AMT Datasouth Fastmark M4 Series Manuel utilisateur

The M4 packs a punch for a compact desktop printer. It provides both thermal transfer and direct thermal printing at up to

3 inches per second. This 203 dpi desktop printer is an ideal solution for a variety of applications, including healthcare,

retail, inventory, process control, or shipping.

Industrial Construction

• Innovative dual motor, gear drive concept handles high print volumes

• Clamshell design is ideal for easy loading of labels and ribbons

• 4.3” OD roll media capacity

Standard Features

• Our powerful and versatile “PAL” plus other popular emulations

• Compact design, small footprint

• Serial and USB ports

Fastmark M Series

Meeting Your Compact Printer Needs

Fastmark M Series

Meeting Your Compact Printer Needs

M4 – The Most Economical PAL Printer in the Market

Printer Model M4

Print Speed 2,3 ips (typical)

Resolution 203 dpi (8 dots/mm)

Command Set 203 dpi: PAL, EZPL, DPL

Resident Fonts San Serif and OCRB with smooth Scaling

Font and Barcode

Rotation 0, 90, 180, 270 degrees

Bar Code

Symbologies Code 39, Code93, Code 128UCC, Code 128

subsets A.B.C., Codabar, Interleaved 2 of 5,

EAN-8, EAN-13, EAN-128, UPC-A, UPC-E,

EAN and UPC 2(5) digits add-on, RSS

2-D Bar Code

Symbologies PDF-417, DataMatrix

Max Print Width 4.09” (104mm)

Max Print Length 40” (1016mm)

Printing Method Thermal Transfer and Direct Thermal

Media Size Width: 1.0-4.4” (25.4-114mm)

Thickness: 2.36-9.84 mil (0.06-0.25mm)

Media Diameter: 4.3” (109mm) OD (max)

Core Diameter: 1” (25.4mm)

Length: 0.4-39” (10-1000mm)

Media Sensor Type Auto sensor calibration

Gap transmissive sensor

Black mark reflective sensor

Ribbon end sensor

Media Type Continuous, die-cut, fan-fold, tag

Ribbon Capacity Max. Lenght: 984 ft. (300m)

Max. Width: 1” - 4.33” (25.4 - 110mm)

Memory 2MB Flash memory, 2MB DRAM

Software PAL Windows driver

Interface Standard RS-232 (max. 19200 bps) & USB 1.1

Physical Dimension 9.13” (W) x 11.34” (D) x 6.14” (H) 5.9 lbs

(232mm (W) x 288mm (D) x 156mm (H))

Power DC 24V, 60W, universal switching power supply

Operation Panel One power switch. Feed button and Pause

button

Processor 32-bit RISC CPU

Enclosure ABS Plastic

Environment

Conditions Operation: 41° to 104° F (5° to 40°C)

25-85% non-condensing

Storage: -40° to 140° F (-40° to 60°C)

10-90% non-condensing

Safety Regulations FCC Class A, CE Class A, UL, CUL

User Option KU-007 plus

External ethernet print server

External roll mount, media OD. 8.4” (214mm)

with 1” or 3” core 3” core label spindle

Accessories

CD, Ribbon for TT, USB cable and

Quick Start Guide

Warranty One year Parts and Labor, Return to Depot

Six months Printhead

PRINTER SPECIFICATIONS INCLUDE:

Part No. 121580 rev. A

Specifications are subject to change without notice.

# 8642

All M4s are ready for loading custom PAL applications

www.amtdatasouth.com

Charlotte Operation

4216 Stuart Andrew Blvd.,

Charlotte, NC 28217

(704) 523-8500 PH

(704) 525-6104 FX

Corporate Headquarters

803 Camarillo Springs Road, Suite D,

Camarillo, California 93012

(805) 388-5799 PH

(805) 484-5282 FX
