Declaration of Conformity

Manufacturer: InFocus Corporation, 27500 SW Parkway Ave. Wilsonville, Oregon

97070 USA

European Office: Louis Armstrongweg 110, 1311 RL Almere, The Netherlands

We declare under our sole responsibility that this projector conform to the following

directives and norms:

EMC Directive 2004/108/EC

EMC: EN 55022

EN 55024

EN 61000-3-2

EN 61000-3-3

Low Voltage Directive 2006/95/EC

Safety: IEC 60950-1: 1st Edition

Trademarks

Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple

Computer, Inc. IBM is a trademark or registered trademark of International Business

Machines, Inc. Microsoft, PowerPoint, and Windows are trademarks or registered

trademarks of Microsoft Corporation. Adobe and Acrobat are trademarks or

registered trademarks of Adobe Systems Incorporated. DLP® and the DLP logo are

registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of

Texas Instruments. InFocus, In Focus, and INFOCUS (stylized) are either registered

trademarks or trademarks of InFocus Corporation in the United States and other

countries.

FCC Warning

Note: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

--Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by InFocus Corporation may void

authority to operate the equipment.

Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Agency Approvals

UL, cUL

Other specific Country Approvals may apply. Please see product certification label.

This document applies to regulatory models W2100 and W2106.

Input ratings: 100-240Vac, 3.0A, 50-60Hz

InFocus reserves the right to alter product offerings and specifications at any time

without notice.

Table of Contents

Introduction 3

Positioning the projector 5

Projector and device connector guide 6

Connecting a computer source 9

Required computer connections 9

Optional computer connections 9

Displaying an image 10

Adjusting the image 11

Connecting a video device 12

Composite video connection 13

S-video connection 13

VESA connection 13

Component video connection 13

Shutting down the projector 14

Troubleshooting your setup 14

Using the remote control 22

Using the audio 23

Using the keypad buttons 24

Optimizing computer images 25

Presentation features 25

Optimizing video images 26

Customizing the projector 26

Using the menus 27

Basic Picture menu 28

Advanced Picture menu 29

Setup menu 30

Status and Service menu 32

Maintenance 33

Cleaning the lens 33

Using the security lock 33

Replacing the projection lamp 34

Important Operating Considerations for Safety

•Place the projector in a horizontal position no greater than 15 degrees

off axis.

• Locate the projector in a well-ventilated area without any obstructions

to intake or exhaust vents. Do not place the projector on a tablecloth or

other soft covering that may block the vents.

• Locate the projector at least 4' (1.2 m) away from any heating or cooling

vents.

• Use only InFocus-approved ceiling mounts. Warning:To prevent eye

injury if the projector is ceiling mounted, wear protective eyewear

before opening lamp door. A warning sticker is included with the user

documentation. Place this sticker on the lamp door if the projector is

mounted on the ceiling.

• Only genuine InFocus lamps are tested for use in this projector. InFocus

is not liable for the performance, safety or certification of any other

lamps. The use of other lamps violates the projector warranty and

voids all certification marks on this projector.

• Use only the power cord provided. A surge-protected power strip is

recommended.

• Refer to this guide for proper startup and shutdown procedures.

• Hg – Lamp contains mercury. Manage in accordance with local

disposal laws. See www.lamprecycle.org.

• In the unlikely event of a lamp rupture, particles may exit through the

projector side vents. When the projector is turned on, keep people,

food, and drinks out of the "keep out" area under and around the pro-

jector, as indicated by the "X" areas below.

Follow these instructions to help ensure image quality and lamp life over

the life of the projector. Failure to follow these instructions may affect the

warranty. For complete details of the warranty, see the Warranty booklet.

5’/1.5m

8’/2.4m

2’/0.6

3’/1m

Introduction

Your new digital projector is simple to connect, easy to use, and straightfor-

ward to maintain. It is a versatile projector that is flexible enough for busi-

ness presentations and home video viewing too. The A1100 has native

SVGA 800x600 resolution, the A1200 has native XGA 1024x768 resolution,

and the A1300 has WXGA 1280x800 resolution. This guide applies to all

products. They are compatible with a wide variety of computers and video

devices.

Product specifications

To read the latest specifications on your multimedia projector, be sure to

visit our website at www.infocus.com, as specifications are subject to

change.

Accessories

The standard accessories that came with your projector are listed in the

included Quick Start card. Optional accessories can be found on our website

at www.infocus.com or at your retailer or dealer.

Online Registration

vate your warranty and receive product updates, announcements, and reg-

istration incentives.

keypad

elevator foot release

focus (front ring)

remote control

receiver (IR)

zoom (rear ring)

panel

connector

Connector Panel

The projector provides both computer and video connection options,

including:

•VESAcomputer(2)

•S-video

• Composite video

• Separate audio inputs for video and computer

The projector also provides the following connectors:

• Monitor out, to provide an image on your desktop computer as well as

on the projection screen

• Audio out, to provide sound for external speakers

• USB, to provide mouse control (used with an optional remote control

only)

• A 5 volt DC output (see below)

It also has an RS-232 connector for serial control. The Command Line Inter-

face (CLI) specifications and commands are on our website.

5 volt DC output

The 3.5mm mini-jack triggers provide a 5 volt, 2 amp DC output. It provides

a constant output while the projector is on. It is designed to provide power

for an InFocus LiteShow II wireless device, which allows wireless projec-

tion. More information can be found on our website at www.infocus.com or

at your retailer or dealer.

computer

monitor

S-video

audio

out out

USB

composite video

audio in

foot

adjustable

security lock

RS-232

5 volt output

Positioning the projector

To determine where to position the projector, consider the size and shape of

your screen, the location of your power outlets, and the distance between

the projector and the rest of your equipment. Here are some general guide-

lines:

• Position the projector on a flat surface at a right angle to the screen. The

projector must be at least 4.9 feet (1.5m) from the projection screen.

• Position the projector within 10 feet (3m) of your power source and

within 6 feet (1.8m) of your video device (unless you purchase exten-

sion cables). To ensure adequate cable access, do not place the projector

within 6 inches (.15m) of a wall or other object.

• If you are installing the projector on the ceiling, refer to the installation

guide that comes with the Ceiling Mount Kit for more information. To

turn the image upside down, see “Ceiling” on page 30. We recommend

using an InFocus authorized ceiling mount.

• Position the projector the desired distance from the screen. The distance

from the lens of the projector to the screen, the zoom setting, and the

video format determine the size of the projected image.

• The image exits the projector at a given angle. This image offset is 115%.

This means that if you have an image 10’ high, the bottom of the image

will be 1.15’ above the center of the lens.

Table 1:

Range of distance to the screen for a given screen size

Diagonal

Screen Size

(inches/m)

Distance to screen

Maximum

distance

(feet/m)

Minimum

Distance

(feet/m)

60/1.5 7.7/2.3 8.5/2.6

80/2 10.3/3.1 11.5/3.5

92/2.3 11.8/3.6 13.1/4.0

150/3.8 19.4/5.9 21.7/6.6

bottom of image

1.15 ft above center

10 ft high


Projection angle

lens center

of lens

Projector and device connector guide

The following illustration and table should help you find the connectors to

use and obtain the best resolution possible from your input devices, such as

computers, standard VCRs, DVD players (progressive and interlaced),

HDTV sources (1080i and 720p HDTV formats), TV and satellite tuners,

camcorders, video games (progressive and interlaced), and laser disc play-

ers.

computer

monitor

S-video

audio

out out

USB

composite video

audio in

foot

adjustable

security lock

RS-232

5 volt output

Video Device Video

Compatibility

If Your Device

Connector Is

Attach to Adapter

or Labeled

Connector on

Projector

For Setup Instructions, see Comments

Standard Broadcast TV (not

HDTV) via: cable, digital

cable, satellite TV, DVD, or

VCR

NTSC, PAL, and

SECAM formats

Composite video

or S-video

Video 2

or Video 1

Composite video connection on

page 13.

S-video connection on page 13

Not for progressive

(i.e. HDTV) sources.

See page 8.

Standard Video Camera

NTSC, PAL, and

SECAM formats

Composite video

or S-video

Video 2

or Video 1

Composite video connection on

page 13.

S-video connection on page 13

Not for progressive

(i.e. HDTV) sources.

See page 8.

Standard Video Game

NTSC, PAL, and

SECAM formats

Composite video

or S-video

Video 2

or Video 1

Composite video connection on

page 13.

S-video connection on page 13

Not for progressive

(i.e. HDTV) sources.

See page 8.

Video Device Video

Compatibility

If Your Device

Connector Is

Attach to Adapter

or Labeled

Connector on

Projector

For Setup Instructions, see Comments

HDTV

(High Definition TV)

1080i, 720p

Component 480i

VGA

Component video

Computer 1 or

Computer 2

Computer 1 or

Computer 2

via optional VESA to

Component adapter

VESA connection on page 13

Component video connection on

page 13

Progressive DVD

1080i, 720p

Component 480p

and 480i

VGA

Component video

Computer 1 or

Computer 2

Computer 1 or

Computer 2 via

optional VESA to

Component adapter

VESA connection on page 13

Component video connection on

page 13

Progressive Video Game

1080i, 720p

Component 480p

and 480i

VGA

Component video

Computer 1 or

Computer 2

Computer 1 or

Computer 2

via optional VESA to

Component adapter

VESA connection on page 13

Component video connection on

page 13

Connecting a computer source

Required computer connections

Connect one end of the provided computer cable to the Computer 1 or

Computer 2 connector on the projector and the other to the VESA connec-

tor on your computer. If you are using a desktop computer, you will need to

disconnect the monitor cable from the computer’s video port first (you can

connect this monitor cable to the Monitor Out connector on the projector,

see below).

Connect the black power cord to the Power connector on the side of the pro-

jector and to your electrical outlet. The Power light on the Status Indicator

Panel (page 14) turns amber.

NOTE: Always use the power cord that shipped with the projector.

Optional computer connections

To get sound from the projector, connect an audio cable (optional cable, not

included) to your computer and to the Audio In Computer connector on

the projector. You may also need an adapter.

If you are using a desktop computer and want to see the image on your

computer screen as well as on the projection screen, connect the computer’s

monitor cable to the Monitor Out connector on the projector.

To advance slides in a PowerPoint presentation using an optional remote

control, plug the USB cable into the USB mouse connector on your com-

puter and the USB connector on the projector.

connect computer cable

connect power cord

connect audio cable

connect monitor cable

connect USB cable

Autres manuels pour A1100

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ask Proxima Projecteur

Ask Proxima

Ask Proxima Impression A6+ Manuel utilisateur

Ask Proxima

Ask Proxima DP5900 Mode d’emploi

Ask Proxima

Ask Proxima C250 Manuel utilisateur

Ask Proxima

Ask Proxima A4 Compact Manuel utilisateur

Ask Proxima

Ask Proxima C440 Manuel utilisateur

Ask Proxima

Ask Proxima A1100 Manuel utilisateur

Ask Proxima

Ask Proxima C440 (DP8400X) Manuel utilisateur

Ask Proxima

Ask Proxima M6 Manuel utilisateur

Ask Proxima

Ask Proxima E1655 series Manuel utilisateur

Ask Proxima

Ask Proxima C447 Manuel utilisateur

Ask Proxima

Ask Proxima DLP Projector Manuel utilisateur

Ask Proxima

Ask Proxima Impression A9 Manuel utilisateur

Ask Proxima

Ask Proxima M1 Manuel utilisateur

Ask Proxima

Ask Proxima M2+ Manuel utilisateur

Ask Proxima

Ask Proxima C110 Manuel utilisateur

Ask Proxima

Ask Proxima M8 Manuel utilisateur

Ask Proxima

Ask Proxima A1200EP Manuel utilisateur

Ask Proxima

Ask Proxima Impression A10+ Manuel utilisateur

Ask Proxima

Ask Proxima 9280 Manuel utilisateur

Ask Proxima

Ask Proxima C310 Manuel utilisateur

Ask Proxima

Ask Proxima C250 Manuel utilisateur

Ask Proxima

Ask Proxima M8 Manuel utilisateur

Ask Proxima

Ask Proxima Campus 700 Manuel utilisateur

Ask Proxima

Ask Proxima 9290 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
