Release Notes

OmniSwitch 6850E/6855/9000E

Release 6.4.6.R01

This release notes accompany release 6.4.6.R01 software for the OmniSwitch 6850E/6855/9000E

hardware. The release notes provides important information on individual software features and

hardware modules for the current release and related previous releases. Since much of the information

in this release notes is not included in the hardware and software user manuals, it is important that you

read all sections of this document before installing new hardware or loading new software.

Note: The OS6400 is not supported in Release 6.4.6.R01.

ATTENTION: Please refer to the 6.4.6.R01 Prerequisite section for important release specific

information prior to upgrading or incorporating a switch with AOS release 6.4.6.R01.

OmniSwitch AOS 6.4.6.R01 Release Notes Page 1 of 80

Part Number 032886-10 Rev. A

November 2013 AOS Release 6.4.6.R01 Release Notes

Contents

Contents..........................................................................................................................................................2

Related Documentation.................................................................................................................................3

System Requirements....................................................................................................................................5

Supported Hardware/Software Combinations...........................................................................................7

New Hardware Supported............................................................................................................................8

6.4.6.R01 New Software Features and Enhancements...............................................................................9

Monitoring/Troubleshooting Features ......................................................................................................13

SNMP Traps ................................................................................................................................................20

Unsupported Software Features ................................................................................................................34

Unsupported CLI Commands....................................................................................................................35

Open Problem Reports and Feature Exceptions in Release 6.4.6.R01 ...................................................37

Technical Support.......................................................................................................................................41

Appendix A: AOS 6.4.6.R01 Upgrade Instructions..................................................................................42

Appendix B: AOS 6.4.6.R01 Auto-FPGA Upgrade Instructions (OS6850E Only) ...............................51

Appendix C: AOS 6.4.6.R01 Downgrade Instructions.............................................................................59

Appendix D: Required Minimum Uboot for Modules with New Flash Component.............................67

Appendix E: Previous Release Features and Enhancements ..................................................................69

Page 2 of 80 OmniSwitch 6850E/6855/9000E—Release 6.4.6.R01

AOS Release 6.4.6.R01 Release Notes November 2013

Related Documentation

This release notes should be used in conjunction with the OmniSwitch 6850E, 6855, and 9000E user

manuals. The following are the titles and descriptions of the user manuals that apply to this release.

User manuals can be downloaded at:

http://enterprise.alcatel-lucent.com/?dept=UserGuides&page=Portal

•OmniSwitch 6850E Series Getting Started Guide

Describes the hardware and software procedures for getting an OmniSwitch 6850E Series

switch up and running.

•OmniSwitch 6855 Series Getting Started Guide

Describes the hardware and software procedures for getting an OmniSwitch 6855 Series

switch up and running.

•OmniSwitch 9000E Series Getting Started Guide

Describes the hardware and software procedures for getting an OmniSwitch 9000E Series

switch up and running.

•OmniSwitch 6850E Series Hardware User Guide

Complete technical specifications and procedures for all OmniSwitch 6850E Series chassis,

power supplies, and fans.

•OmniSwitch 6855 Series Hardware User Guide

Complete technical specifications and procedures for all OmniSwitch 6855 Series chassis,

power supplies, and fans.

•OmniSwitch 9000E Series Hardware User Guide

Complete technical specifications and procedures for all OmniSwitch 9000E Series chassis,

power supplies, and fans.

•OmniSwitch AOS Release 6 CLI Reference Guide

Complete reference to all CLI commands supported on the OmniSwitch. Includes syntax

definitions, default values, examples, usage guidelines, and CLI-to-MIB variable mappings.

•OmniSwitch AOS Release 6 Network Configuration Guide

Includes network configuration procedures and descriptive information on all the major

software features and protocols included in the base software package. Chapters cover Layer 2

information (Ethernet and VLAN configuration), Layer 3 information (routing protocols),

security options (Authenticated Switch Access (ASA), Quality of Service (QoS), link

aggregation.

•OmniSwitch AOS Release 6 Switch Management Guide

Includes procedures for readying an individual switch for integration into a network. Topics

include the software directory architecture, software rollback protections, authenticated switch

access, managing switch files, system configuration, using SNMP, and using web management

software (WebView).

•OmniSwitch AOS Release 6 Advanced Routing Configuration Guide

Includes network configuration procedures and descriptive information on all the software

features and protocols included in the advanced routing software package. Chapters cover

multicast routing (DVMRP and PIM), BGP, OSPF, and OSPFv3.

•OmniSwitch AOS Release 6 Transceivers Guide

Includes SFP and XFP transceiver specifications and product compatibility information.

OmniSwitch 6850E/6855/9000E------ Release 6.4.6.R01 Page 3 of 80

November 2013 AOS Release 6.4.6.R01 Release Notes

•Upgrade Instructions for 6.4.6.R01

Provides instructions for upgrading the OmniSwitch 6850E, 6855, and 9000E to 6.4.6.R01

(Included in this document).

•Technical Tips, Field Notices

Contracted customers can visit our customer service website at: service.esd.alcatel-lucent.com.

Page 4 of 80 OmniSwitch 6850E/6855/9000E—Release 6.4.6.R01

AOS Release 6.4.6.R01 Release Notes November 2013

System Requirements

Memory Requirements

•OmniSwitch 6850E Series Release 6.4.6.R01 requires 512 MB of SDRAM and 128 MB of

flash memory. This is the standard configuration shipped.

•OmniSwitch 6855 Series Release 6.4.6.R01 requires 256 MB of SDRAM and 128 MB flash

memory. This is the standard configuration shipped.

•OmniSwitch 9000E Series Release 6.4.6.R01 requires 1GB of SDRAM and 256 MB of flash

memory for the Chassis Management Module (CMM). This is the standard configuration

shipped.

Configuration files and the compressed software images—including web management software

(WebView) images—are stored in the flash memory. Use the show hardware info command to

determine your SDRAM and flash memory.

UBoot, FPGA, Miniboot, BootROM, Upgrade Requirements

The software versions listed below are the MINIMUM required, except where otherwise noted.

Switches running the minimum versions, as listed below, do not require any Uboot, Miniboot, or

FPGA upgrades when upgrading to AOS 6.4.6.R01.

Switches not running the minimum version required should upgrade to the latest Uboot, Miniboot,

FPGA that is available with the 6.4.6.R01 AOS software available from Service & Support.

Note: Refer to the 6.4.6.R01 Upgrade Instructions section for step-by-step instructions on upgrading

to Release 6.4.6.R01.

OmniSwitch 9000E

Release

Miniboot.uboot CMM

UBoot CMM

UBoot NI

FPGA CMM

CMM/NI

with Old

Flash

6.4.6.125.R01

6.4.3.479.R01

Major Revision: 2

Minor Revision: 25

(displays as 0x19;

recommended)

CMM/NI

with New

Flash

6.4.6.125.R01

6.4.4.506.R01

Major Revision: 2

Minor Revision: 25

(displays as 0x19;

recommended)

Note: Refer to the Required Minimum Uboot for Modules with New Flash Component for help with

determining OS9000E module Flash components.

OmniSwitch 6850E/6855/9000E------ Release 6.4.6.R01 Page 5 of 80

November 2013 AOS Release 6.4.6.R01 Release Notes

OmniSwitch 6850E

Release

Miniboot.uboot

UBoot

CPLD

6.4.6.125.R01

6.4.5.398.R02

OS6850E-C24/P24/C48/P48 (10 or 11)

OS6850E-U24X (7 or 8)

Note: CPLD version 17 is shipped for OS6850E-C24/P24/C48/P48 by factory default. CPLD version 12 is

shipped for OS6850E-U24X by factory default.

OmniSwitch 6850E with OS-BPS

Release

Miniboot.uboot

UBoot

CPLD

6.4.6.125.R01

6.4.5.398.R02

OS6850E-24/P24/48/P48 (17)

Note: The OS-BPS is not supported with the OS6850E-U24X.

OmniSwitch 6855-14/24/U10/U24/U24X

Release

Miniboot.uboot

UBoot

FPGA

6.4.6.125.R01

6.4.3.479.R01

v2.2

OmniSwitch 6855-P14

Release

Miniboot.uboot

UBoot

FPGA

6.4.6.125.R01

6.4.4.5.R02

v1.4

Prerequisites

Please verify the code version of a new switch being inserted into an existing stack. In some cases it may be

required to downgrade a new switch running AOS release 6.4.6 prior to inserting it into an existing stack

that is running an earlier code version. Please refer to the Downgrade Instructions.

Page 6 of 80 OmniSwitch 6850E/6855/9000E—Release 6.4.6.R01

AOS Release 6.4.6.R01 Release Notes November 2013

Supported Hardware/Software Combinations

The following table shows the 6.X software releases that support each of the listed OS6850E, OS6855

and 9000E module types:

Module Type

Part No.

6.3.1.R01

6.3.2.R01

6.3.3.R01

6.3.4.R01

6.4.1.R01

6.4.2.R01

6.4.3.R01

6.4.4.R01

6.4.5.R02

6.4.6.R01

OS9700E/9702E-CMM

902668

supported

OS9702E-CMM

902808

supported

OS9702-CHASSIS

902727

supported

OS9-GNI-C24E

902669

supported

OS9-GNI-U24E

902670

supported

OS9-XNI-U2E

902671

supported

OS9-XNI-U12E

902851

supported

OS9-GNI-P24E

902927

supported

OS6855-14

902648

supported

OS6855-24

902664

supported

OS6855-U10

902647

supported

OS6855-U24

902555

supported

OS6855-U24X

902802

supported

OS6855-P14

902970

supported

OS6850E-24

902936

supported

OS6850E-P24

902934

supported

OS6850E-24X

902937

supported

OS6850E-P24X

902935

supported

OS6850E-48

902938

supported

OS6850E-P48

902932

supported

OS6850E-48X

902939

supported

OS6850E-P48X

902933

supported

OS6850E-U24X

902940

supported

OmniSwitch 6850E/6855/9000E------ Release 6.4.6.R01 Page 7 of 80

November 2013 AOS Release 6.4.6.R01 Release Notes

New Hardware Supported

SFP-10G-24DWD80 Transceiver

Now supported on OS9-XNI-U12E, 6850E, 6850E-U24X.

iSFP-100-MM Transceiver

Now supported on OS9-GNI-U24E, OS6850E, OS6850E-U24X.

Note: Not supported on SFP+ ports.

iSFP-GIG-SX Transceiver

Now supported on OS9-GNI-U24E, OS9-XNI-U12E, OS6850E, OS6850E-U24X.

Note: Not supported on SFP+ ports.

iSFP-GIG-LX Transceiver

Now on OS9-GNI-U24E, OS9-XNI-U12E, OS6850E, OS6850E-U24X.

Note: Not supported on SFP+ ports.

iSFP-10G-LR Transceiver

Now supported on OS9-XNI-U12E, OS6850E , OS6850E-U24X.

iSFP-GIG-EZX Transceiver.

Now supported on OS9-GNI-U24E, OS6850E, OS6850E-U24X.

iSFP-GIG-BX-D/U Transceiver

Now supported on OS9-GNI-U24E, OS6850E, OS6850E-U24X.

iSFP-10G-ER Transceiver

Now supported on OS9-XNI-U12E, OS6850E, OS6850E-U24X.

Page 8 of 80 OmniSwitch 6850E/6855/9000E—Release 6.4.6.R01

AOS Release 6.4.6.R01 Release Notes November 2013

6.4.6.R01 New Software Features and

Enhancements

The following software features and enhancements are new with the 6.4.6.R01 release, subject to the

feature exceptions and problem reports described later in these release notes:

6.4.6.R01 New Feature/Enhancement Summary

Feature

Platform

Software Package

Hardware/Stacking Features:

- Split Stack Protection (SSP)

6850E

OS9000E (helper function

only)

Base

- LLDP PoE power negotiation

6850E/9000E

Base

Layer 3 Features:

- ISIS-IPv6

All

Adv. Rtg.

- M-ISIS

All

Adv. Rtg.

Management Features :

- Enabling or Disabling Console Session

All

Base

Monitoring/Troubleshooting Features :

- Gigaword packet counter

All

Base

Multicast Features:

- PIM Startup Delay

All

Adv. Rtg.

- Initiak multicast packet loss

All

Base

- Multicast Address Boundaries

All

Base

- L2 Star-G mode

All

Base

QoS Features :

- Per port rate limiting

All

Base

Security Features :

- Case sensitive MAC address

All

Base

- HIC HTTPS Web redirection

All

Base

VRF Features :

- IP Helper per-VLAN / per-VRF

All

Base

Application Fluency :

- mDNS Relay

All

Base

- VDI Support

All

Base

OmniSwitch 6850E/6855/9000E------ Release 6.4.6.R01 Page 9 of 80

November 2013 AOS Release 6.4.6.R01 Release Notes

Feature

Platform

Software Package

Bring Your Own Device (BYOD)

- Clearpass and Access Guardian Integration

- Change of Authorization (CoA)

- Port Bounce and URL redirect

All

Base

Additional Features:

- 802.1q Capability on NNI ports

All

Base

- Autoboot Interruption

6850E/6855

Base

- Control packet tunneling enhancement

All

Base

Page 10 of 80 OmniSwitch 6850E/6855/9000E—Release 6.4.6.R01

Autres manuels pour OmniSwitch 6850E Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Alcatel-Lucent Changer

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6560 Series Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6250 Manuel de programmation

Alcatel-Lucent

Alcatel-Lucent 7250 SAS Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6450 Series Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent 7210 SAS-R6 OS Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-3 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7210 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1850 Guide de l'utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6450 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850-48 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-320 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6400 Series Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent 7210 SAS E OS Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-320 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6900 Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent 7670 RSP Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 10K Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6855 Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7210 SAS E OS Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1850 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7210 SAS D Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6250 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent LambdaUnite 1675 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
