Alfalaval ThinkTop V20 Manuel utilisateur

ThinkTop

V20

BRITISH ENGLISH

2066-0184

Lit. Code 200008387-1-EN-GB

Manual No. 100008401 Instruction Manual

Published by

Alfa Laval Kolding A/S

Albuen 31

DK-6000 Kolding, Denmark

+45 79 32 22 00

The original instructions are in English

This document and its contents are subject to copyrights and other intellectual property rights owned by Alfa Laval Corporate AB. No part of this document may be copied, re-produced or

transmitted in any form or by any means, or for any purpose, without Alfa Laval Corporate AB’s prior express written permission. Information and services provided in this document are

made as a benefit and service to the user, and no representations or warranties are made about the accuracy or suitability of this information and these services for any purpose. All rights

are reserved.

Contents

1 EU Declaration of Conformity.......................................................................... 5

2 UK Declaration of Conformity.......................................................................... 7

3 About ThinkTop..........................................................................................................9

3.1 About this manual......................................................................................................9

4 Installation................................................................................................................... 11

4.1 Mechanical installation............................................................................................ 12

4.2 Electrical installation................................................................................................13

5 Setup...............................................................................................................................15

5.1 Unassisted setup.....................................................................................................15

5.2 Manual setup...........................................................................................................16

5.3 Reset....................................................................................................................... 17

6 Troubleshooting.......................................................................................................19

7 Spare parts................................................................................................................. 21

1 EU Declaration of Conformity

The Designated Company

Alfa Laval Kolding A/S, Albuen 31, DK-6000 Kolding, Denmark, +45 79 32 22 00

Company name, address and phone number

Hereby declare that

Top Unit for Valve Indication

Designation

ThinkTop V20

Type

Serial number from 0 to 10.000.000

is in conformity with the following directives with amendments:

- EMC Directive 2014/30/EU

- RoHS Directive 2011/65/EU and amendments

The person authorised to compile the technical file is the signer of this document.

Global Product Quality Manager Lars Kruse Andersen

Title Name

Kolding, Denmark 2022–11–01

Place Date (YYYY-MM-DD) Signature

200008387-1-EN-GB 5

200008387-1-EN-GB6

1 EU Declaration of ConformityEN

2 UK Declaration of Conformity

The Designated Company

Alfa Laval Kolding A/S, Albuen 31, DK-6000 Kolding, Denmark, +45 79 32 22 00

Company name, address and phone number

Hereby declare that

Top Unit for Valve Indication

Designation

ThinkTop V20

Type

Serial number from 0 to 10.000.000

is in conformity with the following directives with amendments:

- The Electromagnetic Compatibility Regulations 2016

- The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regula-

tions 2012

Signed on behalf of: Alfa Laval Kolding A/S

Global Product Quality Manager Lars Kruse Andersen

Title Name

Kolding, Denmark 2022–11–01

Place Date (YYYY-MM-DD) Signature

DoC Revision_01_112022

200008387-1-EN-GB 7

200008387-1-EN-GB8

2 UK Declaration of ConformityEN

3 About ThinkTop

ThinkTop V20 is a valve-top surveillance unit that provides surveillance of valves during the fluid

handling process. The surveillance unit has been developed with user friendliness and robustness in

mind.

ThinkTop V20 comes with a valve surveillance sensor board for connection to any PLC system. There

are three types of communication interfaces available:

Digital I/O 24 VDC, AS-Interface V3.0, and IO-Link.

The ThinkTop V20 detects valve position through a sensor target attached to the valve stem through a

touch-free sensor system The position is then evaluated and if valid, the corresponding feedback is

returned to the automation system via the communication interface.

V20, V50 and V70 series

ThinkTop comes in three series: V20, V50 and V70. The V20 series is the option for when all you

need is sensing. The V50 series is the compact option with a feature set tailored to valves that require

only one solenoid valve such as butterfly and single seat valves. The V70 series is the more flexible

option that can be configured to meet the needs of the most demanding valve applications such as

mixproof valves.

3.1 About this manual

In this manual, you will find detailed descriptions of how to install and setup the ThinkTop V20 as well

as detailed information about fault finding and maintenance. We recommend that you familiarize

yourself with the content of the manual before you begin installation.

2066-0185

200008387-1-EN-GB 9

200008387-1-EN-GB10

3 About ThinkTopEN
