Ameriwood 6421403COM Manuel utilisateur

2Door/1DrawerBaseCabinet

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

AssemblyDifficultyMeter

Easy Tough

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.

Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

2

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.

‐Identify,sortandcountthepartsbeforeattemptingassembly.

‐Compressiondowelsarelightlytappedinwithahammer.

‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.

‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.

‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.

‐Backpanelmustbeusedtomakesureyourunitissturdy.

‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.

‐Neverpush,pull,ordragyourfurniture.

3

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder

Separateandcountallyourpartsandhardware

Giveyourselfenoughroomfortheassemblyprocess

Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

5

BoardIdentification

Notactualsize

LeftPanel

37367015012

RightPanel

37367015022

Bottom

37367015041

LeftDrawerSide

37368302061

Top

37368015030

DrawerFront

31346403050

RightDrawerSide

37368302071

DrawerBack

37368302080

DrawerBrace

37368000130

DrawerBottom

37368302140

AdjustableShelf

37367015150

Door(x2)

36421403160

BackPanel

K73671500

GHMN

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

6

BoardIdentification

Notactualsize

This piece is paperboard

construction. It is not made

from wood, but is required for

the assembly of your unit.

7

PartList

ActualSize

(x8)

#A22620

camlock

(x8)

#A22610

cambolt

(x12)

#A12120

7/16"panhead

(x8)

#A12420

5/8"panhead

(x4)

#A12930

1‐1/8"panhead

(x2)

#A21520

compressiondowel

(x34)

#A21110

nail

(x4)

#A23030

confirmat screw

(x6)

#A11600

1‐1/4"flathead

(x6)

#A17400

8‐32x7/8"truss

(x2)

#A89020

bumper

(x2)

#A11160

5/8"screw

(x4)

#A80250

shelfsupport

16 17 18

8

PartList

NotActualSize

14a

14b

14c

14d

(x1)

#A56100

drawerslide

#A84050

safetybracketkit

(x3)

#A50395

handle (x4)

#A44135

adjustablefoot

(x4)

#A65700

hinge

9

STEP1

Separatethehingeplatebypressingthehingereleaseattheendofthehingearm.

Removethehingecoverfromthehingearm.

Presstoreleasehingeplate.

hingeplate

hingecover

10

STEP2

(x2)

#A22610

13 15

(x3)

#A12120

(x1)

#A56100

(x2)

#A65700

Locatetheslidekit(13).Extendtheslidesasshownandpressthereleaselevertoremovetheinnerslide.Setthe

innerslidesasideforlater.Startbyattachingtheslidestothepanelsattherearoftheslide.Whileslidingthe

middleslidelocatetheholesinthepanelswiththeaccessholeinthemiddleslideandfastenwithscrews(3)as

shown.

inner slide

release lever middle slide

outer slide

use this hole

access holes

use these holes
