Avalue Technology LPC-17 Manuel utilisateur

Part No. E2017LP17A1R

LPC-17 Series

Fanless 17” SXGA TFT

Multifunctional Touch Panel PC

Quick Reference Guide

2nd Ed –19 November 2013

LPC-17 Series

2 LPC-17 Series Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

Notice

This guide is designed for experienced users to setup the system within the shortest time.

For detailed information, please always refer to the electronic user's manual.

No part of this document may be reproduced, copied, translated, or transmitted in any form

or by any means, electronic or mechanical, for any purpose, without the prior written

permission of the original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their respective

owners.

Disclaimer

Avalue Technology Inc. reserves the right to make changes, without notice, to any product,

including circuits and/or software described or contained in this manual in order to improve

design and/or performance. Avalue Technology assumes no responsibility or liability for the

use of the described product(s), conveys no license or title under any patent, copyright, or

masks work rights to these products, and makes no representations or warranties that

Quick Reference Guide

LPC-17 Series Quick Reference Guide

these products are free from patent, copyright, or mask work right infringement, unless

otherwise specified. Applications that are described in this manual are for illustration

purposes only. Avalue Technology Inc. makes no representation or warranty that such

application will be suitable for the specified use without further testing or modification.

Life Support Policy

Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN

LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL

OF Avalue Technology Inc.

As used herein:

1. Life support devices or systems are devices or systems which, (a) are intended for

surgical implant into body, or (b) support or sustain life and whose failure to perform,

when properly used in accordance with instructions for use provided in the labeling, can

be reasonably expected to result in significant injury to the user.

2. A critical component is any component of a life support device or system whose

failure to perform can be reasonably expected to cause the failure of the life

support device or system, or to affect its safety or effectiveness.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

LPC-17 Series

4 LPC-17 Series Quick Reference Guide

Contents

1. Getting Started ........................................................................................................5

1.1 Safety Precautions....................................................................................................5

1.2 Packing List...............................................................................................................5

1.3 System Specifications...............................................................................................6

1.4 System Overview......................................................................................................8

1.4.1 Front View................................................................................................................................ 8

1.4.2 Rear View................................................................................................................................ 8

1.5 System Dimensions ................................................................................................10

1.5.1 LPC-1705 Front and Rear side.............................................................................................. 10

1.5.2 LPC-1707 Front and Rear side.............................................................................................. 11

1.5.3 LPC-17A4 Front and Rear side............................................................................................. 12

2. Hardware Configuration .......................................................................................13

2.1 LPC 17 Series connector mapping..........................................................................14

2.1.1 Serial Port 1 connector (COM1).............................................................................................. 14

2.2 Installing Hard Disk & Memory................................................................................15

Quick Reference Guide

LPC-17 Series Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

Risk of explosion if battery is replaced by an incorrect type.

Dispose of used batteries according to the instructions.

1.2 Packing List

1 x LPC 17" Series Panel PC

1 x DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—WiFi drivers and utilities

—Touch controller drivers and utilities

—Chipset drivers and utilities

1 x Power Adapter

4 x VESA mounting screws

LPC-17 Series

6 LPC-17 Series Quick Reference Guide

1.3 System Specifications

Panel

Model

LPC-1705

LPC-1707

LPC-17A4

LCD size

17”, 4:3

Display type

SXGA TFT

Resolution

1280 x 1024

Pixel Pitch

0.264mm (H) x 0.264mm (V)

Luminance

350cd/m2

Contrast ratio

800

Viewing angle

80 (U), 80 (D), 85 (L), 85 (R)

Response time

30 ms

Backlight

LED

Touch screen

5-wire Resistive

Light transmission

80%

Touch interface

USB

System

Board

EBM-PNV

EBM-CDV

EBM-A50M

CPU

Onboard Intel® Atom™

D525 Dual Core 1.8GHz

CPU

Onboard Intel® Atom™

D2550 1.86GHz CPU

Onboard AMD eOntario

T40E 1.0GHz CPU

System Chipset

Intel® ICH8-M

Intel® NM10 Chipset

AMD A50M Chipset

I/O Chip

Nuvoton W83627DHG-P

E/C IT8518E

Nuvoton W83627DHG-P

System Memory

Onboard 1GB SDRAM and

One 204-pin SODIMM

Supports Up to 3GB DDR3

800MHz SDRAM

One 204-pin SODIMM

Supports Up to 4GB DDR3

1066MHz SDRAM

Onboard 2GB 1066MHz

DDR3 and One 204-pin

SODIMM Supports Up to

4GB DDR3 1066MHz

SSD

One CF Socket by IDE

Secondary Slave Channel

Supports Type I/II Compact

Flash Card

One CF Socket by IDE

Secondary Slave Channel

Supports Type I/II Compact

Flash Card

One CF Socket by IDE

Secondary Slave Channel

Supports Type I/II Compact

Flash Card

Hard Driver Bay

One 2.5” SATA HDD

Watchdog Timer

Reset: 1sec. ~ 255min. and

1sec. or 1min./step

Reset: 1sec. ~ 255min. and

1sec. or 1min./step

Reset: 1sec. ~ 255min. and

1sec. or 1min./step

H/W Status Monitor

Monitoring System

Temperature, Voltage, and

Cooling Fan Status with

Auto Throttling Control

Monitoring System

Temperature, Voltage, and

Cooling Fan Status with

Auto Throttling Control

Monitoring System

Temperature, Voltage, and

Cooling Fan Status with Auto

Throttling Control

Expansion

2 x Mini PCIe Slot

1 x Mini PCIe Slot, Optional

Supports mSATA

2 x Mini PCIe Slot, Optional

Supports mSATA

Rear Panel I/O

Serial Port

1xRS-232/422/485 (default RS-232, RS-422/485 setting by jumper) Optional 2nd COM

Ethernet

1 x RJ-45 (Intel® 82574L

2 x RJ-45 (Dual Realtek

Quick Reference Guide

LPC-17 Series Quick Reference Guide

Gigabit Ethernet,

Optional Dual 82574L

Gigabit Ethernet)

Gigabit Ethernet,

Optional Dual 82574L

Gigabit Ethernet)

RTL8111E Gigabit Ethernet)

VGA

1 x DB-15

1 x HDMI

Audio

Line-out (Realtek ALC888

Supports 5.1-CH Audio)

Line-out (Realtek ALC892

Supports 5.1-CH Audio)

Line-out (Realtek ALC892

Supports 5.1-CH Audio)

USB

2 x USB 2.0 (Optional Extra 2 x USB)

Mouse & K/B

1 x PS/2 KB & MS

N/A

Speaker

2 x 1W Speaker

Environment & Mechanical

Color

Front Silver & Rear Panel Black

Mounting

Wall/ Stand/ VESA 75mm x 75mm and 100mm x 100mm

System Power

Requirement

+12 ~ +26V DC Power Input

Power Adapter

Input: 100 ~ 250VAC/ 47 ~ 63Hz

Output: 60W Adapter (12V @ 5A Adapter)

Operating

Temperature

0°C ~ 40°C (32°F ~ 104°F)

Storage

Temperature

-10°C ~ 60°C (14°F ~ 140°F)

Relative Humidity

5% ~ 90% Relative Humidity, Non-condensing

Dimensions (W x D x

382mm x 320mm x 58.8mm

Weight

5.2Kgs

LPC-17 Series

8 LPC-17 Series Quick Reference Guide

1.4 System Overview

1.4.1 Front View

1.4.2 Rear View

LPC-1705

LPC-1707/LPC-17A4

POWER

Quick Reference Guide

LPC-17 Series Quick Reference Guide

Connectors

Label

Function

Note

POWER

Power on button

Compact

Flash/COM2

CF Type I/II Socket with Ejector

Optional for 2nd COM port

COM1

Serial port 1 connector

DB-9 male connector

LINE OUT

Line-out audio jack

USB

2 x USB 2.0 connector

Dock USB

LAN1

RJ-45 Ethernet connector 1

KB/MS

(LAN2)

LPC-1705/1707 -- PS/2 connector

LPC-17A4 -- LAN2

HDD

HDD indicator

PWR

System power indicator

VGA/HDMI

CRT connector/HDMI connector

RESET

Reset button

DC-IN

DC Power-in connector

LPC-17 Series

10 LPC-17 Series Quick Reference Guide

1.5 System Dimensions

1.5.1 LPC-1705 Front and Rear side

(Unit: mm)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Avalue Technology Écran tactile

Avalue Technology

Avalue Technology BFC-10R1 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-1503 Manuel utilisateur

Avalue Technology

Avalue Technology LPC 10 SERIES Manuel utilisateur

Avalue Technology

Avalue Technology FPC-1736 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-1235 Manuel utilisateur

Avalue Technology

Avalue Technology APC-2132 Manuel utilisateur

Avalue Technology

Avalue Technology CCD-07W01 Manuel utilisateur

Avalue Technology

Avalue Technology Medi-View AID-156 Manuel utilisateur

Avalue Technology

Avalue Technology ASM-BYT Manuel utilisateur

Avalue Technology

Avalue Technology OFP-07W33 Manuel utilisateur

Avalue Technology

Avalue Technology HID-2334 Manuel utilisateur

Avalue Technology

Avalue Technology VNS-15W01 Manuel utilisateur

Avalue Technology

Avalue Technology APC-18W5 Manuel utilisateur

Avalue Technology

Avalue Technology APC-2138 Manuel utilisateur

Avalue Technology

Avalue Technology FPC 17 W Series Manuel utilisateur

Avalue Technology

Avalue Technology MPC-10W3 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-1732 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-1232 Manuel utilisateur

Avalue Technology

Avalue Technology SPC-1207 Series Manuel utilisateur

Avalue Technology

Avalue Technology ARC-21W33 Manuel utilisateur

Avalue Technology

Avalue Technology AID-240SBW Manuel utilisateur

Avalue Technology

Avalue Technology SPC-22W7 Manuel utilisateur

Avalue Technology

Avalue Technology SID-21WR2 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-15W32 Manuel utilisateur

Manuels Écran tactile populaires d'autres marques

FlowLine

FlowLine Data loop Manuel utilisateur

ALPEX

ALPEX AEx-8 P Series Manuel utilisateur

Ltech

Ltech E5S Manuel utilisateur

Harman

Harman AMX MODERO S MSD-701-L2 Manuel utilisateur

Acnodes

Acnodes PC 1150 Manuel utilisateur

AIS

AIS IP10IA99 series Manuel utilisateur

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manuel utilisateur

YASKAWA

YASKAWA TP 610C Manuel utilisateur

B&R

B&R Power Panel C Series Manuel utilisateur

Beijer Electronics

Beijer Electronics X2 control Manuel utilisateur

AXIOMTEK

AXIOMTEK GOT321W-521 Manuel utilisateur

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manuel utilisateur

Qomo

Qomo QIT1386 Manuel utilisateur

DFI

DFI KS104-CD Manuel utilisateur

AMX

AMX AXP-PPC Mode d’emploi

Sartorius

Sartorius X3 PR 5410 Manuel utilisateur

AMX

AMX Modero X Series Manuel utilisateur

Advantech

Advantech TPC-30 Series Manuel utilisateur
