GDO-9

INSTALLATION INSTRUCTIONS | OWNERS COPY

Overhead Garage Door Opener

Featuring TrioCode™Technology

Technical Document

Installation Manual

v1.01

14 Dec 2011

English

Part # 13214 (Manual)

2GDO-9 Owner Installation Instructions

WARNING: It is vital for the safety of persons to follow

all instructions. Failure to comply with the installation

instructions and the safety warnings may result in serious

personal injury and/or property damage.

Please save these instructions for future reference.

Automatic Technology (Australia) Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all

conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an

Automatic Technology (Australia) Pty Ltd Garage Door Opener. Automatic Technology (Australia) Pty Ltd hereby further

expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any person

as a result whether directly or indirectly from failure to install the Automatic Technology (Australia) Pty Ltd Garage Door

Opener in accordance with these installation instructions.

Owner Installation Instructions GDO-9 3

GDO-9

Overhead Garage Door Opener

Important Safety Instructions 4

Features 6

Enduro™ Controls 8

Dynamo™ Controls 10

Kit Contents 12

Installation 13

C-Rail Attachment 13

Determine Door Type 14

Mounting - Track Type Door 15

Mounting - Spring Loaded Door 16

Mounting Door Bracket & Arms 17

Programming the Opener 18

Setting Travel Limits - Control Panel 18

Setting Travel Limits - Transmitter 19

Safety Obstruction Forces 20

Safety Obstruction Force Test 20

Adjusting Safety Obstruction Forces 21

Coding Transmitters 22

Door 22

Vacation Mode 22

Auxiliary out put 22

Pet Mode 22

Courtesy Light 23

Remotely Coding Transmitters 24

Erasing Transmitter Codes 24

Accessories 25

Photo Electric Beam Installation 25

Auto-Close Setup 25

SmartSolar™ Installation 26

Battery Backup installation 27

Final Setup 28

Courtesy Light Time 28

Pet Mode Door Height 28

Wall Mounted Transmitters 28

Re-Initialising 28

Default Settings & Speciﬁcations 29

Door Status Indicators 30

Button Functions 30

Troubleshooting Guide 31

Maintenance 32

Parts Listing Enduro™ 33

Parts Listing Dynamo™ 34

Warranty 35

4GDO-9 Owner Installation Instructions

CAUTION: If your garage has no pedestrian entrance door, an emergency access device should be installed.

This accessory allows manual operation of the garage door from outside in case of power failure.

For ADDITIONAL SAFETY protection we STRONGLY recommend the ﬁtting of a Photo Electric (PE)

Beam. In most countries PE Beams are mandatory on all garage doors ﬁtted with automatic openers.

For a small additional outlay Automatic Technology recommends that Photo Electric Beams be

installed with the automatic opener ensuring additional safety and peace of mind.

DO NOT operate the opener unless the garage door is in full view and free from objects such

as cars and children/people. Make sure that the door has ﬁnished moving before entering or

leaving the garage.

DO NOT operate the opener when children/people are near the door. Children must

be supervised at all times when the Enduro™ or Dynamo™ is in use. Serious personal

injury and/or property damage can result from failure to follow this warning.

DO NOT allow children to operate the opener. Serious personal injury and/or

property damage can result from failure to follow this warning.

Regularly check to make sure that the Safety Obstruction Force is working

correctly, and is tested and set as per page 20 of this manual. Failure to

follow these instructions could result in serious personal injury and/or

property damage. This test must be repeated at regular intervals and the

necessary adjustments made as required.

Photo Electric beams must be installed if the closing force at the

bottom edge of the door exceeds 400N (40kg).

DO NOT disengage the door opener to manual operation with

children/people or any other objects including motor vehicles

within the doorway.

The door opener is not intended for use by young children

or inﬁrm persons without adequate supervision. Children

should be supervised to ensure that they do not play

with the remote transmitters or the opener.

Keep hands and loose clothing clear of the door

and door opener at all times.

WARNING: It is vital for the safety of persons to follow all

instructions. Failure to comply with the following Safety

instructions may result in serious personal injury and/or

property damage.

Important Safety Instructions

Owner Installation Instructions GDO-9 5

The unit should be installed so that it is protected from the elements. It should not be exposed to water or rain.

It is not to be immersed in water or sprayed directly by a hose or other device.

The garage door must be well balanced. Sticking or binding doors must be repaired by a qualiﬁed garage

door installer prior to installation of the opener.

Frequently examine the installation, in particular cables, springs and mountings for signs of wear, damage

or imbalance. DO NOT use if repair or adjustment is needed since a fault in the installation or an

incorrectly balanced door may cause injury. DO NOT attempt to repair the door yourself as hardware

is under extreme tension.

Remove or disengage all garage door locks and mechanisms prior to installation of the opener.

Connect the opener to a properly earthed general purpose 240V mains power outlet installed

by a qualiﬁed electrical contractor.

Disconnect the power cord from mains power before making any repairs or removing

covers. Only experienced service personnel should remove covers from the opener.

When using auto close mode, a photo electric beam must be ﬁtted correctly and

tested for operation at regular intervals. Extreme caution is recommended when

using auto close mode. All safety rules must be followed.

In order for the opener to sense an object obstructing the door way, some

force must be exerted on the object. As a result the object, door and/or

person may suffer damage or injury.

If the power supply cord is damaged, it must be replaced by an

Automatic Technology service agent or suitably qualiﬁed person.

Make sure that the door is fully open before driving in or out of the

garage and fully closed before leaving the driveway.

Make sure that remote controls are kept out of reach of

children.

Install the wall switch or wall mounted transmitter in

a location where it is out of reach of children and the

garage door is visible.

Important Safety Instructions

6GDO-9 Owner Installation Instructions

Operation

To open or close the door simply press a button on a TrioCode™ handheld

transmitter, a wall mounted transmitter, or optional wall switch for two seconds.

During open and close cycles the door can be stopped by pressing the button

again. The next actuation will move the reverse the door’s direction.

TrioCode™ Code Hopping Technology

Every time a TrioCode™ transmitter is used a new security code is randomly

generated from over 4.29 billion possibilities. This greatly enhances the security

of the system and makes “code grabbing” a thing of the past

These transmitters also overcome interference issues by simultaneously sending a

signal over three different frequencies. Even if two of the three signals are jammed,

the system will still work.

ALPS (Automatic Limits Positioning System)

ALPS does away with manual adjustment of the door’s limits position using mechanical

parts, such as cams and microswitches. During installation the hand held transmitter

can be programmed to set the door limits positions.

ISS (intelligent safety obstruction system)

While the door is performing a close cycle, should it hit an obstacle or be restricted in some

manner, it will automatically reverse. The amount of force the door should encounter before

reversing is automatically adjusted by the doors control system during the initial installation of the

automatic door opener. The door will also stop if restricted whilst opening. The Safety Obstruction

Force should be checked monthly.

Auto courtesy light

The courtesy light comes on automatically for three minutes whenever the door is activated. The light can also

be operated independently of the door by coding a dedicated button on a transmitter.

Features

Thank you for purchasing the Automatic Technology

GDO-9 Overhead Garage Door Opener. Designed

to suit sectional overhead and one piece tilt up

doors, the components and materials used ensure

this opener will provide years of smart, simple

and secure operation. Listed below are some

of the many features:

Owner Installation Instructions GDO-9 7

SmartSolar™ and Battery Backup Compatibility (optional)

The opener can be ﬁtted with a SmartSolar™ or Battery Backup kit for operation in the

event of a power outage, or where mains power access is not available. NOTE: If the

door is the only entrance to the garage, and a battery backup kit is not ﬁtted, a

keyed cable release should be ﬁtted externally to the garage.

Vacation mode

A hand held transmitter can be programmed to lock and unlock all other

transmitters that have been programmed into the openers’ memory. The vacation

mode can be used when the door is left idle for long periods of time.

Pet/Pedestrian mode

The transmitter can be programmed to open the door to an adjustable partial

height so that the family pet can enter and exit the garage at any time. You may

also wish to open the door to a height suitable only for pedestrian access.

Auto-Close mode

The opener can be programmed to automatically close after an open cycle. The Auto-

Close time is adjustable. It is compulsory to install a PE Beam if this mode is selected,

otherwise the door may cause personal injury or damage to property.

Photo Electric (PE) Beam (optional)

The opener has an input to connect a PE Beam for extra safety and use of the Auto-Close

mode.

Manual operation

The opener is equipped with a unique manual disengaging device. If the power to the opener is disrupted, the

door can be put into manual mode by pulling down on the string handle on an angle towards the door. This

allows for manual operation of the door. To re-engage the opener, pull the string handle away from the door.

8GDO-9 Owner Installation Instructions

Enduro™ Controls

Terminal Block.

24V PWR is used to power devices such as:

PE (Input) for photo electric beam for safety and Auto-Close function.

LGT (Input) allow hard wired external trigger for the opener’s courtesy light.

O/S/C INPUT is used for the connection of a wired switch (momentary contact). This switch

can then be used to open, stop or close the door. Install the wall switch in a location where

the switch is out of reach of children and the garage door is visible.

SET button (orange) is used during the installation phase together with the Open and MINUS (-) buttons to

set the door limit positions. The Set button is also used to re-initialize the Opener.

LIGHT CODE button (white) is used for storing or erasing the transmitter button (code) you wish to use

to switch the courtesy light on the opener on or off.

CODING LED (red) light ﬂashes when a code is being stored or when a transmitter button is pressed.

OPERATE button (Yellow) is used during installation to test the open, stop and close cycles for the

opener. The opener has to be initialised by the SET button to make the O/S/C button operable.

DOOR CODE BUTTON (blue) is used for storing or erasing transmitter buttons for door operation

DOOR STATUS LED (Yellow)

MINUS (-) button (red) is used during installation to help set the close limit position. Pressing and holding

this button will move the door in the close direction. Movement stops when the button is released.

NOTE: The safety obstruction detection is inoperable when the CLOSE button is used to move door.

PLUS (+) button (green) is used during installation to help set the open limit position. Pressing and holding

this button will move the door in the open direction, releasing stops the door.

NOTE: The safety obstruction detection is inoperable when the PLUS (+) button is used to move door.

CLOSE LIMIT LED (red) the LED is very helpful during installation. It illuminates and ﬂashes when the

door is closing and remains steady on when the close limit position has been reached.

OPEN LIMIT LED (green) the LED is very helpful during installation. It illuminates and ﬂashes when the

door is opening and remains steady on when the open limit position has been reached.

AUTO CLOSE TIME button (White) is used to adjust the auto close time. While holding in the AUTO

CLOSE TIME button and then pressing the PLUS (+) button the time is increased. Each press will increase

the time by 1 second. Pressing the MINUS (-) button will decrease the time.

FORCE MARGIN SET Button: The obstruction force margin is set automatically during installation. The

margin can be adjusted manually using the Force Margin Set button (White). Holding the Force Margin Set

button and pressing PLUS (+) or MINUS (-) buttons will increase or decrease the amount of force. The Force

Margin Set should only be used if environmental factors (wind, etc.) affect the door’s operation.

JP1 SOLAR CONNECTOR onto this the shunt must be ﬁtted for solar operation.

PROG INPUT is used to connect the Automatic Technology Handheld Programmer “PG-3” for editing

control and receiver functions, accessing diagnostic tools, and activating special features and operating

modes.

SBY-3 CONNECTOR is used to connect both Battery Backup Kits and SmartSolar™ kits.

10A FUSE

Owner Installation Instructions GDO-9 9

17 16

02 03 04 05 07 09 10 11 12 13

ﬁg

10 GDO-9 Owner Installation Instructions

Dynamo™ Controls
