Billion BiPAC 7300NX Manuel utilisateur

BiPAC 7300NX

BiPAC 7300N RE

(3G) / Wireless-N

ADSL2+ Firewall Ro ter

Q ick Start G ide

Billion BiPAC 7300NX, 7300N RE (3G)/ Wireless-N ADSL2+ Firewall Ro ter

Package Contents

BiPAC 7300NX, 7300N RE (3G) / Wireless-N ADSL2+ Firewall Ro ter

CD containing the on-line man al and QSG

RJ-11 ADSL/ telephone cable

Ethernet (RJ-45) cable

Two 2dBi detachable antennas

Power adapter

Q ick Start G ide

Splitter/ Micro-filter (Optional)

Warning

PLEASE READ THE QUICK START GUIDE AND FOLLOW THE

STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU

INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE.

IF YOU NEED MORE INFORMATION ON THIS SOFTWARE

CONFIGURATION, PLEASE REFER TO THE USER MANUAL ON

CD-ROM.



Do not se the

ro ter

in high h midity or high temperat res.

 Do not se the same power so rce for the ro ter as other

eq ipment.

 Do not open or repair the case yo rself. If the ro ter is too hot,

t rn off the power immediately and have it repaired at a q alified

service center.



Avoid sing this

prod ct

and all

accessories

o tdoors.



Place the ro ter on a stable s rface.

 Only se the power adapter that comes with the package. Using a

different voltage rating power adaptor may damage the ro ter.

Q ick Start G ide

The Front LEDs

The Rear Ports

* Note 1. For advanced reset and restore setting, please refer to ser man al.

.2. For WPS config ration, please refer to the WPS section of ser man al.

Connect

with

the

s pplied power

adapter.

Connect the s pplied

RJ-11 cable to this

port when connecting

to the ADSL/

telephone network.

(1)

Press

seconds

ntil WPS LED

flashes green to trigger WPS f nction.

(2) W

h: Press over 6

seconds after WPS LED is off to switch on

wireless f nction. Press over 6 seconds

again for disable wireless f nction.

Flash green when

WPS config ration

is in progress.

Lit red when WAN port

fails to get IP address.

Lit green when WAN

port gets IP address

s ccessf lly.

Connect yo r

comp ter to a

LAN port with

the incl ded

Ethernet cable.

Power

ON/OFF

switch

Blink green when power is

on and system is booting.

Lit green when the system

is ready. Lit Red if the

system is dead.

Lit green when a wireless

connection is established.

Blink when data is being

sent / received.

Lit

reen when the

device

is s ccessf lly connected

to an ADSL DSLAM. (“Line

sync”).

When the device

power is on, press

to reset or to

restore its factory

defa lt setting.

Antenna

(

)

Lit when the ro ter is

connected to a USB

device.

(

)

Connect the USB

cable to this port.

(

)

t for

connecting to Cable Modem,

VDSL, fiber modem or PON

optic lines with RJ-45 cable.

Lit when connected to an

Ethernet device. Lit green when

the speed of transmission hits

10/100Mbps; Blink when data is

being Transmitted / Received.

Billion BiPAC 7300NX, 7300N RE (3G)/ Wireless-N ADSL2+ Firewall Ro ter

ADSL Ro ter Mode(USB connection is only for 7300NX)

BiPAC 7300NX – 3G Ro ter Mode

BiPAC 7300N RE – Broadband Ro ter Mode

Q ick Start G ide

1. Power Connection

Plug the supplied power adapter to the wall jack and the other side to the router.

Please note that the plug type may differ according to country.

2. LAN Connection

Connect the supplied RJ 45 Ethernet cable to one of the Ethernet ports, and the other

side to the PC’s Ethernet interface.

3. ADSL Connection

Connect the supplied RJ 11 phone cable to the router’s ADSL port, and the other side

to the phone jack on the wall.

4. EWAN Connection (BiPAC 7300N RE only)

Connect RJ 45 Ethernet cable to the Ethernet port # 1 (EWAN), and connect the

other side to another alternative broadband device, such as Cable Modem, VDSL,

Fiber Modem or PON optic lines. Please refer to User Manual for detail instruction.

Billion BiPAC 7300NX, 7300N RE (3G)/ Wireless-N ADSL2+ Firewall Ro ter

5. USB Connection (BiPAC 7300NX only)

The USB 2.0 port s pports 3G/ HSDPA modem connectivity: sers can

conveniently access Internet via 3G, eliminating the limitations of the wired

network. This sol tion also employs an a to fail-over feat re to ens re

always-on connectivity for SOHO sers. (Note: For compatible 3G USB

modems, please refer to http://www.billion.com/compatible-3G.html for

pdated list.)

6. USB Storage (BiPAC 7300NX only)

Storage feat re thro gh USB 2.0 port: FTP server, samba server

7. Splitter/ Micro-filter Connection

Splitter / Micro filter are important for ADSL installation. High frequency signals are

directed to the ADSL modem, and low frequency signals are directed to the

telephone or other analog voice channel device to prevent inter modulation

distortion and also to get good speed and stable ADSL sync rate.

a) Splitter connection

If the installation has only a single telephone and a single ADSL modem, then a

splitter can be employed.

Q ick Start G ide

b) Micro filter connection

If the installation has several telephones or other analog devices, then an internal

micro filter can be employed at each analog device.

-O

Make sure power on the device, Ethernet cable is connected to your PC and ADSL line is in

sync. Then open up a web browser and you will automatically be directed to the step by step

easy sign on configuration wizard which will guide you to complete the basic network

configuration to connect to the internet.

1. Open the web browser and type h

4 in the browser's address box. This

number is the default IP address for this router. Press Enter.

2. A username and password window will appear. The default

“

“a

n”

”,

“

“a

n”

”. Press OK to proceed.

3. You will get a status report web page and main menu screen.

Please see the relevant sections of ser man al for detailed instr ctions on how to

config re yo r ro ter.

1. None of the LEDs are on when yo t rn on the ro ter.

Check the connection between the adapter and the router. If the error persists, you may have

a hardware problem. In this case you should contact technical support.

2. Can’t ping any PCs on the LAN.

Check the Ethernet LEDs on the front panel. The LED should be on for a port that has a PC

connected. If it is off, check the cables between your router and the PC. Make sure you have

uninstalled any software firewall for troubleshooting. Verify that the IP address and the subnet

mask are consistent between the router and the workstations.

3. Freq ent loss of ADSL line sync (disconnections).

Ensure that all other devices connected to the same telephone line as your router (e.g.

telephones, fax machines, analogue modems) have a line filter connected between them and

the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified

and licensed electrician), and ensure that all line filters are correctly installed and the right

way around. Missing line filters or line filters installed the wrong way around can cause

problems with your ADSL connection, including causing frequent disconnections. If you have

a back to base alarm system you should contact your security provider for a technician to

make any necessary changes.

Billion BiPAC 7300NX, 7300N RE (3G)/ Wireless-N ADSL2+ Firewall Ro ter

Most problems can be solved by referring to the Tro bleshooting section in the User Manual. If

you cannot resolve the problem with the Tro bleshooting chapter, please contact the dealer

where you purchased this product.

WORLDWIDE

http://www.billion.com

BiPAC

7300NX, 7300N

Series

: V1.0

(AAMPIMBIL7300NXXX1)
