Quick Start for Hardware
Installation:
Avaya G450 Media Gateway
03-602053
Issue 2
December 2008
© 2008 Avaya Inc.
All Rights Reserved.
Notice
While reasonable efforts were made to ensure that the information in this
document was complete and accurate at the time of printing, Avaya Inc. can
assume no liability for any errors. Changes and corrections to the information
in this document may be incorporated in future releases.
For full support information, please see the complete document,
Avaya Support Notices for Hardware Documentation, document number
03-600759.
To locate this document on our Web site, simply go to
http://www.avaya.com/support and search for the document number in
the search box.
Documentation disclaimer
Avaya Inc. is not responsible for any modifications, additions, or deletions to
the original published version of this documentation unless such modifications,
additions, or deletions were performed by Avaya. Customer and/or End User
agree to indemnify and hold harmless Avaya, Avaya's agents, servants and
employees against all claims, lawsuits, demands and judgments arising out of,
or in connection with, subsequent modifications, additions or deletions to this
documentation to the extent made by the Customer or End User.
Link disclaimer
Avaya Inc. is not responsible for the contents or reliability of any linked Web
sites referenced elsewhere within this documentation, and Avaya does not
necessarily endorse the products, services, or information described or offered
within them. We cannot guarantee that these links will work all of the time and
we have no control over the availability of the linked pages.
Warranty
Avaya Inc. provides a limited warranty on this product. Refer to your sales
agreement to establish the terms of the limited warranty. In addition, Avaya’s
standard warranty language, as well as information regarding support for this
product, while under warranty, is available through the following Web site:
http://www.avaya.com/support.
Copyright
Except where expressly stated otherwise, the Product is protected by copyright
and other laws respecting proprietary rights. Unauthorized reproduction,
transfer, and or use can be a criminal, as well as a civil, offense under the
applicable law.
Avaya support
Avaya provides a telephone number for you to use to report problems or to ask
questions about your product. The support telephone number
is 1-800-242-2121 in the United States. For additional support telephone
numbers, see the Avaya Web site: http://www.avaya.com/support.
Issue 2 December 2008 3
Chapter 1: Before you Start
Before you install your Avaya G450 Media Gateway, prepare all the information, resources, and tools that
you need during the installation process.
Preparing the Pre-Installation Worksheet
The Electronic Pre-installation Worksheet (EPW) is a customized Excel spreadsheet that you can use to
collect configuration information. The EPW verifies that you have a complete set of installation information.
Once filled out by the customer and project manager, the EPW can be loaded directly into the Avaya
Installation Wizard (IW) or Gateway Installation Wizard (GIW) for configuration. The EPW should be
completed before the installation. Download the latest version of the EPW spreadsheet from the Avaya Web
site at http://support.avaya.com/avayaiw.
Preparing Contacts you might need
Ensure that you have the names and phone numbers of any people you might need to contact at the
installation site. This list might include the people responsible for network architecture, system
administration, site security, site deliveries, etc.
Preparing Installation Files
Ensure that you load the latest versions of all firmware files for the G450, S8300, and Media Modules onto
your laptop before configuration. If you install a G450 without an S8300 Server, the configuration process
prompts you for the filenames of all firmware files needed. You can download the firmware files needed for
your installation from the Avaya Support Web site, at http://support.avaya.com.
Preparing the G450 Serial Number
In order to create the license file, you need the serial number of the G450. The serial number is printed on a
sticker on the back of the G450 chassis.
Obtaining RFA access
You need to obtain a personal Single Sign-On (SSO) for Remote Feature Activation (RFA) web site
authentication login before going to the site for installation. You must complete the authentication process
before you can be assigned an SSO authentication login.
Before you Start
4 Quick Start for Hardware Installation: Avaya G450 Media Gateway
As a first-time user:
●Business Partners should point their browsers to the Business Partner portal option sales_market,
services-voice, training tools and procedures to select RFA.
●Associates should point their browsers to the Avaya Associate portal.
●Contractors should point their browsers to Avaya.com.
●Alternatively go directly to http://rfa.avaya.com.
From that point, log into SSO and complete the process to obtain your personal login.
Downloading a G450 license file to your laptop
If you are installing VPN, obtain a VPN license file from the Remote Feature Activation (RFA).
1. Create a directory on your laptop for storing license files (for example, C:\licenses).
2. Access the Internet from your laptop and go to rfa.avaya.com.
3. Login using your SSO login and password. The AFS and RFA information home page appears.
4. Start the RFA application from the RFA information page. To create and download the license file,
follow the instructions outlined in the Avaya Remote Feature Activation (RFA) User Guide, 03-300149.
Downloading CM license and authentication files to your laptop
If you are installing a G450 with an S8300 Server as a primary controller, you need license and
authentication files for the Communication Manager.
1. Create a directory on your laptop for storing license and authentication files.
2. Access the Internet from your laptop and go to rfa.avaya.com.
3. Login using your SSO login and password. The AFS and RFA information home page appears.
4. Start the RFA application from the RFA information page. To create and download the license file and
authentication file, follow the instructions outlined in the Avaya Remote Feature Activation (RFA) User
Guide, 03-300149.
5. Use the download or e-mail capabilities of the RFA web site to download the license and
authentication files to your laptop.
Preparing the INADS IP address
The INADS IP address is required in order to configure the S8300’s modem for alarming. If you are
preparing a G450 with an S8300 for a remote installation, you must first obtain an INADS IP address. Use
the Automatic Registration Tool (ART) to obtain an IP address for an INADS alarming modem.
1. Access the ART Web site on your laptop at http://art.dr.avaya.com.
Preparing Needed Hardware
Issue 2 December 2008 5
2. Select Administer S8x00 Server products for installation script, and then log in.
3. Enter the customer information, select Installation Script, and click Start Installation script & IP
Addr Admin. A script file is created and downloaded or e-mailed to you.
Preparing Needed Hardware
●Laptop – to configure the Avaya G450 Media Gateway, you need to prepare a laptop with a serial port.
The laptop must have Internet Explorer installed. If you install a G450 without an S8300, you must
prepare the laptop with a Windows 2000 or Windows XP operating system and a TFTP server.
●Modem – in order to set up a remote configuration of the G450, you must prepare a USB modem.
Currently, the G450 supports the MultiTech USB modem, model MT5634ZBA-USB-V92. If a USB
modem is not available, you can also use a serial modem, the Multitech MultiModem ZBA,
MT5634ZBA-V92.
Preparing Tools Needed for Mounting
To mount on a rack or wall, prepare a Phillips head screwdriver.
To mount on a wall prepare also:
●Plywood board ½ in (1.2 cm) thick and at least 2 x 2 ft (0.6 x 0.6 m) in size
●Minimum of four wood screws
●Minimum of four screws (pan head at least ½ in, # 10-12 screw) to fasten the G450 to the wall
You might also need wire cutters to attach the grounding conductors, if your site uses a ground block.
Choosing the Installation Site
Ensure that the location where you install your G450 fulfills the following requirements:
●Cables are away from sources of electrical noise such as radio transmitters, broadcast amplifiers,
power lines, fluorescent light fixtures
●Water or moisture cannot enter the case of the chassis.
●Air can flow freely around all sides of the chassis.
●The vents on the sides of the case are not blocked.
●The installation is no more than 25 feet (7.6 m) from an approved ground.
Note:
Note: If the G450 is more than 25 feet away from an approved ground, you must contact a licensed
electrician to install a supplementary ground conductor.
●The environmental conditions match the following requirements:
●Ambient temperature – 32oto 104oF (0oto 40oC)
Before you Start
6 Quick Start for Hardware Installation: Avaya G450 Media Gateway
●Relative humidity – 10-90% relative humidity
●Minimum clearance for ventilation – 18 in. (45 cm)
●Weight support – 22.5-35 lbs (10-16 kg)
Issue 2 December 2008 7
Chapter 2: Unpack the Device
!CAUTION:
CAUTION: Wear an anti-static wrist ground strap whenever you handle components of a G450 Media
Gateway. Connect the strap to an approved ground, such as an unpainted metal surface.
Equipment
Open the box that contains the Avaya G450 Media Gateway, and ensure that it contains the following
components and accessories:
●One Avaya G450 Media Gateway chassis. The required media modules may be installed.
●An Accessory Kit (see Table 1)
Removing the Power Supply Units
For ease of installation, it is recommended to remove the power supply unit(s) before unpacking the G450.
1. Open the package. Note that the G450 is lying flat. Turn it so that the rear panel is facing up.
2. Remove the power supply unit (PSU). If you ordered two power supplies, remove them both.
a. Loosen the two PSU captive screws, one on each side of the PSU.
b. Grasp the two side handles and pull the PSU up and out.
c. Place the PSU carefully on the table.
Other Components
The Avaya Partner Contact Closure adjunct box, if ordered, is packaged separately.
Unpack the Device
8 Quick Start for Hardware Installation: Avaya G450 Media Gateway
Table 1: G450 Accessory Kit
One 115V 3 Wire Power Cable
Note: Outside the US, the cord
must be VDE Certified or
Harmonized (HAR), rated 250V,
3-conductor (3rd wire ground),
1.0 mm2 minimum conductor
size
One Grounding Cable Assembly Four Rubber Standoffs
Two 19 in. Rack mount
brackets One Cable Management
Assembly Fifteen 3/8 in. Flat Head Screws
Two 5/16 in. Round Head Screw Two Serrated Lock Washers One Ground
Screw One Jumper for
Bridging
NVRAM init
Pins
Issue 2 December 2008 9
Chapter 3: Mount the Device
You can position the Avaya G450 Media Gateway on a suitable table, or mount it in a rack or on the wall.
Once the G450 is mounted, re-insert the Power Supply Units.
Positioning on a Table
To install the Avaya G450 Media Gateway as a tabletop unit:
1. Remove the four rubber standoffs from their package.
2. Turn the G450 upside down.
3. Position each standoff into one of the mounting sites, near each corner of the chassis.
Mounting in a Rack
You can fasten the G450 to a standard 19-inch rack either at the front of the G450 or at its middle. Before
you mount the G450, attach the mounting brackets to the device.
Front Mounting Bracket Placement
Attach a regular mounting bracket to one side of the G450, near the front, as shown in Figure 1: Front
mounting bracket placement on page 10. Attach a mounting bracket with cable guides to the other side of
the G450 (refer to Figure 3: Attaching a mounting bracket with cable guides on page 10).
Middle Mounting Bracket Placement
Attach regular mounting brackets to the sides of the G450, as shown in Figure 2: Middle mounting bracket
placement on page 10. Attach a mounting bracket with cable guides on one side of the G450, as shown in
Figure 3: Attaching a mounting bracket with cable guides on page 10.
Mount the Device
10 Quick Start for Hardware Installation: Avaya G450 Media Gateway
Figure 1: Front mounting bracket placement
Figure 2: Middle mounting bracket placement
Figure 3: Attaching a mounting bracket with cable guides
Attaching Mounting Brackets
Follow these steps to attach the mounting brackets:
1. Position a bracket over the desired mounting position.
2. Affix the bracket to the chassis with five flat head 3/8 in. screws.
3. Tighten the screws with the screwdriver.
Autres manuels pour G450 Manager
14
Table des matières
Autres manuels Avaya Porte
Avaya
Avaya G450 Manager Mode d’emploi
Avaya
Avaya G860 Manuel
Avaya
Avaya Advanced Gateway 2330 Manuel utilisateur
Avaya
Avaya G700 Manuel utilisateur
Avaya
Avaya G430 Manuel utilisateur
Avaya
Avaya IG550 Mode d’emploi
Avaya
Avaya G700 Mode d’emploi
Avaya
Avaya W310 Manuel utilisateur
Avaya
Avaya Media Gateway G250 Guide d'installation
Avaya
Avaya IG550 Manuel utilisateur
Avaya
Avaya Media Gateway G350 Manuel utilisateur
Avaya
Avaya Media Gateway G350 Manuel utilisateur
Avaya
Avaya Media Gateway G350 Manuel utilisateur
Avaya
Avaya Residential Gateway-I Manuel utilisateur
Avaya
Avaya Media Gateway G350 Mode d’emploi
Avaya
Avaya W310 Manuel utilisateur
Avaya
Avaya CMC1 Guide de démarrage rapide
Avaya
Avaya G860 Manuel utilisateur
Avaya
Avaya G430 Manuel utilisateur
Avaya
Avaya G700 Guide d'installation
Manuels Porte populaires d'autres marques
LST
LST M500RFE-AS Manuel utilisateur
Kinnex
Kinnex Media Gateway Manuel utilisateur
2N Telekomunikace
2N Telekomunikace 2N StarGate Manuel utilisateur
Mitsubishi Heavy Industries
Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur
ZyXEL Communications
ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur
Telsey
Telsey CPVA 500 - SIP Manuel utilisateur
