English

A520M-HDV

A520M-HVS

AMD

Promontory

A520

A520M-HDV

BIOS

ROM

ATXPWR1

FSB800

DDR4_A1 (64 bit, 288-pin module)

DDR4_A2 (64 bit, 288-pin module)

Super

I/O

LAN

AUDIO

CODEC

PCIE2

PCIE1

HD_AUDIO1

CPU_FAN1

COM1

USB 2.0

T: USB1

B: USB2

PS2

Keyboard/

Mouse

CMOS

Battery

USB3_5_6

CHA_FAN2

HDLED RESET

PLED PWRBTN

PANEL1

9813

SPK_CI1

USB 3.2 Gen1

T: USB1

B: USB2

Top:

LINE IN

Center:

FRONT

Bottom:

MIC IN

RJ-45 LAN

USB 3.2 Gen1

T: USB3

B: USB4

ATX12V

SOCKETAM4

CHA_FAN1

M2_1

USB_5_6

USB_3_4

12 11

RoHS

SPI_TPM_J1

HDMI1

CLRCMOS1

Ultra M.2

PCIe Gen3 x4

SATA3_3

SATA3_4

SATA3_1

SATA3_2

Motherboard Layout

A520M-HDV:

English

AMD

Promontory

A520

A520M-HVS

BIOS

ROM

ATXPWR1

FSB800

DDR4_A1 (64 bit, 288-pin module)

DDR4_A2 (64 bit, 288-pin module)

Super

I/O

LAN

AUDIO

CODEC

PCIE2

PCIE1

HD_AUDIO1

CPU_FAN1

COM1

USB 2.0

T: USB1

B: USB2

PS2

Keyboard/

Mouse

CMOS

Battery

USB3_5_6

CHA_FAN2

HDLED RESET

PLED PWRBTN

PANEL1

SPK_CI1

USB 3.2 Gen1

T: USB1

B: USB2

Top:

LINE IN

Center:

FRONT

Bottom:

MIC IN

RJ-45 LAN

USB 3.2 Gen1

T: USB3

B: USB4

ATX12V

SOCKETAM4

CHA_FAN1

M2_1

USB_5_6

USB_3_4

RoHS

SPI_TPM_J1

HDMI1

CLRCMOS1

Ultra M.2

PCIe Gen3 x4

981314 12 11

SATA3_3

SATA3_4

SATA3_1

SATA3_2

A520M-HVS:

English

A520M-HDV

A520M-HVS

No. Description

1 ATX 12V Power Connector (ATX12V1)

2 CPU Fan Connector (CPU_FAN1)

3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)

4 ATX Power Connector (ATXPWR1)

5 USB 3.2 Gen1 Header (USB3_5_6)

6SATA3 Connector (SATA3_3) (Upper), SATA3 Connector (SATA3_4) (Lower)

7SATA3 Connector (SATA3_4) (Upper), SATA3 Connector (SATA3_2) (Lower)

8 System Panel Header (PANEL1)

9 Chassis Intrusion and Speaker Header (SPK_CI1)

10 Chassis Fan Connector (CHA_FAN2)

11 USB 2.0 Header (USB_3_4)

12 USB 2.0 Header (USB_5_6)

13 COM Port Header (COM1)

14 Clear CMOS Jumper (CLRCMOS1)

15 Front Panel Audio Header (HD_AUDIO1)

16 SPI TPM Header (SPI_TPM_J1)

17 Chassis Fan Connector (CHA_FAN1)

English

I/O Panel

No. Description No. Description

1 USB 2.0 Ports (USB_12) 7 USB 3.2 Gen1 Ports (USB3_34)

2 D-Sub Port 8 USB 3.2 Gen1 Ports (USB3_12)

3 LAN RJ-45 Port* 9 DVI-D Port

4 Line In (Light Blue)** 10 HDMI Port

5 Front Speaker (Lime)** 11 PS/2 Mouse/Keyboard Port

6 Microphone (Pink)**

No. Description No. Description

1 USB 2.0 Ports (USB_12) 6 Microphone (Pink)**

2 D-Sub Port 7 USB 3.2 Gen1 Ports (USB3_34)

3 LAN RJ-45 Port* 8 USB 3.2 Gen1 Ports (USB3_12)

4 Line In (Light Blue)** 9 HDMI Port

5 Front Speaker (Lime)** 10 PS/2 Mouse/Keyboard Port

9 6710

A520M-HDV:

A520M-HVS:

10 6711 9

English

A520M-HDV

A520M-HVS

* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

ACT/LINK LED

SPEED LED

LAN Port

** Function of the Audio Ports in 7.1-channel Conguration:

Port Function

Light Blue (Rear panel) Rear Speaker Out

Lime (Rear panel) Front Speaker Out

Pink (Rear panel) Central /Subwoofer Speaker Out

Lime (Front panel) Side Speaker Out

English

Chapter 1 Introduction

ank you for purchasing ASRock A520M-HDV / A520M-HVS motherboard,

a reliable motherboard produced under ASRock’s consistently stringent quality

control. It delivers excellent performance with robust design conforming to

ASRock’s commitment to quality and endurance.

1.1 Package Contents

• ASRock A520M-HDV / A520M-HVS Motherboard (Micro ATX Form Factor)

• ASRock A520M-HDV / A520M-HVS Quick Installation Guide

• ASRock A520M-HDV / A520M-HVS Support CD

• 1 x I/O Panel Shield

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x Screw for M.2 Socket (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

English

A520M-HDV

A520M-HVS

1.2 Specications

Platform • Micro ATX Form Factor

• Solid Capacitor design

CPU • Supports 3rd Gen AMD AM4 Ryzen™ / future AMD Ryzen™

Processors (3000 and 4000 Series Processors)*

* Not compatible with AMD Ryzen™ 5 3400G and Ryzen™ 3

3200G.

• 6 Power Phase design

Chipset • AMD A520

Memory • Dual Channel DDR4 Memory Technology

• 2 x DDR4 DIMM Slots

• AMD Ryzen series CPUs (Matisse) support DDR4

4600+(OC)/4533(OC)/4466(OC)/4400(OC)/4333

(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000

(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466|

(OC)/3200/2933/2667/2400/2133 ECC & non-ECC, un-

buered memory*

• AMD Ryzen series APUs (Renoir) support DDR4 4733+

(OC)/4666(OC)/4600(OC)/4533(OC)/4466(OC)/4400(OC)/

4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866

(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3200/2933/

2667/2400/2133 ECC & non-ECC, un-buered memory*

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

* Please refer to page 21 for DDR4 UDIMM maximum

frequency support.

• Max. capacity of system memory: 64GB

• Supports Extreme Memory Prole (XMP) memory modules

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

• 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*

* Supports NVMe SSD as boot disks

• 1 x PCI Express 3.0 x1 Slot

English

Graphics • Integrated AMD RadeonTM Vega Series Graphics in Ryzen

Series APU*

* Actual support may vary by CPU

• DirectX 12, Pixel Shader 5.0

• Shared memory default 2GB. Max Shared memory supports

up to 16GB.

* e Max shared memory 16GB requires 32GB system

memory installed.

A520M-HDV:

• ree graphics output options: D-Sub, DVI-D and HDMI

• Supports Triple Monitor

• Supports HDMI 2.1 with max. resolution up to 4K x 2K

(4096x2160) @ 60Hz

• Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant

HDMI monitor is required)

• Supports HDR (High Dynamic Range) with HDMI 2.1

• Supports HDCP 2.3 with DVI-D and HDMI 2.1 Ports

• Supports 4K Ultra HD (UHD) playback with HDMI 2.1

Port

• Supports Microso PlayReady®

A520M-HVS:

• Dual graphics output: support D-Sub and HDMI ports by

independent display controllers

• Supports HDMI 2.1 with max. resolution up to 4K x 2K

(4096x2160) @ 60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant

HDMI monitor is required)

• Supports HDR (High Dynamic Range) with HDMI 2.1

• Supports HDCP 2.3 with HDMI 2.1 Port

• Supports 4K Ultra HD (UHD) playback with HDMI 2.1

Port

• Supports Microso PlayReady®

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels ASROCK Carte mère

ASROCK

ASROCK P4VM900-SATA2 Manuel utilisateur

ASROCK

ASROCK 775i65GV Manuel utilisateur

ASROCK

ASROCK X570S PG Riptide Manuel utilisateur

ASROCK

ASROCK PV530 Manuel utilisateur

ASROCK

ASROCK A68M-ITX Manuel utilisateur

ASROCK

ASROCK Z77TM-ITX Manuel utilisateur

ASROCK

ASROCK X299E-ITX/ac Manuel utilisateur

ASROCK

ASROCK K7S41 Manuel utilisateur

ASROCK

ASROCK CONROE1333-D667 Manuel utilisateur

ASROCK

ASROCK Z690M Phantom Gaming 4 Manuel utilisateur

ASROCK

ASROCK Z68M-ITX/HT Manuel utilisateur

ASROCK

ASROCK H61M-ITX Manuel utilisateur

ASROCK

ASROCK A55M-VS Manuel utilisateur

ASROCK

ASROCK A780GXH-128M Manuel utilisateur

ASROCK

ASROCK K7VT4A PRO Manuel utilisateur

ASROCK

ASROCK H67M-GE Manuel utilisateur

ASROCK

ASROCK J5005-ITX Manuel utilisateur

ASROCK

ASROCK ALIVENF5-VSTA Manuel utilisateur

ASROCK

ASROCK H87M Pro4/ASM Manuel utilisateur

ASROCK

ASROCK FM2A55 Pro Manuel utilisateur

ASROCK

ASROCK H61M-VS - ANNEXE 811 Manuel utilisateur

ASROCK

ASROCK IMB-391 Manuel de service

ASROCK

ASROCK 890FX Deluxe3 Manuel utilisateur

ASROCK

ASROCK H310M-STX Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
