ADSL2+ Ethernet Modem - User Guide

Page 1 of 33

ADSL Ethernet Modem

User Guide

Version 1.0

ADSL2+ Ethernet Modem - User Guide

Page 2 of 33

Table of Contents

Preliminary Pages Page

Table of Contents ................................................................................................. 2

List of Illustrations ............................................................................................... 4

Chapter 1- About this Manual ............................................................................. 6

1.1 Introduction........................................................................... 6

1.2 Scope and Purpose .............................................................. 6

1.3 Targeted Audience ............................................................... 6

1.4 Manual Organization............................................................. 6

Chapter 2– ADSL Ethernet Modem Description ................................................ 7

2.1 ADSL Modem Overview........................................................ 7

Chapter 3- Your Gateway At A Glance ............................................................... 8

3.1 Ports and Buttons ................................................................. 8

3.2 ADSL Modem Overview........................................................ 9

3.2.1 Front Indicators..................................................................... 9

3.2.2 Back Panel.......................................................................... 10

Chapter 4- Setting Up the ADSL Modem.......................................................... 11

4.1 Logging into your ADSL Modem......................................... 11

4.2 Quick Start.......................................................................... 12

4.3 LAN / DHCP Configuration ................................................. 13

4.4 Diagnostic Test................................................................... 14

4.4.1 Ping Test............................................................................. 15

4.5 Advanced............................................................................ 16

4.5.1 WAN Connection ................................................................ 16

4.5.2 New Connection ................................................................. 17

4.5.3 Connection Scan ................................................................ 17

4.5.4 Quickstart............................................................................ 18

4.5.5 LAN Configuration .............................................................. 19

4.5.6 LAN Clients......................................................................... 20

4.5.7 Application (UPnP) ............................................................. 21

4.5.8 DNS Proxy.......................................................................... 21

4.5.9 Dynamic DNS Client........................................................... 22

4.5.10 Port Forwarding.................................................................. 22

4.5.11 Bridge Filters....................................................................... 23

ADSL2+ Ethernet Modem - User Guide

Page 3 of 33

4.5.12 Routing (Static Routing)...................................................... 24

4.5.13 Routing Table ..................................................................... 24

4.5.14 System Password............................................................... 25

4.5.15 Firmware Upgrade.............................................................. 25

4.5.16 Restore to Default............................................................... 26

4.6 Security............................................................................... 26

4.6.1 IP Filters.............................................................................. 26

4.6.2 LAN Isolation ...................................................................... 27

4.7 Status.................................................................................. 28

4.7.1 Connection Status .............................................................. 28

4.7.2 System Log......................................................................... 29

4.7.3 Remote Log Settings .......................................................... 30

4.7.4 Network Statistics ............................................................... 30

4.7.5 DDNS Update Status.......................................................... 31

4.7.6 DHCP Clients...................................................................... 31

4.7.7 Modem Status..................................................................... 32

4.7.8 Product Information ............................................................ 32

4.8 Help .................................................................................... 33

ADSL2+ Ethernet Modem - User Guide

Page 4 of 33

List of Illustrations

Figure Page

Figure 1-1 : ADSL Modem Configuration Diagram................................................. 7

Figure 1-2 : Front Panel Indicators......................................................................... 9

Figure 1-3 : Back Panel Indicators........................................................................ 10

Figure 1-4 : Quick Start ........................................................................................ 11

Figure 1-5 : Basic Home....................................................................................... 12

Figure 1-6 : Quick Start Page............................................................................... 12

Figure 1-7 : LAN / DHCP Configuration................................................................ 14

Figure 1-8 : Diagnostics Test Screen ................................................................... 14

Figure 1-9 : Diagnostics Test Result Screen ........................................................ 15

Figure 1-10 : Ping Test Screen............................................................................. 15

Figure 1-11 : Advanced Screen............................................................................ 16

Figure 1-12 : New Connection (PPPoE Connection Setup).................................. 17

Figure 1-13 : Connection Scan............................................................................. 17

Figure 1-14 : Quickstart (PPPoE Connection Setup)............................................ 19

Figure 1-15 : LAN Configuration........................................................................... 20

Figure 1-16 : LAN Clients ..................................................................................... 20

Figure 1-17 : UPnP............................................................................................... 21

Figure 1-18 : DNS Proxy....................................................................................... 22

Figure 1-19 : Dynamic DNS Client........................................................................ 22

Figure 1-20 : Port Forwarding............................................................................... 23

Figure 1-21 : Bridge Filters................................................................................... 23

Figure 1-22 : Static Routing.................................................................................. 24

Figure 1-23 : Routing Table.................................................................................. 24

Figure 1-24 : System Password............................................................................ 25

ADSL2+ Ethernet Modem - User Guide

Page 5 of 33

Figure 1-25 : Firmware Upgrade........................................................................... 25

Figure 1-26 : Restore to Default prompt............................................................... 26

Figure 1-27 : Security ........................................................................................... 26

Figure 1-28 : IP Filters.......................................................................................... 27

Figure 1-29 : LAN Isolation................................................................................... 27

Figure 1-30 : Status.............................................................................................. 28

Figure 1-31 : Connection Status........................................................................... 29

Figure 1-32 : System Log ..................................................................................... 29

Figure 1-33 : Remote Log Settings....................................................................... 30

Figure 1-34 : Network Statistics............................................................................ 30

Figure 1-35 : DDNS Update Status ...................................................................... 31

Figure 1-36 : DHCP Clients.................................................................................. 31

Figure 1-37 : Modem Status................................................................................. 32

Figure 1-38 : Product Information......................................................................... 32

Figure 1-39 : Help Screen..................................................................................... 33

Safety Summary Messages

WARNING

HIGH VOLTAGE

is used in the equipment. Make sure equipment is properly grounded

BEFORE opening. Failure to observe safety precautions may result in

electric shock to user.

CAUTION

Check voltages before connecting equipment to power supplies.

Wrong voltages applied may result in damage to equipment.

ADSL2+ Ethernet Modem - User Guide

Page 6 of 33

Chapter 1 - About this Manual

1.1 Introduction

This manual provides a general product overview and description of its subsystems and

components and basic operation and preventive maintenance instructions of the

ADSL2+ Ethernet Modem.

1.2 Scope and Purpose

This manual provides the following:

•

An overview of the ADSL2+ Ethernet Modem configuration and connectivity;

•

General description and specifications of the ADSL2+ Ethernet Modem system

components;

•

Operating instructions of the system and equipment;

1.3 Targeted Audience

This manual is designed and developed for the operators and users who are required to

operate and perform first-level maintenance of the ADSL2+ Ethernet Modem. It

assumes the user of this manual has basic knowledge and experience in operating

similar modem configuration and computer systems equipment.

1.4 Manual Organization

The manual is divided into the following chapters:

1. Chapter 1 – About this Manual; this chapter provides an introduction to the

manual’s scope and purpose, targeted audience and contents organisation.

2. Chapter 2 – ADSL Ethernet Modem Description; this chapter provides the system

description and system configuration diagram of ADSL Modem connection.

3. Chapter 3 – Your Gateway At A Glance; this chapter provides an overview of

ports and LEDs, Front and Back indicators of the ADSL Modem.

4. Chapter 4 – Setting Up the ADSL Modem; this chapter provides description of all

function within the Web User Interface.

ADSL2+ Ethernet Modem - User Guide

Page 7 of 33

Chapter 2 – ADSL Ethernet Modem Description

The ADSL2+ Ethernet Modem is the perfect high-speed WAN bridge/router. This full-

featured product is specifically designed to connect to the Internet and directly connect

to your local area network via high speed 10/100 Mbps Ethernet. The Modem has also

full NAT firewall and DMZ services to block unwanted users from accessing your

network.

For game users, the ADSL Modem had already pre configured for several low latency

game ports. Just click on the game you are playing on line and the rest is done for you.

The ADSL Modem is fully compatible with all PCs; as long as the PC supports an

Ethernet interface and is running a TCP/IP protocol stack, your PC can have high-speed

WAN access. So, plug in the ADSL Modem (refer to easy start guide), configure it (per

your ISP’s requirements) and enjoy the fast Internet access like never before.

2.1 ADSL Modem Overview

Fig 1-1 shows the system configuration diagram of a typical ADSL Modem connection.

Figure 1-1 : ADSL Modem Configuration Diagram

ADSL2+ Ethernet Modem - User Guide

Page 8 of 33

Chapter 3 - Your Gateway At A Glance

The ADSL2+ Ethernet Modem may have different ports and LEDs. Let’s take a look at

the different options. Depending on your model, it may have some or all of the features

listed below.

3.1 Ports and Buttons

Reset and Restore to Factory Defaults: The restore to factory defaults feature will set

the ADSL Modem to its factory default configuration by resetting the ADSL Modem.

You may need to place the ADSL Modem into its factory defaults if the configuration is

changed; you lose the ability to interface to the ADSL Modem via the web interface, or

following a software upgrade. To reset the ADSL Modem, simply press the reset button

for about ~ 10 seconds. The ADSL Modem will be reset to its factory defaults and after

about 30 ~ 40 seconds the ADSL Modem will become operational again.

LAN (local area network) ETHERNET port: connects to Ethernet network devices,

such as a PC, hub, switch, or routers. Some ADSL Modem came with a single LAN

connection and some come with four LAN connections. Depending on the connection,

you may need a cross over cable or a straight through cable.

Power is where you connect the power. Make sure to observe the proper power

requirements. The required power is 9 volts.

DSL port: This is the WAN interface that connects directly to your phone line.

ADSL2+ Ethernet Modem - User Guide

Page 9 of 33

3.2 ADSL Modem Overview

3.2.1 Front Indicators

Fig 1-2 shows the front indicators of the ADSL Modem.

Figure 1-2 : Front Panel Indicators

LED Name Status & Meaning

1 PPP Lights up when the PPP connection is established.

2 PWR Lights up when power is supplied to the Modem.

3 DSL Lights up when the ADSL connection is established.

Flickers when the ADSL Modem is trying to establish a

connection with the ADSL Service Provider.

4 ETH/ACT Lights up when the Ethernet cable is properly connected from

your ADSL Modem to the Ethernet Card.

Flickers when the ADSL is transmitting / receiving data.

ADSL2+ Ethernet Modem - User Guide

Page 10 of 33

3.2.2 Back Panel

Fig 1-3 shows the back panel indicators of the ADSL Modem.

Figure 1-3 : Back Panel Indicators

Label Description

1 ADSL Telephone jack (RJ-11) to connect to your Telephone Wall

Socket (ADSL line).

2ETHERNET 10/100 Base-T Auto-MDI/MDIX (allows either cross or straight

cable) Ethernet jack (RJ-45) to connect to your Ethernet

Network card or Ethernet Hub/Switch.

3 RESET To reset the ADSL Modem, simply press the reset button for

about 10 seconds (all customised settings that you have

saved will be lost!).

4 DC 9V To connect to the Power Adapter that comes with your

package.

5 ON/OFF Switch To power ON and power OFF the ADSL modem.

Autres manuels pour DSL600E

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Aztech Modem

Aztech

Aztech DSL 300P Fiche d'information produit

Aztech

Aztech DSL Turbo 900 Package Manuel utilisateur

Aztech

Aztech 100U Fiche d'information produit

Aztech

Aztech DSL605E Manuel utilisateur

Aztech

Aztech DSL Turbo 900 Package Manuel utilisateur

Aztech

Aztech 206U Manuel utilisateur

Aztech

Aztech DSL 300P Fiche d'information produit

Aztech

Aztech MDP3858W Series Manuel utilisateur

Aztech

Aztech HomePlug AV with Simple Connect Button Manuel utilisateur

Aztech

Aztech MSP3880U Series Manuel utilisateur

Aztech

Aztech MSP2950(W) Manuel utilisateur

Aztech

Aztech MDP3880 Manuel utilisateur

Aztech

Aztech DSL Turbo 900 Package Manuel utilisateur

Aztech

Aztech MDP3880SP-U Manuel utilisateur

Aztech

Aztech DSL600E(C) Manuel utilisateur

Aztech

Aztech MR8800-U Manuel utilisateur

Aztech

Aztech DSL1015EN L Manuel utilisateur

Aztech

Aztech DSL 1015EN L Mode d’emploi

Aztech

Aztech DSL705EU Manuel

Aztech

Aztech HL110EW Instructions d'utilisation

Aztech

Aztech ADSL2/2+ Modem Manuel utilisateur

Aztech

Aztech HW550-3G Instructions d'utilisation

Aztech

Aztech 56K External Modem Fiche d'information produit

Aztech

Aztech MDP3880SP-U Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
