ASROCK Z77TM-ITX Manuel utilisateur

Z77TM-ITX

H77TM-ITX

B75TM-ITX

H61TM-ITX

User Manual

Version 1.1

Published November 2013

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1. Introduction ................................................................ 5

1.1 Package Contents.......................................................... 5

1.2 Specications ................................................................. 6

1.3 Unique Features............................................................. 10

1.4 Motherboard Layout (Z77M-ITX) .................................. 13

1.5 Motherboard Layout (H77M-ITX) ................................. 15

1.6 Motherboard Layout (B75M-ITX) ................................. 17

1.7 Motherboard Layout (H61M-ITX) ................................. 19

1.8 I/O Panel (Z77M-ITX) ................................................... 21

1.9 I/O Panel (H77M-ITX) .................................................. 22

1.10 I/O Panel (B75M-ITX) ................................................... 23

1.11 I/O Panel (H61M-ITX) .................................................. 24

2. Installation .................................................................. 25

2.1 Installing the CPU .......................................................... 26

2.2 Installing the CPU Fan and Heatsink ............................. 28

2.3 Installing Memory Modules (DIMM) ............................... 29

2.4 Expansion Slots (PCI Express Slots) ............................. 30

2.5 Installing Serial SATA2 / SATA3 Hard Disks................... 31

2.6 Power Connectors.......................................................... 32

2.7 Installing the System Panel............................................ 33

2.8 Onboard Headers and Connectors ................................ 34

2.9 Jumpers Setup ............................................................... 39

2.10 Operating System Setup ................................................ 40

2.11 Installing Drivers............................................................. 41

3. UEFI SETUP UTILITY.................................................. 42

3.1 Introduction .................................................................... 42

3.1.1 UEFI Menu Bar ..................................................... 42

3.1.2 Navigation Keys .................................................... 43

3.2 Main Screen ................................................................... 44

3.3 OC Tweaker Screen ....................................................... 45

3.4 Advanced Screen........................................................... 49

3.4.1 CPU Conguration ............................................... 50

3.4.2 North Bridge Conguration................................... 52

3.4.3 South Bridge Conguration .................................. 54

3.4.4 Storage Conguration .......................................... 56

3.4.5 Intel(R) Rapid Start Technology ........................... 57

3.4.6 Intel(R) Smart Connect Technology ..................... 58

3.4.7 Super IO Conguration ........................................ 59

3.4.8 ACPI Conguration............................................... 60

3.4.9 USB Conguration ............................................... 62

3.4.10 Trusted Computing............................................. 63

3.5 Tool .............................................................................. 64

3.6 Hardware Health Event Monitoring Screen.................... 66

3.7 Boot Screen ................................................................... 67

3.8 Security Screen.............................................................. 69

3.9 Exit Screen..................................................................... 70

1. Introduction

Thank you for purchasing ASRock Z77TM-ITX / H77TM-ITX / B75TM-

ITX / H61TM-ITX motherboard, a reliable motherboard produced under

ASRock’s consistently stringent quality control. It delivers excellent perfor-

mance with robust design conforming to ASRock’s commitment to quality

and endurance.

In this manual, chapter 1 contains the introduction of the motherboard.

Chapter 2 provides step by step installation instructions. Chapter 3 in-

cludes information about the UEFI.

Because the motherboard specications and the BIOS software

might be updated, the content of this manual will be subject to

change without notice. In case any modications of this manual

occur, the updated version will be available on ASRock’s web-

site. You may nd the latest VGA cards and CPU support list on

ASRock’s website as well. http://www.asrock.com

If you require technical support related to this motherboard,

please visit our website for specic information about the model

you are using. www.asrock.com/support/index.asp

1.1 Package Contents

ASRock Z77TM-ITX / H77TM-ITX / B75TM-ITX / H61TM-ITX Motherboard

(Thin Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock Z77TM-ITX / H77TM-ITX / B75TM-ITX / H61TM-ITX Quick Instal-

lation Guide

ASRock Z77TM-ITX / H77TM-ITX / B75TM-ITX / H61TM-ITX Support CD

1 x I/O Panel Shield

1.2 Specications

Platform

Thin Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0

cm (Compatible with Mini-ITX)

Solid Capacitors for CPU power

CPU

Supports 3rd and 2nd Generation Intel®CoreTM i7 / i5 / i3 in

LGA1155 Package

Supports Intel®Turbo Boost 2.0 Technology

Supports Hyper-Threading Technology

Chipset

Intel®Z77/H77/B75/H61

Supports Intel® Small Business Advantage (B75TM-ITX)

Supports Intel®Rapid Start Technology and Smart Connect

Technology

Memory

Dual Channel DDR3 Memory Technology

2 x DDR3 SO-DIMM slots

Supports DDR3 1600/1333/1066 non-ECC, un-buffered

memory

Max. capacity of system memory: 16GB (see CAUTION 1)

Expansion

Slots

1 x PCI Express 3.0 x4 slot (PCIE1: x4 mode) (see CAU-

TION 2)

1 x mini-PCI Express slot

Graphics

Supports Intel® HD Graphics Built-in Visuals (see CAUTION

Pixel Shader 5.0, DirectX 11 with Intel®Ivy Bridge CPU.

Pixel Shader 4.1, DirectX 10.1 with Intel®Sandy Bridge CPU

Max. shared memory 1760MB with Intel®Ivy Bridge CPU.

Max. shared memory 1759MB with Intel®Sandy Bridge CPU

Three VGA Output options: HDMI, DVI-I and LVDS

Supports HDMI 1.4a Technology with max. resolution up to

1920x1200 @ 60Hz

Supports DVI-I with max. resolution up to 1920x1200 @

75Hz

Supports LVDS with max. resolution up to 1920x1200 @

60Hz

Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI

Supports HDCP with HDMI

Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with HDMI

Audio

7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

Premium Blu-ray audio support

LAN

PCIE x1 Gigabit LAN 10/100/1000 Mb/s

RTL8111E-VL

Supports Wake On LAN

Supports LAN Cable Detection

Supports Energy Efcient Ethernet 802.3az

Supports PXE

Rear Panel

I/O

1 x DC Jack

1 x DVI-I Port

1 x HDMI Port

1 x eSATA Connector

2 x USB 3.0 Ports (H61TM-ITX by Etron EJ188)

2 x USB 2.0 Ports

1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

HD Audio Jacks: Front Speaker / Microphone

Connectors

2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel

Smart Response Technology), NCQ, AHCI and “Hot Plug”

functions (Z77TM-ITX / H77TM-ITX)

1 x SATA3 6.0 Gb/s connector and 1 x SATA2 3.0 Gb/s con-

nector, support NCQ, AHCI and Hot Plug functions (B75TM-

ITX)

2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and

Hot Plug (H61TM-ITX)

1 x CIR header

1 x COM port header

1 x HDMI_SPDIF header

1 x LVDS connector

1 x LPC Debug header

1 x Home Theater PC header

1 x CPU Fan connector (4-pin)

1 x Chassis Fan connector (4-pin)

1 x Front Panel Audio connector

1 x Analog Surround Audio header

1 x Digital MIC header

1 x 3W Audio AMP Output Wafer header

1 x SATA Power connector

WARNING

Please realize that there is a certain risk involved with over-

clocking, including adjusting the setting in the BIOS, applying

Untied Overclocking Technology, or using third-party overclock-

ing tools. Overclocking may affect your system’s stability, or

even cause damage to the components and devices of your

system. It should be done at your own risk and expense. We are

not responsible for possible damage caused by overclocking.

* For detailed product information, please visit our website:

http://www.asrock.com

3 x USB 2.0 headers (support 5 USB 2.0 ports)

1 x USB 3.0 header (supports 2 USB 3.0 ports) (H61TM-ITX

by Etron EJ188)

BIOS

32Mb AMI UEFI Legal BIOS with GUI support

Supports “Plug and Play”

ACPI 1.1 Compliance Wake Up Events

Supports jumperfree

SMBIOS 2.3.1 Support

CPU Core, IGPU, DRAM, 1.8V PLL, VTT, VCCSA Voltage

Multi-adjustment

Support CD

Drivers, Utilities, AntiVirus Software (Trial Version), Cyber-

Link MediaEspresso 6.5 Trial, Google Chrome Browser and

Toolbar

Hardware

Monitor

CPU/Chassis Temperature Sensing

CPU/Chassis Fan Tachometer

CPU/Chassis Quiet Fan

CPU/Chassis Fan Multi-Speed Control

Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS Microsoft®Windows®8 / 8 64-bit / 7 / 7 64-bit / VistaTM /

VistaTM 64-bit / XP / XP 64-bit compliant

Certications

FCC, CE, WHQL

ErP/EuP Ready (ErP/EuP ready power supply is required)

CAUTION!

1. Due to limitation, the actual memory size may be less than 4GB

for the reservation for system usage under Windows®32-bit

operating systems. Windows®64-bit operating systems do not

have such limitations. You can use ASRock XFast RAM to uti-

lize the memory that Windows®cannot use.

2. PCIE 3.0 is only supported with Intel®Ivy Bridge CPU. With In-

tel®Sandy Bridge CPU, it only supports PCIE 2.0.

3. Intel® HD Graphics Built-in Visuals and the VGA outputs can be

supported only with processors which are GPU integrated. Intel®

Quick Sync Video 2.0, Intel®InTruTM 3D, Intel®Clear Video HD

Technology, Intel®InsiderTM, Intel® HD Graphics 2500/4000 are

supported by Intel®Ivy Bridge CPU. Intel®Quick Sync Video,

Intel®InTruTM 3D, Intel®Clear Video HD Technology, Intel®HD

Graphics 2000/3000, Intel® Advanced Vector Extensions (AVX)

are supported by Intel®Sandy Bridge CPU.

1.3 Unique Features

ASRock Instant Boot

ASRock Instant Boot provides an efcient way to save

energy, time, money, and improve the system’s running

speed. It leverages the S3 and S4 ACPI features which

normally enable Sleep/Standby and Hibernation modes

in Windows®to shorten the boot time. By calling S3 and

S4 at a specic timing during the shutdown and startup

process, Instant Boot allows you to enter your Windows®

desktop in a few seconds.

ASRock Instant Flash

ASRock Instant Flash is a BIOS ash utility embedded

in Flash ROM. This convenient BIOS update tool allows

you to update the system BIOS without entering operat-

ing systems first like MS-DOS or Windows®. With this

utility you can press <F6> or <F2> during POST to enter

the BIOS setup menu to access ASRock Instant Flash.

Just launch this tool and save the new BIOS le to your

USB ash drive, oppy disk or hard drive, then you can

update your BIOS in a few clicks without preparing an

additional oppy diskette or other complicated ash utili-

ty. Please be noted that the USB ash drive or hard drive

must use FAT32/16/12 le system.

ASRock APP Charger

If you desire a faster, less restricted way of charging your

Apple devices, such as iPhone/iPad/iPod Touch, ASRock

has prepared a wonderful solution for you - ASRock APP

Charger. Simply install the APP Charger driver, it makes

your iPhone charge much quickly from your computer

and up to 40% faster than before. ASRock APP Charger

allows you to quickly charge many Apple devices simul-

taneously and even supports continuous charging when

your PC enters into Standby mode (S1), Suspend to

RAM (S3), hibernation mode (S4) or power off (S5). With

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK H61M-HVGS Manuel utilisateur

ASROCK

ASROCK B75M R2.0 Manuel utilisateur

ASROCK

ASROCK X570 PHANTOM GAMING 4 Manuel utilisateur

ASROCK

ASROCK P4DUAL-915GL Manuel utilisateur

ASROCK

ASROCK Z370 Taichi Manuel utilisateur

ASROCK

ASROCK 890GX Extreme3 Manuel utilisateur

ASROCK

ASROCK A55M-HVS Manuel utilisateur

ASROCK

ASROCK A68M-ITX Manuel utilisateur

ASROCK

ASROCK G41M-GS3 Manuel utilisateur

ASROCK

ASROCK H81M-HG4 Manuel utilisateur

ASROCK

ASROCK 870iCafe Manuel utilisateur

ASROCK

ASROCK SBC-230D Manuel utilisateur

ASROCK

ASROCK P43DE3 Manuel utilisateur

ASROCK

ASROCK H61M-HVGS Manuel utilisateur

ASROCK

ASROCK J3455 PRO BTC+ Manuel utilisateur

ASROCK

ASROCK E35LM1 Manuel utilisateur

ASROCK

ASROCK 870iCafe Manuel utilisateur

ASROCK

ASROCK IMB-185 Manuel de service

ASROCK

ASROCK A230GC - V1.0 Manuel utilisateur

ASROCK

ASROCK P85 Pro3 Manuel utilisateur

ASROCK

ASROCK C226 WS+ Manuel utilisateur

ASROCK

ASROCK Z390M-ITX/ac Manuel utilisateur

ASROCK

ASROCK Z390 Phantom Gaming 9 Manuel utilisateur

ASROCK

ASROCK IMB-X790 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
