ASROCK A55M-VS Manuel utilisateur

A55M-VS

User Manual

Version 1.1

Published May 2013

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for



Disclaimer:

          -

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-





any indirect, special, incidental, or consequential damages (including damages for



even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

 

 

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic



passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1. Introduction................................................................. 5

1.1 Package Contents ..................................................................... 5

  ............................................................................. 6

1.3 Motherboard Layout ................................................................. 11

1.4 I/O Panel .................................................................................. 12

2. Installation................................................................... 13

Pre-installation Precautions ................................................................ 13

2.1 CPU Installation ......................................................................... 14

2.2 Installation of CPU Fan and Heatsink ...................................... 14

   .................................... 15

  ........................... 16

2.5 Dual Graphics Operation Guide ................................................ 17

2.6 Multi Monitor Feature ................................................................ 19

2.7 ASRock Smart Remote Installation Guide................................. 21

2.8 Jumpers Setup........................................................................... 23

2.9 Onboard Headers and Connectors ....................................... 24

  

Installation .............................................................................. 28

2.11 Hot Plug and Hot Swap Functions for SATA / SATAII HDDs...... 28

2.12 SATA / SATAII HDD Hot Plug and Hot SwapFeature and

Operation Operation Guide........................................................ 29

2.13 Driver Installation Guide ............................................................ 31

2.14 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP /

XP 64-bit With RAID Functions.................................................. 31

2.14.1 Installing Windows®XP / XP 64-bit With RAID

Functions ....................................................................... 31

2.14.2 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit

With RAID Functions ..................................................... 32

2.15 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP /

XP 64-bit Without RAID Functions............................................. 33

2.15.1 Installing Windows®XP / XP 64-bit Without RAID

Functions ....................................................................... 33

2.15.2 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit

Without RAID Functions ................................................ 34

3. UEFI SETUP UTILITY.......................................................... 35

3.1 Introduction ................................................................................ 35

3.1.1 UEFI Menu Bar................................................................ 35

3.1.2 Navigation Keys............................................................... 36

3.2 Main Screen............................................................................... 36

3.3 OC Tweaker Screen................................................................... 37

3.4 Advanced Screen ...................................................................... 40

   ........................................................... 41

    .............................................. 42

    ............................................. 43

   ...................................................... 44

   .................................................... 45

   .......................................................... 46

   ........................................................... 48

3.5 Hardware Health Event Monitoring Screen ............................... 49

3.6 Boot Screen ............................................................................... 50

3.7 Security Screen ......................................................................... 51

3.8 Exit Screen ................................................................................ 52

4. Software Support......................................................... 53

4.1 Install Operating System............................................................ 53

4.2 Support CD Information ............................................................. 53

4.2.1 Running Support CD ....................................................... 53

4.2.2 Drivers Menu ................................................................... 53

4.2.3 Utilities Menu ................................................................... 53

4.2.4 Contact Information ......................................................... 53

1. Introduction

Thank you for purchasing ASRock A55M-VS motherboard, a reliable motherboard





endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-



guide to BIOS setup and information of the Support CD.

         

be updated, the content of this manual will be subject to change without

-

sion will be available on ASRock website without further notice. You may

    

well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit



www.asrock.com/support/index.asp

1.1 Package Contents

ASRock A55M-VS Motherboard

 

ASRock A55M-VS Quick Installation Guide

ASRock A55M-VS Support CD



1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows®7 / 7 64-bit / VistaTM / VistaTM 64

           

to AHCI mode. For the BIOS setup, please refer to the “User Manual” in

our support CD for details.

1.2 Specifications

Platform - Micro ATX Form Factor: 8.8-in x 6.8-in, 22.4 cm x 17.3 cm

- Solid Capacitor for CPU power

CPU - Support for Socket FM1 100W processors

 TM Technology

- UMI-Link GEN2

Chipset 

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 1

- 2 x DDR3 DIMM slots

 

1066/800 non-ECC, un-buffered memory (see CAUTION 2

- Max. capacity of system memory: 16GB (see CAUTION 3

Expansion Slot - 1 x PCI Express 2.0 x16 slot

- 1 x PCI slot

- Supports AMD Dual Graphics

Graphics - AMD Radeon HD 65XX/64XX graphics

- DirectX 11, Pixel Shader 5.0

- Max. shared memory 512MB (see CAUTION 4

- Supports D-Sub with max. resolution up to 1920x1600 @

60Hz

- Supports AMD Steady VideoTM: New video post processing

capability for automatic jutter reduction on home/online

video

Audio 

LAN - Realtek PCIE x1 LAN RTL8105E

- Speed: 10/100 Ethernet

- Supports Wake-On-LAN

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x VGA Port

- 4 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

 

- HD Audio Jack: Line in/Front Speaker/Microphone

Connector - 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,

 

- 1 x IR header

- 1 x CIR header

- 1 x Print port header

- 1 x COM port header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 4 pin 12V power connector

- Front panel audio connector

 

BIOS Feature - 32Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU, DRAM, VDDP, SB Voltage Multi-adjustment

Support CD 

CyberLink MediaEspresso 6.5 Trial

Unique Feature CAUTION 5

- ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 6

- ASRock APP Charger (see CAUTION 7

- ASRock XFast USB (see CAUTION 8

- ASRock XFast LAN (see CAUTION 9

- ASRock XFast RAM (see CAUTION 10

- Hybrid Booster:

- ASRock U-COP (see CAUTION 11

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU Quiet Fan

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

OS - Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP

SP3 / XP 64-bit compliant (see CAUTION 12

 - FCC, CE, WHQL

 

(see CAUTION 13

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking, including adjusting the

setting in the BIOS, applying Untied Overclocking Technology, or using the third-party over-

clocking tools. Overclocking may affect your system stability, or even cause damage to the

components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

CAUTION!

1. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 15 for proper installation.

2. Whether 2400/1866/1600MHz memory speed is supported depends on

the CPU you adopt. If you want to adopt DDR3 2400/1866/1600 memory

module on this motherboard, please refer to the memory support list on

our website for the compatible memory modules.

ASRock website http://www.asrock.com

3. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows®7 /

VistaTM / XP. For Windows®64-bit OS with 64-bit CPU, there is no such

limitation. You can use ASRock XFast RAM to utilize the memory that

Windows®cannot use.

 

is subject to change. Please check AMD website for the latest informa-

tion.

           

different system functions in a user-friendly interface, which is including

Hardware Monitor, Fan Control and IES. In Hardware Monitor, it shows

the major readings of your system. In Fan Control, it shows the fan speed



voltage regulator can reduce the number of output phases to improve

efficiency when the CPU cores are idle without sacrificing computing

performance. Please visit our website for the operation procedures of



ASRock website: http://www.asrock.com

            

This convenient BIOS update tool allows you to update system BIOS

®. With

this utility, you can press <F6> key during the POST or press <F2> key to

BIOS setup menu to access ASRock Instant Flash. Just launch this tool



drive, then you can update your BIOS only in a few clicks without prepar-





system.

7. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful solu-

tion for you - ASRock APP Charger. Simply installing the APP Charger

driver, it makes your iPhone charged much quickly from your computer

and up to 40% faster than before. ASRock APP Charger allows you to

quickly charge many Apple devices simultaneously and even supports

-

           

Charger driver installed, you can easily enjoy the marvelous charging

experience than ever.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

8. ASRock XFast USB can boost USB storage device performance. The

performance may depend on the property of the device.

9. ASRock XFast LAN provides a faster internet access, which includes be-

-

cation priority ideally and/or add new programs. Lower Latency in Game:

After setting online game priority higher, it can lower the latency in game.

Traffic Shaping: You can watch Youtube HD video and download files

simultaneously. Real-Time Analysis of Your Data: With the status window,

you can easily recognize which data streams you are currently transfer-

ring.

10. ASRock XFast RAM is a new function that is included into ASRock Ex-



be used under Windows®OS 32-bit CPU. ASRock XFast RAM shortens



than ever. And it also boosts the speed of Adobe Photoshop 5 times

faster. Another advantage of ASRock XFast RAM is that it reduces the

frequency of accessing your SSDs or HDDs in order to extend their lifes-

pan.

11. While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the moth-

erboard functions properly and unplug the power cord, then plug it back

again. To improve heat dissipation, remember to spray thermal grease

between the CPU and the heatsink when you install the PC system.

12. ASRock XFast RAM is not supported by Microsoft® Windows®XP / XP 64-

bit.

13. EuP, stands for Energy Using Product, was a provision regulated by Eu-



According to EuP, the total AC power of the completed system shall be

under 1.00W in off mode condition. To meet EuP standard, an EuP ready

motherboard and an EuP ready power supply are required. According to





consumption. For EuP ready power supply selection, we recommend you

checking with the power supply manufacturer for more details.

Autres manuels pour A55M-VS

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK AB350 Pro4 Manuel utilisateur

ASROCK

ASROCK 970DE3/U3S3 Manuel utilisateur

ASROCK

ASROCK 785GM-GS3 - V1.0 Manuel utilisateur

ASROCK

ASROCK N68PV-GS Manuel utilisateur

ASROCK

ASROCK IMB-V1000 Manuel utilisateur

ASROCK

ASROCK H61DE-S3 Manuel utilisateur

ASROCK

ASROCK 2Core1333-2.66G Manuel utilisateur

ASROCK

ASROCK X300D4-P1 Manuel utilisateur

ASROCK

ASROCK G41M-PS Manuel utilisateur

ASROCK

ASROCK ATW-HC2260 Manuel utilisateur

ASROCK

ASROCK EP2C622D24LM2 Manuel utilisateur

ASROCK

ASROCK 775Twins-HDTV Manuel utilisateur

ASROCK

ASROCK H170 Pro4 Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z87 Professional Manuel utilisateur

ASROCK

ASROCK FM2A55 Pro+ Manuel utilisateur

ASROCK

ASROCK B460 STEEL LEGEND Manuel utilisateur

ASROCK

ASROCK IMB-130 Instructions d'utilisation

ASROCK

ASROCK H81 Pro-G Manuel utilisateur

ASROCK

ASROCK SBC-210 Manuel de service

ASROCK

ASROCK H55M-USB3 - V1.0 Manuel utilisateur

ASROCK

ASROCK H61M-DP3 Manuel utilisateur

ASROCK

ASROCK H61 Pro BTC Manuel utilisateur

ASROCK

ASROCK M3A760GMH Manuel utilisateur

ASROCK

ASROCK H61M-PS2 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
