ASROCK ROMED8HM3 Manuel utilisateur

ROMED8HM3

User Manual

Version 1.0

Published March 2020

Version 1.0

Published July2020

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished

for informational use only and subject to change without notice, and should not

be constructed as a commitment by ASRock Rack. ASRock Rack assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRock Rack has been advised of the possibility of such damages

arising from any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack,

you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you

may contact your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 5

1.4 Motherboard Layout 6

1.5 Onboard LED Indicators 9

1.6 I/O Panel 11

1.7 Block Diagram 12

Chapter 2 Installation 13

2.1 Screw Holes 13

2.2 Pre-installation Precautions 13

2.3 Installing the CPU 14

2.4 Installation of Memory Modules (DIMM) 18

2.5 Expansion Slots (PCI Express Slots) 20

2.6 Jumper Setup 21

2.7 Onboard Headers and Connectors 22

2.8 Unit Identication purpose LED/Switch 28

2.9 Driver Installation Guide 28

2.10 M.2_SSD (NGFF) Module Installation Guide 29

Chapter 3 UEFI Setup Utility 31

3.1 Introduction 31

3.1.1 UEFI Menu Bar 31

3.1.2 Navigation Keys 32

3.2 Main Screen 33

3.3 Advanced Screen 34

3.3.1 CPU Conguration 35

3.3.2 Chipset Conguration 36

3.3.3 Storage Conguration 38

3.3.4 ACPI Conguration 39

3.3.5 USB Conguration 40

3.3.6 Super IO Conguration 41

3.3.7 Serial Port Console Redirection 42

3.3.8 H/W Monitor 45

3.3.9 AMD CBS 46

3.3.10 AMD PBS 47

3.3.11 PSP Firmware Versions 48

3.3.12 Instant Flash 49

3.4 Server Mgmt 50

3.4.1 System Event Log 51

3.4.2 BMC Network Conguration 52

3.4.3 BMC Tools 54

3.5 Security 55

3.5.1 Key Management 56

3.6 Boot Screen 59

3.6.1 CSM Parameters 61

3.7 Event Logs 64

3.8 Exit Screen 66

Chapter 4 Software Support 67

4.1 Install Operating System 67

4.2 Support CD Information 67

4.2.1 Running The Support CD 67

4.2.2 Drivers Menu 67

4.2.3 Utilities Menu 67

4.2.4 Contact Information 67

Chapter 5 Troubleshooting 68

5.1 Troubleshooting Procedures 68

5.2 Technical Support Procedures 70

5.3 Returning Merchandise for Service 70

Appendix TPM Module Support List 71

ROMED8HM3

PB 1

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack ROMED8HM3 motherboard, a reliable

motherboard produced under ASRock Rack’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock Rack’s

commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration

guide to BIOS setup and information of the Support CD.

1.1 Package Contents

• ASRock Rack ROMED8HM3 Motherboard

(Half Form Factor: 17-in x 6.5-in, 43.1 cm x 16.5 cm)

• Quick Installation Guide

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

http://www.asrockrack.com/support/

2 3

English

1.2 Specications

ROMED8HM3

MB Physical Status

Form Factor Half Width

Dimension 6.5’’ x 17’’ (16.5 cm x 43.1 cm)

Processor System

CPU AMD EPYC™ 7002/7001 Series Processor Family

Socket Single Socket SP3 (LGA4094)

Chipset N/A

System Memory

Type - Eight Channel DDR4 memory technology

- Supports DDR4 RDIMM, LRDIMM

DIMM Size Per

DIMM

- RDIMM: 64GB*,32GB, 16GB, 8GB

- LRDIMM: 128GB**, 64GB*, 32GB

- NV DIMM:32GB***

*64GB: wait for the device to be validated

**128GB: wait for the device to be validated

***Wait for the device to be validated

DIMM

Frequency

- RDIMM: 3200MHz

- LRDIMM: 3200MHz

- NVDIMM: 2666MHz*

*Wait for the device to be validated

Voltage 1.2V

Expansion Slot

PCIe 3.0/4.0 x16 PCIE1: Gen3/Gen4 x16 link

PCIe 3.0/4.0 x24 PCIE2: Gen3/Gen4 x24 link

Storage

SATA Controller 8 x SATA3 (8 from 2x mini SAS HD connector, 2 for M.2 slots)

M.2 Slot 2 (2230/2242/2260/2280/22110, SATA3 x1 or PCIE Gen4 x4)

Slimline SLIM1: PCIe Gen4 x8

SLIM2: PCIe Gen4 x8

SLIM3: PCIe Gen4 x8

SLIM4: PCIe Gen4 x8

SLIM5: PCIe Gen4 x8

SLIM6: PCIe Gen4 x8

Mezzanine 1 x OCP3.0 4C+ SFF(PCIe x16)

Ethernet

Interface N/A

LAN 1 x RJ45 Dedicated IPMI LAN port

Management

BMC Controller ASPEED AST2500

IPMI Dedicated

GLAN

1 x Realtek RTL8211E for dedicated management GLAN

ROMED8HM3

2 3

English

Features - Watch Dog

- NMI

Graphics

Controller ASPEED AST2500

VRAM DDR4 512MB

Rear Panel I/O

VGA Port 1 (Mini DisplayPort)*

*Not supported for the standard Mini DisplayPort connection.

USB 3.0 Port 2

LAN Port 1 (IPMI) LAN port (RJ45)

LAN Ports with LED (ACT/LINK LED and SPEED LED)

UID 1

Internal Connector

Auxiliary Panel

Header

1 (includes chassis intrusion, location button & LED, front

LAN LED)

Front Panel 1

TPM Header 1

IPMB Header 1

Fan Header 4 Fans x 6-pin

USB 3.1 Gen1

Header

1 (supports 2 USB 3.1 Gen1 ports)

ATX Power 2 x (8-pin)

CM SB Power 2

SATA SGPIO 2

OCulink 1

BMC SMB 1

PSU SMB 1

TR 1

NMI Button 1

COM Header 1

Speaker(4pin) 1

ClearCMOS 1

CPU1_HSBP1 1

CM_SB_L 1

CM_SB_R 1

OH/FanFail

LED

4 (only Fan Fail LED)

System BIOS

BIOS Ty pe 64MB AMI UEFI Legal BIOS

BIOS Features - Plug and Play (PnP)

- ACPI 2.0 Compliance Wake Up Events

- SMBIOS 2.8 Support

- ASRock Rack Instant Flash

4 5

English

Hardware Monitor

Temperature - CPU Temperature Sensing

- MB/Card side Temperature Sensing

Fan - Fan Tachometer

- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by

CPU Temperature)

- Fan Multi-Speed Control

Voltage Voltage Monitoring: +12V, +5V, +3.3V, VDDCR_CPU,

VDDCR_SOC, VCCM_ABCD, VCCM_EFGH, +BAT, 3VSB,

5VSB, +12V_EDGE, +3V_EDGE

Support OS

OS Microso® Windows®

- Server 2016 (64 bit)

- Server 2019 (64 bit)

Linux®

- RedHat Enterprise Linux Server 8.0 (64 bit) / 7.6 (64 bit)

- CentOS 8.0 (64 bit) / 7.6 (64 bit)

- SUSE SLES 15.1 (64 bit) / 12.4 (64 bit)

- UBuntu 18.04.3 (64 bit) / 16.04.6 (64 bit)

- CITRIX Hypervisor 8.1.0

Virtual

- VMWare ESXi 6.5 u3 / 6.7 u3*

*Due to no embedded LAN devices on this motherboard for the VMWare

installation, please use either the ASRock Rack OCP-series LAN Mezzanine

cards or standard PCIe LAN cards for this OS installation.

*Please refer to our website for the latest OS support list.

Environment

Temperature Operation temperature: 10°C ~ 35°C / Non operation

temperature: -40°C ~ 70°C

is motherboard supports Wake from on Board LAN. To use this function, please make

sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager

> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is

enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard

LAN1&2 can wake up S5 under OS.

If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-

dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it

will pass the WHQL tests.
