Avery Dennison SNAP 700 Manuel d'utilisation

Operator’s and Service Manual

Avery Dennison

SNAPTM 700 Printer

SNAPTM 700 RFID Printer

621398

Rev 4.5 3/14

028028

ser’s Manual—SNAP™ 700 Printer

WARNIN

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference that may cause undesired operations.

This Class A digital apparatus meets all requirements of the Canadian Interference

Causing Equipment Regulations. Cet appareil numerique de la classe A respecte

toutes les

exigences du Reglement sur le material

broilleur d

u Canada

ser’s Manual—SNAP™ 700 Printer

Table of Contents

1.0 INTRODUCTION 9

2.0 INSTALLATION 10

2.1 Preparing for the installation 10

2.1.1 AC Power Line 10

2.1.2 Location Considerations 10

2.1.3 PC Requirements 11

2.1.4 User Safety 12

2.2 Receiving 12

2.3 Unpacking 13

2.3.1 Removin the printer from the carton 13

2.3.2 Inspection / Inventory Checklist 14

2.3.3 Downloadin Support Documentation 14

2.4 Printer Description 15

2.4.1 Printer Confi urations 16

2.5 Setting up the Printer 17

2.5.1 Attachin the Stacker 17

2.5.2 Checkin the Main Fuse Confi uration 18

2.5.3 Installin the Power Cord 19

2.5.4 Installin the PC Interface Cable 19

2.5.5 Installin PCMate Platinum Software 20

2.5.6 Attachin the Unwind Assembly 20

2. Printing a Test Label 21

2.6.1 Loadin Supplies 21

2.6.2 Turnin the Printer on 21

2.6.3 Selectin the Test Format 21

2.6.4 Printin the Test Labels 22

3.0 OPERATION 23

3.1 Loading Supplies 23

3.1.1 Installin Ink to the Top Ink Supply Station 23

3.1.2 Installin Ink to the Bottom Ink Supply Station 26

3.1.3 Loadin the Stock 26

ser’s Manual—SNAP™ 700 Printer

3.1.4 Butt Splice 28

3.1.5 Threadin Dia rams 29

3.2 Sending a Print Job to the Printer 30

3.3 Printing Labels 30

3.3.1 The Control Panel 30

3.3.2 Printin 31

3.3.3 Handlin the Leader 31

3.3.4 Feedin the stock 31

3.3.5 Errors 32

3.3.6 End of Day 32

3.3.7 Clearin Print Jobs 32

3.4 Using Pre-Printed Stock 33

3.4.1 Selectin the Sensor 34

3.4.2 Ali nin the Stock to the Sensor 34

3.4.3 Ali nin the Sensor to the Stock 34

3.5 Option Menu System 35

3.5.1 Runnin Test Patterns 36

3.5.2 Settin / Adjustin Voice Button Volume 38

4.0 MAKIN ADJUSTMENTS 40

4.1 Print Head Adjustments 40

4.1.1 Adjustin Print Head Pressure 40

4.1.2 Adjustin Density (Darkness) 41

4.2 Adjusting the Stacker 41

4.2.1 Stacker Position 42

4.2.2 To le Switch 42

4.2.3 Stacker An le 42

4.2.4 Platform 43

4.3 Virtual Control Panel 44

4.3.1 Introduction 44

4.3.2 Chan in Printer Settin s in PCMate (Printer Settin s) 45

4.3.3 Print/Cut Adjust (VCP Print/Cut Adjust Tab) 45

4.3.4 Selectin the Printer Lan ua e (VCP Options Tab) 46

4.3.5 Settin the Date and Time (VCP Options Tab) 47

4.3.6 Enablin or Disablin the Cutter (VCP Options Tab) 47

4.3.7 Selectin the Print Speed (VCP Options Tab) 47

4.3.8 Selectin the Fla in Mode (VCP Options Tab) 48

4.3.9 Selectin the Sense Mark Type (VCP Options Tab) 48

4.3.10 Settin the Default Transfer Type (VCP Options Tab) 48

4.3.11 Viewin the Life Counts (VCP Versions/History Tab) 49

4.3.12 Firmware Version (VCP Versions/History Tab) 49

4.3.13 Print Quality (VCP Arbor Tension Adjust Tab) 50

4.3.14 Other information on VCP 50

ser’s Manual—SNAP™ 700 Printer

4.4 Web Server 51

4.4.1 Settin the Printer IP Address 51

4.4.2 Obtainin a DHCP Address 51

4.4.3 Determinin the DHCP Address 52

4.4.4 Convertin the DHCP Address to a Static Address 53

4.4.5 Resettin the Printer to DHCP Mode 54

4.4.6 Viewin and Chan in the Printer Settin s 55

4.4.7 Troubleshootin the Network Connection 56

5.0 MAINTENANCE 57

5.1 Print Head Cleaning and Handling 57

5.1.1 Handlin Techniques 57

5.1.2 Cleanin Procedures 58

5.2 Print Head Replacement 59

5.3 Lubrication 2

5.4 Rotary Knife Assembly 2

5.4.1 Removin and Replacin the Knife Assembly 63

5.4.2 Adjust the Knife Home Position 66

5.5 Rubber Roller Replacement

6.0 SERVICE ADJUSTMENTS 67

6.1 Stock (Web) Guide Position 67

6.2 Stock (Web) Guide Width Adjustments 67

6.3 Stock Feed 67

6.4 Knife Shear Adjustment 67

7.0 UP RADIN THE PRINTER FIRMWARE 69

7.1 Introduction 9

7.2 Selecting the UPG file 9

7.3 Getting the UPG file 70

7.3.1 Gettin UPG file usin D2Comm 70

7.3.2 Gettin UPG file without usin D2Comm 70

7.4 Performing the Upgrade 71

7.4.1 Unzippin the file 71

7.4.2 Up radin throu h PCMate 72

7.4.3 Up radin throu h USB Flash Drive 75

7.4.4 Up radin throu h the Webserver 75

8.0 ELECTRICAL TROUBLESHOOTIN 79

8.1 Power Up / Sign On / Communications 79

ser’s Manual—SNAP™ 700 Printer

8.2 Stock / Ink Advance 81

8.3 Print 82

8.4 Cut / Stack 84

10.5 Printer Errors 85

9.0 MECHANICAL TROUBLESHOOTIN 91

9.1 Stock 91

9.2 Ink 92

9.3 Print 92

9.4 Knife 92

APPENDICES 93

1. Fuse Configuration 93

2. Ink and Stock Transfer Types 94

3. Printer Specifications 9

4. Instructions for Factory / Field Installation of Top Sensor Assemblies 2000 & 20007

Installation Procedure 98

5. Programming the Contrast Sensors 102

Pro rammin the Contrast Sensor 103

Pro rammin the Color Contrast Sensor 104

. Instructions for Factory / Field Installation of High Speed Verifier Assembly 20008F

(Factory) and 20008 (Field) 10

Installation Procedure - Mechanical 106

Installation Procedure - Electrical 108

Installation – Rear Cover 109

7. Warranty Policy 110

Service 111

8. Option Menu System Flowchart 112

ELECTRICAL DRAWIN S 113

Electrical System Schematic 114

Harness Connections 115

MECHANICAL ASSEMBLY DRAWIN S 117

ser’s Manual—SNAP™ 700 Printer

Unwind Assembly – Single Shaft Design (Old) 118

Unwind Assembly – Two Shaft Design (New) 119

Unwind Assembly RFID 3” / 4” – Single Shaft Design (Old) 120

Unwind Assembly RFID 3” / 4” – Two Shaft Design (New) 121

Unwind Motor Assembly 122

Decurler Assembly 123

Web Guide Assembly 124

Sensor Tray Assembly 125

Sensor Tray Assembly RFID 12

Top Print Head Assembly 127

Bottom Print Head Assembly 128

Print Head Assembly 129

Platen Roller Assembly 130

Ink Arbor Assembly 131

Ink Unwind / Rewind Motor(s) Assembly 132

Drive Assembly 133

Knife Assembly 134

Nip Roller Assembly 13

Knife / Drive Motors Assembly 137

Knife / Drive Motors Assembly RFID 138

RFID Reader Assembly 139

Covers Assembly 140

Cooling Fans Assembly 141

Stacker Assembly (Sheet 1 of 2) 142

Stacker Assembly (Sheet 2 of 2) 143

Stacker Parts List 144

Addendum I – Printing and Supplies Handling Procedure 145

ser’s Manual—SNAP™ 700 Printer

Addendum II – Short Feed 147

Short Feed O-Rin Replacement 147

Short Feed Assembly 149

Short Feed Part List 150

Revision Record 152

ser’s Manual—SNAP™ 700 Printer

1.0 Introduction

AVERY DENNISON has designed the SNAP

700 printer for simple installation,

easy operation, and dependability. se your printer to produce two-sided,

brand/care labels paper hang tags and self-adhesive stickers for your apparel,

footwear, or other products needing identification. Printing up to a speed of up to

7 inches (178 mm) per second for care labels and 12 inches (305mm) per

second for tags and stickers, (supply dependent) the SNAP 700 printer features

quick change-outs of inks and tapes, multilingual voice prompts, and easy

operating system updates. Finally, the SNAP 700 printer supports various

options including RFID.

The SNAP 700 multiple head printer can have two different head configurations

when ordered. This manual covers both configurations.

This manual guides the printer operator as an easy-to-use, quick-reference

guide. It contains procedures for receiving, handling, set-up, installation,

operation, and maintenance of the SNAP 700 printer.

Please read this section of the manual to familiarize yourself with the printer and

to guide you through the initial receiving and set-up of your new SNAP 700

printer. Throughout this manual, a system of NOTES, CA TIONS, and

WARNINGS identify key information to ensure your personal safety and to proper

printer operation. Please review these carefully.

We also strongly suggest that you watch the 17-minute training video,

which is available on the D2Comm web site. Refer to the documentation

included with the printer for more details.

NOTES call attention to information that is especially

significant to understanding and operating the equipment.

CAUTION notices inform you of actions or situations in

which the printer might be damaged.

WARNIN notices describe situations in which lack of

attention or insufficient equipment knowledge could cause

either personal injury or damage to the printer.





ser’s Manual—SNAP™ 700 Printer

2.0 Installation

2.1 Preparing for the installation

2.1.1 AC Power Line

NOTE: AVERY DENNISON requires that the minimum

electrical service be 10 Amps @ 115VAC or 6 Amps @

230VAC. This will allow you to plug the SNAP 700 printer,

PC, and any additional support or service equipment into

the same service. We highly recommend that the printer

and its accessories be on a dedicated circuit.

The electrical service supplying power to the SNAP 700 printer or to peripheral

equipment connected to the SNAP 700 printer should meet standard electrical

code practices, including proper grounding and neutrals.

2.1.2 Location Considerations

The SNAP 700 printer weighs 60 pounds (27.2 Kg) and requires a table of

sufficient quality and strength to handle this load. The printer requires an area of

approximately 72" wide x 30" deep x 32" high (1.8 m x 76 cm x 81 cm). The host

PC (if used) and any printer options will increase the required area. AVERY

DENNISON recommends using an industrial type worktable. Refer to Figure 1

below.

The SNAP 700 printer is designed for easy operator accessibility to the printer

controls and components. Select your SNAP 700 printer’s location to meet the

following criteria:

1. Physical demands on the operator will dictate proper height of the table

supporting the printer. Ensure the operator has comfortable access to the

printer. Refer to Figure 1.

2. Allow enough space for smooth flow of materials that the operator will

load on the printer as well as space for processing the finished product

from the printer.

3. While AVERY DENNISON has designed the printer to be reasonably

quiet, select an area where repetitious noise from printing and cutting

processes is acceptable.

CAUTION: Each customer must take responsibility to

ensure the workstation created for the SNAP 700 printer

meets the recommended requirements to ensure optimal

operation of the printer.



Autres manuels pour SNAP 700

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Avery Dennison Imprimante

Avery Dennison

Avery Dennison M09416 TTXLI Manuel utilisateur

Avery Dennison

Avery Dennison Monarch Pathfinder Ultra Platinum 6039 Manuel utilisateur

Avery Dennison

Avery Dennison MONARCH 9416 XL Instructions d'installation et d'utilisation

Avery Dennison

Avery Dennison Monarch 9460 SNP Manuel de service

Avery Dennison

Avery Dennison Monarch 9460 Manuel de service

Avery Dennison

Avery Dennison TC9820PHI Manuel utilisateur

Avery Dennison

Avery Dennison SNAP 500 Manuel d'utilisation

Avery Dennison

Avery Dennison Pathfinder 6059 Manuel de service

Avery Dennison

Avery Dennison Monarch ADTP2 EcoCut Manuel de service

Avery Dennison

Avery Dennison TrafficJet Manuel utilisateur

Avery Dennison

Avery Dennison MonarchNet2 9855 Manuel utilisateur

Avery Dennison

Avery Dennison 9417 Manuel utilisateur

Avery Dennison

Avery Dennison SNAP 700 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch Pathfinder Ultra Silver Manuel utilisateur

Avery Dennison

Avery Dennison Wireless Ethernet Print Server Monarch 7411 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch 9825 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch TC6039SA Manuel de service

Avery Dennison

Avery Dennison AP4.4 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch ADTP1 Manuel de service

Avery Dennison

Avery Dennison Monarch 9855 Manuel de service

Avery Dennison

Avery Dennison SNAP 500 Manuel utilisateur

Avery Dennison

Avery Dennison AP7.t Manuel utilisateur

Avery Dennison

Avery Dennison FRESHMARX 9415 Manuel de service

Avery Dennison

Avery Dennison Monarch 9864 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
