ASROCK H61M-DEL Manuel utilisateur

H61M-DEL

User Manual

Version 1.1

Published May 2012

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1 Introduction ......................................................... 5

1.1 Package Contents ......................................................... 5

1.2 Specications ................................................................. 6

1.3 Motherboard Layout ....................................................... 12

1.4 I/O Panel ...................................................................... 13

2 Installation ........................................................... 14

2.1 Screw Holes ................................................................... 14

2.2 Pre-installation Precautions ......................................... 14

2.3 CPU Installation ............................................................. 15

2.4 Installation of Heatsink and CPU fan ............................. 17

2.5 Installation of Memory Modules (DIMM) ........................ 18

2.6 Expansion Slots (PCI Express Slots)................................. 19

2.7 Dual Monitor and Surround Display Features ................ 20

2.8 Jumpers Setup .......................................................... 23

2.9 Onboard Headers and Connectors ............................ 24

2.10 Serial ATA (SATA) / Serial ATAII (SATAII) Hard Disks

Installation .................................................................. 28

2.11 Hot Plug Function for SATA / SATAII HDDs .................. 28

2.12 SATA / SATAII HDD Hot Plug Feature and Operation

Guide ......................................................................... 29

2.13 Driver Installation Guide ............................................ 31

2.14 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

/ XP / XP 64-bit Without RAID Functions ................... 31

2.14.1 Installing Windows® XP / XP 64-bit Without RAID

Functions............................................................ 31

2.14.2 Installing Windows® 7 / 7 64-bit / VistaTM /

VistaTM 64-bit Without RAID Functions ............... 32

3 UEFI SETUP UTILITY ................................................. 33

3.1 Introduction .................................................................... 33

3.1.1 UEFI Menu Bar .................................................... 33

3.1.2 Navigation Keys ................................................... 34

3.2 Main Screen ................................................................... 34

3.3 OC Tweaker Screen ...................................................... 35

3.4 Advanced Screen ........................................................... 39

3.4.1 CPU Conguration ............................................... 40

3.4.2 North Bridge Conguration................................... 42

3.4.3 South Bridge Conguration .................................. 43

3.4.4 Storage Conguration .......................................... 44

3.4.5 Intel(R) Rapid Start Technology ........................... 45

3.4.6 Intel(R) Smart Connect Technology ..................... 46

3.4.7 Super IO Conguration ........................................ 47

3.4.8 ACPI Conguration............................................... 48

3.4.9 USB Conguration ............................................... 49

3.5 Hardware Health Event Monitoring Screen ................... 50

3.6 Boot Screen ................................................................... 51

3.7 Security Screen ............................................................. 52

3.8 Exit Screen .................................................................... 53

4 Software Support ................................................. 54

4.1 Install Operating System ................................................ 54

4.2 Support CD Information ................................................. 54

4.2.1 Running Support CD ............................................ 54

4.2.2 Drivers Menu ........................................................ 54

4.2.3 Utilities Menu........................................................ 54

4.2.4 Contact Information .............................................. 54

Chapter 1: Introduction

Thank you for purchasing ASRock H61DEL motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration

guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock H61DEL Motherboard

(ATX Form Factor: 12.0-in x 6.8-in, 30.5 cm x 17.3 cm)

ASRock H61DEL Quick Installation Guide

ASRock H61DEL Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-

bit, it is recommended to set the BIOS option in Storage Conguration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

1.2 Specifications

Platform - ATX Form Factor: 12.0-in x 6.8-in, 30.5 cm x 17.3 cm

- Solid Capacitor for CPU power

CPU - Supports 3rd and 2nd Generation Intel® CoreTM i7 / i5 / i3 in

LGA1155 Package

- Supports Intel® Turbo Boost 2.0 Technology

- Supports K-Series unlocked CPU

- Supports Hyper-Threading Technology (see CAUTION 1)

Chipset - Intel® H61

- Supports Intel® Rapid Start Technology and Smart Connect

Technology

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 2)

- 2 x DDR3 DIMM slots

- Supports DDR3 1600/1333/1066 non-ECC, un-buffered

memory (DDR3 1600 with Intel® Ivy Bridge CPU, DDR3

1333 with Intel® Sandy Bridge CPU)

- Max. capacity of system memory: 16GB (see CAUTION 3)

- Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2 with

Intel® Ivy Bridge CPU

Expansion Slot - 1 x PCI Express 3.0 x16 slot (blue @ x16 mode)

* PCIE 3.0 is only supported with Intel® Ivy Bridge CPU. With

Intel® Sandy Bridge CPU, it only supports PCIE 2.0.

- 5 x PCI Express 2.0 x1 slots

Graphics * Intel® HD Graphics Built-in Visuals and the VGA outputs

can be supported only with processors which are GPU

integrated.

- Supports Intel® HD Graphics Built-in Visuals: Intel® Quick

Sync Video 2.0, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 2500/4000

with Intel® Ivy Bridge CPU

- Supports Intel® HD Graphics Built-in Visuals: Intel® Quick

Sync Video, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® HD Graphics 2000/3000, Intel® Advanced

Vector Extensions (AVX) with Intel® Sandy Bridge CPU

- Pixel Shader 5.0, DirectX 11 with Intel® Ivy Bridge CPU.

Pixel Shader 4.1, DirectX 10.1 with Intel® Sandy Bridge

CPU.

- Max. shared memory 1760MB with Intel® Ivy Bridge CPU.

Max. shared memory 1759MB with Intel® Sandy Bridge

CPU. (see CAUTION 4)

- Dual VGA Output: support HDMI and D-Sub ports by

independent display controllers

- Supports HDMI 1.4a Technology with max. resolution up to

1920x1200 @ 60Hz

- Supports D-Sub with max. resolution up to 2048x1536 @

75Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI

(Compliant HDMI monitor is required) (see CAUTION 5)

- Supports HDCP function with HDMI port

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with HDMI port

Audio - 5.1 CH HD Audio (VIA® VT1705 Audio Codec)

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efcient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x D-Sub Port

- 1 x HDMI Port

- 6 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

Connector - 4 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and

Hot Plug functions

- 1 x IR header

- 1 x COM port header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

BIOS Feature - 32Mb AMI BIOS

- AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or

using the third-party overclocking tools. Overclocking may affect your system

stability, or even cause damage to the components and devices of your system.

It should be done at your own risk and expense. We are not responsible for possible

damage caused by overclocking.

- Supports jumperfree

- SMBIOS 2.3.1 Support

- IGPU, DRAM, PCH, CPU PLL, VTT, VCCSA Voltage

Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

Multimedia Suite - OEM

Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 6)

- ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 7)

- ASRock APP Charger (see CAUTION 8)

- ASRock SmartView (see CAUTION 9)

- ASRock XFast USB (see CAUTION 10)

- ASRock XFast LAN (see CAUTION 11)

- ASRock XFast RAM (see CAUTION 12)

- Hybrid Booster:

- ASRock U-COP (see CAUTION 13)

- Boot Failure Guard (B.F.G.)

- Combo Cooler Option (C.C.O.) (see CAUTION 14)

- Good Night LED

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan (Allow Chassis Fan Speed

Auto-Adjust by CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS - Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

/ XP / XP 64-bit compliant

Certications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 15)

* For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. About the setting of “Hyper Threading Technology”, please check page

40.

2. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 18 for proper installation.

3. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows® 7 /

VistaTM / XP. For Windows® OS with 64-bit CPU, there is no such limita-

tion. You can use ASRock XFast RAM to utilize the memory that Win-

dows® cannot use.

4. The maximum shared memory size is dened by the chipset vendor and

is subject to change. Please check Intel® website for the latest informa-

tion.

5. xvYCC and Deep Color are only supported under Windows® 7 64-bit /

7. Deep Color mode will be enabled only if the display supports 12bpc

in EDID. HBR is supported under Windows® 7 64-bit / 7 / VistaTM 64-bit /

VistaTM.

6. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune

different system functions in a user-friendly interface, which is including

Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In

Hardware Monitor, it shows the major readings of your system. In Fan

Control, it shows the fan speed and temperature for you to adjust. In

Overclocking, you are allowed to overclock CPU frequency for optimal

system performance. In OC DNA, you can save your OC settings as a

prole and share with your friends. Your friends then can load the OC

prole to their own system to get the same OC settings. In IES (Intelligent

Energy Saver), the voltage regulator can reduce the number of output

phases to improve efciency when the CPU cores are idle without

sacrificing computing performance. Please visit our website for the

operation procedures of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

7. ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems rst like MS-DOS or Windows®. With

this utility, you can press <F6> key during the POST or press <F2> key to

BIOS setup menu to access ASRock Instant Flash. Just launch this tool

and save the new BIOS le to your USB ash drive, oppy disk or hard

drive, then you can update your BIOS only in a few clicks without prepar-

ing an additional oppy diskette or other complicated ash utility. Please

be noted that the USB ash drive or hard drive must use FAT32/16/12 le

system.

8. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful

solution for you - ASRock APP Charger. Simply installing the APP Char-

ger driver, it makes your iPhone charged much quickly from your com-

puter and up to 40% faster than before. ASRock APP Charger allows you

to quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Sus-

pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP

Charger driver installed, you can easily enjoy the marvelous charging

experience than ever.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

9. SmartView, a new function of internet browser, is the smart start page for

IE that combines your most visited web sites, your history, your Facebook

friends and your real-time newsfeed into an enhanced view for a more

personal Internet experience. ASRock motherboards are exclusively

equipped with the SmartView utility that helps you keep in touch with

friends on-the-go. To use SmartView feature, please make sure your

OS version is Windows® 7 / 7 64 bit / VistaTM / VistaTM 64 bit, and your

browser version is IE8. ASRock website: http://www.asrock.com/Feature/

SmartView/index.asp

10. ASRock XFast USB can boost USB storage device performance. The

performance may depend on the property of the device.

11. ASRock XFast LAN provides a faster internet access, which includes

below benefits. LAN Application Prioritization: You can configure your

application priority ideally and/or add new programs. Lower Latency in

Game: After setting online game priority higher, it can lower the latency in

game. Trafc Shaping: You can watch Youtube HD video and download

les simultaneously. Real-Time Analysis of Your Data: With the status

window, you can easily recognize which data streams you are currently

transferring.

12. ASRock XFast RAM is a new function that is included into ASRock Ex-

treme Tuning Utility (AXTU). It fully utilizes the memory space that cannot

be used under Windows® OS 32-bit CPU. ASRock XFast RAM shortens

the loading time of previously visited websites, making web surng faster

than ever. And it also boosts the speed of Adobe Photoshop 5 times

faster. Another advantage of ASRock XFast RAM is that it reduces the

frequency of accessing your SSDs or HDDs in order to extend their lifes-

pan.

13. While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the

motherboard functions properly and unplug the power cord, then plug it

back again. To improve heat dissipation, remember to spray thermal

grease between the CPU and the heatsink when you install the PC sys-

tem.

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK P43TWINS1600 Manuel utilisateur

ASROCK

ASROCK 775i65G R2.0 Manuel utilisateur

ASROCK

ASROCK 890GX Extreme3 Manuel utilisateur

ASROCK

ASROCK 970 Extreme3 R2.0 Manuel utilisateur

ASROCK

ASROCK H81M-DGS Manuel utilisateur

ASROCK

ASROCK Z87E-ITX Manuel utilisateur

ASROCK

ASROCK 939Dual-SATA2 Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z270 Professional Gaming i7 Series Manuel utilisateur

ASROCK

ASROCK B660M-ITX/eDP Manuel utilisateur

ASROCK

ASROCK FM2A75M-ITX R2.0 Manuel utilisateur

ASROCK

ASROCK AOD790GX-128M Manuel utilisateur

ASROCK

ASROCK K8N68PV-GLAN Manuel utilisateur

ASROCK

ASROCK IMB-154 Manuel utilisateur

ASROCK

ASROCK Z77 Extreme4 Manuel utilisateur

ASROCK

ASROCK M3A780GXH/128M Manuel utilisateur

ASROCK

ASROCK GENOAD8HM3 Manuel utilisateur

ASROCK

ASROCK Fatal1ty B450 Manuel utilisateur

ASROCK

ASROCK Z87 OC Formula/ac Manuel utilisateur

ASROCK

ASROCK NUC-1165G7 Manuel utilisateur

ASROCK

ASROCK IMB-X1233-WV Manuel utilisateur

ASROCK

ASROCK Z97 Extreme9 Manuel utilisateur

ASROCK

ASROCK H510M-HVS R2.0 Manuel utilisateur

ASROCK

ASROCK B85M-HDS Manuel utilisateur

ASROCK

ASROCK FM2A88M Extreme4 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
