Avery Dennison MonarchNet2 9855 Manuel utilisateur

N9855

9860™

Monarch

Printers

Each product and program carries a respective written warranty, the only

warranty on which the customer can rely. Paxar reserves the right to make

changes in the product, the programs, and their availability at any time and

without notice. Although Paxar has made every effort to provide complete and

accurate information in this manual, Paxar shall not be liable for any omissions

or inaccuracies. Any update will be incorporated in a later edition of this

manual.

reserved. No part of this publication may be reproduced, transmitted, stored in

a retrieval system, or translated into any language in any form by any means,

without the prior written permission of Paxar Americas, Inc.

Trademarks

Monarch®, Monarch Net2, Smart Relay, 7411, 939, 9855®, and 9860 are

trademarks of Paxar Americas, Inc.

Avery Dennison® is a trademark of Avery Dennison Corp.

Microsoft, Windows, and NT are trademarks of Microsoft Corporation in the

United States and/or other countries.

Firefox is a trademark of Mozilla Corporation.

UNIX®is a trademark of The Open Group.

Novell and NetWare are trademarks of Novell, Inc. in the United States and

other countries.

HP Jet Admin and HP Web Jet Admin are trademarks of Hewlett-Packard, Inc.

The Bluetooth trademarks are owned by Bluetooth SIG, Inc.

Netscape and Netscape Navigator are trademarks of Netscape Communications

Corporation in the United States and other countries. Netscape's logos and

Netscape product and service names are also trademarks of Netscape

Communications Corporation, which may be registered in other countries.

Excerpts reprinted from Wireless LANs Implementing High Performance IEEE

802.11 Networks, Second Edition with permission.

Excerpts reprinted from the TROY200 Installation and User’s Guide with

permission from Silex Technology America, Inc.

Avery Dennison Printer Systems Division

170 Monarch Lane

Miamisburg, OH 45342

TABLE OF CONTENTS

GETTING STARTED......................................................................................1-1

Overview................................................................................................1-1

Audience................................................................................................1-1

Using This Manual...................................................................................1-2

System Requirements..............................................................................1-2

Supported Operating Systems...................................................................1-3

Supported Network Protocols....................................................................1-3

Setting Up the Print Server.......................................................................1-4

Checking the Print Server Hardware..........................................................1-5

Verifying Successful Installation ...............................................................1-5

Verifying Successful Installation ...............................................................1-6

About “Print Mode Ready” ........................................................................1-8

Printing a Configuration Label...................................................................1-9

CONFIGURING THE 802.11B/G AND IP SETTINGS .........................................2-1

Saving Settings.......................................................................................2-2

MAC Address..........................................................................................2-2

IP Address..............................................................................................2-3

Subnet Mask...........................................................................................2-4

IP Gateway.............................................................................................2-5

Boot Method ...........................................................................................2-6

Wireless.................................................................................................2-7

Signal Strength ...................................................................................2-8

SSID ..................................................................................................2-9

Wireless Mode................................................................................... 2-10

A-Point Density ................................................................................. 2-11

Transmit Rate ................................................................................... 2-12

Channel............................................................................................ 2-13

Default Network.................................................................................... 2-14

Factory Defaults................................................................................ 2-15

Test Label............................................................................................ 2-16

NCL Settings........................................................................................ 2-17

USING A WEB BROWSER ............................................................................3-1

Logging In..............................................................................................3-2

Configuring the Printer ............................................................................3-4

Changing the Printer Setup...................................................................3-5

Changing the System Setup..................................................................3-7

Reset/Initialize Network...........................................................................3-8

Configuring the Network Settings..............................................................3-8

Configuring the Network Settings..............................................................3-9

Changing TCP/IP Settings.................................................................. 3-10

Changing SNMP Settings.................................................................... 3-12

Changing Wireless Settings................................................................ 3-14

Setting Alerts.................................................................................... 3-18

Receiving An Alert............................................................................. 3-19

iii

Reading the Virtual Panel.......................................................................3-20

Using Custom Commands.......................................................................3-21

Changing the Password..........................................................................3-22

Updating Firmware ................................................................................3-24

Basic Security Configurations.................................................................3-25

CONSOLE COMMANDS ................................................................................4-1

Conventions............................................................................................4-2

Accessing Telnet Console Mode................................................................4-2

Help Commands......................................................................................4-4

General Commands .................................................................................4-6

Setup Commands ..................................................................................4-11

RFID Commands ...................................................................................4-16

802.11b/g Wireless Commands...............................................................4-16

TCP/IP Commands ................................................................................4-20

SNMP Commands..................................................................................4-23

Using the Network Packet ......................................................................4-24

USING THE SMART RELAY SYSTEM.............................................................5-1

Initial Smart Relay Setup Procedures ........................................................5-2

About the Primary Printer.........................................................................5-2

About the Partner Printer .........................................................................5-3

Connecting the Printers............................................................................5-4

Configuring the Partner Printer.................................................................5-5

Using the Smart Relay Telnet Commands ..................................................5-5

About the Smart Relay Counter.................................................................5-7

TROUBLESHOOTING...................................................................................6-1

Printing a Test Label...............................................................................6-1

General Troubleshooting Information ........................................................6-4

Troubleshooting Wireless Configuration Problems......................................6-7

Technical Support...................................................................................6-7

SPECIFICATIONS........................................................................................A-1

802.3 Specifications................................................................................A-1

Optional 802.11b/g Specifications.............................................................A-1

Options..................................................................................................A-2

GLOSSARY................................................................................................ G-1

INDEX.............................................................................................................i

Getting Started 1-1

GETTING STARTED

Your Monarch®9855®or 9860™Version 5.0 or greater printer

contains MonarchNet2™software, which allows you to access, configure,

and control your printers with the Monarch®7411™Ethernet Print Server

remotely across a LAN (local area network), WLAN (wireless local area

network), or WWW (world-wide web) connection.

Information in this document supercedes information in previous

versions. Check our Web site (www.monarch.com) for the latest release

and documentation information.

Overview

The Monarch®7411™Print Server lets you communicate with Monarch®

printers on an 802.11b and 802.11g wireless network or wired Ethernet

802.3 network. 802.11b/g refers to 802.11b and 802.11g in this manual.

You can use the print server in Ad-Hoc (peer-to-peer) or infrastructure

(access point) wireless mode. The print server operates at speeds of up

to 54 Mbps on any IEEE 802.11b/g wireless compatible network.

The wireless print server includes a dual-mode built-in wired Ethernet

(802.3) connection so the print server automatically switches between

wireless and wired Ethernet mode within the same subnet address. When

switching between wired and wireless mode on different subnets, turn off

the printer and then turn it back on to reinitialize the print server.

Refer to your network manuals for more information. This manual does

not include information about setting up your wireless or wired network.

We recommend reviewing the terms in the glossary before you

begin.

Audience

This manual is written for the System Administrator who sets up printers

on the network and is familiar with basic networking principles.

1-2 MonarchNet2 Operating Instructions

Using This Manual

Following is a summary of the contents of this manual:

Chapter Contents

1 Getting Started Information you should know before using the

printer.

2 Configuring the

802.11b/g and

IP Settings

Setting communications between your network and

printer.

3 Using a Web Browser Using your Web browser to configure and monitor

your network printer.

4 Console Commands Lists the supported console commands for your

network printer.

5 Using the Smart Relay

System

Explains how to configure a primary and partner

printer.

6 Troubleshooting Common problems and their solutions.

A Specifications Printer and radio specifications.

G Glossary Networking and printer terms and their definitions.

System Requirements

To use the print server for printing from a wireless network, you need an

802.11b/g wireless network. The wireless network consists of either of

the following:

♦ An 802.11b/g wireless enabled computer printing straight to the

printer

(Ad-Hoc mode).

♦ An 802.11b/g wireless access point allowing wireless and wired

Ethernet enabled computers to print to the print server (infrastructure

mode).

To configure and print, you need the following:

1. The MAC address from the label of the print server (for example:

004017023F96).

2. Obtain the following information from your wireless network

administrator:

Getting Started 1-3

♦ Wireless mode (infrastructure or Ad-Hoc).

♦ The SSID (service set identifier) for your wireless network.

♦ If you are using TCP/IP (recommended for Windows Networks) and

are not connected to a DHCP server (for obtaining an IP address

automatically), you need a unique IP address for the wireless print

server (for example: 192.0.0.192) and a subnet mask. If the print

server is not on the same IP subnet as the computers you are printing

from, you need a router. A print server with an IP address of

192.0.0.192 will not be seen by a network looking for devices with a

prefix of 10.1.xxx.xxx. A router (default gateway) address is optional.

♦ Wireless security settings.

Supported Operating Systems

The print server supports multiple network protocols for users with

Microsoft®Windows®, Novell®NetWare®, NDS, and UNIX®.

Supported Network Protocols

♦ TCP/IP:

LPD/LPR

BOOTP

DHCP

HP JetDirect™

Raw TCP/IP (port 9100 or any chosen port)

NetWare (NEST)

NetBIOS over IP (with SMB)

NetBEUI

DLC

♦ Telnet

♦ RSH or REMSH (remote shell)

♦ WINS

♦ DHCP

♦ FTP

♦ SNMP

All protocols are simultaneously active.

1-4 MonarchNet2 Operating Instructions

Setting Up the Print Server

For MonarchNet2 to operate, make sure the print server is set to use the

printer’s internal parallel port and use bi-directional communications.

If this is not already set for you:

1. From the printer’s Main Menu, select Setup, Port Settings, Parallel

Comm., Port, and press or until you see Internal.

Press Enter/Pause to save the setting.

2. Then, press to display Mode. Press Enter/Pause. Press or 

until you see IEEE1284. Press Enter/Pause to save the setting.

3. Press Escape/Clear until you see the Main Menu.

Note: MonarchNet2 uses the printer’s internal parallel port.

You can switch between MonarchNet2 and using the parallel port, but

you must set the Port to External and the Mode to Compatible. Then,

turn off the printer and turn it back on to detect the cable. MonarchNet2

is not available until you disconnect the parallel cable and change the

Port to Internal and Mode to IEEE1284.

The serial and USB port are still active. However, allow a two-second

delay when switching from one port (serial, Ethernet, or USB) to another.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Avery Dennison Imprimante

Avery Dennison

Avery Dennison MONARCH 9416 XL Document technique

Avery Dennison

Avery Dennison ALS 204 Manuel utilisateur

Avery Dennison

Avery Dennison Pathfinder 6057 Manuel de service

Avery Dennison

Avery Dennison FreshMarx 9417 Manuel utilisateur

Avery Dennison

Avery Dennison Pathfinder 6059 Document technique

Avery Dennison

Avery Dennison Pathfinder 6140 Document technique

Avery Dennison

Avery Dennison FreshMarx 9417 Manuel de service

Avery Dennison

Avery Dennison Monarch Pathfinder Ultra Platinum 9462 Manuel utilisateur

Avery Dennison

Avery Dennison Pathfinder6057 Manuel d'utilisation et d'entretien

Avery Dennison

Avery Dennison Monarch 9419 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch 9855 Manuel de service

Avery Dennison

Avery Dennison Monarch 9485 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch ADTP1 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch 9493 SNP Manuel de service

Avery Dennison

Avery Dennison Monarch 938 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch SIERRA SPORT4 9493 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch Pathfinder Ultra Silver 6032 Manuel de service

Avery Dennison

Avery Dennison Monarch ADTP2 EcoCut Manuel de service

Avery Dennison

Avery Dennison Monarch 9906 Manuel utilisateur

Avery Dennison

Avery Dennison Monarch 9433 Sierra Sport3 Manuel de service

Avery Dennison

Avery Dennison Monarch 9493 SNP Manuel d'utilisation et d'entretien

Avery Dennison

Avery Dennison 9444 Manuel utilisateur

Avery Dennison

Avery Dennison 9417 Manuel utilisateur

Avery Dennison

Avery Dennison AP7.t Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
