Avalue Technology LPC SERIES Manuel utilisateur

Part No. E20171205A2R

LPC 10”/12”Series

10.4”/12.1”Multifunctional Touch Panel PC

Quick Reference Guide

3rd Ed –20 September 2015

LPC 10”/12”Series

2 LPC 10”/12”Series Quick Reference Guide

Contents

1. Getting Started.................................................................................................3

1.1 Safety Precautions.............................................................................................3

1.2 Packing List.......................................................................................................3

1.3 System Specifications ........................................................................................4

1.4 System Overview............................................................................................. 10

1.4.1 Front View....................................................................................................................10

1.4.2 Rear View ....................................................................................................................10

1.5 System Dimensions ......................................................................................... 11

1.5.1 LPC-12 Front and Rear side..........................................................................................11

1.5.2 LPC-10 Front and Rear side..........................................................................................12

1.5.3 Bottom and Rear Side...................................................................................................13

2. Hardware Configuration................................................................................. 15

2.1 BIOS settings...................................................................................................16

2.1.1 RS232/422/485 setting using BIOS ................................................................................16

2.1.2 PWM Backlight control setting for EBM-PNV...................................................................19

2.2 Installing Hard Disk & Memory ..........................................................................20

Quick Reference Guide

LPC 10”/12”Series Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

Français:

Attention!

Débranchez le câble d'alimentation de votre châssis

chaque fois que vous travaillez avec le matériel. Ne faites

pas de connexion lorsque le système est allumé. Les

composants électroniques sensibles peuvent être

endommagés par les surtensions soudaines. Seule les

personnels expérimentés de l'électronique peuvent ouvrir le

châssis du PC.

Précaution!

Il faut toujours mettre à la masse pour éliminer l’électricité

statique avant de toucher la carte CPU. Les appareils

électroniques modernes sont très sensibles aux électricité

statique. Pour des raisons de sécurité, utilisez un bracelet

électrostatique. Placez tous les composants électroniques

sur une surface antistatique ou dans un sac antistatique

quand ils ne sont pas dans le châssis.

1.2 Packing List

1 x LPC 10"/12" Series Panel PC

1 x Driver/Utility DVD-ROM

1 x Power Adapter

1 x Stand for Panel PC (optional)

LPC 10”/12”Series

4 LPC 10”/12”Series Quick Reference Guide

1.3 System Specifications

Panel

Model

LPC-1205

LPC-1005

LCD size

12.1”, 4:3

10.4”, 4:3

Display type

SVGA

XGA

SVGA

XGA

Resolution

800 x 600

1024 x 768

800 x 600

1024 x 768

Color

262K

16.2M

Pixel pitch

0.240mm(H) x

0.240mm(V)

0.240mm(H) x

0.240mm(V)

0.264mm(H) x

0.264mm(V)

0.0685mm(H) x

0.2055mm(V)

Luminance

600 cd/m²

300 cd/m²

500 cd/m²

Contrastratio

700

500

1200

Viewing angle

70(U), 70(D),

80(L), 80(R)

70(U), 70(D),

80(L), 80(R)

45(U), 65(D),

65(L), 65(R)

88(U), 88(D),

88(L), 88(R)

Responsetime

16 ms

25 ms

Backlight

LED

Touch type

5 Wires resistive

Touch interface

USB

System

Board

EBM-PNV

CPU

Onboard Intel® Pineview D525 1.8GHz CPU

BIOS

AMI 8Mbit Flash BIOS

System Chipset

Intel ICH8-M

I/O Chipset

Winbond W83627DHG

System Memory

Onboard 1GB SDRAM and one SODIMM supports up to 3GB

SSD

One CF socket supports Type I / II Compact Flash Card.

HDD

Optional 2.5”SATA HDD

WiFi

Optional USB WiFi 802.11b/g

Watchdog Timer

Reset: 1 ~ 65535 sec./min. and 1 min./step

Audio

Realtek ALC888 supports 5.1-CH Audio

Ethernet

Intel® 82574L Gigabit LAN, Optional Dual LAN

Quick Reference Guide

LPC 10”/12”Series Quick Reference Guide

External I/O Ports

COM Port

1 x RS-232

Ethernet Port

1 x RJ-45

VGA / LCD Port

1 x DB-15

USB Port

2 x USB 2.0

Audio Port

Line-out

Mouse & K/B

1 x PS/2 KB & MS

Power Supply Unit

PowerRequirement

+12V ~ +26V

Power Output

12V/5A (60W)

Environment & Mechanical

Operating Temperature

-10~40°C (14~104°F)

Storage Temperature

-20 to +75°C (-4~167°F)

Relative Humidity

5 to 90% @ 40°C (104°F), relative humidity, non-condensing

Dimension(W x D x H)

283 x 222x 45 mm

259 x 196 x 41mm

Weight

2.84 Kgs

2.11 Kgs

Mounting

Desktop (VESA Compliance)

LPC 10”/12”Series

6 LPC 10”/12”Series Quick Reference Guide

Panel

Model

LPC-1203

LPC-1003

LCD size

12.1”, 4:3

10.4”, 4:3

Display type

SVGA

XGA

SVGA

XGA

Resolution

800 x 600

1024 x 768

800 x 600

1024 x 768

Color

262K

Pixel pitch

0.3075mm(H) x

0.3075mm(V)

0.240mm(H) x

0.240mm(V)

0.264mm(H) x

0.264mm(V)

0.20625mm(H) x

0.20625mm(V)

Luminance

450 cd/m²

230 cd/m²

300 cd/m²

Contrastratio

1000

700

500

Viewing angle

89(U), 89(D),

89(L), 89(R)

80(U), 80(D),

80(L), 80(R)

55(U), 65(D),

70(L), 70(R)

60(U), 60(D),

70(L), 70(R)

Responsetime

25 ms

Backlight

CCFL

Touch type

5 Wires resistive

Touch interface

USB

System

Board

EBM-945GSE

CPU

Onboard Intel Atom N270 1.6GHz (2.5W)

BIOS

Award 4 Mbit Flash BIOS

System Chipset

Intel 945GSE + ICH7-M

I/O Chipset

ITE 8712F

System Memory

Onboard 1GB DDR2, extra one SODIMM supports up to 2GB 400/533 SDRAM

SSD

One CF socket supports Type I / II Compact Flash Card.

HDD

Optional 2.5”SATA HDD or 44-pin enhanced IDE HDD

WiFi

Optional USB WiFi 802.11b/g

Watchdog Timer

Reset: 1 ~ 65535 sec./min. and 1 min./step

Display

Intel 945GSE GMCH integrated GMA950 graphics

Audio

Realtek ALC 655 supports 5.1-CH Audio

Ethernet

Dual Realtek RTL8111C Gigabit LAN, supports wake on LAN

Quick Reference Guide

LPC 10”/12”Series Quick Reference Guide

External I/O Ports

COM Port

1 x RS-232/422/485 setting by BIOS*, optional extra 1 x RS-232/422/485

Ethernet Port

Dual RTL8111C Giga LAN

VGA / LCD Port

1 x DB-15

Audio Port

Line-out

USB Port

2 x USB 2.0

Power Supply Unit

PowerRequirement

+12V ~ +26V

PowerOutput

12V/5A (60W)

Environment & Mechanical

Operating Temperature

0~60°C (32~140°F)

0~40°C (32~104°F)

Storage Temperature

-20 to +75°C (-4~167°F)

Relative Humidity

5 to 90% @ 40°C (104°F), relative humidity, non-condensing

Dimension (W x D x H)

283 x 222x 45 mm

259 x 196 x 41mm

Weight

2.84 Kgs

2.11 Kgs

Mounting

Desktop (VESA Compliance)

LPC 10”/12”Series

8 LPC 10”/12”Series Quick Reference Guide

Panel

Model

LPC-1201

LPC-1001

LCD size

12.1”, 4:3

10.4”, 4:3

Display type

SVGA

XGA

SVGA

XGA

Resolution

800 x 600

1024 x 768

800 x 600

1024 x 768

Color

262K

Pixel pitch

0.3075mm(H) x

0.3075mm(V)

0.240mm(H) x

0.240mm(V)

0.264mm(H) x

0.264mm(V)

0.20625mm(H) x

0.20625mm(V)

Luminance

450 cd/m²

230 cd/m²

300 cd/m²

Contrastratio

1000

700

500

Viewing angle

89(U), 89(D),

89(L), 89(R)

80(U), 80(D),

80(L), 80(R)

55(U), 65(D),

70(L), 70(R)

60(U), 60(D),

70(L), 70(R)

Responsetime

25 ms

Backlight

CCFL

Touch type

5 Wires resistive

4 Wires resistive

5 Wires resistive

Touch interface

USB

System

Board

EBM-CX700

CPU

Onboard VIA Eden ULV 1GHz (3.5W), up to 1.6GHz (8W) CPU

BIOS

Award, 512KB Flash BIOS

System Chipset

VIA CX700M

I/O Chipset

VIA VT1211

System Memory

One 200-pin DDR2 SODIMM socket, supports up to 1GB DDR2 400/533 SDRAM

SSD

One CF socket supports Type I / II Compact Flash Card.

HDD

Optional 2.5”SATA HDD or 44-pin enhanced IDE HDD

WiFi

Optional USB WiFi 802.11b/g

Watchdog Timer

Reset: 1 ~ 65535 sec./min. and 1 min./step

Display

VIA CX700M

Audio

VIA VT1708A supports 2CH Audio

Ethernet

Dual RTL8110SC Gigabit LAN/10/100/1000 Base-Tx Fast Ethernet compatible

Quick Reference Guide

LPC 10”/12”Series Quick Reference Guide

External I/O Ports

COM Port

1 x RS-232

Ethernet Port

Dual RTL8110SC Giga LAN

VGA / LCD Port

1 x DB-15

Audio Port

Line-out

USB Port

2 x USB 2.0

Power Supply Unit

PowerInput

12V

PowerOutput

12V/5A (60W)

Environment & Mechanical

Operating Temperature

-10~60°C (14~140°F)

0~40°C (32~104°F)

Storage Temperature

-20 to +75°C (-4~167°F)

Relative Humidity

5 to 90% @ 40°C (104°F), relative humidity, non-condensing

Dimension (W x D x H)

283 x 222x 45 mm

259 x 196 x 41mm

Weight

2.84 Kgs

2.11 Kgs

Mounting

Desktop (VESA Compliance)

Note: Specifications are subject to change without notice.

LPC 10”/12”Series

10 LPC 10”/12”Series Quick Reference Guide

1.4 System Overview

1.4.1 Front View

1.4.2 Rear View

Connectors

Label

Function

Note

POWER

Power on button

CF Type I/II Socket with Ejector

Optional for 2nd COM port

COM

Serial port

DB-9 male connector

LINE OUT

Line-out audio jack

USB

2 x USB 2.0 connector

Dock USB

LAN1

RJ-45 Ethernet connector 1

KB/MS

(LAN2)

LPC-1005/1205 --PS/2 connector

LPC-1001/1003/1201/1203 -- LAN2

HDD

HDD indicator

PWR

System power indicator

VGA

CRT connector

DB-15 female connector

RESET

Reset button

DC-IN

DC Power-in connector

Note:

UL Certified Cables are required & purchased from the distributors.

Français:

Il est nécssaire que vous achetez des câbles certifiés par UL auprès des distributers.

POWER

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Avalue Technology Écran tactile

Avalue Technology

Avalue Technology RITY122 Manuel utilisateur

Avalue Technology

Avalue Technology VNS-15W01 Manuel utilisateur

Avalue Technology

Avalue Technology FPC-10W09 Manuel utilisateur

Avalue Technology

Avalue Technology C Series Manuel utilisateur

Avalue Technology

Avalue Technology BFC-10R1 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-1909 Series Manuel utilisateur

Avalue Technology

Avalue Technology FPC-1736 Manuel utilisateur

Avalue Technology

Avalue Technology CCD-07WR2 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-15W32 Manuel utilisateur

Avalue Technology

Avalue Technology SID-21WR1 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-17 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-1206 Manuel utilisateur

Avalue Technology

Avalue Technology SID-10WR2 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-0809 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-15W33 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-1532-C2 Manuel utilisateur

Avalue Technology

Avalue Technology SID-21W04 Manuel utilisateur

Avalue Technology

Avalue Technology EPD-42T Manuel utilisateur

Avalue Technology

Avalue Technology FPC-10W07 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-08A1 Manuel utilisateur

Avalue Technology

Avalue Technology Medi-View AID-185 Manuel utilisateur

Avalue Technology

Avalue Technology FPC 17 W Series Manuel utilisateur

Avalue Technology

Avalue Technology LPC-1231 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-1533 Manuel utilisateur

Manuels Écran tactile populaires d'autres marques

FlowLine

FlowLine Data loop Manuel utilisateur

ALPEX

ALPEX AEx-8 P Series Manuel utilisateur

Ltech

Ltech E5S Manuel utilisateur

Harman

Harman AMX MODERO S MSD-701-L2 Manuel utilisateur

Acnodes

Acnodes PC 1150 Manuel utilisateur

AIS

AIS IP10IA99 series Manuel utilisateur

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manuel utilisateur

YASKAWA

YASKAWA TP 610C Manuel utilisateur

B&R

B&R Power Panel C Series Manuel utilisateur

Beijer Electronics

Beijer Electronics X2 control Manuel utilisateur

AXIOMTEK

AXIOMTEK GOT321W-521 Manuel utilisateur

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manuel utilisateur

Qomo

Qomo QIT1386 Manuel utilisateur

DFI

DFI KS104-CD Manuel utilisateur

AMX

AMX AXP-PPC Mode d’emploi

Sartorius

Sartorius X3 PR 5410 Manuel utilisateur

AMX

AMX Modero X Series Manuel utilisateur

Advantech

Advantech TPC-30 Series Manuel utilisateur
