Asus RT-AC68U Manuel utilisateur
User Guide
RT-AC68U
Wireless-AC1900 Dual Band Gigabit Router
8U
2
Copyright © 2013 ASUSTeK Computer Inc. All Rights Reserved.
No part of this manual, including the products and software described
in it, may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form or by any means, except
documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK Computer Inc. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired,
modied or altered, unless such repair, modication of alteration is authorized
in writing by ASUS; or (2) the serial number of the product is defaced or
missing.
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS
AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR
PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE
FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE
AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A
COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY
FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent
to infringe.
E8119
First Edition
March 2013
3
Table of contents
1 Getting to know your wireless router 6
1.1 Welcome! ........................................................................................6
1.2 Package contents.........................................................................6
1.3 Your wireless router.....................................................................7
1.4 Positioning your router..............................................................9
1.5 Setup Requirements ................................................................ 10
1.6 Router Setup............................................................................... 11
1.6.1 Wired connection..................................................................11
1.6.2 Wireless connection.............................................................12
2 Getting started 14
2.1 Logging into the Web GUI ..................................................... 14
2.2 Quick Internet Setup (QIS) with Auto-detection ........... 15
2.3 Connecting to your wireless network................................ 19
3 Conguring the General settings 20
3.1 Using the Network Map ......................................................... 20
3.1.1 Setting up the wireless security settings......................21
3.1.2 Managing your network clients.......................................22
3.1.3 Monitoring your USB device.............................................23
3.2 Creating a Guest Network...................................................... 26
3.3 Using the Trac Manager ...................................................... 28
3.3.1 Managing QoS (Quality of Service) Bandwidth..........28
3.3.2 Monitoring Trac .................................................................31
3.4 Setting up Parental Control................................................... 32
3.5 Using the USB Application..................................................... 33
3.5.1 Using AiDisk...............................................................................33
3.5.2 Using Servers Center............................................................35
3.5.3 3G/4G ........................................................................................41
4
Table of contents
3.6 Using AiCloud............................................................................. 43
3.6.1 Cloud Disk................................................................................44
3.6.2 Smart Access...........................................................................46
3.6.3 Smart Sync...............................................................................47
4 Conguring the Advanced Settings 48
4.1 Wireless......................................................................................... 48
4.1.1 General......................................................................................48
4.1.2 WPS ............................................................................................51
4.1.3 Bridge ........................................................................................53
4.1.4 Wireless MAC Filter...............................................................55
4.1.5 RADIUS Setting ......................................................................56
4.1.6 Professional.............................................................................57
4.2 LAN................................................................................................. 59
4.2.1 LAN IP ........................................................................................59
4.2.2 DHCP Server............................................................................60
4.2.3 Route .........................................................................................62
4.2.4 IPTV...............................................................................................63
4.3 WAN ............................................................................................... 64
4.3.1 Internet Connection.............................................................64
4.3.2 Port Trigger..............................................................................67
4.3.3 Virtual Server/Port Forwarding........................................69
4.3.4 DMZ............................................................................................72
4.3.5 DDNS .........................................................................................73
4.3.6 NAT Passthrough...................................................................74
4.4 IPv6................................................................................................. 75
4.5 VPN Server................................................................................... 76
4.6 Firewall.......................................................................................... 77
4.6.1 General......................................................................................77
4.6.2 URL Filter ..................................................................................77
4.6.3 Keyword lter .........................................................................78
5
Table of contents
4.6.4 Network Services Filter .......................................................79
4.7 Administration ........................................................................... 81
4.7.1 Operation Mode ....................................................................81
4.7.2 System.......................................................................................82
4.7.3 Firmware Upgrade................................................................83
4.7.4 Restore/Save/Upload Setting ...........................................83
4.8 System Log .................................................................................. 84
5 Utilities 85
5.1 Device Discovery....................................................................... 85
5.2 Firmware Restoration .............................................................. 86
5.3 Setting up your printer server .............................................. 87
5.3.1 ASUS EZ Printer Sharing .....................................................87
5.3.2 Using LPR to Share Printer .................................................91
5.4 Download Master...................................................................... 96
5.4.1 Conguring Bit Torrent download settings.................97
5.4.2 NZB settings............................................................................98
6 Troubleshooting 99
6.1 Basic Troubleshooting............................................................. 99
6.2 Frequently Asked Questions (FAQs) ................................102
Appendices 112
Notices .....................................................................................................112
ASUS Contact information..................................................................126
Networks Global Hotline Information.............................................127
6
1 Getting to know your wireless
router
NOTES:
• If any of the items are damaged or missing, contact ASUS for
technical inquiries and support, Refer to the ASUS Support Hotline
list at the back of this user manual.
• Keep the original packaging material in case you would need future
warranty services such as repair or replacement.
RT-AC68U Wireless Router Network cable (RJ-45)
Power adapter Quick Start Guide
Support CD (Manual)
1.1 Welcome!
Thank you for purchasing an ASUS RT-AC68U Wireless Router!
The ultra-thin and stylish RT-AC68U features a 2.4GHz and 5GHz
dual bands for an unmatched concurrent wireless HD streaming;
SMB server, UPnP AV server, and FTP server for 24/7 le sharing;
a capability to handle 300,000 sessions; and the ASUS Green
Network Technology, which provides up to 70% power-saving
solution.
1.2 Package contents
7
1.3 Your wireless router
8 9 12
10
7
8U
1235
41311
6
14
1LAN 1~4 LED
Off: No power or no physical connection.
On: Has physical connection to a local area network (LAN).
2WAN (Internet) LED
Off: No power or no physical connection.
On: Has physical connection to a wide area network (WAN).
3USB 3.0 / 2.0 LED
Off: No power or no physical connection.
On: Has physical connection to USB 3.0 / 2.0 devices.
42.4GHz LED / 5GHz LED
Off: No 2.4GHz or 5GHz signal.
On:Wireless system is ready.
Flashing: Transmitting or receiving data via wireless connection.
5Power LED
Off: No power.
On: Device is ready.
Flashing slow: Rescue mode
Flashing quick:WPS is processing.
6WPS button
This button launches the WPS Wizard.
8
NOTES:
• Use only the adapter that came with your package. Using other
adapters may damage the device.
• Specications:
DC Power adapter DC Output: +19V with max 1.75A current;
Operating
Temperature 0~40oCStorage 0~70oC
Operating Humidity 50~90% Storage 20~90%
7WI-FI On/Off button
Press this button to turn on /off the Wi-Fi connection.
8Power button
Press this button to power on or off the stystem.
9Power (DC-IN) port
Insert the bundled AC adapter into this port and connect your router to a power source.
10 USB 3.0 / 2.0 ports
Insert USB 3.0 / 2.0 devices such as USB hard disks or USB flash drives into these ports.
Insert your iPad’s USB cable into one of these ports to charge your iPad.
11 WAN (Internet) port
Connect a network cable into this port to establish WAN connection.
12 LED On/Off button
Press this button to turn on/off the backlight LED on the panel.
13 LAN 1 ~ 4 ports
Connect network cables into these ports to establish LAN connection.
14 Reset button
This button resets or restores the system to its factory default settings.
On Off
9
1.4 Positioning your router
For the best wireless signal transmission between the wireless
router and the network devices connected to it, ensure that you:
• Place the wireless router in a centralized area for a maximum
wireless coverage for the network devices.
• Keep the device away from metal obstructions and away from
direct sunlight.
• Keep the device away from 802.11g or 20MHz only Wi-Fi
devices, 2.4GHz computer peripherals, Bluetooth devices,
cordless phones, transformers, heavy-duty motors, fluorescent
lights, microwave ovens, refrigerators, and other industrial
equipment to prevent signal interference or loss.
• Always update to the latest firmware.Visit the ASUS website at
http://www.asus.com to get the latest firmware updates.
• To ensure the best wireless signal, orient the three detachable
antennas as shown in the drawing below.
45°
90°
45°
8U
10
1.5 Setup Requirements
To set up your wireless network, you need a computer that meets
the following system requirements:
• Ethernet RJ-45 (LAN) port (10Base-T/100Base-TX/
1000BaseTX)
• IEEE 802.11a/b/g/n/ac wireless capability
• An installed TCP/IP service
• Web browser such as Internet Explorer, Firefox, Safari, or
Google Chrome
NOTES:
• If your computer does not have built-in wireless capabilities, you may
install an IEEE 802.11a/b/g/n/ac WLAN adapter to your computer to
connect to the network.
• With its dual band technology, your wireless router supports 2.4GHz
and 5GHz wireless signals simultaneously. This allows you to do
Internet-related activities such as Internet surng or reading/writing
e-mail messages using the 2.4GHz band while simultaneously
streaming high-denition audio/video les such as movies or music
using the 5GHz band.
• Some IEEE 802.11n devices that you want to connect to your network
may or may not support 5GHz band. Refer to the device's manual for
specications.
• The Ethernet RJ-45 cables that will be used to connect the network
devices should not exceed 100 meters.
Autres manuels pour RT-AC68U
12
Table des matières
Autres manuels Asus Routeur sans fil
Asus
Asus RT-N10 - Wireless Router - 802.11b/g/n Manuel utilisateur
Asus
Asus RT-N66U Dark Knight Manuel utilisateur
Asus
Asus ZenWiFi XD6S Manuel utilisateur
Asus
Asus WL-500GP_V2 Manuel utilisateur
Asus
Asus DSL-N11 Manuel utilisateur
Asus
Asus WL-320gP - Wireless Access Point Manuel utilisateur
Asus
Asus 4G-N12 B1 Manuel utilisateur
Asus
Asus ROG STRIX GS-AX3000 Manuel utilisateur
Asus
Asus RT-AC68P Manuel utilisateur
Asus
Asus ROG Rapture GT-AC2900 Manuel utilisateur
Asus
Asus RT-N10E EZ N Manuel utilisateur
Asus
Asus RT-AC68U Manuel utilisateur
Asus
Asus RT-AC88U Manuel d'instructions
Asus
Asus WL520GC - Wireless Router Manuel utilisateur
Asus
Asus ZenWiFi AX Mini Manuel utilisateur
Asus
Asus ROG Rapture GT-AXE11000 Manuel utilisateur
Asus
Asus TM-AC1900 Mode d’emploi
Asus
Asus WL-500b Manuel utilisateur
Asus
Asus RX3041 Manuel utilisateur
Asus
Asus ZenWiFi Pro ET12 Manuel utilisateur
