Quick Start for Hardware

Installation:

Avaya G250 Media Gateway

03-300433

Issue 5

November 2009

Notice

While reasonable efforts were made to ensure that the information in this

document was complete and accurate at the time of printing, Avaya Inc. can

assume no liability for any errors. Changes and corrections to the information

in this document may be incorporated in future releases.

For full legal page information, please see the complete document,

Avaya Legal Page for Hardware Documentation, document number

03-600759.

To locate this document on our Web site, simply go to

http://www.avaya.com/support and search for the document number in

the search box.

Documentation disclaimer

Avaya Inc. is not responsible for any modifications, additions, or deletions to

the original published version of this documentation unless such modifications,

additions, or deletions were performed by Avaya. Customer and/or End User

agree to indemnify and hold harmless Avaya, Avaya's agents, servants and

employees against all claims, lawsuits, demands and judgments arising out of,

or in connection with, subsequent modifications, additions or deletions to this

documentation to the extent made by the Customer or End User.

Link disclaimer

Avaya Inc. is not responsible for the contents or reliability of any linked Web

sites referenced elsewhere within this documentation, and Avaya does not

necessarily endorse the products, services, or information described or offered

within them. We cannot guarantee that these links will work all of the time and

we have no control over the availability of the linked pages.

Warranty

Avaya Inc. provides a limited warranty on this product. Refer to your sales

agreement to establish the terms of the limited warranty. In addition, Avaya’s

standard warranty language, as well as information regarding support for this

product, while under warranty, is available through the following Web site:

http://www.avaya.com/support.

Except where expressly stated otherwise, the Product is protected by copyright

and other laws respecting proprietary rights. Unauthorized reproduction,

transfer, and or use can be a criminal, as well as a civil, offense under the

applicable law.

Avaya support

Avaya provides a telephone number for you to use to report problems or to ask

questions about your product. The support telephone number

is 1-800-242-2121 in the United States. For additional support telephone

numbers, see the Avaya Web site: http://www.avaya.com/support.

Issue 5 November 2009 3

Chapter 1: Before you Start. . . . . . . . . . . . . . . . . . . . . . . . . 5

Gathering Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Defining the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Using the Pre-Installation Worksheet . . . . . . . . . . . . . . . . . . . . . . 5

Preparing Contacts you might need . . . . . . . . . . . . . . . . . . . . . . . 6

Preparing Installation Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Preparing Communication Manager License and Authentication Files . . . . . . 6

Preparing the G250 Serial Number . . . . . . . . . . . . . . . . . . . . . . . . 6

Preparing the Gateway Authentication File . . . . . . . . . . . . . . . . . . . . . 7

Preparing the INADS IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Preparing Needed Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Laptop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Preparing Needed Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Choosing the Installation Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 2: Unpack the Device . . . . . . . . . . . . . . . . . . . . . . . 11

Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Other Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Chapter 3: Mount the Device . . . . . . . . . . . . . . . . . . . . . . . . 15

Positioning on a Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Mounting in a Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Front mounting bracket placement. . . . . . . . . . . . . . . . . . . . . . . . 16

Middle Mounting Bracket Placement . . . . . . . . . . . . . . . . . . . . . . . 16

Mounting bracket with cable guide. . . . . . . . . . . . . . . . . . . . . . . . 16

Attaching Mounting Brackets. . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Mounting the G250. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Mounting on the Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Chapter 4: Install Media Modules. . . . . . . . . . . . . . . . . . . . . . 19

Installing an S8300 Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Identifying the S8300 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Installing other Media Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Supported Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Inserting Media Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Contents

4 Quick Start for Hardware Installation Avaya G250 Media Gateway

Chapter 5: Power Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Grounding Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Connecting Ground Conductors . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using a Ground Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connecting Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

LED Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Chapter 6: Prepare for Configuration . . . . . . . . . . . . . . . . . . . 27

Preparing a G250 with an S8300 server . . . . . . . . . . . . . . . . . . . . . . . 27

Configuring the G250 and S8300 using the Avaya IW. . . . . . . . . . . . . . 28

Preparing a G250 without an S8300 server . . . . . . . . . . . . . . . . . . . . . 30

Configuring the G250 using the GIW . . . . . . . . . . . . . . . . . . . . . . . 30

Preparing for a remote configuration of the G250. . . . . . . . . . . . . . . . 31

Preparing for a remote configuration of the G250 through the network. . 31

Preparing for a remote configuration of the G250 via a modem . . . . . . 32

Next steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using Avaya IW and GIW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using the Command Line Interface. . . . . . . . . . . . . . . . . . . . . . . . 33

Issue 5 November 2009 5

Chapter 1: Before you Start

Before you install your Avaya G250 Media Gateway, prepare all the information, resources, and

tools that you need during the installation process. Good preparation ensures a smooth

installation with the least amount of interruption.

Note:

Note: The G250, G250-DS1, G250-DCP and G250-BRI will be referred to as the G250

in this Guide and graphics will show the G250 unless there are differences which

affect the documented information.

Gathering Information

Defining the Installation

The G250 can be installed in several different configurations. Before you start the installation,

find out what configuration is needed for your site:

●Are you installing an S8300 Server?

●What Media Modules are you installing?

●See Supported Modules on page 22 to review limitations that exist on Media Modules that

the G250 supports.

Using the Pre-Installation Worksheet

The Electronic Pre-installation Worksheet (EPW) is a customized Excel spreadsheet that you

can use to collect configuration information. The EPW verifies that you have a complete set of

installation information. Once filled out, the EPW can be loaded directly into the AIW or GIW for

configuration. Meet with the customer to complete the EPW before you start the installation

process.

You can download a blank EPW spreadsheet from the Avaya Web site at support.avaya.com/

avayaiw.

Before you Start

6 Quick Start for Hardware Installation Avaya G250 Media Gateway

Preparing Contacts you might need

Ensure that you have the names and phone numbers of any people you might need to contact

at the installation site. This list might include the people responsible for:

●Network architecture

●System administration

●Site security

●Site deliveries

Preparing Installation Files

Ensure that you load the latest versions of all firmware files for the G250 and S8300 onto your

laptop before configuration. If you install a G250 without an S8300 Media Server, the

configuration process prompts you for the file names of all firmware files needed. You can

download the firmware files needed for your installation from the Avaya Support Web site, at

http://support.avaya.com.

Preparing Communication Manager License and

Authentication Files

If you install a G250 with an S8300 Media Server, you need license and authentication files to

complete the configuration. Browse to http://rfa.avaya.com to download the needed files. For

detailed information about license and authentication files, see the Avaya Remote Feature

Activation (RFA) User Guide, 03-300149.

Preparing the G250 Serial Number

In order to create the license file, you need the serial number of the G250. The serial number is

printed on a sticker on the back of the G250 chassis.

Preparing the Gateway Authentication File

Issue 5 November 2009 7

Preparing the Gateway Authentication File

The Authentication File System (AFS) is pre-installed at the factory.

Preparing the INADS IP address

The INADS IP address is required in order to configure the S8300 modem for alarming. If you

are preparing a G250 with an S8300 for a remote install, you must first obtain an INADS IP

address. You use the Automatic Registration Tool (ART) to obtain an IP address for an INADS

alarming modem.

1. Access the ART Web site on your laptop at http://art.dr.avaya.com.

2. Select Administer S8x00 Server products for installation script, and then log in.

3. Enter the customer information, select Installation Script, and click Start Installation

script & IP Addr Admin. A script file is created and downloaded or emailed to you.

Before you Start

8 Quick Start for Hardware Installation Avaya G250 Media Gateway

Preparing Needed Hardware

Laptop

To configure the Avaya G250 Media Gateway, you need to prepare a laptop with a serial port.

The laptop must have Internet Explorer installed. If you install a G250 without an S8300, you

must prepare the laptop with the following software:

●Windows 2000 or Windows XP operating system

●A TFTP server

Modem

in order to set up a remote configuration of the G250, you must prepare a USB modem.

Currently, the G250 supports the following modems:

●MultiTech USB modem, model MT5634ZBA-USB-V92

●USRobotics USB modem, model 5637

Preparing Needed Tools

Prepare the tools you need to mount the G250, according to the following table:

You might also need wire cutters to attach the grounding conductors, if your site uses a ground

block.

Table 1: Mounting Tools

If you need to mount on... Prepare these tools

Rack or wall Phillips head screwdriver

Flat wall Screws to fasten G250 to the wall

Uneven wall A 48 in. x 48 in. (1.2 m x 1.2 m) plywood board

(US: 3/4 inch plywood), 0.75 in (20 mm) thick

Screws to fasten the G250 to the wall

Choosing the Installation Site

Issue 5 November 2009 9

Choosing the Installation Site

Ensure that the location where you install your G250 fulfills the following requirements:

●Cables are away from sources of electrical noise such as:

●radio transmitters

●broadcast amplifiers

●power lines

●fluorescent light fixtures

●Water or moisture cannot enter the case of the chassis.

●Air can flow freely around all sides of the chassis.

●The vents on the sides of the case are not blocked.

●The installation is no more than 16 feet (5 m) from an approved ground.

!CAUTION:

CAUTION: If the installation location is more than 16 feet (5 m) feet away from an approved

ground, do not install the Avaya G250 Media Gateway until a licensed electrician

is present to install a Supplementary Ground Conductor per Article 250 of the

National Electrical Code (NEC).

●The environmental conditions match the requirements listed in Table 2.

See Appendix A of Installing and Upgrading the Avaya G250 Media Gateway, 03-300434, for

additional information on environmental requirements.

Table 2: Environmental Requirements

Condition Acceptable values

Ambient temperature 32oto 104oF (0oto 40oC)

Relative humidity 5% to 95%, non-condensing

Minimum clearance for

ventilation 2.5 in. (6.4 cm)

Weight support 22 lb. (10 kg)

Before you Start

10 Quick Start for Hardware Installation Avaya G250 Media Gateway

Autres manuels pour Media Gateway G250

Table des matières

Autres manuels Avaya Porte

Avaya

Avaya G150 Instructions d'utilisation et d'entretien

Avaya

Avaya 1000 Series Mode d’emploi

Avaya

Avaya 700457013 Manuel utilisateur

Avaya

Avaya G430 Manuel utilisateur

Avaya

Avaya CMC1 Manuel utilisateur

Avaya

Avaya G450 Manager Manuel utilisateur

Avaya

Avaya G450 Manager Manuel utilisateur

Avaya

Avaya Media Gateway G350 Mode d’emploi

Avaya

Avaya RAD IPmux-14 TDMoIP Supplément

Avaya

Avaya G700 Guide de démarrage rapide

Avaya

Avaya CMC1 Manuel utilisateur

Avaya

Avaya G450 Manager Manuel utilisateur

Avaya

Avaya Remote Gateway 911 Series Manuel utilisateur

Avaya

Avaya G700 Guide de démarrage rapide

Avaya

Avaya VSU 10000 Manuel de service

Avaya

Avaya Media Gateway G350 Manuel utilisateur

Avaya

Avaya P330 Manuel utilisateur

Avaya

Avaya VPN Gateway Manuel utilisateur

Avaya

Avaya Media Gateway G350 Manuel utilisateur

Avaya

Avaya G450 Manager Manuel utilisateur

Avaya

Avaya MCC1 Guide de démarrage rapide

Avaya

Avaya Media Gateway G350 Mode d’emploi

Avaya

Avaya Advanced Gateway 2330 Manuel du propriétaire

Avaya

Avaya G650 Mode d’emploi

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
