Ask Proxima Impact 21 Manuel utilisateur

USER

GUIDE

IMPACT 21

801.060C

USG/021/AE-C

14.06.95

Not actual front page

USER GUIDE LCD PANEL

USER GUIDE

IMPACT 21

USER GUIDE LCD PANEL

TABLE OF CONTENTS

1 INTRODUCTION...................................................................................5

2 MAIN FEATURES.................................................................................5

3 SUPPLIED MATERIAL..........................................................................6

4 OPTIONAL MATERIAL .........................................................................6

5 SETTING UP THE LCD PANEL ............................................................7

6 USING THE LCD PANEL......................................................................8

6.1 REMOTE CONTROL............................................................8

6.2 FRONT PANEL................................................................... 10

6.3 CONNECTORS.................................................................. 10

7 FEATURES......................................................................................... 11

8 PRACTICAL HINTS AND TIPS............................................................ 15

9 MAINTENANCE.................................................................................. 16

10 SERVICE.......................................................................................... 16

11 TECHNICAL DATA............................................................................ 17

12 CONNECTORS................................................................................. 19

13 FCC STATEMENT ............................................................................ 20

14 ENVIRONMENTAL STATEMENT...................................................... 21

15 SERVICE INFORMATION................................................................. 22

16 CONNECTION LAYOUT................................................................... 23

(Foldout Page)

USER GUIDE LCD PANEL

This publication is printed on recycled paper.

The information contained in this user guide is preliminary, and the products described

herein are subject to change without prior notice.

USER GUIDE LCD PANEL

1INTRODUCTION

The LCD panel is a state of the art projection device that can be connected

to several sources, like the popular IBM, Apple and NEC computers, in

addition to NTSC, PAL or SECAM video (through an external adapter).

The ability to display a multitude of true colors simultaneously, in real time,

makes it the ideal choice for presenting computer generated text and

graphics, television and video.

Applications include presentations, software training, educational use,

advertising, information boards and other situations where a small or large

audience shares information.

2MAIN FEATURES

-2.1 Million colors

-User settings memorized

-Individual settings for all sources

-Video through external adapter

-Correct VGA text mode

-Compatible with all popular computers

-Cable adapters for different computers

-BatMouse™, infrared remote mouse

- Housing footprint fits OHP glass exactly

-Low weight

-Intelligent fan cooling

-No false light

-4 meters Y-cable

USER GUIDE LCD PANEL

3SUPPLIED MATERIAL

A complete set includes the following components :

1. LCD Panel 6. Power Cable

2. VGA-Cable 7. BatMouse Remote Control

3. Cable-Adapt. MACII mon 8. Batteries

4. Cable-Adapt. MACII comp. 9. Attachè Case

5. Power -5, 12, 5 V 10. User Guide

4OPTIONAL MATERIAL

Optional cables and adapters are available for special computer sources.

An external video adapter is available that is compatible with NTSC, PAL

and SECAM.

USER GUIDE LCD PANEL

5SETTING UP THE LCD PANEL

Switch off all equipment before connecting the components. Be aware of

static electricity that may build up, especially in the dry season and when

operating on synthetic carpets. Discharge any static electricity by touching

a metallic surface before you start.

Place the LCD panel on top of a transmissive overhead projector (OHP).

Select a high intensity type projector, for instance 400W halogen or metal-

halide. Best results are obtained in a dimmed room with no direct sunlight

shining in.

Connect the cables and power supply as described in the rear foldout page

(see Connection Layout)). Cable adapters are not used with VGA, only

with MACII and NEC9801.

Connect cable (1) between the LCD panel and the computer. Use the

Y-split on the computer end to connect the monitor.

If you have a Macintosh, EGA, CGA or NEC computer, insert applicable

adapters (2) and (3) as described in the table below.

Connect the power supply to the LCD panel (4).

COMPUTER CABLE ADAPTER

VGA Analog None

EGA/CGA Digital (option) None

MACII c../v../LC/

Quadra/Powerbook/

Duo

Analog MACII (640x480)

NEC 9801 Analog NEC 9801(option)

USER GUIDE LCD PANEL

6USING THE LCD PANEL

The LCD panel has a set of connectors and controls that you need to know

in order to operate the device correctly.

6.1 REMOTE CONTROL

The infrared BatMouse remote control (RC) is the main user interface to

the device. The RC is used to set the device correctly (to get the best

possible viewing conditions).

The figure shows the different keys of the BatMouse.

Set-up should be done once with the application(s) you are running most

frequently. Allow some minutes for the equipment to warm up before

adjusting. Most settings will automatically be memorized individually for

each source for future use.
