GDO-7v2 SecuraLift®

Overhead Garage Door Opener

INSTALLATION INSTRUCTIONS | OWNERS COPY

Featuring TrioCode™Technology

Part # 13215 (Manual)

2GDO-7v2 SecuraLift® Owner Installation Instructions

WARNING: It is vital for the safety of persons to follow all

instructions.Failuretocomplywiththeinstallationinstructions

and the safety warnings may result in serious personal injury

and/or property and remote control opener damage. Please

save these instructions for future reference.

Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all

conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of

an Automatic Technology Australia Pty Ltd Garage Door Opener. Automatic Technology Australia Pty Ltd hereby further

expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any person as a

result whether directly or indirectly from failure to install the Automatic Technology Australia Pty Ltd Garage Door Opener

in accordance with these installation instructions.

Owner Installation Instructions GDO-7v2 SecuraLift® 3

Important Safety Instructions 4

Features 6

Operating Controls 8

Package Contents 10

Installation 11

Tube Rail Assembly 11

Determine the Door Type 12

Mounting on a Track Type Door 13

Mounting on a non-Track Type Door 14

Mounting Door Bracket & Arms 15

Programming the Opener 16

Setting Limits 16

Setting Limits: via Transmitter 17

Safety Obstruction Force 18

Safety Obstruction Force Test 18

Adjustin Safety Obstruction Forces 19

Coding Transmitters 20

Door 20

Courtesy Light 20

Vacation Mode 20

Pet (Pedestrian)Mode 20

Remotely Coding Transmitters 21

Deleting Transmitter Codes 21

Accessories 22

Photo Electric Beam 22

Auto-Close 22

Final Set Up 23

Courtesy Light Time 23

Pet Mode Door Height 23

Wall Mounted Transmitter 23

Re-Initialising 23

Parameters 24

Door Status Indicators 24

Button Functions 25

System Speciﬁcations 26

Troubleshooting Guide 27

Maintenance 28

Spare Parts 29

Warranty 30

GDO-7v2 SecuraLift®

Overhead Garage Door Opener

4GDO-7v2 SecuraLift® Owner Installation Instructions

CAUTION: If your garage has no pedestrian entrance door, an emergency access device should be installed.

This accessory allows manual operation of the garage door from outside in case of power failure.

For ADDITIONAL SAFETY protection we STRONGLY recommend the ﬁtting of a Photo Electric (P.E.)

Beam. In most countries P.E. Beams are mandatory on all garage doors ﬁtted with automatic openers.

For a small additional outlay Automatic Technology recommends that Photo Electric Beams be

installed with the automatic opener ensuring additional safety and peace of mind.

DO NOT operate the opener unless the garage door is in full view and free from objects such

as cars and children/people. Make sure that the door has ﬁnished moving before entering or

leaving the garage.

DO NOT operate the opener when children/persons are near the door. Children must be

supervised at all times when the SecuraLift® is in use. Serious personal injury and/or

property damage can result from failure to follow this warning.

DO NOT allow children to operate the SecuraLift®. Serious personal injury and/or

property damage can result from failure to follow this warning.

Regularly check to make sure that the safety obstruction force is working

correctly, and is tested and set as per page 18 of this manual. Failure to

follow these instructions could result in serious personal injury and/or

property damage. This test must be repeated at regular intervals and the

necessary adjustments made as required.

Doors requiring over 400N of force to move must have P.E. Beams

installed.

DO NOT disengage the door opener to manual operation with

children/persons or any other objects including motor vehicles

within the doorway.

The door opener is not intended for use by young children

or inﬁrm persons without adequate supervision. Children

should be supervised to ensure that they do not play

with the remote transmitters or the opener.

Keep hands and loose clothing clear of the door

and door opener at all times.

WARNING: It is vital for the safety of persons to follow

all instructions. Failure to comply with the following

Safety Rules may result in serious personal injury and/or

property damage.

Important Safety Instructions

Owner Installation Instructions GDO-7v2 SecuraLift® 5

The unit should be installed so that it is protected from the elements. It should not be exposed to water or rain.

It is not to be immersed in water or sprayed directly by a hose or other device.

The garage door must be well balanced. Sticking or binding doors must be repaired by a qualiﬁed garage

door installer prior to installation of the opener.

Frequently examine the installation, in particular cables, springs and mountings for signs of wear,

damage or imbalance. DO NOT use if repair or adjustment is needed since a fault in the installation

or an incorrectly balanced door may cause injury. DO NOT attempt to repair the door yourself as

hardware is under extreme tension.

Remove or disengage all garage door locks and mechanisms prior to installation of the opener.

Connect the opener to a properly earthed general purpose 240V mains power outlet

installed by a qualiﬁed electrical contractor.

Disconnect the power cord from mains power before making any repairs or removing

covers. Only experienced service personnel should remove covers from the opener.

When using auto close mode, a photo electric beam must be ﬁtted correctly and

tested for operation at regular intervals. Extreme caution is recommended when

using auto close mode. All safety rules must be followed.

In order for the SecuraLift® to sense an object obstructing the door way,

some force must be exerted on the object. As a result the object, door

and/or person may suffer damage or injury.

If the power supply cord is damaged, it must be replaced by an

Automatic Technology service agent or suitably qualiﬁed person.

Make sure that the door is fully open before driving in or out of

the garage and fully closed before leaving the driveway.

Make sure that remote controls are kept out of reach of

children.

Install the wall switch or wall mounted transmitter in a

location where it is out of reach of children and the

Important Safety Instructions

6GDO-7v2 SecuraLift® Owner Installation Instructions

Operation

To open or close the door simply press a button on a TrioCode™ handheld

transmitter, a wall mounted transmitter, or optional wall switch for two seconds.

During open and close cycles the door can be stopped by pressing the button

again. The next actuation will move the reverse the door’s direction.

TrioCode™ Code Hopping Technology

Every time a TrioCode™ transmitter is used a new security code is randomly

generated from over 4.29 billion possibilities. This greatly enhances the security of

the system and makes “code grabbing” a thing of the past

These transmitters also overcome interference issues by simultaneously sending a

signal over three slightly different frequencies. Even if two of the three signals are

jammed, the system will still work.

S-ALPS (Semi Automatic Limits Positioning System)

The S-ALPS system does away with manual adjustment of the door’s limits position

using mechanical parts, such as cams and microswitches. During installation the handheld

transmitter can be programmed to set the limits positions.

Anti-travel electronic brakes

The SecuraLift® features an anti-travel electronic brake mechanism to ensure the opener stops the door

at exact location

ISS (intelligent safety obstruction system)

While the door is performing a close cycle, should it hit an obstacle or be restricted in some manner, it

will automatically reverse. The amount of force the door should encounter before reversing is automatically

adjusted by the doors control system during the initial installation of the automatic door opener. The door will

also stop if restricted whilst opening. The Safety Obstruction Force should be checked at least once a month.

See installation manual for instructions.

Features

Thank you for purchasing the Automatic Technology

SecuraLift® Automatic Garage Door Opener.

overhead and one piece tilt up doors, the SecuraLift®

will provide years of smart, simple & secure

convenience to your home.

Owner Installation Instructions GDO-7v2 SecuraLift® 7

Overload indicator

When the maximum opening and closing capacity of the SecuraLift® is exceeded

the red and green Limits LEDs ﬂash alternately to indicate that an overload has

occurred.

Auto courtesy light

The SecuraLift® courtesy light comes on automatically whenever the door is

activated. The light can also be switched on and off without operating the door

by coding a dedicated button on a TrioCode™ transmitter. The light will stay on

for approximately three minutes then switch off. This time is adjustable.

Vacation mode

A hand held transmitter can be programmed to lock and unlock all other

transmitters that have been programmed into the openers’ memory. The vacation

mode can be used when the door is left idle for long periods of time.

Pet/Pedestrian mode

The hand held transmitter can be programmed to open the door partially so that the

family pet can enter and exit the garage at any time. You may also wish to open the

door to a height suitable only for pedestrian access. The door opening position is also

programmable.

Auto-close mode

The opener can be programmed to automatically close after an open cycle. The auto-close time

is adjustable. It is compulsory to install a P.E. Beam if this mode is selected, otherwise the door may

cause personal injury or damage to property.

Photo Electric (P.E.) Beam (optional)

The opener has an input for a P.E. beam to be connected for extra safety protection and use of the auto-close

mode.

Manual operation

The opener is equipped with a unique manual disengaging device. If the power to the opener is disrupted for

any reason the door can be put into manual mode by pulling down on the string handle on an angle towards

the door. This will allow you to manually open or close the door. To re-engage the opener pull the string

8GDO-7v2 SecuraLift® Owner Installation Instructions

Operating Controls

P.E. Shunt. The shunt has to be removed when connecting a Photo Electric Beam.

NOTE: P.E. Shunt must only be removed when P.E. Beams are being connected, otherwise the opener will

malfunction. PROG INPUT is used to connect of the Automatic Technology Handheld Programmer for the

purpose of editing control and receiver functions.

Terminal Block. 24V PWR is used to power devices such as:

PE (Input) for photo electric beam for safety and auto-close function.

LGT (Input) allow hard wired external trigger for the opener’s courtesy light.

O/S/C INPUT is used for the connection of a wired switch (momentary contact). This switch can then

be used to open, stop or close the door. Install the wall switch in a location where the switch is out of

reach of children and the garage door is visible.

SET button (yellow) is used during the installation phase together with the Open and Close buttons to set

the door limit positions. The Set button is also used to re-initialize the Opener.

OPERATE button (Yellow) is used during installation to test the open, stop and close cycles for the

opener. The opener has to be initialised by the Reset button to make the O/S/C button operable.

PLUS (+) button (green) is used during installation to help set the open limit position. Pressing and

holding this button will move the door in the open direction, releasing stops the door.

NOTE: The safety obstruction detection is inoperable when the PLUS (+) button is used to move door.

OPEN LIMIT LED (green) the LED is very helpful during installation. It illuminates and ﬂashes when the

door is opening and remains steady on when the open limit position has been reached.

FORCE MARGIN SET Button The obstruction force margin is set automatically during installation. The

margin can be adjusted manually using the Force Margin Set button (White). Holding the Force Margin Set

button and pressing Plus (+) or Minus (-) buttons will increase or decrease the amount of force. The Force

Margin Set should only be used if environmental factors (wind, etc.) affect the door’s operation.

LIGHT CODE button (white) is used for storing or erasing the transmitter button (code) you wish to use

to switch the courtesy light on the opener on or off.

CODING LED (red) light ﬂashes when a code is being stored or when a transmitter button is pressed.

DOOR CODE BUTTON (blue) is used for storing or erasing the transmitter button you wish to use to

command the door to open, stop or close.

DOOR STATUS LED (Yellow)

MINUS (-) button (red) is used during installation to help set the close limit position. Pressing and holding

this button will move the door in the close direction. Movement stops when the button is released.

NOTE: The safety obstruction detection is inoperable when the MINUS (-) button is used to move door..

CLOSE LIMIT LED (red) the LED is very helpful during installation. It illuminates and ﬂashes when the

door is closing and remains steady on when the close limit position has been reached.

Datum adjust screw is used during limits set up to indicate the mid point of the door’s travel.

AUTO CLOSE TIME button (White) is used to adjust the auto close time. While holding in the AUTO

CLOSE TIME button and then pressing the open button the time is increased. Each press will increase the

time by 5 seconds. Pressing the close button will decrease the time.

•

Owner Installation Instructions GDO-7v2 SecuraLift® 9

01 02

03 04 05 06 07

12 13

10 GDO-7v2 SecuraLift® Owner Installation Instructions

Package Contents

GDO-7V2 Securalift®drive unit 1

TrioCode™keyring transmitters 2

TrioCode™wall mounted transmitters (not available all models) 1

Tubes 5

Tube inserts 4

Pipe support assembly (either steel or plastic version) 1

Chain 1

Shuttle assembly 1

Door attachment arms 2

Hardware pack 1

Installation Manual 1

Table des matières

Autres manuels Automatic Technology ouvre-porte de garage

Automatic Technology

Automatic Technology GDO-8V2 EasyRoller II Manuel utilisateur

Automatic Technology

Automatic Technology Toro GDO-10v2 Manuel utilisateur

Automatic Technology

Automatic Technology Axess Pro Series Manuel utilisateur

Automatic Technology

Automatic Technology 62717 Manuel utilisateur

Automatic Technology

Automatic Technology GDO-9 Dynamo Gen 2 Manuel utilisateur

Automatic Technology

Automatic Technology iOpener RD40 Manuel utilisateur

Automatic Technology

Automatic Technology GDO-2 SecuraLife Manuel utilisateur

Automatic Technology

Automatic Technology GDO-6 v2 Manuel utilisateur

Automatic Technology

Automatic Technology GDO-6v3 EasyRoller Manuel utilisateur

Automatic Technology

Automatic Technology GDO-8 Shed Master Manuel utilisateur

Automatic Technology

Automatic Technology ATS Series Manuel utilisateur

Automatic Technology

Automatic Technology SecuraLift GDO-7V1 Guide de démarrage rapide

Automatic Technology

Automatic Technology Hiro GDO-12V1 Manuel utilisateur

Automatic Technology

Automatic Technology GDO-9v2 Enduro Gen 2 Manuel utilisateur

Automatic Technology

Automatic Technology GDO-11V3 Ero Manuel utilisateur

Automatic Technology

Automatic Technology Ero GDO-11v2 Manuel utilisateur

Automatic Technology

Automatic Technology NeoSlider TrioCode 128 NES-500 Manuel utilisateur

Automatic Technology

Automatic Technology AM-808 Manuel utilisateur

Automatic Technology

Automatic Technology GDO-10v1Toro Manuel utilisateur

Automatic Technology

Automatic Technology GDO-8v1 EasyRoller II Manuel utilisateur

Automatic Technology

Automatic Technology GDO-11v1 SecuraLift Manuel utilisateur

Automatic Technology

Automatic Technology GDO-10V3L2 Toro Manuel utilisateur

Automatic Technology

Automatic Technology Smart Phone Control Manuel utilisateur

Automatic Technology

Automatic Technology SecuraLift Rhino Manuel utilisateur

Manuels ouvre-porte de garage populaires d'autres marques

Dorma

Dorma ES 90 Manuel utilisateur

Garaga

Garaga SECURITY+ 3265GCM 1HP Manuel utilisateur

Chamberlain

Chamberlain Whisper Drive SECURITY+ WD822K Series Manuel utilisateur

Chase Doors

Chase Doors DuraShield Manuel utilisateur

CSI

CSI Classic Manuel utilisateur

HATO

HATO 120 Manuel utilisateur

Chamberlain

Chamberlain Elite 3575S Manuel utilisateur

Richmond

Richmond GTR156 Manuel utilisateur

Raynor

Raynor 1280RGD Manuel utilisateur

CAME

CAME F4000 Series Manuel utilisateur

B&D

B&D Controll-A-Door 5 Manuel utilisateur

BFT

BFT PRV AA SL Manuel utilisateur

Craftsman

Craftsman 139.53924 Manuel utilisateur

Chamberlain

Chamberlain MyQ 940ESTD Manuel utilisateur

Westfalia

Westfalia 19 36 07 Manuel utilisateur

Chamberlain

Chamberlain HD520EVP Manuel utilisateur

Cardin

Cardin BL Series Manuel utilisateur

Chamberlain

Chamberlain 8355 - 1/2 hp Manuel utilisateur
