BIPAC 5100/5100W

(Wireless) ADSL Router

User’s Manual

Table of Contents

Chapter 1.......................................................................... 6

1.1 Introducing the BIPAC-5100/5100W......................................... 6

1.2 Features of the BIPAC-5100/5100W ........................................6

1.3 Applications for the BIPAC-5100/5100W .................................. 9

Chapter 2........................................................................ 11

2.1 Web Configurator Overview ................................................... 11

2.2 Accessing the BIPAC-5100/5100W Web Configurator ........... 11

2.3 Navigating the BIPAC-5100/5100W Web Configurator ..........12

2.4 Configuring Password ............................................................ 13

2.5 Resetting the BIPAC-5100/5100W ......................................... 13

Chapter 3........................................................................ 15

3.1 Wizard Setup Introduction ......................................................15

3.2 Encapsulation ......................................................................... 15

3.3 Multiplexing ............................................................................ 16

3.4 VPI and VCI............................................................................ 16

3.5 Wizard Setup Configuration: First Screen .............................. 16

3.6 IP Address and Subnet Mask ................................................. 17

3.7 IP Address Assignment........................................................... 18

3.8 Nailed-Up Connection (PPP).................................................. 19

3.9 NAT......................................................................................... 19

3.10 Wizard Setup Configuration: Second Screen ....................... 19

3.11 DHCP Setup ......................................................................... 24

3.12 Wizard Setup Configuration: Third Screen ........................... 24

3.13 Wizard Setup Configuration: Connection Tests .................... 26

3.14 Test Your Internet Connection .............................................. 27

Chapter 4........................................................................ 28

4.1 LAN Overview.........................................................................28

4.2 DNS Server Address ..............................................................28

4.3 DNS Server Address Assignment........................................... 29

4.4 LAN TCP/IP ............................................................................ 30

4.5 Configuring LAN ..................................................................... 31

Chapter 5........................................................................ 33

5.1 Wireless LAN Overview.......................................................... 33

5.2 Levels of Security ................................................................... 35

5.3 Data Encryption with WEP .....................................................35

5.4 Configuring Wireless LAN ...................................................... 35

5.5 Configuring MAC Filter ...........................................................37

Chapter 6........................................................................ 39

6.1 WAN Overview ....................................................................... 39

6.2 PPPoE Encapsulation ............................................................ 39

6.3 PPTP Encapsulation............................................................... 40

6.4 Traffic Shaping........................................................................ 40

6.5 Configuring WAN Setup .........................................................41

Chapter 7........................................................................ 45

7.1 NAT Overview......................................................................... 45

7.2 SUA (Single User Account) Versus NAT................................. 48

7.3 SUA Server............................................................................. 48

7.4 Selecting the NAT Mode.........................................................50

7.5 Configuring SUA Server .........................................................50

7.6 Configuring Address Mapping ................................................51

7.7 Editing an Address Mapping Rule ..........................................53

Chapter 8........................................................................ 55

8.1 Dynamic DNS......................................................................... 55

8.1.1 DYNDNS Wildcard .............................................................. 55

8.2 Configuring Dynamic DNS...................................................... 55

Chapter 9........................................................................ 57

9.1 Configuring Time Zone ...........................................................57

Chapter 10...................................................................... 60

10.1 Remote Management Overview ........................................... 60

10.2 Telnet .................................................................................... 61

10.3 FTP....................................................................................... 61

10.4 Web ...................................................................................... 61

10.5 Configuring Remote Management........................................ 61

Chapter 11...................................................................... 63

11.1 Universal Plug and Play Overview........................................63

11.2 Cautions with UPnP..............................................................63

11.3 Installing UPnP in Windows Example ................................... 64

11.4 Using UPnP in Windows XP Example .................................. 67

Chapter12....................................................................... 71

12.1 Maintenance Overview ......................................................... 71

12.2 System Status Screen .......................................................... 71

12.3 DHCP Table Screen .............................................................74

12.4 Wireless Screens.................................................................. 75

12.5 Diagnostic Screens............................................................... 77

12.6 Firmware Screen .................................................................. 79

Appendix........................................................................ 81

A.1 Using LEDs to Diagnose Problems........................................ 81

A.2 Console Port .......................................................................... 82

A.3 Telnet...................................................................................... 82

A.4 Web Configurator ................................................................... 83

A.5 Login Username and Password ............................................. 83

A.6 LAN Interface ......................................................................... 84

A.7 WAN Interface........................................................................ 84

A.8 Internet Access ...................................................................... 85

A.9 Remote Management............................................................. 85

A.10 Remote Node Connection.................................................... 85

Chapter 1

Getting to Know the BIPAC-5100/5100W

802.11b is only supported for the BIPAC-5100W

This chapter describes the key features and applications of BIPAC-5100/5100W.

1.1 Introducing the BIPAC-5100/5100W

The BIPAC-5100/5100W integrates high-speed 10/100Mbps auto-negotiating LAN interface(s)

and a high-speed ADSL port into a single package. The BIPAC-5100/5100W is ideal for

high-speed Internet browsing and making LAN-to-LAN connections to remote networks. By

integrating DSL and NAT, the BIPAC-5100/5100W provides super-fast Internet access to

multiple users at minimum cost.

The BIPAC-5100/5100W is a bridge/router and includes two models, one for ADSL over POTS

(Plain Old Telephone System) and one for ADSL over ISDN (Integrated Synchronous Digital

System).

The BIPAC-5100/5100W provides a wireless LAN connectivity allowing users to enjoy the

convenience and mobility of working anywhere within the coverage area.

The web browser-based Graphical User Interface provides easy management and is totally

independent of the operating system platform you use.

1.2 Features of the BIPAC-5100/5100W

The following sections describe the features of the BIPAC-5100/5100W.

 Four-Port Switch

A combination of switch and router makes the BIPAC-5100/5100W a cost-effective and viable

network solution. You can connect up to four computers to the LAN ports on you

BIPAC-5100/5100W without the cost of a hub.

 High Speed Internet Access

The BIPAC-5100/5100W ADSL router can support downstream transmission rates of up to 8

Mbps and upstream transmission rates of 1 Mbps.

 IEEE 802.11b 11Mbps Wireless LAN

The 11 Mbps wireless LAN provides mobility and a fast network environment for small and

home offices. Computers with wireless LAN Ethernet adapters can connect to the local area

network without any wiring efforts and enjoy reliable high-speed connectivity.

 PPPoE Support (RFC2516)

PPPoE (Point-to-Point Protocol over Ethernet) emulates a dial-up connection. It allows your

ISP to use their existing network configuration with newer broadband technologies such as

ADSL. The PPPoE driver on the BIPAC-5100/5100W is transparent to the computers on the

LAN, which see only Ethernet and are not aware of PPPoE thus saving you from having to

manage PPPoE clients on individual computers.

 Network Address Translation (NAT)

Network Address Translation (NAT) allows the translation of an Internet protocol address used

within one network (for example a private IP address used in a local network) to a different IP

address known within another network (for example a public IP address used on the Internet).

 Universal Plug and Play (UPnP)

Using the standard TCP/IP protocol, the BIPAC-5100/5100W and other UPnP enabled devices

can dynamically join a network, obtain an IP address and convey its capabilities to other

devices on the network.

 10/100M Auto-negotiation Ethernet/Fast Ethernet Interface

This auto-negotiation feature allows the BIPAC-5100/5100W to detect the speed of incoming

transmissions and adjust appropriately without manual intervention. It allows data transfer of

either 10 Mbps or 100 Mbps in either half-duplex or full-duplex mode depending on the

Ethernet network.

 Dynamic DNS Support

With Dynamic DNS support, you can have a static hostname alias for a dynamic IP address,

allowing the host to be more easily accessible from various locations on the Internet. You must

 Multiple PVC (Permanent Virtual Circuits) Support

The BIPAC-5100/5100W supports up to 8 PVC’s.

 ADSL Standards

♦ Full-Rate (ANSI T1.413, Issue 2; G.dmt (G.992.1) with line rate support of up to 8

Mbps downstream and 1 Mbps upstream.

♦ G.lite (G.992.2) with line rate support of up to 1.5Mbps downstream and 512Kbps

upstream.

♦ Supports Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1); G.994.1

and G.996.1 (for ISDN only); G.991.1;G.lite (G992.2)).

♦ Supports OAM F4/F5 loop-back, AIS and RDI OAM cells.

♦ ATM Forum UNI 3.1/4.0 PVC.

♦ Supports up to 8 PVCs (UBR, CBR, VBR).

♦ Multiple Protocols over AAL5 (RFC 1483).

♦ PPP over AAL5 (RFC 2364).

♦ PPP over Ethernet (RFC 2516).

 DHCP Support

DHCP (Dynamic Host Configuration Protocol) allows individual clients (computers) to obtain

TCP/IP configuration at start-up from a centralized DHCP server. The BIPAC-5100/5100W has

built-in DHCP server capability enabled by default. It can assign IP addresses, an IP default

gateway and DNS servers to DHCP clients. The BIPAC-5100/5100W can now also act as a

surrogate DHCP server (DHCP Relay) where it relays IP address assignment from the actual

real DHCP server to the clients.

 IP Alias

IP Alias allows you to partition a physical network into logical networks over the same Ethernet

interface. The BIPAC-5100/5100W supports three logical LAN interfaces via its single physical

Ethernet interface with the BIPAC-5100/5100W itself as the gateway for each LAN network.

 IP Policy Routing (IPPR)

Traditionally, routing is based on the destination address only and the router takes the shortest

path to forward a packet. IP Policy Routing (IPPR) provides a mechanism to override the

default routing behavior and alter the packet forwarding based on the policy defined by the

network administrator.

 Protocol Support

♦ PPP (Point-to-Point Protocol) link layer protocol.

- PPP over PAP (RFC 1334).

- PPP over CHAP (RFC 1994).

♦ RIP I/RIP II

♦ IGMP Proxy

♦ ICMP support

♦ MIB II support (RFC 1213)

♦ PPPoE feature

- PPPoE idle time out

- PPPoE dial on demand

 Networking Compatibility

The BIPAC-5100/5100W is compatible with major ADSL DSLAM (Digital Subscriber Line

Access Multiplexer) providers.

 Multiplexing

The BIPAC-5100/5100W supports VC-based and LLC-based multiplexing.

 Encapsulation

The BIPAC-5100/5100W series supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer

5), RFC 1483 encapsulation over ATM, MAC encapsulated routing (ENET Encapsulation) as

well as PPP over Ethernet (RFC 2516).

 Network Management

♦ Embedded Web Configurator

♦ CLI (Command Line Interpreter)

♦ SNMP manageable

♦ DHCP Server/Client

♦ Built-in Diagnostic Tools

♦ Syslog

♦ TFTP/FTP server, firmware upgrade and configuration backup/support supported

 Diagnostics Capabilities

♦ The BIPAC-5100/5100W can perform self-diagnostic tests. These tests check the

integrity of the following circuitry:

- FLASH memory

- ADSL circuitry

- RAM

- LAN port

 Filters

The BIPAC-5100/5100W's packet filtering functions allows added network security and

management.

 Ease of Installation

The BIPAC-5100/5100W is designed for quick, intuitive and easy installation.

 Housing

The BIPAC-5100/5100W's all new compact and ventilated housing minimizes space

requirements making it easy to position anywhere in your busy office.

1.3 Applications for the BIPAC-5100/5100W

The BIPAC-5100/5100W is the ideal high-speed Internet access solution. The

BIPAC-5100/5100W supports the TCP/IP protocol, which the Internet uses exclusively. It is

compatible with all major ADSL DSLAM (Digital Subscriber Line Access Multiplexer) providers.

A DSLAM is a rack of ADSL line cards with data multiplexed into a backbone network

interface/connection (for example, T1, OC3, DS3, ATM or Frame Relay). Think of it as the

equivalent of a modem rack for ADSL. In addition, for BIPAC-5100/5100W, you can insert an

optional wireless PCMICA card into the BIPAC-5100/5100W and allow wireless stations

access to your network resources. A typical Internet access application is shown below.

Autres manuels pour BiPAC 5100

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Billion Routeur réseau

Billion

Billion BIPAC-7402 Manuel utilisateur

Billion

Billion BiPAC 7202 Manuel utilisateur

Billion

Billion BiPAC 7300VGP Manuel utilisateur

Billion

Billion BiPAC 5200W Manuel utilisateur

Billion

Billion BiPAC 4700ZU Manuel utilisateur

Billion

Billion BiPAC 7100SV Manuel utilisateur

Billion

Billion BiPAC 8700AX-1600 Manuel utilisateur

Billion

Billion BiPAC 8501 R3 Manuel utilisateur

Billion

Billion BiPAC 7404VGOX Manuel utilisateur

Billion

Billion BiPAC 7700N Manuel utilisateur

Billion

Billion BiPAC 7402VL Manuel utilisateur

Billion

Billion BiPAC 7300G RA Manuel utilisateur

Billion

Billion BILLION BIPAC-7500GL Manuel utilisateur

Billion

Billion BiPAC 7800(N) Manuel utilisateur

Billion

Billion BiPAC 8500 Manuel utilisateur

Billion

Billion M500 Manuel utilisateur

Billion

Billion BiPAC 7402NXL Manuel utilisateur

Billion

Billion BIPAC 6600 Manuel utilisateur

Billion

Billion BiPAC 7300NX Manuel utilisateur

Billion

Billion BiPAC 8501 Manuel utilisateur

Billion

Billion BiPAC 7402NX Manuel utilisateur

Billion

Billion BiPAC 7800NEXL Manuel utilisateur

Billion

Billion BiPAC 7800(N) Manuel utilisateur

Billion

Billion BiPAC 7404V series Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

LevelOne

LevelOne FBR-1416 Manuel utilisateur
