ASROCK H310CM-HDV Manuel utilisateur

Version 1.0

Published January 2018

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure and

compensation for any other reasonably foreseeable loss or damage caused by our

goods. You are also entitled to have the goods repaired or replaced if the goods fail

to be of acceptable quality and the failure does not amount to a major failure. If

you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard

International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 8

Chapter 2 Installation 10

2.1 Installing the CPU 11

2.2 Installing the CPU Fan and Heatsink 14

2.3 Installing Memory Modules (DIMM) 15

2.4 Expansion Slots (PCI Express Slots) 17

2.5 Onboard Headers and Connectors 18

Chapter 3 Software and Utilities Operation 22

3.1 Installing Drivers 22

3.2 A-Tuning 23

3.3 ASRock Live Update & APP Shop 26

3.3.1 UI Overview 26

3.3.2 Apps 27

3.3.3 BIOS & Drivers 30

3.3.4 Setting 31

Chapter 4 UEFI SETUP UTILITY 32

4.1 Introduction 32

4.2 EZ Mode 33

4.3 Advanced Mode 34

4.3.1 UEFI Menu Bar 34

4.3.2 Navigation Keys 35

4.4 Main Screen 36

4.5 OC Tweaker Screen 37

4.6 Advanced Screen 46

4.6.1 CPU Conguration 47

4.6.2 Chipset Conguration 49

4.6.3 Storage Conguration 51

4.6.4 Super IO Conguration 52

4.6.5 ACPI Conguration 53

4.6.6 USB Conguration 54

4.6.7 Trusted Computing 55

4.7 Tools 56

4.8 Hardware Health Event Monitoring Screen 58

4.9 Security Screen 60

4.10 Boot Screen 61

4.11 Exit Screen 64

English

H310CM-HDV / H310CM-DVS

Chapter 1 Introduction

ank you for purchasing ASRock H310CM-HDV / H310CM-DVS motherboard,

a reliable motherboard produced under ASRock’s consistently stringent quality

control. It delivers excellent performance with robust design conforming to

ASRock’s commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

•ASRock H310CM-HDV / H310CM-DVS Motherboard (Micro ATX Form Factor)

•ASRock H310CM-HDV / H310CM-DVS Quick Installation Guide

•ASRock H310CM-HDV / H310CM-DVS Support CD

•1 x I/O Panel Shield

•2 x Serial ATA (SATA) Data Cables (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

English

1.2 Specications

Platform •Micro ATX Form Factor

•Solid Capacitor design

CPU •Supports 8th Generation Intel® CoreTM Processors (Socket

1151)

•4 Power Phase design

•Supports Intel® Turbo Boost 2.0 Technology

Chipset •Intel® H310

Memory •Dual Channel DDR4 Memory Technology

•2 x DDR4 DIMM Slots

•Supports DDR4 2666/2400/2133 non-ECC, un-buered

memory

•Max. capacity of system memory: 32GB

•Supports Intel® Extreme Memory Prole (XMP) 2.0

•15 Gold Contact in DIMM Slots

Expansion

Slot

•1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*

* Supports NVMe SSD as boot disks

•1 x PCI Express 2.0 x1 Slot

Graphics •Intel® UHD Graphics Built-in Visuals and the VGA outputs

can be supported only with processors which are GPU

integrated.

•Supports Intel® UHD Graphics Built-in Visuals : Intel®

Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® UHD Graphics

•DirectX 12

•HWAEncode/Decode: AVC/H.264, HEVC/H.265 8-bit,

HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode

only), MPEG2, MJPEG, VC-1 (Decode only)

English

H310CM-HDV / H310CM-DVS

H310CM-HDV:

•ree graphics output options: D-Sub, DVI-D and HDMI

* Supports up to 2 displays simultaneously

•Supports HDMI with max. resolution up to 4K x 2K

(4096x2160) @ 30Hz

•Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

•Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

•Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

•Supports HDCP with DVI-D and HDMI Ports

•Supports 4K Ultra HD (UHD) playback with HDMI Port

H310CM-DVS:

•Dual graphics output: Support DVI-D and D-Sub ports by

independent display controllers

•Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

•Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

•Supports HDCP with DVI-D Port

Audio •7.1 CH HD Audio (Realtek ALC887 Audio Codec)

* To congure 7.1 CH HD Audio, it is required to use an HD

front panel audio module and enable the multi-channel audio

feature through the audio driver.

•Supports Surge Protection

•ELNA Audio Caps

LAN •PCIE x1 Gigabit LAN 10/100/1000 Mb/s

•1 x Realtek RTL8111H

•Supports Wake-On-LAN

•Supports Lightning/ESD Protection

•Supports Energy Ecient Ethernet 802.3az

•Supports PXE

English

Rear Panel

I/O

•1 x PS/2 Mouse/Keyboard Port

•4 x USB 2.0 Ports (Supports ESD Protection)

•2 x USB 3.1 Gen1 Ports (Supports ESD Protection)

•1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

•HD Audio Jacks: Line in / Front Speaker / Microphone

H310CM-HDV:

•1 x D-Sub Port

•1 x DVI-D Port

•1 x HDMI Port

H310CM-DVS:

•1 x D-Sub Port

•1 x DVI-D Port

Storage •4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and

Hot Plug

Connector •1 x TPM Header

•1 x Chassis Intrusion and Speaker Header

•1 x CPU Fan Connector (4-pin)

* e CPU Fan Connector supports the CPU fan of maximum

1A (12W) fan power.

•1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan

Speed Control)

* e Chassis/Water Pump Fan supports the water cooler fan of

maximum 2A (24W) fan power.

* CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.

•1 x 24 pin ATX Power Connector

•1 x 8 pin 12V Power Connector

•1 x Front Panel Audio Connector

•1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports

ESD Protection)

•1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports)

(Supports ESD Protection)

BIOS

Feature

•AMI UEFI Legal BIOS with multilingual GUI support

•ACPI 6.0 Compliant wake up events

•SMBIOS 2.7 Support

•DRAM, PCH 1.05V Voltage Multi-adjustment

English

H310CM-HDV / H310CM-DVS

* For detailed product information, please visit our website: http://www.asrock.com

Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using third-party

overclocking tools. Overclocking may aect your system’s stability, or even cause damage to

the components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

Hardware

Monitor

•Temperature Sensing: CPU, Chassis/Water Pump Fans

•Fan Tachometer: CPU, Chassis/Water Pump Fans

•Quiet Fan (Auto adjust chassis fan speed by CPU

temperature): CPU, Chassis/Water Pump Fans

•Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans

•CASE OPEN detection

•Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

OS •Microso® Windows® 10 64-bit

Certica-

tions

•FCC, CE

•ErP/EuP ready (ErP/EuP ready power supply is required)

Autres manuels pour H310CM-HDV

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ASROCK Matériel informatique

ASROCK

ASROCK BTC PRO Kit Manuel utilisateur

ASROCK

ASROCK SBC-372 Manuel utilisateur

ASROCK

ASROCK ROMED6U-2L2T Manuel utilisateur

ASROCK

ASROCK NUCS BOX-1360P/D4 Manuel utilisateur

ASROCK

ASROCK Jupiter H610 Manuel utilisateur

ASROCK

ASROCK iEPF-9000S-EX4 Manuel utilisateur

ASROCK

ASROCK NUC BOX-1360P/D5 Manuel utilisateur

ASROCK

ASROCK A620M-C Manuel utilisateur

ASROCK

ASROCK IMB-184 Manuel de service

ASROCK

ASROCK IMB-1225 Manuel de service

ASROCK

ASROCK LiveMixer B650 Manuel utilisateur

ASROCK

ASROCK 1U12LX Series Manuel utilisateur

ASROCK

ASROCK 4X4 BOX-7040 Series Manuel utilisateur

ASROCK

ASROCK IMB-1237 Manuel utilisateur

ASROCK

ASROCK Thunderbolt 4 AIC Manuel utilisateur

ASROCK

ASROCK PHANTOM GAMING B760M PG LIGHTNING Manuel utilisateur

ASROCK

ASROCK MARVELL SATA3 RAID Manuel utilisateur

ASROCK

ASROCK NUC BOX-1165G7 Manuel utilisateur

ASROCK

ASROCK IMB-1712 Manuel de service

ASROCK

ASROCK USB 3.1/A+C Manuel utilisateur

ASROCK

ASROCK IMB-X1316 Manuel de service

ASROCK

ASROCK iBOX-155 Manuel utilisateur

ASROCK

ASROCK Thunderbolt 4 AIC R2.0 Manuel utilisateur

ASROCK

ASROCK athena A1 Kit Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
