ASROCK NUCS BOX-1360P/D4 Manuel utilisateur

NUC BOX-1260P

NUC BOX-1240P

NUC BOX-1220P

User Manual

Version 1.0

Published May 2022

Version 1.0

Published January 2023

No part of this documentation may be reproduced, transcribed, transmitted, or translated

in any language, in any form or by any means, except duplication of documentation by the

purchaser for backup purpose, without written consent of ASRock Industrial Inc.

Products and corporate names appearing in this documentation may or may not be

registered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specifications and information contained in this documentation are furnished for

informationa l use only and subject to change without notice, and should not be

constructed as a commitment by ASRock Industrial. ASRock Industrial assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Industrial does not provide

warranty of any kind, either expressed or implied, including but not limited to the implied

warranties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock Industrial, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for loss of

prots, loss of business, loss of data, interruption of business and the like), even if ASRock

Industrial has been advised of the possibility of such damages arising from any defect or

error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may

cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Industrial’s Website: https://www.asrockind.com

Replaceable batteries

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS

Contact Information

If you need to contact ASRock Industrial or want to know more about ASRock

Industrial, you’re welcome to visit ASRock Industrial’s website at https://www.

asrockind.com; or you may contact your dealer for further information.

ASRock Industrial Incorporation

Email: Info_ipc@asrockind.com

e terms HDMI®and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Product Specications 2

1.3 Block Diagram 4

Chapter 2 Product Overview 5

2.1 Front View 5

2.2 Rear View 6

2.3 Inside View 7

Chapter 3 Hardware Installation 8

3.1 How to Remove the Bottom Case 8

3.2 How to Install the Memory Modules 9

3.3 How to Install the WiFi Module 10

3.4 How to Install the M.2 SSD (Type 2242) 11

3.5 How to Install the M.2 SSD (Type 2280) 13

3.6 How to Install the VESA Bracket 14

Chapter 4 Motherboard 16

4.1 Motherboard Layout 16

4.2 Motherboard Specications 17

4.3 Onboard Headers and Connectors 19

4.4 Expansion Slots (M.2 Slots) 21

Chapter 5 UEFI SETUP UTILITY 22

5.1 Introduction 22

5.1.1 Entering BIOS Setup 22

5.1.2 UEFI Menu Bar 23

5.1.3 Navigation Keys 24

5.2 Main Screen (Advanced Mode) 25

5.3 Advanced Screen 26

5.3.1 CPU Conguration 27

5.3.2 Chipset Conguration 30

5.3.3 Super IO Conguration 32

5.3.4 AMT Conguration 33

5.3.5 ACPI Conguration 35

5.3.6 USB Conguration 36

5.3.7 Trusted Computing 37

5.4 Hardware Health Event Monitoring Screen 40

5.5 Security Screen 41

5.6 Boot Screen 42

5.7 Exit Screen 44

Chapter 6 Software Support 45

6.1 Install Operating System 45

6 1

Chapter 1 Introduction

1.1 Package Contents

• NUCS BOX-1360P/D4 / NUCS BOX-1340P/D4

• 1 x Screw for M.2 slot

• 1 x 19V/90W Power Adapter

• 1 x Screw Package

• 1 x VESA mounting bracket

• Quick Installation Guide

NUCS BOX-1360P/D4

NUCS BOX-1340P/D4

6 1

English

Chapter 1 Introduction

1.1 Package Contents

• NUCS BOX-1360P/D4 / NUCS BOX-1340P/D4

• 1 x Screw for M.2 slot

• 1 x 19V/90W Power Adapter

• 1 x Screw Package

• 1 x VESA mounting bracket

• Quick Installation Guide

Because the hardware specications might be updated, the content of this documentation

will be subject to change without notice.

If any items are missing or appear damaged, contact your authorized dealer.

2 3

English

1.2 Product Specications

NUCS BOX-1360P/D4

NUCS BOX-1340P/D4 Barebone

CPU

Intel® 13th Gen (Raptor Lake-P) Core™ Processors

NUCS BOX-1360P/D4( i7-1360P, 4P+8E)

NUCS BOX-1340P/D4( i5-1340P, 4P+8E)

Chipset MCP

BIOS AMI SPI 256 Mbit

Memory Supports Dual Channel DDR4 3200 MHz

Storage 1 x M.2 (KEY M, 2242/2280)

with PCIe Gen4 x4 for SSD

LAN Intel® I226LM with 10/100/1000/2500 Mbps

WiFi 1 x Wi-Fi 6E 802.11ax (2.4Gbps) + BT 5.2

(M.2 Key E, 2230 PCIe x1, USB 2.0 for Wireless)

Audio Realtek ALC233, High Denition Audio

Front I/O 2 x USB 3.2 Gen2 (Type A)

1 x USB4 (Supports DP1.4a display output)

1 x USB3.2 Gen2 (Type-C, Supports DP1.4a display

output)

1 (headphone & microphone jack)

Rear I/O 1 x HDMI 2.0b, 1 x DP1.4a, 1 x 2.5 Gigabit LAN, 2 x USB

3.2 Gen2 (Type-A), DC-IN

Power Unit 19V/90W Power Adapter

M.2 slot

NUCS BOX-1360P/D4

NUCS BOX-1340P/D4

2 3

English

Dimension 110.mm (W)x 117.5mm (D) x 37mm (H)

VESA Bracket included , supports 75 x 75 and 100 x 100 mm

Weight 0.9Kg

Operating Tem-

perature 0°C~40°C

4 5

English

1.3 Block Diagram

M.2 M Key

2280

PCIe x4 Gen4

3.5mm

Combo Conn.

DDR4 SO-DIMM 3200 (32GB)

M.2 KEY-E (2230)

DDR4 - CH1

LAN1

RPL-P 28W

PCIe#6+CNVi+USB2#10

Intel

DDR4 - CH0

DDR4 SO-DIMM 3200 (32GB)

PCIe#6+USB2#10

CPU_PCIEX4_A_[3:1]

SPI0 CS0#

SPI ROM 32MB

Flash Box

TPM2.0

CS2#

TCP0+USB2#5

TCP2+USB2#6

TCP3

HDMI

Conn.

ITE

Retimer

TypeC Conn.

(USB+DP)

cedoC ADH

ALC233/256

Line_Out

MIC_In

USB3#1+USB#1

USB3#2+USB#2

USB3.2 Rear IO

TypeA

USB3#3+USB2#3

USB3.2 Front IO

TypeA

SIO

NCT5525D

GPIO

USB

PWR Ctrl

I226LM

PCIe#5(vPro)

2.5G LAN

RJ45

MDIO

Transformer

MDIO

DDIB

ITE

Retimer

HDMI

Conn.

TMDS

eSPI

Heder

CPU

5V FAN(4pin)

PWM

ADC

Hardware

Monitor(+Vcore,+DC in)

GPIO

WDT

USB2#7

TypeC Conn.

(TBT)

TBT/USB3/DP

NUCS BOX-1360P/D4

NUCS BOX-1340P/D4
