Beckhoff ELX3252 Manuel utilisateur

Operating manual | EN

ELX3252

Two channel analog intput terminal for potentiometers, 16 Bit,

Ex i

2020-07-01 | Version: 1.0.0

Table of contents

ELX3252 3Version: 1.0.0

Table of contents

1 Foreword ....................................................................................................................................................5

1.1 Notes on the documentation..............................................................................................................5

1.2 Safety instructions .............................................................................................................................6

1.3 Documentation Issue Status..............................................................................................................7

1.4 Marking of ELX terminals ..................................................................................................................8

2 Product overview.....................................................................................................................................12

2.1 ELX3252 - Introduction....................................................................................................................12

2.2 Technical data .................................................................................................................................13

2.3 Intended use....................................................................................................................................14

3 Mounting and wiring................................................................................................................................15

3.1 Special conditions of use for ELX terminals ....................................................................................15

3.2 Installation notes for ELX terminals .................................................................................................15

3.3 Arrangement of ELX terminals within a bus terminal block .............................................................17

3.4 Installation position and minimum distances ...................................................................................20

3.5 Installation of ELX terminals on mounting rails................................................................................21

3.6 Connection ......................................................................................................................................23

3.6.1 Connection system .......................................................................................................... 23

3.6.2 Wiring............................................................................................................................... 24

3.6.3 Proper line connection ..................................................................................................... 25

3.6.4 Shielding and potential separation................................................................................... 25

3.6.5 Contact assignment ......................................................................................................... 26

4 Appendix ..................................................................................................................................................28

4.1 EtherCAT AL Status Codes.............................................................................................................28

4.2 UL notice .........................................................................................................................................28

4.3 FM notice.........................................................................................................................................29

4.4 Support and Service ........................................................................................................................30

Table of contents

ELX32524 Version: 1.0.0

Foreword

ELX3252 5Version: 1.0.0

1 Foreword

1.1 Notes on the documentation

Intended audience

This description is only intended for the use of trained specialists in control and automation engineering who

are familiar with the applicable national standards.

It is essential that the documentation and the following notes and explanations are followed when installing

and commissioning these components.

It is the duty of the technical personnel to use the documentation published at the respective time of each

installation and commissioning.

The responsible staff must ensure that the application or use of the products described satisfy all the

requirements for safety, including all the relevant laws, regulations, guidelines and standards.

Disclaimer

The documentation has been prepared with care. The products described are, however, constantly under

development.

We reserve the right to revise and change the documentation at any time and without prior announcement.

No claims for the modification of products that have already been supplied may be made on the basis of the

data, diagrams and descriptions in this documentation.

Trademarks

Beckhoff®, TwinCAT®, EtherCAT®, EtherCATG®, EtherCATG10®, EtherCATP®, SafetyoverEtherCAT®,

TwinSAFE®, XFC®, XTS® and XPlanar® are registered trademarks of and licensed by Beckhoff Automation

GmbH. Other designations used in this publication may be trademarks whose use by third parties for their

own purposes could violate the rights of the owners.

Patent Pending

The EtherCAT Technology is covered, including but not limited to the following patent applications and

patents: EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 with corresponding

applications or registrations in various other countries.

EtherCAT® is registered trademark and patented technology, licensed by Beckhoff Automation GmbH,

Germany.

The reproduction, distribution and utilization of this document as well as the communication of its contents to

others without express authorization are prohibited.

patent, utility model or design.

Foreword

ELX32526 Version: 1.0.0

1.2 Safety instructions

Safety regulations

Please note the following safety instructions and explanations!

Product-specific safety instructions can be found on following pages or in the areas mounting, wiring,

commissioning etc.

Exclusion of liability

All the components are supplied in particular hardware and software configurations appropriate for the

application. Modifications to hardware or software configurations other than those described in the

documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG.

Personnel qualification

This description is only intended for trained specialists in control, automation and drive engineering who are

familiar with the applicable national standards.

Description of instructions

In this documentation the following instructions are used.

These instructions must be read carefully and followed without fail!

DANGER

Serious risk of injury!

Failure to follow this safety instruction directly endangers the life and health of persons.

WARNING

Risk of injury!

Failure to follow this safety instruction endangers the life and health of persons.

CAUTION

Personal injuries!

Failure to follow this safety instruction can lead to injuries to persons.

NOTE

Damage to environment/equipment or data loss

Failure to follow this instruction can lead to environmental damage, equipment damage or data loss.

Tip or pointer

This symbol indicates information that contributes to better understanding.

Foreword

ELX3252 7Version: 1.0.0

1.3 Documentation Issue Status

Version Comment

1.0.0 • Technical data and cover picture updated

0.2 • Technical data updated

0.1 • First preliminary version

Foreword

ELX32528 Version: 1.0.0

1.4 Marking of ELX terminals

Name

An ELX terminal has a 15-digit technical designation, composed of

• family key

• type

• software variant

• revision

example family type software variant revision

ELX1052-0000-0001 ELX terminal 1052: two-channel digital input terminal

for NAMUR sensors, Ex i

0000: basic type 0001

ELX9560-0000-0001 ELX terminal 9560: power supply terminal 0000: basic type 0001

Notes

• The elements mentioned above result in the technical designation. ELX1052-0000-0001 is used in

the example below.

• Of these, ELX1052-0000 is the order identifier, commonly called just ELX1052 in the "-0000" revision.

“-0001” is the EtherCAT revision.

• The order identifier is made up of

- family key (ELX)

- type (1052)

- software version (-0000)

• The Revision -0001 shows the technical progress, such as the extension of features with regard to the

EtherCAT communication, and is managed by Beckhoff.

In principle, a device with a higher revision can replace a device with a lower revision, unless specified

otherwise, e.g. in the documentation.

Associated and synonymous with each revision there is usually a description (ESI, EtherCAT Slave

Information) in the form of an XML file, which is available for download from the Beckhoff website.

The revision has been applied to the terminals on the outside, see ELX1052 with date code

3218FMFM, BTN 10000100 and Ex marking.

• The hyphen is omitted in the labeling on the side of the terminal. Example:

Name: ELX1052-0000

Label: ELX1052 0000

• The type, software version and revision are read as decimal numbers, even if they are technically

saved in hexadecimal.

Identification numbers

ELX terminals have two different identification numbers:

• date code (batch number)

•Beckhoff Traceability Number, or BTN for short (as a serial number it clearly identifies each terminal)

Datecode

The date code is an eight-digit number given by Beckhoff and printed on the ELX terminal. The date code

indicates the build version in the delivery state and thus identifies an entire production batch, but does not

distinguish between the terminals in a batch.

Structure of the date code: WWYYFFHH

WW - week of production (calendar week)

YY - year of production

FF - firmware version

HH - hardware version

Example with date code: 02180100:

02 - week of production 02

18 - year of production 2018

01 - firmware version 01

00 - hardware version 00

Foreword

ELX3252 9Version: 1.0.0

Beckhoff Traceability Number (BTN)

In addition, each ELX terminal has a unique Beckhoff Traceability Number (BTN).

Ex marking

The Ex marking can be found at the top left on the terminal:

II 3 (1) G Ex ec [ia Ga] IIC T4 Gc

II (1) D [Ex ia Da] IIIC

I (M1) [Ex ia Ma] I

IECEx BVS 18.0005X

BVS 18 ATEX E 005 X

Examples

Fig.1: ELX2008-0000 with date code 2519HMHM, BTN 0001f6hd and Ex marking

Foreword

ELX325210 Version: 1.0.0

Fig.2: ELX9560-0000 with date code 12150000, BTN 000b000 and Ex marking
