Baumatic BPP75L Manuel utilisateur

User Manual for your Baumatic

BPP75L

75 cm Stainless Steel Powerpack Rangehood

NOTE: This user manual contains important information including safety &

installation points which will enable you to get the most out of your appliance.

Please keep it in a safe place so that it is readily available for future reference.

Contents

Environmental note 1

Important safety information 2

Specifications of your rangehood 5

Using your rangehood

Before first use 6

To use your rangehood 6

Cleaning your rangehood

The grease filter 7

Maintenance

Removing and cleaning the grease filter 8

Changing a light bulb 8

Fitting the carbon filter 9

Installation

Electrical connection 10

Before beginning installation 11

Installing your rangehood 12

Connecting to external ducting 13

Completing the installation 13

Packing List 14

Extraction mode or recirculation mode? 14

Troubleshooting 15

Environmental note

Note: Before discarding an old appliance, switch off and disconnect it from the

power supply. Cut off and render any plug useless. Cut the cable off directly

behind the appliance to prevent misuse. This should be undertaken by a

competent person.

This appliance is marked according to the European directive 2002/96/EC on Waste

electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of

correctly, you will help prevent potential negative consequences for the environment

and human health, which could otherwise be caused by inappropriate waste handling of

this product.

The symbol on the product or on the documents accompanying the product

indicates that this appliance may not be treated as household waste. Instead it

shall be handed over to the applicable collection point for the recycling of electrical and

electronic equipment.

Disposal must be carried out in accordance with local environmental regulations for

waste disposal. For more detailed information about treatment, recovery and recycling

of this product, please contact your local city office or local waste management office.

oThe packaging materials that we use are environmentally friendly and can be

recycled.

oPlease discard all packaging material with due regard for the environment.

Important safety information

Your safety is of the utmost importance to us. Please make sure that

you read this instruction booklet before attempting to install or use

the appliance. If you are unsure of any of the information contained in

this booklet, please contact the Retailer where you purchased your

unit from.

IMPORTANT: Any installation work must be carried out by a

qualified electrician or competent person.

oThe rangehood must be installed in accordance with the installation instructions

and all measurements followed.

oIf the rangehood is installed for use above a gas appliance then the provision for

ventilation must be in accordance with the Gas Installations standard AS/NZS

5601.1 & 2:2013, the Gas Safety and Measurement Regulations 2010, and the

Building (Specified Systems, Change the Use, and Earthquake-prone Buildings)

Regulations 2005 issued under the Building Act 2004.

oIt is dangerous to alter the specifications or to modify this product. Do not tamper

with it or attempt to modify the appliance in any way.

oWhen installing the rangehood, ensure that the following recommended

distances are observed between the highest point on the hob top (including the

burners) and the bottom of the rangehood:

Electric cookers: 700 mm

Gas cookers: 700 mm

Coal/ oil cookers: 800 mm

IMPORTANT: Do not set your rangehood less than 700mm above your

cooker.

oWhen installed between adjoining wall cabinets, the cabinets must not overhang

the hob.

oThe edges of the rangehood are sharp –be mindful of this as you handle your

appliance, especially during installation and cleaning. DO NOT CLEAN IN

BEHIND THE GREASE FILTERS!

oIf the room where the rangehood is to be used contains a fuel burning appliance

such as a central heating boiler then its flue must be of the sealed or balanced

flue type.

oIf other types of flue or appliances are fitted, ensure that there is an adequate

supply of air in the room.

oWhen the rangehood is being used in its extractor function, ensure that the

ducting is fire retardant and that there are no bends sharper than 90 degrees as

this will reduce the efficiency of the rangehood.

oEnsure the ducting for the extractor function has the same diameter as the outlet

hole all the way through.

oKeep young children from using, playing with or tampering with the rangehood.

oYour rangehood is for domestic use only.

oPlease dispose of the packing material carefully –children are especially

vulnerable to it.

oDirty oil is an even greater fire risk.

oAlways put lids on pots and pans when cooking on a gas cooker.

oThe manufacturer refuses to accept any responsibility for damages arising to the

rangehood, including it catching on fire, due to a failure to observe the fire safety

advice contained in this instruction booklet.

oRemember that when in extraction mode, your rangehood is removing air from

your room. Ensure that proper ventilation measures are being observed.

oNote that the rangehood removes odours from your room, not steam.

oWarning - Always ensure that the rangehood has been switched off before

carrying out any work, including replacing light bulbs.

oDo not connect the ducting system of this appliance to any existing ventilation

system which is being used for any other purpose.

oDo not install above a cooker with a high level grill.

oNever leave frying pans unattended during use as overheated fats and oils might

catch fire.

oThe rangehood should not be exposed to a direct heat source from the cooking

device underneath it, i.e. a naked flame from a gas burner or heat from electric

hob zones without a pan on them.

oDo not attempt to use the rangehood if it is damaged in any way. Never attempt

to use it without the grease filters fitted or if the filters are excessively greasy!

oNever flambé cook under this rangehood.

oThe lights on this appliance should only be used during operation of the

rangehood. They should not be left on permanently and used as a lighting

source.

THE MANUFACTURER DECLINES ALL RESPONSIBILITY IN THE

EVENT OF FAILURE TO OBSERVE THE INSTRUCTIONS GIVEN

HERE FOR INSTALLATION, MAINTENANCE AND SUITABLE USE

OF THE RANGEHOOD.

Specifications of your rangehood

Product dimensions

Height: 254mm

Width: 750mm

Depth: 296mm

Your rangehood is fitted with:

oModern LED lighting (2 lamps)

oPush buttons

oA 3 speed fan

oBrushed stainless steel finish

oS/S panel Aluminium filter

o60dB min. noise level

o70dB max. noise level

o150mm diameter ducting outlet

Extraction capacity: 700m³/hr

Optional extras: Recirculation possible with optional charcoal filter (ST1)

Where to find your model number and serial number: Your appliance has a data plate

that provides identifying information that is important to know when registering your

purchase online and for service. You can find the data plate behind the motor after

removing the grease filter. For information on how to remove the grease filter, see page

Using your rangehood

Before first use

IMPORTANT: This process must be followed before the rangehood is used for the

first time.

You should use a mild liquid detergent and a damp cloth on all the external areas of

your rangehood before it is used for the first time. This will help to remove any residues

from the manufacturing process.

To use your rangehood

oMake sure that it has been installed by a suitably qualified person,

as per the information contained in these installation instructions.

oFind the control panel, which is located in the middle of the

canopy.

oThe control panel contains switches, as shown in the picture

below, which perform separate functions.

Push button

1. Push stop button, and the motor will stop.

2. Push the Low button, and the motor runs at low speed.

3. Push the high button, and the motor runs at mid speed.

4. Push the High button, and the motor runs at high speed.

Push the light button and the two lights will come on. Push it again and the light will turn off.

IMPORTANT: Ideally you should switch on your rangehood ten minutes before

you start to cook, or at the very least when you begin cooking. You should also

run your rangehood for ten minutes after you have finished cooking.

Cleaning your rangehood

IMPORTANT: Before cleaning, always ensure that you have

switched your rangehood off at the omni-polar switch, set at the

wall from the cable.

Cleaning

oClean the external parts of your rangehood with mild liquid detergent and a new

damp cloth.

oNever use abrasive powder, corrosive solvents or brushes.

oNever insert pointed objects into the motor’s protective grid.

oOnly clean the control panel and grease filter grill with mild liquid detergents and

a new damp cloth.

oIf you are using the appliance in recirculation mode, then be sure to replace the

carbon filters at the recommended interval (see section on “Fitting the carbon

filter” on page 9). A build up of grease could cause a fire hazard.

oNever attempt to clean the area above the grease filter.

The Grease filter

oYour rangehood includes a grease filter which helps to absorb grease particles to

protect your kitchen and furniture from greasy residues.

oYour rangehood includes a metal filter which can be periodically washed.

oThe filter may become flammable if it becomes saturated with greasy residue.

oTo prevent this fire hazard, the metal filter should be cleaned regularly.

Depending on use, this should be done every two months, using hot water and

normal washing-up detergent.

IMPORTANT: Do not wash the grease filter in a dishwasher as the chemicals can

cause damage.

Maintenance

Removing and cleaning the grease filter

oFirst remove the grease filter by sliding the securing nibs at the sides of the grille

on the underside of the cooker hood.

oSoak the grease filter in hot water and washing up liquid for about an hour.

oRinse it off thoroughly with hot water.

oRepeat the process if required.

oIMPORTANT: Let the grease filter dry thoroughly before refitting it in the

rangehood.

oNever attempt to use your rangehood without the grease filter in place.

Changing a light bulb (Part number: SYKL25 –LED LIGHT)

oIMPORTANT –Always ensure the rangehood has been

switched off before carrying out any work, including

replacing light bulbs.

oPrior to removing the LED light, ensure that it has

cooled down.

oPress gently on the underside of the bulb that needs to be replaced and twist

anticlockwise to release.

oReplace in reverse order using only genuine spare part SYKL25.

oIMPORTANT: Defective bulbs should be replaced immediately.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Baumatic hotte de ventilation

Baumatic

Baumatic PV972GL Manuel utilisateur

Baumatic

Baumatic BTI9170GL Manuel utilisateur

Baumatic

Baumatic Pythagora P25SS Manuel utilisateur

Baumatic

Baumatic BT10.3GL Manuel utilisateur

Baumatic

Baumatic BT98SS Manuel utilisateur

Baumatic

Baumatic F60 SS Manuel utilisateur

Baumatic

Baumatic BTW600ME Manuel utilisateur

Baumatic

Baumatic CAN52.3ME Manuel utilisateur

Baumatic

Baumatic BTC6750GL Manuel utilisateur

Baumatic

Baumatic BWT7.3GL Manuel utilisateur

Baumatic

Baumatic ISL5SS Manuel utilisateur

Baumatic

Baumatic BTI970SS Manuel utilisateur

Baumatic

Baumatic BWE600GL Manuel utilisateur

Baumatic

Baumatic STD6.2 Manuel utilisateur

Baumatic

Baumatic GUH52SD Manuel utilisateur

Baumatic

Baumatic OMBRA3.1SS Manuel utilisateur

Baumatic

Baumatic BT120 Manuel de la liste des pièces

Baumatic

Baumatic P37SS Manuel utilisateur

Baumatic

Baumatic ISL95SS Manuel utilisateur

Baumatic

Baumatic BT6GL Manuel de la liste des pièces

Baumatic

Baumatic AS35SS Manuel utilisateur

Baumatic

Baumatic BESW601BGL Manuel utilisateur

Baumatic

Baumatic BT6.3GL Manuel utilisateur

Baumatic

Baumatic BEDD600SS Manuel utilisateur

Manuels hotte de ventilation populaires d'autres marques

emmeti

emmeti RECUPA MED A-140 Mode d’emploi

Nibe

Nibe F135 Manuel utilisateur

Kuppersberg

Kuppersberg INTRO 60 Instructions d'installation et d'entretien

Zephyr

Zephyr Spruce AK9834BS Guide d'installation

Hisense

Hisense MH6INBG Manuel utilisateur

Miele

Miele DA 1255 Manuel utilisateur

Broan

Broan 46000 Manuel utilisateur

GE Profile PV977 Instructions originales

FALMEC

FALMEC FFRIA24W5FS Manuel utilisateur

Whirlpool

Whirlpool RH2600XL-1 SERIES Manuel utilisateur

Küppersbusch

Küppersbusch DX ISLA Manuel utilisateur

ETNA

ETNA AV360RVS Manuel utilisateur

JUNO

JUNO JDF603E6 Manuel utilisateur

Miele

Miele DA 6708 D Manuel utilisateur

Tricity Bendix

Tricity Bendix LE 150 Manuel

AEG

AEG X68163BV1 Manuel utilisateur

AEG

AEG 125 D Manuel utilisateur

Smeg

Smeg KSEV97X Manuel utilisateur
