AWS DK-5K Manuel utilisateur

DK-5K (5000g x 1g /

1000g x 0.1g)

User Manual

DK-5K

Thank you for purchasing the American Weigh DK-

5K dual platform kitchen scale. Please read all operating

instructions carefully before use. Scales are precision

measuring devices and should always be handled with proper

care. To ensure years of reliable service, keep these simple

tips in mind:

• Do not exceed the scale’s maximum capacity. This scale

has integrated overload protection, but any overload

protection has its limits.

• Avoid weighing in extreme heat or cold. Scales perform

best at normal room temperature.

• This scale has been calibrated at the factory. Only

advanced users should attempt recalibration using the

speciedcalibrationmasses.

• Store your scale in a clean, dry location. Dust, dirt, and

moisture can accumulate on the weighing sensors and

electronics causing inaccuracy or malfunction.

• Keep the area around and under the scale clean. Loose

debris under the scale can push against the base causing

inaccuracy.

• Avoid using your scale in close proximity to strong radio

wave emitting devices such as cordless phones.

• Alwaysweighonaatandlevelsurface,freefrom

vibrations and drafts. The corner of a room is usually the

most stable.

• Gently apply all items to be weighed. Do not drop items

onto the weighing platform. Overload protection does not

protect the sensor from shock loading.

• Avoid dropping your scale. The warranty does not cover

damage due to rough treatment or overload.

• Checkthebatteriesrstifyouarehavinganytroublewith

your scale. This simple step can remedy most scale issues.

MODE TARE UNIT

ON/OFF

I. Part List

1. Scale

2. CR2032 Batteries (x2)

II. Key Description

1. MODE Key - Press to change the display mode between

Platform A and Platform B.

2. TARE Key - Press to rezero the scale (removes the weight of

an empty container)

3. UNIT Key - Press to change the weighing unit

4. ON/OFF Key - Press to turn the scale ON or OFF.

III. Battery Installation

1. Beforeusingthescaleforthersttime,checkthebattery

compartment and remove any plastic insulation strips or

packaging that may be in place to prevent battery drainage

during shipping/storage.

2. If you are replacing the batteries, make sure the positive and

negative contacts are properly aligned

Platform A

Platform B

1. 4.

2. 3.

DK-5K

IV. Platform A Operation (Glass Platform, Max Weight 5kg/11lb)

This platform is designed for general kitchen weighing up to 5000g

in increments of 1g.

1. Placethescaleonaat,levelsurface.

2. Tap the ON/OFF key to turn the scale on.

3. The current active platform will be indicated by an Aor Bto the

left of the display.

4. If the display shows B, press the MODE key to change the

display to platform A.

5. Once the scale displays zero, you are ready to weigh your items

on the platform A.*

V. Platform B Operation (Pull-out Platform, Max Weight 1000g)

Thisplatformhasahighresolutionforweighingneringredientsup

to 1000g in increments of 0.1g.

1. Placethescaleonaat,levelsurface.

2. Tap the ON/OFF key to turn the scale on.

3. The current active platform will be indicated by an Aor Bto the

left of the display.

4. If the display shows A, press the MODE key to change the

display to platform B.

5. Once the scale displays zero, you are ready to weigh your items

on platform B.*

*The scale will auto-off after 60 seconds of non-use to save battery life.

VI. Using the Tare Feature

You can use this scale’s tare feature to subtract the weight of an empty

container or vessel to weigh only the contents. NOTE: The weight of

the container will subtract from the available capacity.

1. Place the empty container or vessel on the weighing platform.

2. Press the TARE key once. The display will then reset to zero.

If the container is removed, its weight will be displayed as a

negative number.

3. Youmaynowllthecontainerwiththequantitytobeweighed.

The display will show just the weight of the contents.

4. To return to normal weight display (gross weight), remove any

items from the weighing platform and press the TARE key again

to re-zero the scale.

VII. Changing the Unit of Measure

1. Press the UNIT key to change the scale’s displayed unit of

measure.

2. If the scale is turned off then back on, it will default to the last

unit used.

• Platform A: g (gram) lb (pound) oz (ounce) ml (milliliter)

.oz.(uidounce-US)

• Platform B: g (gram) oz (ounce) ozt (troy ounce) dwt

(pennyweight) ct (carat) gn (grain)

VIII. Calibration Adjustment (Advanced Users Only)

You do not need to perform calibration on this scale unless the

scale is malfunctioning. PlatformAandplatformBrequireseparate

DK-5K

calibrationprocedures.Undernormalcircumstances,platformAshould

notrequirecalibration.PlatformBmaybecalibratedifyounotice

an error greater than ±0.2g when checking with calibration weights.

Only use a real calibration weight. Do not use items such as coins to

calibrate as this will degrade accuracy.

IX. Platform A Calibration

Before proceeding, make sure you have a 5000g calibration

weight. Using the wrong weight will cause inaccuracy.

1. Turn the scale ON and press the MODE key to change the

display to platform A (‘A’ will be displayed on the left)

2. Turn the scale OFF.

3. PressandholdtheUNITkeythentaptheON/OFFkeytoturn

the scale on.

4. TaptheUNITkeyagain,thedisplaywillshow“CAL”followedby

therequiredcalibrationweight(5000g).

5. PlacetherequiredcalibrationweightonthecenterofplatformA

(theglassplatform).Thedisplaywillshow“PASS”thenreturnto

normal weighing mode. Calibration is complete!

X. Platform B Calibration

Before proceeding, make sure you have a 500g calibration weight.

weight. Using the wrong weight will cause inaccuracy.

1. Turn the scale ON and press the MODE key to change the

display to platform B (‘B’ will be displayed on the left)

2. Turn the scale OFF.

3. PressandholdtheUNITkeythentaptheON/OFFkeyatthe

same time. Now release both keys.

4. TaptheUNITkeyagain,thedisplaywillshow“CAL”followedby

therequiredcalibrationweight(500g).

5. Placetherequiredcalibrationweightonthecenteroftheplatform

B(thestainlesssteelplatform).Thedisplaywillshow“PASS”then

return to normal weighing mode. Calibration is complete!

XI. Troubleshooting

1. Lo- Batteries are low. Replace the batteries.

2. O-ld Maximum capacity exceeded. This scale cannot be used to

give measurements over 11lbs (5kg).

3. Scale Not Weighing - Make sure that the display is set to the

correct platform - A or B.

XII. Specications

DK-5K

Platform A Capacity 5000g/176.4oz/5000ml/169.oz/11lb

Platform A Readability 1g/0.1oz/1ml/0.1.oz/0.002lb

Platform B Capacity 1000.0g / 5000.0ct / 35.27oz / 643.0dwt /

15432gn / 32.15ozt

Platform B Readability 0.1g / 0.5ct / 0.01oz / 0.1dwt / 2gn /

0.01ozt

Calibration Weights 500g, 5000g (not included)

Power 2 x AAA Batteries (included)

Auto-Off Time 60SecondsofNon-Use

Dimensions 6.4x9.1x0.8”(closed)

9.0 x 9.1 x 0.8 (platform extended)

Display Size 1.0x2.3”

Warranty 10 Year Limited Warranty

DK-5K

American Weigh Scales, Inc.

Norcross,GA30092,U.S.A

MadeinChinatoourexactspecicationsandqualitycontrol.
