AMG4683BxR

Instruction Manual

8 Channel Video Transmit Unit with up to 2 Bi-directional

Data and Audio Channels for a Multimode Fibre Link

The AMG4683BxR is a rackmount eight channel video transmit unit designed to transmit 8 video

signals and transmit and receive up to 2 data or audio signals over two Multimode fibres.

The AMG4683BxR is designed to plug into an AMG2005 subrack, which in turn fits into a 19" rack

system.

The AMG4683BxR is designed to operate with AMG4684Bx or rackmount equivalent AMG4684BxR

eight channel video receive unit in a point to point configuration.

AMG Systems Ltd. reserves the right to make changes to this

document without notice. The information herein is believed to

be accurate. No responsibility is assumed by AMG for its use.

Page 2 of 10 AMG4683BxR Instruction Sheet

D16810-00.doc

issue 00

Contents

Introduction 3

Unit Functional Schematic .................................................................................................................. 3

Optical Connection ............................................................................................................................. 3

Connections 4

Video Input Connections..................................................................................................................... 4

Optical Connections............................................................................................................................ 4

Power Connection .............................................................................................................................. 4

Data and Audio Channel Connections ............................................................................................... 4

Data and Audio Channel Configuration 5

Data and Audio Channel Configuration .............................................................................................. 5

Data Interface Connections Channel A .............................................................................................. 5

Data Channel A Configuration ............................................................................................................ 5

Data / Audio Channel B Configuration................................................................................................ 6

Data Interface Daughter Board Options ............................................................................................. 6

Audio / Data Interface Connections RJ45 - Channel B ...................................................................... 6

Front panel Indicators 7

Power LED.......................................................................................................................................... 7

Video Input LED’s ............................................................................................................................... 7

Fibre Optic LED’s................................................................................................................................ 7

Low Speed Data LEDs ....................................................................................................................... 7

Physical Information 9

Dimensions ......................................................................................................................................... 9

Mounting Details ................................................................................................................................. 9

Removal / replacement from / to the Case ......................................................................................... 9

Safety 9

Maintenance and Repair 9

AMG Systems Ltd. reserves the right to make changes to this

document without notice. The information herein is believed to

be accurate. No responsibility is assumed by AMG for its use.

Page 3 of 10 AMG4683BxR Instruction Sheet

D16810-00.doc

issue 00

Introduction

Unit Functional Schematic

The AMG4683BxR transmits up to 8

video and 2 data and audio signals to the

AMG4684BxR.

It also receives up to 2 data and audio

channels transmitted from the

AMG4684BxR.

Optical Connection

The AMG4683BxR is connected as illustrated below when used with an AMG4684BxR 8-channel

receive unit acting as a point to point system.

AMG Systems Ltd. reserves the right to make changes to this

document without notice. The information herein is believed to

be accurate. No responsibility is assumed by AMG for its use.

Page 4 of 10 AMG4683BxR Instruction Sheet

D16810-00.doc

issue 00

Connections

Video Input Connections

Connector ........................................... 75 ohm BNC Socket.

Input Impedance ................................. 75 ohm terminated.

Input Level .......................................... 1 volt p-p nominal

Frequency Response.......................... 10Hz to 5.75MHz min.

No of channels .................................... 8

Optical Connections

PRIMARY OPTO OUT

Connector ........................................... LC/PC

Primary Optical Launch Power ........... -5dBm

Wavelength ......................................... 1310nm

Optical Fibre........................................ Multimode 50/125 or 62.5/125**

PRIMARY OPTO IN

Connector ........................................... LC/PC

Primary Optical Sensitivity .................. -22dBm

Wavelength ......................................... 1310nm

Optical Fibre........................................ Multimode 50/125 or 62.5/125**

**Note: the transmission distance is limited by the bandwidth of the Multimode optical fibre. The optical

data rate is 1.25Gbits/s. The maximum bandwidth specification at this data rate for Multimode fibre is

2km. although in most cases the units will operate successfully over longer fibre lengths. It is

advisable however for distances greater than 2km, to have the optical fibre tested.

Power Connection

Power supply ...................................... from plug in connection on the 2005 subrack

Power consumption ............................ 10 Watts max.

Data and Audio Channel Connections

Total No. of Data Channels................. 2 channels

DATA CHANNEL A

Data Channel A................................... 1 channel

Data Connector................................... RJ45

Channel A Interface On Board Data Interface – RS232, RS422 or RS485. Selected by slide switch

above the RJ45 connector.

RS485 – switch position - high (closest to BNC connections)

RS422 – switch position – middle

RS232 – switch position – low (furthest from BNC connections)

DATA CHANNEL B

Data Channel B................................... 1 channel

Data Connector................................... RJ45

Channel B Interface ............................ Defined by data/audio interface daughter board fitted into Slot 1

on main board and indicated by the ‘x’ in the AMG partno.

AMG Systems Ltd. reserves the right to make changes to this

document without notice. The information herein is believed to

be accurate. No responsibility is assumed by AMG for its use.

Page 5 of 10 AMG4683BxR Instruction Sheet

D16810-00.doc

issue 00

Data and Audio Channel Configuration

The AMG4683Bx and rackmount equivalent AMG4683BxR sends and receives data to/from Channel

A and Channel B. Channel A is a single data interface selectable by the user with the slide switch on

the rear panel. Channel B carries a second channel of data / audio, the function and physical interface

being determined by the type of daughter board fitted to the B Channel data slot.

Data Interface Connections Channel A

Channel A

RJ45 Pin

No. RS485

[switch high]

RS422

[switch mid]

RS232

[switch low]

Cat 5/6 Cable

Colour Code T568B

1IN + (A) GND White/orange

2IN - (B) IN Orange

3 White/green

4 Blue

5 White/blue

6 Green

7IN/OUT + (A) OUT + (A) N/A White/brown

8IN/OUT - (B) OUT - (B) OUT Brown

Note: (A) or (B) in brackets in above table refers to RS485 / RS422 data specification, not Channel A,

Channel B.

Data Channel A Configuration

Channel A is always present and allows for a RS232, RS422 (full duplex, four wire) or RS485 (half

duplex, two wire) interface depending on the position of the switch located above the RJ45 connector.

The switch signifies the presence of the X16004 Low Speed Data/Audio Interface Board. If there are

LED's present on the RJ45 connector then an X16003 Ethernet Interface Board is fitted.

The data input for both the RS485 and the RS422 modes detects a tri-state input condition by

monitoring the differential voltage level across the input. A differential level below 600mV positive or

negative will be detected as a tri-state condition. A level above 600mV positive or negative will be

detected as a logic 1 or logic zero respectively. It is important therefore to terminate the RS485 bus or

the RS422 input bus using 120Ω if a pre-bias is present on the RS485 or RS422 bus.

A large number of third party equipment manufacturers apply a pre-bias on their RS485 bus. This pre-

bias is applied by pulling one arm of the RS485 bus high (+5 volts) and the other arm low (0 volts)

using high value resistors within the third party equipment. In order to ensure that the AMG equipment

detects a tri-state condition, then these resistors should have a value above 5kΩ. If the third party bias

resistors are less the 750Ω the bus can be double or triple terminated as required to ensure that a tri-

state level is detected.

Note: The Data Channel A is shipped from the factory set up for RS485 operation unless otherwise

requested.

AMG Systems Ltd. reserves the right to make changes to this

document without notice. The information herein is believed to

be accurate. No responsibility is assumed by AMG for its use.

Page 6 of 10 AMG4683BxR Instruction Sheet

D16810-00.doc

issue 00

Data / Audio Channel B Configuration

Data Channel B is operational when fitted with the appropriate daughter board.

Data Interface Daughter Board Options

The data interface daughter board options are as follows:

Option

Code 'x'

Part No. Description

0 X12542 4 Wire Audio Interface Daughter Board

1 X04057 RS422/485 Data Interface Daughter Board

2 X04049 RS232 Data Interface Daughter Board

3 X04058 20mA Current Loop Data Interface Daughter Board

4 X12579 TTL Data Interface Daughter Board

5 X12578 Contact Closure Data Interface Daughter Board

6 X13038 FTT10A Echelon Lonworks Data Interface Daughter Board

Audio / Data Interface Connections RJ45 - Channel B

RJ45 Channel B low speed data/audio interface connections:

Channel B

RJ45 Pin

No. Data / Audio

Daughter Board

Cat 5/6 Cable

Colour Code T568B

1 White/orange

2 Orange

3OUT + (A) White/green

4IN - (B) Blue

5IN + (A) White/blue

6OUT - (B) Green

7 White/brown

8 Brown

Note: (A) or (B) in brackets in above table refers to RS485 / RS422 data specification, not Channel A,

Channel B.

AMG Systems Ltd. reserves the right to make changes to this

document without notice. The information herein is believed to

be accurate. No responsibility is assumed by AMG for its use.

Page 7 of 10 AMG4683BxR Instruction Sheet

D16810-00.doc

issue 00

Front panel Indicators

Power LED

Power...................................................Green - unit powered

Off - no power applied to unit

Video Input LED’s

Video Present CH1-8...........................Green - video signal present on input BNC

R/G - channel present but no video on I/P BNC

Fibre Optic LED’s

Primary Opto Sync TX .........................Green - optical channel transmitting

Off - optical channel not transmitting

Primary Opto Sync RX.........................Green - optical channel receiving

R/G - optical channel receiving but not sync.

Off - optical channel not transmitting

Low Speed Data LEDs

Channel A

Data Present TX (RS485 or RS422) ...Green - logic zero (+V, -V) present on IN+

Red - logic one (-V, V+) present on IN+

Off - tri-state off or no connection on IN+, IN-

Data Present TX (RS232)....................Green - logic zero (+V) present on input IN+

Red - logic transitions present on input IN+

Off - logic one (-V) present on input IN+

This represents the data signals being transmitted on the optical fibre

Data Present RX (RS485 or RS422) ...Green - logic zero (+V,-V) present on OUT+, OUT-

Red - logic one (-V,+V) present on OUT+, OUT-

Off - tri-state off or no connection on OUT+, OUT-

Data Present RX (RS232) ...................Green - logic zero (+V) present on OUT+

Red - logic transitions present on OUT+

Off - logic one (-V) present on OUT+

This represents the data signals being received on the optical fibre

Channel B (When RS232 data daughter board fitted)

Data Present TX ..................................Green - logic zero (+V) present on IN+

Red - logic transitions present on IN+

Off - logic one (-V) present on IN+

This represents the data signals being transmitted on the optical fibre

Data Present RX ..................................Green - logic zero (+V) present on OUT+

Red - logic transitions present on OUT+

Off - logic one (-V) present on OUT+

This represents the data signals being received on the optical fibre

AMG Systems Ltd. reserves the right to make changes to this

document without notice. The information herein is believed to

be accurate. No responsibility is assumed by AMG for its use.

Page 8 of 10 AMG4683BxR Instruction Sheet

D16810-00.doc

issue 00

Channel B (When RS485 / RS422 data daughter board fitted)

Data Present TX ................................. Green - logic zero (+V, -V) present on IN+, IN-

Red - logic transitions present on IN+, IN-

Off - logic one (-V, +V) present on IN+, IN-

This represents the data signals being transmitted on the optical fibre

Data Present RX ................................. Green - logic zero (+V, -V) present on OUT+, OUT-

Red - logic transitions present on OUT+, OUT-

Off - logic one (-V , +V) present on OUT+, OUT-

This represents the data signals being received on the optical fibre

Channel B (When audio daughter board fitted)

Audio Present TX................................ Green - audio present > -40dBm

Red - audio present > 0dBm (overload at +6dBm)

Off - audio not present or < -40dBm

This represents the audio signals being transmitted on the optical fibre

Audio Present RX ............................... Green - audio present > -40dBm

Red - audio present > 0dBm (overload at +6dBm)

Off - audio not present or < -40dBm

This represents the audio signals being received from the optical fibre.

AMG Systems Ltd. reserves the right to make changes to this

document without notice. The information herein is believed to

be accurate. No responsibility is assumed by AMG for its use.

Page 9 of 10 AMG4683BxR Instruction Sheet

D16810-00.doc

issue 00

Physical Information

Dimensions

Height...................................................3U Plug-in

Width....................................................14HP

Depth ...................................................170mm excluding connectors

Weight..................................................1000grams

Mounting Details

The unit is designed to be mounted within a 2005 Subrack on standard card guides. Note the AMG

standard racks are supplied with guide rails every 7HP. In order to fit this unit in the subrack, 2 sets of

card guides have to be removed by pulling gently on the card guides.

Removal / replacement from / to the Case

Note: - The AMG Unit PCB's are static sensitive. Handle with proper care and use normal electrostatic

discharge (ESD) procedures. Use properly grounded protection (for example, wrist straps) when

handling the PCB.

To remove units from the case to access the data expansion boards and the daughter boards, remove

the 4 fixing screws on the rear panel and slide the PCB's out of the case.

Ensure that the fibres do not snag or get trapped.

To replace the PCB's into the case, slide the PCB's gently into the case aligning the boards with the

appropriate slots. Ensure that the fibre do not snag or get trapped.

Safety

AMG Optical Fibre Products use Class 1 laser systems in accordance with EN 60825-2:2000.

It is always advisable to follow good practice when working with optical fibre systems. This includes:

Do not stare with unprotected eyes or with any unapproved collimating device at fibre ends or

connector faces, or point them at other people.

Use only approved filtered or attenuating viewing aids

For other safety issues and advice on good practice associated with optical fibre systems, please see

EN 60825-2:2000 or your local safety officer.

Maintenance and Repair

There are no user serviceable parts within AMG products. See unit data sheet for full specification.

In case of problem or failure, please call your local support centre or contact: AMG Systems Ltd. at

3 The Omega Centre, Stratton Business Park, Biggleswade, Beds., SG18 8QB, UK.

Phone +44 (0) 1767 600 777

Technical support +44 (0) 1767 604 491

Email techsupport@amgsystems.com

AMG Systems Ltd. reserves the right to make changes to this

document without notice. The information herein is believed to

be accurate. No responsibility is assumed by AMG for its use.

Page 10 of 10 AMG4683BxR Instruction Sheet

D16810-00.doc

issue 00

This page is intentionally blank.

Table des matières

Autres manuels AMG Émetteur

AMG

AMG AMG5513 Manuel utilisateur

AMG

AMG AMG4723 Manuel utilisateur

AMG

AMG AMG4707 Manuel utilisateur

AMG

AMG AMG3743E Manuel utilisateur

AMG

AMG AMG4781ER-SF Manuel utilisateur

AMG

AMG AMG5513A5B9 Manuel utilisateur

AMG

AMG AMG5615 Manuel utilisateur

AMG

AMG AMG4787BER-SF Manuel utilisateur

AMG

AMG AMG5803A966G-DF Manuel utilisateur

AMG

AMG AMG4743-SF Manuel utilisateur

AMG

AMG AMG4723-CWDMn-MP Manuel utilisateur

AMG

AMG AMG4687BE Manuel utilisateur

AMG

AMG AMG4783BxE-SF Manuel utilisateur

AMG

AMG AMG4681-1550-C Manuel utilisateur

AMG

AMG AMG6781 Manuel utilisateur

AMG

AMG AMG5913-2A9 Manuel utilisateur

AMG

AMG AMG4681R-CWDMn Manuel utilisateur

AMG

AMG AMG5813R Manuel utilisateur

AMG

AMG AMG4747AG-SF Manuel utilisateur

AMG

AMG AMG4713E Manuel utilisateur

AMG

AMG AMG4687B Manuel utilisateur

AMG

AMG AMG5611 Manuel utilisateur

AMG

AMG AMG3741G-DR-SF Manuel utilisateur

AMG

AMG AMG5713A6B9-DIN Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Honeywell

Honeywell 5816WMBR Manuel utilisateur

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur
