Boneco P340 Manuel utilisateur

P340

MANUAL

READ AND SAVE THESE INSTRUCTIONS

INSTRUCTIONS FOR USE

BONECO P340

1 2 3

4 5 1Front cover

2Pre-filter

3Filter A341

4BONECO P340

5Keypad with displays

OVERVIEW AND PART NAMES

Overview and part names 14

Items included 16

Technical data 16

Start-up 17

Front cover and replacement filter 18

Magnetic front cover 18

Replacement filters 18

Indicators on the display 19

Clearing the filter warning 19

Basic functions 20

“Auto” mode 20

Air quality indicator 20

Manually controlling the fan level 20

Ionizer and timer function 21

Ionizer 21

Timer function 21

Setting the OFF timer 21

Cleaning and maintenance 22

Replacing the filter 22

Cleaning the pre-filter 22

TABLE OF CONTENTS

en INSTRUCTIONS FOR USE FOR BONECO P340

DEAR CUSTOMER,

Congratulations on your purchase of the BONECO P340.

The extremely efficient air purifier is equipped with a

high-quality filter which rids the air of odors as well as

dust, pollen and dirt particles. The filter also effectively

alleviates many forms of discomfort caused by allergies.

This also includes hay fever or allergic reactions to house-

hold dust and mite excrement.

The BONECO P340 is designed for easy, fully automated

operation. The smart control system ensures that the

noise level remains as low as possible. Thanks to the in-

tegrated timer, the appliance also runs whenever you are

not at home. This means you can always come home to

an optimal room climate.

We hope you enjoy your new BONECO P340

air purifier!

BONECO P340 with country-

specific power cable

Filter A341

TECHNICAL DATA*

Type designation BONECO P340

Mains voltage 220–240 V, 50 Hz

Power consumption 46 W

Operating noise level 57 dB(A)

Cleaning output (CADR) 210 m³/h (177 CFM)

Air flow 300 m³/h (177 CFM)

Dimensions L×W×H 206×336×527 mm

Weight (empty) 5.3 kg / 6.3 kg

* Subject to change

ITEMS INCLUDED

START-UP

Take out the filter and remove the protective foil.

Remove the magnetically fixed front cover.

Insert the filter back into the holder

(note the markings).

Take off the pre-filter.

Reattach the front cover.

Put the pre-filter back on.

MAGNETIC FRONT COVER

The front cover of the BONECO P340 is held on by mag-

nets. The air purifier is not switched on if the front cover

is missing or positioned incorrectly.

REPLACEMENT FILTERS

You can obtain replacement filters from your BONECO

specialist dealer or in the online store at:

www.shop.boneco.com.

FRONT COVER AND REPLACEMENT FILTER

CLEARING THE FILTER WARNING

The “Filter” display remains illuminated af-

ter the filter has been replaced. Press and hold the

-button for five seconds to hide the display. This also

resets the counter for the new filter at the same time.

All displays on the appliance

Indicators Meaning

Ionizer is switched on or off 21

Timer function (1, 2, 4 or 8 hours) 21

Display of air quality (green, orange, red) 20

AUTO mode and fan level 20

Filter used up, replace 22

INDICATORS ON THE DISPLAY

The BONECO P340 can easily be adapted to your needs.

During start-up of the appliance, the basic setting of the

fan level is in automatic mode (AUTO MODE).

“AUTO” MODE

In the mode the fan level is automatically regu-

lated depending on the air quality. After the appliance

is switched on for the first time, it runs for the first five

minutes at the lowest fan level “L”.

AIR QUALITY INDICATOR

The air quality is measured by the built-in sensor

and is visualized by different colors on the “air” display.

When the appliance is switched on, it takes around five

minutes until the sensor has measured the current air

quality. The “Air” display flashes during this period .

Please note that the measured values may change de-

pending on the size of the room and the position of the

appliance.

The sensor registers the smallest dirt particles and

gases. They include house dust, pollen, gases such as

tobacco smoke, organic compounds and odors.

MANUALLY CONTROLLING THE FAN LEVEL

The fan level of the BONECO P340 can be manually con-

trolled.

Push the button several times until the desired fan

level is attained.

Clean Acceptable Poor

BASIC FUNCTIONS

IONIZER

The ionizer is activated by pressing the “ION” button

once. Pressing the button again switches off the ionizer.

TIMER FUNCTION

The timer function lets you determine how long the

BONECO P340 should run before it switches off auto-

matically (OFF timer).

SETTING THE OFF TIMER

1. Switch on the BONECO P340 by pressing the

button.

2. Select the desired operating setting and the desired

comfort mode.

3. Press the button once.

4. Use the button to set how long the appliance oper-

ates (1, 2, 4 or 8 hours).

The appliance runs for the specified period and is then

switched off.

5. In order to end the timer prematurely, keep the -but-

ton pressed until the timer switches off and the display

is indicated. Alternatively, you can switch off the

BONECO P340 using the button.

IONIZER AND TIMER FUNCTION
