LCN47

47" native High Definition LCD display

TheBarcoLCDdisplayshavebeenspecificallydesignedforuseindedicated

professional applications. They feature full High Definition (1920 x 1080

pixels) and deliver crisp, clear and coloraccurate perfect images on large

displaysizeswith47”diagonal.

TheLCDtechnologyusedintheBarcoLCseriesoffersmanybenefitsnotfound

inotherflatpaneltechnologies:

•Highbrightness

•Highcontrast,eveninhighambientlightenvironments

•Ultrahighnativeresolution(1920x1080pixels)

•Fanlessdesign(nonoise)

•Framelock

•Accepts1080psignals

•Lowpowerconsumption

•Longlifetime

Foruseincontrolrooms,boardroomsandmeetingrooms,thenative1920x

1080pixelresolutionstandsfortheultimateindetail.

For TV studios the adjustable color temperature setting enables the user to

maintain perfect color balance under all studio lighting conditions. The

fanlessdesignkeepsthebackgroundnoisebelowtheaudiblenoiselevel.

Inboardroomsandvariousmeetingenvironmentslargeamountsof

LCN47

47" native High Definition LCD display

informationcanbepresentedinadynamicwaywiththesimultaneousdisplay

of a second source as a Picturein Picture (PIP) or PictureandPicture

(PAP).

Inlobbiesandpublicaddressenvironmentstheloopthroughfunctionality

allowstheLCDdisplaystobecontrolledfromasinglelocation.

Technicalspecifications LCN47

Technology TFTLCD

Resolution 1920x1080(fullHD)

Lifetime 50,000haverage

Colors 16.8million

Colorgamut 76%NTSC

AspectRatio 16:9

Viewingangle 176°/176°

Responsetime 6.5ms

Dotsperinch 46dpi

Coloradjustment 3200K,5400K,6500K,9300K,User(R,G,Bsliders)

Contrastratio 1500:1

Brightness 500cd/m²

Lightsensor Ambientlightsensorforautomaticdimming

Standardinputs DVI;VGA(D15);SVideo;CompositeVideo;Componentvideo(YPbPr,YCbCr)

Supportedresolution Oncomposite,Svideoandcomponentinputs:PALSecam576i,NTSC480i

OnDVIandVGAinputs:VESA:VGA,SVGA,XGA,WXGA,SXGA,SXGA+,UXGA;

SMPTE296M(1280x720p);SMPTE274M(1920x1080iand1920x1080p)

Control RS232control(withloopthrough);Baudrate:115200,38400,19200or9600

OnScreenDisplay(OSD)

IRremotecontrol

Audio Audiopreampinputmodule(excl.speakers)

Pictureinpicture PIPsourcemax.110MHz

Input 85V264V(50Hz60Hz)

Powerconsumption 303W

Operatingtemperature 5°to40°C(41°to104°F)

Humidity Max.85%

RegulationCompliance CE,UL,FCC,TÜV,CCC

Cooling Lownoiselevel21dB(A)/fanlesscooling

Activescreendiagonal 47”(1,194mm)

Activescreenarea 1,047.4x592.4mm(41.24”x23.32”)

Dimensions 1,139.4x684.4x126.2mm(44.86”x26.94”x4.97”)

Weight 40.2kg(88.7lbs)

Frontglass Optional

Hanging VESAMISF,600,200,8(mountsandtablestandsareoptional)

Warranty Theproductissubjecttowarrantyof2years.

Warrantyforimageretentionissubjecttocertainconditionsofuse.

Generatedon:04Jan2014

Technicalspecificationsaresubjecttochangewithoutpriornotice.

Pleasecheckwww.barco.comforthelatestinformation.
