Alcatel-Lucent 1850 TSS-160

TRANSPORT SERVICE SWITCH | RELEASE 3

The Alcatel-Lucent 1850 TSS-160 is a compact version of the Alcatel-Lucent TSS-320. The two models share

the universal switch matrix architecture, operate on a common software release and use common circuit

packs. The Alcatel-Lucent 1850 TSS-160 is a next-generation, Packet-Optical Transport platform that supports

any mix of trafﬁc, from all-circuit to all-packet. With the Alcatel-Lucent 1850 TSS-160, businesses can begin

with circuit-based transport and gradually ramp up packet transport by simply changing line cards. The Alcatel-

Lucent 1850 TSS-160 supports current trafﬁc requirements while eliminating the scalability issues encountered

when traditional multiservice provisioning platforms (MSPPs) are confronted with the high growth of packet-

based trafﬁc.

The Alcatel-Lucent 1850 TSS-160 offers

the ﬂexibility to split increasing trafﬁc

demands among any combination of

Carrier Ethernet, Transport Multi-

Protocol Label Switching (T-MPLS),

wavelength division multiplexing

(WDM), optical data unit (ODU) and

SDH/SONET transport technologies. It

offers powerful cross-layer network

management and a uniﬁed control

plane, simplifying operations and

reducing the total cost of ownership.

Features

• Commonsoftwareandcircuitpacks

with Alcatel-Lucent 1850 TSS-320

• Unique,universalswitcharchitecture

¬ Switches packets or circuits in their

native format

¬ Accommodates any trafﬁc mix,

from all-circuit to all-packet

¬ Offers TDM and packet line cards

for technology-speciﬁc processing

• Fullyintegratesphotonic,optical

and data layers

¬ Any transport-technology mix

¬ Carrier Ethernet service through

T-MPLS for standards-based con-

nection-oriented packet transport

¬ SONET/SDH Optical Transport

Hierarchy (OTH) switching, includ-

ing higher-order and lower-order

(HO/LO) synchronous transport

signal (STS) and VC-switching

¬ Very long haul (VLH)/ultra long

haul (ULH) support

¬ ATM pseudo-wire transport and

gateway functions

¬ Dense WDM (DWDM)

¬ Transport-oriented OAM and

G-MPLS

Alcatel-Lucent 1850 TSS-160 | Release 3 | Data Sheet2

Technical speciﬁcations

Alcatel-Lucent 1850 TSS-160

system

Alcatel-Lucent 1850 TSS-160

subrack

• 8slots,20Gb/sperslot:16half

slots,10Gb/sperhalfslot

• Two160Gb/sprotectedswitching

fabrics

• Twoprotectedcontrollers

• Protectedpowersupply

• Uptothreesubracksinastandard

ETSI or ANSI rack

Interfaces

• Datacards

¬10xGigabitEthernet(GE)

packet module, Small Form-

Factor Pluggable (SFP)

¬10GEpacketmodule,10Gb/s

Form-Factor Pluggable (XFP)

¬ Multiservice packet over

SONET/SDH(PoS)packet

module, portless

¬ ATM gateway packet module,

portless

• SONET/SDHcards

¬1xOC-192/STM-64:XFP

¬4xOC-48/STM-16:SFP

¬8xOC-3-12/STM-1-4:SFP

¬10xanyportcard:adata/TDM

concentrator:SFP

¬ 1 x optical transport unit

(OTU)-2:10Gb/sbidirectional

transponder, tunable optics

• VLH/ULHcards

¬10Gb/sbooster+10dBm

¬10Gb/spre-amp+10dBm

• FixedOADM(FOADM)DWDM

cards (packs)

¬8channelsMUX/DEMUX,

L1 band

¬8channelsMUX/DEMUX,

L2 band

¬Opticalamplifier22/917dB

¬10Gtransponder,clientand

linepluggable:XFP

• ROADMDWDMcards(packs)

¬ Optical protection switch

¬ DWDM ROADM wavelength

router

¬DWDMtransponder:tunable

line optics, XFP client

¬DWDMMUX/DEMUX

¬ DWDM amplifier

• Deliversmultidegreerecongu-

rable optical add/drop multiplexer

(ROADM) functionality

¬ Reconﬁgurable 44 x 10 G channel

DWDM

¬ Wavelength selective switch (WSS)

1 x 9 ports

¬ Mesh capable ROADM up to

8 degrees

Beneﬁts

• Switchesanycombinationofpackets

and circuits in their native formats

using a single platform

• Fullyscalespackettransport,smoothly

progressing from all-circuit to all-

packet, allowing service providers

to transform networks to packet

transport

• Efcientlyaggregatesandgrooms

metro and long-haul transport

• Simpliesnetworkplanningusing

ROADM and WDM

• Reducestotalcostofownershipand

simpliﬁes operations through cross-

layer network management and

uniﬁed control plane

• Supportsabroadrangeofapplica-

tions, such as triple play services,

business Ethernet and mobility

backhaul

Service level agreement (SLA)

management

• Trafficprofiles

¬Bandwidthguaranteed

¬Regulated:minimumband-

width guaranteed plus burst

¬Besteffort

•Hitlesstraffic-profilemodification

• Metering

¬SingleRateTokenBucket:

RFC2697

¬DualRateTokenBucket:

RFC 2698

¬ IETF and Metro Ethernet Forum

(MEF) Metering, Policing and

Marking

¬ Color-blind and color-aware,

based on Ethernet priority bits

Ethernet functionality

• Ethernetprotocol:802.3

• EthernetMediaAccessControl

(MAC) autolearning and aging

• Ethernet-MACstaticconfiguration

• AccessControlList(ACL)

• VirtualLAN(VLAN)push,pop,

swap:servicedelimiting

• Ethernetvirtualbridging:802.1Q

• Ethernetproviderbridging:802.1ad

• QinQ

• RapidSpanningTreeProtocol

(RSTP) and Multiple Spanning

Tree Protocol (MSTP)

• Linkaggregation

• Jumbo-framemanagement

• Y.1731/802.1agOAM:continuity

check (CC), link trace (LT),

loopback(LB)

• 802.3ahOAM:Ethernetinthe

first mile (EFM)

• EightQualityofService(QoS)

classes

• TwolevelsQoS:perclass,per

transport service

• Ethernetflow,RGYcounters

• L2controlprotocolfiltering/

tunneling

• MetroEthernetForum(MEF)9

andMEF14certified:EPL,EVPL

and E-LAN

Ethernet traffic classification

• Port

• EthernetVLAN

• Ethernetprioritybits

• IPv4differentiatedservices

code points (DSCP)

•EtherType

• MPLSExpbits

Alcatel-Lucent 1850 TSS-160 | Release 3 | Data Sheet 3

Ethernet forwarding criteria

• Port

• PortplusMAC

• PortplusVLAN

• PortplusMACplusVLAN

• PortplusMACplusVLANplus

Prio bits

• Unicasttraffic

• Multicasttraffic

• Broadcasttraffic

IGMP functionality

• InternetGroupManagement

Protocol(IGMP)snooping

• IGMPproxy

• IGMPfastleave

ATM functionality

• Pseudo-wireemulationedgeto

edge(PWE3):ATM-PWE3gateway

• OC-3/STM-1ATMunchannalized

• ATMvirtualpathidentifier/virtual

channelidentifier(VPI/VCI)

N:1mappingwithPWE3static

configuration

• ATMQoS,OAMF4,F5:PWEOAM

T-MPLS functionality

• Dataplane:T-MPLS,MPLS

• T-MPLSOAM:CV,automaticpro-

tection switching (APS), forward

defect indication (FDI)

• TunnelLinProtection1:1

• Ethernetline(E-line),E-LAN

and E-Tree

SONET/SDH functionality

• Cross-connection

• Termination

• EthernetmappingoverSONET/SDH

¬Genericframingprocedure:

GFP,G.7041

• Virtualconcatenation(VCAT)

• Linkcapacityadjustmentscheme

(LCAS)

•Performancemonitoring

• HOandLOcapabilities

DWDM functionality

• Nodeconfigurations

¬ Terminal

¬ In-line amplifier (ILA)

•Networkconfigurations

¬ Point-to-point

¬ Linear

¬ Ring

¬ Mesh

Protection

• Ethernetnetworkprotection

¬RSTP:802.1w

¬MSTP:802.1s

¬ Link aggregation

• T-MPLSnetworkprotection

¬TunnelLinProtection1:1

•SONET/SDHnetworkprotection

¬Single-anddual-endedAPS1+1

¬ Subnetwork Connection

Protocol (SNCP), unidirectional

path-switchedring(UPSR)

¬ Multiplex Section-Protection

Ring(MSPRING)2Fbidirectional

lineswitchingring(BLSR)

•Equipmentprotection

¬ Power protection

¬ Controller protection

¬Universalswitchprotection

G-MPLS control plane

• T-MPLStunnelsetup

• TDMHOpathsetup

Management

• Alcatel-Lucent1350Optical

Management System (OMS)

• TL1

• Zero-installationcraft(ZIC)terminal

• Commandlineinterface(CLI)

• SimpleNetworkManagement

Protocol (SNMP)

• SecureShell(SSH)v2/Secure

Sockets Layer (SSL) for secure

connection

Physical specifications

ANSI

Dimensions: Alcatel-Lucent 1850

TSS-160 subrack

• Subrackdimensions

¬Height:304mm(12.0in.)

¬Width:498mm(19.6in.)

¬Depth:305mm(12.0in.)

or 356 mm (14.0 in.)

• Designedtobeinstalledina

standard ANSI rack

¬Height:2.13m(7.0ft.)

¬Width:660mm(26.0in.)

¬Depth:305mm(12.0in.)

or 356 mm (14.0 in.)

Power and cooling

• Powersupply:DCfeed(-48-VDC

nominal)

• Powersupply:-58-V

• Powerconsumption:upto2000W

• Cooling:forcedair

Environment

• Operatingtemperature:

-5°Cto+45°C(23°Fto113°F)

• Relativehumidity:0%to90%,

non-condensed

Regulatory compliance

• CEandULcertification

• NEBSlevel3

• FCCpart15classA

ETSI

Dimensions: Alcatel-Lucent 1850

TSS-160 subrack

• Subrackdimensions

¬Height:304mm(12.0in.)

¬Width:498mm(19.6in.)

¬Depth:290mm(11.4in.)

• Designedtobeinstalledina

standard ETSI rack

¬Height:2.20m(7.2ft.)

¬Width:600mm(23.6in.)

¬Depth:300mm(11.8in.)

Power and cooling

• Powersupply:DCfeed(-48-VDC

nominal)

• Powersupply:-65-V

• Powerconsumption:upto2000W

• Cooling:forcedair

Environment

• Operatingtemperature:

-5°Cto+45°C(23°Fto113°F)

• Relativehumidity:0%to90%,

non-condensed

Regulatory compliance

•CEcertification

• Operatingconditions:

ETS 300 019, Class 3.2

•Storageconditions:

ETS 300 019, Class 1.2

•Transportationconditions:

ETS 300 019, Class 2.2

• Electrostaticdischarge(ESD)/elec-

tromagneticcompatibility(EMC):

ETS 300 386 “Telecommunications

Center”

www.alcatel-lucent.com Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo

are trademarks of Alcatel-Lucent. All other trademarks are the property of their respective owners.

The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility

CAR4688080916 (09)

Autres manuels Alcatel-Lucent Changer

Alcatel-Lucent

Alcatel-Lucent LambdaUnite 1675 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850-48 Mode d’emploi

Alcatel-Lucent

Alcatel-Lucent OmniAccess 4504 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1671 Service Connect Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1830 PSS-16 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7210 SAS-R6 OS Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7210 SAS D Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6865-P16X Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-7 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7210 SAS-T Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6560 Series Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent ES4 Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniAccess 6000 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1850 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7950 SR Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch AOS Release 7 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch AOS Release 7 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850E Series Comment utiliser

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6250 Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 2220 Instructions d'installation

Alcatel-Lucent

Alcatel-Lucent 7210 SAS Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6855 Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1675 LambdaUnite Guide de l'utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch OS6850-P48L Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
