ASROCK B85M Pro4 Manuel utilisateur

Version 1.0

Published March 2013

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMITM and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

B85M Pro4

English

Motherboard Layout

Intel

B85

DDR3_A2 (64 bit, 240-pin module)

DDR3_A1 (64 bit, 240-pin module)

DDR3_B2 (64 bit, 240-pin module)

DDR3_B1 (64 bit, 240-pin module)

ATX12V 1

CMOS

Battery

Super

I/O

USB 2.0

T: USB0

B: USB1

PS2

Keyboar d

ATXPWR1

USB10_11

LAN

Top:

RJ-45

USB 2.0

T: USB4

B: USB5

Top:

Cent ra l/ Bass

Cent er :

REAR S PK

Top:

LINE I N

Cent er :

FRON T

Bott om :

Opti ca l

SPDI F

Bott om :

MIC IN

CLRCMOS 1

SPE AKER 1

IR1

HDL ED RES ET

PLE D PWRB TN

PANEL 1

USB6_7

USB8 _9

COM1

HD_AUDIO1

B85M Pro4

SATA_ 0_ 1 SATA_ 2_ 3 SATA_ 4_ 5

CHA_FAN1

CHA_FAN2

PCI1

RoHS

CPU_FA N1

CPU _FA N2

64Mb

BIOS

HDMI1

VGA1

DVI1

PCI2

USB 3.0

T: USB2

B: USB3

Aud io

COD EC

SPD IF1 _OUT 1

PCIE1

XFast USB

XFast RAM

XFast LAN

PCI Express 3.0

Front USB 3.0

PCIE2

PWR _FA N1

TPM S1

LPT1

CI1

English

No. Description

1 Power Fan Connector (PWR_FAN1)

2 CPU Fan Connector (CPU_FAN2)

3 CPU Fan Connector (CPU_FAN1)

4 ATX 12V Power Connector (ATX12V1)

5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)

6 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)

7 ATX Power Connector (ATXPWR1)

8 USB 3.0 Header (USB10_11)

9 SATA2 Connectors (SATA_4_5)

10 SATA3 Connectors (SATA_2_3)

11 SATA3 Connectors (SATA_0_1)

12 System Panel Header (PANEL1)

13 Chassis Speaker Header (SPEAKER1)

14 Infrared Module Header (IR1)

15 Chassis Fan Connector (CHA_FAN1)

16 USB 2.0 Header (USB8_9)

17 USB 2.0 Header (USB6_7)

18 TPM Header (TPMS1)

19 Chassis Intrusion Header (CI1)

20 Print Port Header (LPT1)

21 COM Port Header (COM1)

22 Clear CMOS Jumper (CLRCMOS1)

23 Front Panel Audio Header (HD_AUDIO1)

24 SPDIF Out Connector (SPDIF_OUT)

25 Chassis Fan Connector (CHA_FAN2)

B85M Pro4

English

I/O Panel

No. Description No. Description

1 USB 2.0 Ports (USB01) 8 Microphone (Pink)

2 D-Sub Port 9 Optical SPDIF Out Port

3 LAN RJ-45 Port* 10 USB 2.0 Ports (USB_45)

4 Central / Bass (Orange) 11 USB 3.0 Ports (USB_23)

5 Rear Speaker (Black) 12 HDMI Port

6 Line In (Light Blue) 13 DVI-D Port

7 Front Speaker (Lime)** 14 PS/2 Keyboard Port

1 2 3 5

891011121314

English

* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

** If you use a 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”. See the table below

for connection details in accordance with the type of speaker you use.

Audio Output

Channels

Front Speaker

(No. 7)

Rear Speaker

(No. 5)

Central / Bass

(No. 4)

Line In

(No. 6)

2V -- -- --

4V V -- --

6V V V --

8VVVV

To enable Multi-Streaming, you need to connect a front panel audio cable to the front

panel audio header. Aer restarting your computer, you will nd the “Mixer” tool

on your system. Please select “Mixer ToolBox” , click “Enable playback multi-

streaming”, and click “ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are

allowed to select “Realtek HDA Primary output” to use the Rear Speaker, Central/

Bass, and Front Speaker, or select “Realtek HDA Audio 2nd output” to use the front

panel audio.

ACT/LINK LED

SPEED LED

LAN Port

B85M Pro4

English

Chapter 1 Introduction

ank you for purchasing ASRock B85M Pro4 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality

and endurance.

1.1 Package Contents

• ASRock B85M Pro4 Motherboard (Micro ATX Form Factor)

• ASRock B85M Pro4 Quick Installation Guide

• ASRock B85M Pro4 Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • Micro ATX Form Factor

• All Solid Capacitor design

CPU • Supports 4th Generation Intel® CoreTM i7 / i5 / i3 / Xeon® /

Pentium® / Celeron® in LGA1150 Package

• Digi Power Design

• 4 Power Phase Design

• Supports Intel® Turbo Boost 2.0 Technology

Chipset • Intel® B85

• Supports Intel® Small Business Advantage 2.0

Memory • Dual Channel DDR3 Memory Technology

• 4 x DDR3 DIMM slots

• Supports DDR3 1600/1333/1066 non-ECC, un-buered

memory

• Max. capacity of system memory: 32GB

(see CAUTION)

• Supports Intel® Extreme Memory Prole (XMP)1.3/1.2

Expansion

Slot

• 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)

• 1 x PCI Express 2.0 x16 slot (PCIE2: x4 mode)

• 2 x PCI slots

• Supports AMD Quad CrossFireXTM and CrossFireXTM

Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU integrated.

• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 4600

• Pixel Shader 5.0, DirectX 11.1

• Max. shared memory 1792MB

• ree VGA Output options: D-Sub, DVI-D and HDMI

B85M Pro4

English

• Supports Triple Monitors

• Supports HDMI Technology with max. resolution up to

1920x1200 @ 60Hz

• Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

monitor is required)

• Supports HDCP function with DVI-D and HDMI ports

• Supports Full HD 1080p Blu-ray (BD) playback with DVI-D

and HDMI ports

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

• Premium Blu-ray audio support

LAN • Gigabit LAN 10/100/1000 Mb/s

• Giga PHY Intel® I217V

• Supports Intel® Remote Wake Technology

• Supports Wake-On-LAN

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Keyboard Port

• 1 x D-Sub Port

• 1 x DVI-D Port

• 1 x HDMI Port

• 1 x Optical SPDIF Out Port

• 4 x USB 2.0 Ports

• 2 x USB 3.0 Ports

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front

Speaker / Microphone

English

Storage • 4 x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and “Hot

Plug” functions

• 2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and “Hot

Plug” functions

Connector • 1 x IR header

• 1 x Print Port header

• 1 x COM port header

• 1 x Chassis Intrusion header

• 1 x TPM header

• 2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)

• 2 x Chassis Fan connectors (1 x 4-pin, 1 x 3-pin)

• 1 x Power Fan connector (3-pin)

• 1 x 24 pin ATX power connector

• 1 x 8 pin 12V power connector

• 1 x Front panel audio connector

• 1 x SPDIF Out connector

• 2 x USB 2.0 headers (support 4 USB 2.0 ports)

• 1 x USB 3.0 header (supports 2 USB 3.0 ports)

BIOS

Feature

• 64Mb AMI UEFI Legal BIOS with Multilingual GUI support

• ACPI 1.1 Compliance Wake Up Events

• SMBIOS 2.3.1 Support

• CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjust-

ment

Support

• Drivers, Utilities, AntiVirus Soware (Trial Version), Cy-

berLink MediaEspresso 6.5 Trial, Google Chrome Browser

and Toolbar, Start8, MeshCentral, Splashtop Streamer, Intel®

Extreme Tuning Utility (IXTU)

Hardware

Monitor

• CPU/Chassis Temperature Sensing

• CPU/Chassis/Power Fan Tachometer

• CPU/Chassis Quiet Fan (Allow Chassis Fan Speed Auto-

Adjust by CPU Temperature)

• CPU/Chassis Fan Multi-Speed Control

• CASE OPEN detection

Autres manuels pour B85M Pro4

Table des matières

Langues :

Autres manuels ASROCK Carte mère

ASROCK

ASROCK P4AL-8X Manuel utilisateur

ASROCK

ASROCK X570 Phantom Gaming-ITX/TB3 Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z270 Professional Gaming i7 Series Manuel utilisateur

ASROCK

ASROCK X79 Extreme6/GB Manuel utilisateur

ASROCK

ASROCK X299 Designer+ Manuel utilisateur

ASROCK

ASROCK H110M-DVP Manuel utilisateur

ASROCK

ASROCK Z490 Taichi Manuel utilisateur

ASROCK

ASROCK B460M Steel Legend Manuel utilisateur

ASROCK

ASROCK 775XFire-RAID Manuel utilisateur

ASROCK

ASROCK ALIVENF5-ESATA2 -2943 - Manuel utilisateur

ASROCK

ASROCK Z690 AQUA OC Manuel utilisateur

ASROCK

ASROCK K7VM3 Manuel utilisateur

ASROCK

ASROCK P65iCafe Manuel utilisateur

ASROCK

ASROCK G41M-PS Manuel utilisateur

ASROCK

ASROCK 775i65G Manuel utilisateur

ASROCK

ASROCK H310CM-HDV Manuel utilisateur

ASROCK

ASROCK X79 Extreme6 Manuel utilisateur

ASROCK

ASROCK B85M BTC Manuel utilisateur

ASROCK

ASROCK AM1H-ITX Manuel utilisateur

ASROCK

ASROCK H110M-HDS Manuel utilisateur

ASROCK

ASROCK P43DE3 - V1.0 Manuel utilisateur

ASROCK

ASROCK 4Core1333-GLAN Manuel utilisateur

ASROCK

ASROCK Z170 OC FORMULA Manuel utilisateur

ASROCK

ASROCK Z87M OC Formula Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
