Avery Dennison FRESHMARX 9415 Manuel de service
FRESHMARX™
9415™
Labeling
System
TC9415SA Rev. AE 5/09 ©2007 Avery Dennison Corp. All rights reserved.
Each product and program carries a respective written warranty, the
only warranty on which the customer can rely. Avery Dennison
reserves the right to make changes in the product, the programs,
and their availability at any time and without notice. Although Avery
Dennison has made every effort to provide complete and accurate
information in this manual, Avery Dennison shall not be liable for
any omissions or inaccuracies. Any update will be incorporated in a
later edition of this manual.
©2007 Avery Dennison Corporation. All rights reserved. No part of
this publication may be reproduced, transmitted, stored in a retrieval
system, or translated into any language in any form by any means,
without the prior written permission of Avery Dennison.
WARNING
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
CANADIAN D.O.C. WARNING
This digital apparatus does not exceed the Class A limits for
radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of
Communications. Le présent appareil numérique n’émet pas de
bruits radioélectriques dépassant les limites applicables aux
appareils numériques de la classe A prescrites dans le
Réglement sur le brouillage radioélectrique édicte par le
ministère des Communications du Canada.
Trademarks
FreshMarx and 9415 are trademarks of Avery Dennison Retail
Information Services, LLC.
Avery Dennison® is a trademark of Avery Dennison Corp.
Avery Dennison Printer Systems Division
170 Monarch Lane
Miamisburg, OH 45342
i
TABLE OF CONTENTS
INTRODUCTION ...............................................................1-1
Using This Manual.......................................................1-1
Audience ....................................................................1-1
About the Printer .........................................................1-2
CHANGING PRINTER SETTINGS .......................................2-1
Configuring the Printer.................................................2-2
Assigning a Format (Dual Printer Only)..........................2-3
Assigning a format to a category................................2-4
Assigning a format to a printer...................................2-6
Resetting the formats and printers..............................2-7
Selecting a Format (Single Printer Only) ........................2-8
Setting the Time and Date .......................................... 2-10
Adjusting the Touch Screen ........................................ 2-12
Changing the Password.............................................. 2-13
Adjusting the Distance to Tear Bar .............................. 2-14
Adjusting the Print Position......................................... 2-15
ii
USING THE EDIT UTILITY..................................................3-1
Installing the Edit Utility................................................3-2
Creating and Editing the Data File .................................3-3
Editing home keys.....................................................3-3
Creating and editing product buttons...........................3-4
Updating with USB .......................................................3-6
Killing Data Files..........................................................3-8
Configuring the Network Settings.................................3-10
On the printer:........................................................3-10
On your computer: ..................................................3-12
Uploading the Data File ..............................................3-13
Updating with Ethernet ...............................................3-14
Updating the data file..............................................3-14
Updating the application..........................................3-15
LABEL FORMATS ............................................................A-1
Format 1 .................................................................... A-1
Format 2 .................................................................... A-2
Format 3 .................................................................... A-3
Format 4 .................................................................... A-4
Format 5 .................................................................... A-5
Format 6 .................................................................... A-6
Introduction 1-1
INTRODUCTION
The FreshMarx™ 9415™ Labeling System prints
labels for product freshness and inventory.
Information in this document supercedes information
in previous versions. Check our Web site for the
latest documentation and release information.
Using This Manual
Following is a summary of the contents of this manual:
Chapter Contents
1 Introduction Information you should know
before using the printer.
2 Changing Printer
Settings Assigning formats and setting
time and date, backlighting,
password, print position, etc.
3 Using the Edit
Utility Installing and using the Edit
Utility to create and edit product
menus, and updating the printer.
A Label Formats Format sizes and content fields.
Note: You may have a custom application that
differs slightly from the examples in this
manual. The screens shown are for reference
only.
Audience
This manual is for the System Administrator who
configures and updates the printer. For information
on printing labels and printer care and maintenance,
refer to the Operator’s Handbook included with your
printer.
1
1-2 System Administrator’s Guide
About the Printer
There are five control buttons located on the right side
of the touch screen.
Button Action
Stops/cancels the current print job.
Advances supply for the selected printer.
or
Selects which printer feeds the supply.
Printer 1 is located on the left side.
Printer 2 is located on the right side.
Note: For the 9415™SP, these buttons
do not function.
Enters the printer configuration menu.
The rest of the touch screen contains product buttons
that are color-coded so you can easily print the item
labels.
The product buttons are blank until you create a
product menu. The home keys have default captions
that can be changed. See Chapter 3, “Using the Edit
Utility,” for information on creating and editing product
menus.
♦ Yellow
♦ Red
♦ Green
♦ Blue
♦ Orange
Printer 1
Printer 2
(Dual printer only)
Changing Printer Settings 2-1
CHANGING PRINTER
SETTINGS
This chapter tells you how to
♦ configure the printer.
♦ assign formats (dual printer only).
♦ select formats (single printer only).
♦ set the time and date.
♦ adjust the touch screen display.
♦ change the Manager Password.
♦ adjust the distance to the tear bar.
♦ adjust the horizontal print position.
♦ adjust the vertical print position.
2
2-2 System Administrator’s Guide
Configuring the Printer
Use the Configure screen to set the date and time,
assign formats, adjust the touch screen settings, and
update the printer. Instructions for configuring the
printer are located under Manager Help.
To access the Manager Help:
1. Press .
2. Enter the Manager Password and press Enter.
The default password is 1234. The Configure
screen appears.
Note: This screen appears differently on the single
printer version.
Changing Printer Settings 2-3
3. Press Manager Help.
Scroll through the text to the instructions you need.
Assigning a Format (Dual Printer Only)
These instructions apply to the dual printer version
only. See “Selecting a Format” for single printer
instructions.
Assign one of six preset label formats to each menu
category, then assign those formats to a printer to
print freshness labels. See Appendix A, “Label
Formats,” for the size and content of each format.
When you assign a format to a menu category, any
labels you print in that category use the selected
format. When you assign a format to Printer 1 or
Printer 2, that format always prints on the assigned
printer. The default assignments are Format 1, Printer
1 for all categories.
Note: If you select a format larger than the loaded
labels, some information may not print.
2-4 System Administrator’s Guide
Assigning a format to a category
To assign a format to a menu category:
1. Press .
2. Enter the Manager Password and press Enter.
The default password is 1234. The Configure
screen appears.
3. Press Assign Format.
4. Press Assign Format To Category.
The currently selected format number appears
across the top of the screen.
