7,8,9,0

Each of the numeric keys performs a different function.For a

description of each, refer to the section of this guide that describes the

various system functions.

[CLEAR]

Use the [CLEAR] key to exit any function and start over.

[A]

A special function may be assigned to this key by your security company.

For your system, this key_________________________.

[B]

A special function may be assigned to this key by your security company.

For your system, this key_________________________.

[C]

A special function may be assigned to this key by your security company.

For your system, this key_________________________.

[∗]

This key is not used.

Keypad Lights

The keypad uses lights to indicate various conditions,such as whether

your system is on or off,the status of protective points,whether there is

a system trouble,and whether there is an alarm.

Light Function

On Lights when the system is All or Part On.Flashes during

exit delay and when an alarm occurs

No Delay Lights when the system is All or Part On without entry or

exit delay.Flashes during Step Outside function.

1 to 8 Point lights show the status of each point.When a point

light is on steadily, that point was turned on.When the

point light is blinking, the point is faulted.When the point

light is flashing, an alarm is indicated.

All Lights when the system is All On.When the system is off,

the All light comes on when all points are ready to turn on

(no doors or windows are open). Blinks when turning All

On with door or windows open.

Part Lights when the system is Part On. When the system is off,

lights when Part points are ready to turn on. Flashes when

changing passcodes.

OK Flashes when an alarm occurs.Blinks when there is system

trouble.

Keypad Tones

Your keypad emits several distinct tones and flashes keypad lights to

alert you to system events.Additional bells or sirens may also be

connected to your system. Bells or sirens mounted on the exterior of

your premises alert neighbors to emergencies and provide an audible

guide for police and fire fighters.

1. Fire Alarm Tone: When a fire point activates,the keypad

repeatedly emits a warble tone that is on for 1 sec., then briefly

off.

2. Burglary Alarm Tone: When a burglary point activates while

your system is turned on, your keypad emits a continuous

warble tone.The tone sounds for the time set by your security

company.

3. Trouble Tone: When a system component is not functioning

properly,your keypad repeatedly emits a warble tone that is on

briefly, followed by a pause,followed by the warble tone.If the

problem is with a point,the system display indicates which point

is faulted.

4. Keypress Tone: Pressing any key on the keypad sounds a short

pip,indicating that the entry is accepted.

5. Entry Delay Tone: When you enter the premises through a point

programmed for entry delay,the keypad emits a repeating short

beep,long beep tone to remind you to turn off your system.If

the system is not turned off before the entry delay expires, an

alarm report may be sent to your alarm company.

6. Exit Delay Tone: After you turn your system on,the keypad

emits an intermittent beep tone and counts down the exit delay

time. If you do not exit before the delay time expires, and an exit

delay door is faulted, an alarm occurs.

7. Error Tone: If you press an incorrect key, your keypad emits an

error tone to indicate an invalid entry.The error tone is the same

warble tone as the trouble tone,but it is not repeated.

8. OK Tone: Indicates that a keypad entry is accepted; for example,

that a correct passcode was entered.The keypad emits a single,

high-pitched beep tone for 1 second.

9. Watch Tone: The keypad emits a tone to alert you when any

watched point is faulted.The tone varies in duration, depending

upon the watch tone selected (see Selecting Watch Tone on page

19).

System Events

Your system responds to four types of events.If more than one event

occurs, your system sorts them into one of four groups. The groups

(highest priority first) are: Fire Alarms, Burglary Alarms, Fire Troubles,

and Non-Fire Troubles.

Fire Alarms

Fire alarms are the highest priority events.When a fire point activates,

your keypad repeatedly emits a warble tone that is on for one second,

then briefly off. Evacuate all occupants and investigate for smoke or fire.

Ensure that all occupants know the difference between the burglary tone

and the fire tone.The tone sounds for the time set by your security

company.

The keypad lights the point lights of the points that go into alarm.

Burglary Alarms

Burglary alarms are the second priority.When a burglary point activates

while your system is turned on,your keypad emits a constant warble

tone.The tone sounds for the time set by your security company.

The keypad lights the point lights of the points that go into alarm.

Fire Trouble Events

When a fire trouble (such as a loose wire) occurs, your keypad repeatedly

emits a trouble tone,which is a warble tone that is on briefly, then

followed by a pause,followed by the warble tone.

The keypad display blinks the OK light to indicate the presence of

system trouble. See Checking System Troubles (on page 21) to determine

the nature of the trouble.

Non-Fire Trouble Events

When a trouble event such as a power failure occurs,your keypad

repeatedly emits a trouble tone,which is a warble tone that is on briefly,

followed by a pause,followed by the warble tone.

The keypad display blinks the OK light to indicate the presence of a

system trouble. See Checking System Troubles (on page 21) to determine

the nature of the trouble.

How Your System Reports Alarms

Your security system may be programmed to automatically disconnect

your telephones when sending reports to your security company. Once

the report is completed,your security system returns the telephones to

normal operation (check with your security company).

Your system makes repeated attempts to send reports to your security

company.In the event your system fails to report, the keypad signals a

system trouble. Follow the (Checking System Troubles on page 21)

procedure.

Note: If your telephone service is interrupted, your security system

cannot send reports to your security company unless it has an

alternate means of transmitting them.

Silencing Alarms

When there is an alarm,the alarm tone sounds and the point or points

in alarm light up. If you enter your passcode before the system dials your

alarm company, the alarm is canceled.

1. When an alarm occurs, the OK light and point lights (1 through

8) flash.For example if point 4 produces the alarm event, then

point 4 flashes:

2. Enter your passcode to silence the alarm. If you enter your

passcode before the system dials your alarm company, the alarm

is canceled and the OK light stops flashing. If the OK light

continues to flash, an alarm report was sent to your alarm

company.

3. Use Viewing Alarm Memory (on page 17) to review the points

that caused the alarm.Use Resetting The System (on page 18) to

reset the OK light and clear alarm memory.

Table des matières

Autres manuels Bosch Système de sécurité

Bosch

Bosch CM728B Comment utiliser

Bosch

Bosch MBV-BPRO-45 Feuille d'instructions

Bosch

Bosch Solution 6000-IP CC615GWF Manuel utilisateur

Bosch

Bosch CCS 800 Ultro Manuel utilisateur

Bosch

Bosch Spexor Manuel utilisateur

Bosch

Bosch D2000 Manuel utilisateur

Bosch

Bosch Spexor Manuel utilisateur

Bosch

Bosch DIVAR DIP-6080-00N Manuel utilisateur

Bosch

Bosch ISW-BMC1-M82X Comment utiliser

Bosch

Bosch SE 60 LSNi Manuel utilisateur

Bosch

Bosch ICP-AMAX4-P2-EN Manuel utilisateur

Bosch

Bosch Solution 16i Manuel utilisateur

Bosch

Bosch DB24C4200R2 Manuel utilisateur

Bosch

Bosch DIVAR IP 7000 2U Manuel utilisateur

Bosch

Bosch DB18C3100R2 Manuel utilisateur

Bosch

Bosch FMC-210-DM-G-B Manuel utilisateur

Bosch

Bosch DB-CO Manuel utilisateur

Bosch

Bosch D222TD Manuel utilisateur

Bosch

Bosch PRAESENSA Comment utiliser

Bosch

Bosch Security Escort SE2005 Manuel utilisateur

Bosch

Bosch DS484Q Manuel utilisateur

Bosch

Bosch Solution 16plus Manuel utilisateur

Bosch

Bosch Solution 16i Manuel utilisateur

Bosch

Bosch B Series Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
