ASROCK X670E PRO RS Manuel utilisateur

Contact Information

If you need to contact ASRock or want to know more about ASRock, you’re welcome

to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer

for further information. For technical questions, please submit a support request

form at https://event.asrock.com/tsd.asp

ASRock Incorporation

e-mail: info@asrock.com.tw

ASRock EUROPE B.V.

e-mail: sales@asrock.nl

ASRock America, Inc.

e-mail: sa[email protected]

Scan the QR code to view more manuals and documents.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 7

1.4 I/O Panel 9

1.5 Block Diagram 11

1.6 802.11ax Wi-Fi 6E Module and ASRock WiFi 2.4/5/6 GHz

Antenna 12

1.7 Graphics Card Holder 13

Chapter 2 Installation 14

2.1 Installing the CPU 15

2.2 Installing the CPU Fan and Heatsink 18

2.3 Installing Memory Modules (DIMM) 27

2.4 Connecting the Front Panel Header 29

2.5 Installing the Motherboard 30

2.6 Installing SATA Drives 31

2.7 Installing a Graphics Card 33

2.8 Connecting Peripheral Devices 35

2.9 Connecting the Power Connectors 36

2.10 Power On 37

2.11 Jumpers Setup 38

2.12 Onboard Headers and Connectors 39

2.13 Smart Switches 55

2.14 Post Status Checker 57

2.15 M.2 SSD Module Installation Guide (M2_1) 58

2.16 M.2 SSD Module Installation Guide (M2_2) 61

2.17 M.2 SSD Module Installation Guide (M2_3 and M2_5) 63

2.18 M.2 SSD Module Installation Guide (M2_4) 66

X670E Pro RS

Chapter 1 Introduction

ank you for purchasing ASRock X670E Pro RS motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

1.1 Package Contents

• ASRock X670E Pro RS Motherboard (ATX Form Factor)

• ASRock X670E Pro RS User Manual

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x Graphics Card Holder (Optional)

• 1 x ASRock WiFi 2.4/5/6 GHz Antenna (Optional)

• 4 x Screws for M.2 Sockets (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

1.2 Specications

Platform • ATX Form Factor

• 8 Layer PCB

CPU • Supports AMD AM5 Socket RyzenTM 7000 Series Desktop

Processors

Chipset • AMD X670

Memory • Dual Channel DDR5 Memory Technology

• 4 x DDR5 DIMM Slots

• Supports DDR5 ECC/non-ECC, un-buered memory up to

6600+(OC)*

• Max. capacity of system memory: 128GB

• Supports Extreme Memory Prole (XMP) and EXTended

Proles for Overclocking (EXPO) memory modules

* Please refer to Memory Support List on ASRock's website for

more information. (http://www.asrock.com/)

Expansion

Slot

CPU:

• 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*

Chipset:

• 2 x PCIe 4.0 x1 Slots (PCIE2 and PCIE3)*

• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe

WiFi module

* Supports NVMe SSD as boot disks

• 15μ Gold Contact in VGA PCIe Slot (PCIE1)

Graphics • Integrated AMD RDNATM 2 graphics (Actual support may

vary by CPU)

• 1 x HDMI 2.1 TMDS Compatible, supports HDR, HDCP 2.3

and max. resolution up to 4K 60Hz

• 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP

2.3 and max. resolution up to 4K 120Hz

Audio • 7.1 CH HD Audio (Realtek ALC897 Audio Codec)

• Nahimic Audio

X670E Pro RS

LAN • 2.5 Gigabit LAN 10/100/1000/2500 Mb/s

• Dragon RTL8125BG

• Supports Dragon 2.5G LAN Soware

- Smart Auto Adjust Bandwidth Control

- Visual User Friendly UI

- Visual Network Usage Statistics

- Optimized Default Setting for Game, Browser, and

Streaming Modes

- User Customized Priority Control

Wireless

LAN

• 802.11ax Wi-Fi 6E Module

• Supports IEEE 802.11a/b/g/n/ac/ax

• Supports Dual-Band 2x2 with extended 6GHz band* sup-

port

* Wi-Fi 6E (6GHz band) will be supported by Microso®

Windows® 11. e availability will depend on the dierent

regulation status of each country and region. It will be activated

(for supported countries) through Windows Update and so-

ware updates once available.

* A 6GHz compatible router is required for 6E functionality.

• 2 antennas to support 2 (Transmit) x 2 (Receive) diversity

technology

• Supports Bluetooth + High speed class II

• Supports MU-MIMO

USB • 1 x USB 3.2 Gen2x2 Type-C (Front)

• 1 x USB 3.2 Gen2 Type-C (Rear)

• 1 x USB 3.2 Gen2 Type-A (Rear)

• 8 x USB 3.2 Gen1 (4 Rear, 4 Front)

• 8 x USB 2.0 (4 Rear, 4 Front)

* All USB ports support ESD Protection

Rear Panel

I/O

• 2 x Antenna Ports

• 1 x HDMI Port

• 1 x DisplayPort 1.4

• 1 x Optical SPDIF Out Port

• 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver)

• 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver)

• 4 x USB 3.2 Gen1 Ports

• 4 x USB 2.0 Ports

• 1 x RJ-45 LAN Port

• 1 x BIOS Flashback Button

• 1 x Line Out Jack (Gold Audio Jack)

• 1 x Microphone Input Jack (Gold Audio Jack)

Storage CPU:

• 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280

PCIe Gen5x4 (128 Gb/s) mode*

• 1 x Hyper M.2 Socket (M2_2, Key M), supports type

2260/2280 PCIe Gen4x4 (64 Gb/s) mode*

Chipset:

• 1 x Hyper M.2 Socket (M2_3, Key M), supports type

2260/2280 PCIe Gen4x4 (64 Gb/s) mode*

• 1 x M.2 Socket (M2_4, Key M), supports type

2242/2260/2280 SATA3 6.0 Gb/s & PCIe Gen3x2 (16 Gb/s)

modes*

• 1 x Hyper M.2 Socket (M2_5, Key M), supports type

2260/2280 PCIe Gen4x4 (64 Gb/s) mode*

• 6 x SATA3 6.0 Gb/s Connectors

* Supports NVMe SSD as boot disks

* Supports ASRock U.2 Kit

RAID • Supports RAID 0, RAID 1 and RAID 10 for SATA storage

devices

• Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe

storage devices

X670E Pro RS

Connector • 1 x SPI TPM Header

• 1 x Power LED and Speaker Header

• 1 x RGB LED Header*

• 3 x Addressable LED Headers**

• 1 x CPU Fan Connector (4-pin)***

• 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan

Speed Control)****

• 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan

Speed Control)*****

• 1 x 24 pin ATX Power Connector (Hi-Density Power

Connector)

• 1 x 8 pin 12V Power Connector (Hi-Density Power

Connector)

• 1 x 4 pin 12V Power Connector (Hi-Density Power

Connector)

• 1 x Front Panel Audio Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

• 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)

• 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)

* Supports in total up to 12V/3A, 36W LED Strip

** Support in total up to 5V/3A, 15W LED Strip

*** CPU_FAN1 supports the fan power up to 1A (12W).

**** CPU_FAN2/WP supports the fan power up to 2A (24W).

***** CHA_FAN1~4/WP support the fan power up to 2A (24W).

***** CPU_FAN2/WP and CHA_FAN1~4/WP can auto detect

if 3-pin or 4-pin fan is in use.

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

OS • Microso® Windows® 10 64-bit / 11 64-bit

Certica-

tions

• FCC, CE

• ErP/EuP ready (ErP/EuP ready power supply is required)

Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using third-party

overclocking tools. Overclocking may aect your system’s stability, or even cause damage to

the components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

* For detailed product information, please visit our website: http://www.asrock.com
