MDSC-2242

42-inch full HD large-screen surgical display

Barco's MDSC-2242 is a 42-inch

large-screen surgical display with LED

backlight, featuring full HD resolution.

Purpose-built for the operating room, the

MDSC-2242 can visualize a wide range

of analog and digital video sources,

including HD endoscopic video, room

and boom camera video, patient and

surgery information, radiology and

pathology images, with ultimate detail.

Color-calibrated, artifact-free images

Thanks to its high brightness, high contrast and high resolution, the

MDSC-2242 presents surgeons with accurate, realistic images and

excellent depth perception. It also offers the fastest, lag-free

transmission of surgical images and the highest image quality available

today.

Our next-generation motion adaptive de-interlacing and noise reduction

algorithms, using full 10-bit image processing and a 12-bit look-up table,

make the MDSC-2242 ideal for consulting PACS images in the OR.

Multi-source, multi-display imaging over IP

With its broad input connectivity, the MDSC-2242 offers the highest

flexibility for multi-modality imaging (PiP & PaP), enabling reproduction

of images from multiple sources and to multiple displays in the

integrated operating room.

The 42-inch display is one of Barco's network-enabled surgical displays

and offers integrated functionality (optional) for use with Nexxis digital

OR, ensuring smooth distribution of uncompressed video and data over

the IP network without delay.

MDSC-2242

42-inch full HD large-screen surgical display

Designed for use in the operating room

Barco's MDSC-2242 allows easy cleaning and disinfection thanks to its

anti-reflective protective front glass.

The fan-less design avoids the spread of contaminants in the operating

room.

Product specifications MDSC-2242

屏幕技术 TFT AM LCD with LED backlight

活跃屏幕大小（对角线） 1067 mm (42")

活跃屏幕大小（H x V） 930 x 523 mm (36.6” x 20.6")

屏幕高宽比 16:9

分辨率 2MP (1920 x 1080)

像素度 0.4845 mm

彩色成像 Yes

色彩支持 1073 million (10-bit)

色阶度 72% NTSC

视角 178° Hor / 178° Ver

最大灯光 500 cd/m² (typical)

对比度 4000:1 (typical)

响应率 8 msec (GtG - typ)

Dot钟表 (max) 165 Mhz

伽玛曲线 Native, 1.8, 2.0, 2.2, 2.4, X-ray

机箱颜色 White RAL 9003

视频输入 Video input signals:

-DVI-I Single-Link (Digital & Analog – HDMI video support with HDCP)

-Component Video RGBS / YPbPr (4xBNC)

-S-video (4-pin Mini DIN)

-Composite video (1xBNC)

-3G-SDI (1xBNC)

-DisplayPort (VESA std 1.1a)

-Optional: integrated Nexxis network adapter

Video input formats:

-VGA & DVI: Up to 1920x1200 at 60Hz (reduced blanking)

Maximum pixel clock: 165MHz

Maximum Hor freq: 90kHz

Maximum Ver freq: 75Hz

-Standard PAL and NTSC for S-Video, Composite and Component

-Component YPbPr/ RGBS: HDTV - up to 1080i & 1080p

-SDI Format Supported: 625/25 PAL, 525/29.97 NTSC, 1080i50,

1080i59.94, 1080i60, 720p50, 720p59.94, 720p60, 1080p50, 1080p59.94,

1080p60

-SDI Compliance: SMPTE 425M (Level A), SMPTE 424M, SMPTE 292M,

SMPTE 259M-C, SMPTE 296M, ITU-R BT.656, ITU-R BT.601

-Displayport 1.1a: up to 1920 x 1200 60Hz

视频输出 DVI-D

S-video (4-pin Mini DIN)

Composite video (1xBNC)

3G-SDI (1xBNC)

Visualization modes Picture-in-Picture, Picture-by-Picture, Zoom

演示控制 OSD menu / Infrared remote control / serial RS-232 interface (D-sub 9-pin)

Product specifications MDSC-2242

电力要求（标称） Power source (integrated power supply): 100 – 250 VAC / 47-63 Hz

auto-switch

Power supply for external module: +5VDC ±10% @500mA (max) through

the DVI connectors DVI-in & DVI-out

电力消耗（标称） less than 150 W

OSD语言 English, French, German, Spanish, Italian

无底座维数(W x H x D) 1015 x 608 x 90 mm ( 40” x 23.9” x 3.5”)

无底座净重 24 kg (52.9 lbs)

包装无底座净重 30 kg (66.1 lbs)

安装标准 VESA 600 and 200

屏幕保护 IP21 / Front face: IPx5

Protective, non-reflective tempered glass

推荐模式 Endoscopy, Laparoscopy, X-ray, CT, MR, US

校准 IEC60601 3rd Edition

Approvals/Marking: CE, C-UL-US, DEMKO

Safety (Medical equipment): IEC60601-1, UL60601-1, CSA-C22.2 nr

601-1-M90

Electromagnetic Compatibility: EMC Medical EMC Standards:

IEC60601-1-2, EN55011 /CISPR 11, FCC CFR47 part 15 & 18/Class A

Environment: ROHS-2, REACH, WEEE compliant

温度 Operating: 0° - 40° C / Storage: -20° - 60° C

湿度 Operating: 10% – 90% R.H. / Storage: 5% – 90% R.H.

键盘/鼠标 7-key membrane, side-right

备件 User Manual, Infrared Remote Control, DVI Dual-Link cable 3.0m, Mains

cables (EU (CEBEC/KEMA) & US (Hospital grade UL))

可选附件 wall mount

保修期 3 years
