Alcatel-Lucent

1675 LambdaUnite

MultiService Switch

Versatile switching platform designed

to meet today’s network requirements

and to drive future network trends

The Alcatel-Lucent 1675 LambdaUnite MultiService

Switch (MSS) is a unique, future-proof platform that

supports a wide variety of applications in ring and

mesh network topologies while keeping the network

flexible, cost-effective and easy to manage. In addition

it provides the ability to cost-effectively integrate

Ethernet services in metropolitan and backbone

networks, enabling carriers to generate new revenue

streams. The Alcatel-Lucent 1675 LambdaUnite MSS,

a global product applicable to both SONET and SDH

markets, is deployed worldwide.

Alcatel-Lucent 1675 LambdaUnite MultiService Switch2

The system supports both SDH and SONET rates,

making it suitable for global network deployments.

Its common hardware/software and industry-standards

compliance help position you for rapid feature introduc-

tion and increased revenue opportunities, for small to

large office applications in backbone and metro networks.

In a Metro Network

In a metro network, the Alcatel-Lucent 1675

LambdaUnite MSS serves as a metro hub terminal,

efficiently aggregating multiple 2.5G and 10G rings

to help eliminate stacked ADMs. An optional passive

wavelength division multiplexing (WDM) unit can

be integrated for fiber exhaust situations.

The Alcatel-Lucent 1675

LambdaUnite MultiService Switch

(MSS) is a next-generation optical

switch that supports a variety of

applications, including add/drop

multiplexer (ADM), terminal

multiplexer, multi-ring hub and

broadband cross-connect. This

multifunctional platform helps lower

costs by reducing equipment, floor-

space and power requirements while

improving operational efficiency

and network reliability.

Alcatel-Lucent 1675 LambdaUnite MultiService Switch 3

Cost-Effective Support for a

Variety of Network Applications

4 Alcatel-Lucent 1675 LambdaUnite MultiService Switch

In Backbone Networks

In backbone networks, efficient

use of existing fiber is critical to

satisfying bandwidth demands. The

Alcatel-Lucent 1675 LambdaUnite

MSS efficiently aggregates and

grooms traffic to help maximize

bandwidth utilization and lower

per-bit costs. The optional, fully

transparent OC-48/STM-16 inter-

face card can help carriers to cost-

effectively address wavelength service

delivery using the existing SONET/

SDH network infrastructure.

Figure 1 shows two complete

Alcatel-Lucent 1675 LambdaUnite

MSSs in one rack, with a capacity

of 640G.

Figure 1. Two Alcatel-Lucent 1675 LambdaUnite MSS Systems

1675 LambdaUnite MSS

160G Conﬁguration

1675 LambdaUnite MSS

320G Conﬁguration

STM-16/STM-64

OC-48/OC-192

STM-16/STM-64

OC-48/OC-192

STM-4/STM-16

OC-12/OC-48

STM-1...STM-256

OC-3... OC-768

• VC-4-Xc

• STS-1-Xc

Ethernet

• STS-1-kv

• VC-4-kv

Navis®Optical

Management System

1663 Metropolis®

Add Drop Multiplexer-

universal (ADMu)

Wavestar®TDM 10G

(OC-192/STM-64)

Wavestar®OLS 1.6T

Lambdaunite®

Multiservice Switch

(MSS)

Multiterabit

Switch/Router

GX 550®ATM Switch

Transponder

10G/40G

Optical Backbone/

Transoceanic

With DWDM Systems and

Transoceanic Applications

When the Alcatel-Lucent 1675

LambdaUnite MSS is deployed

with an Alcatel-Lucent dense WDM

(DWDM) system, you can achieve

significant equipment savings by

using express optics because expen-

sive optical transport units (OTUs)

on the DWDM equipment are

eliminated.

The Alcatel-Lucent 1675

LambdaUnite MSS is well suited

for transoceanic applications. The

transoceanic protocol mechanism

supported by the system helps to

effectively protect groomed and

consolidated traffic for your

valuable undersea fiber route.

5Alcatel-Lucent 1675 LambdaUnite MultiService Switch

The Alcatel-Lucent 1675

LambdaUnite MSS performs as

a metro hub terminal, efficiently

aggregating multiple high-capacity

rings in your central office. This

deployment can result in significant

cost savings by eliminating stacked

ADMs at metro hubs. The central-

ized non-blocking switch is available

in 160G, 320G and 640G switching-

capacity options in a single shelf,

to help reduce floor space and

operation costs.

The Alcatel-Lucent 1675

LambdaUnite MSS leverages your

existing investments in SONET/

SDH networks to support traditional

revenue-generating services while

enabling new Ethernet services.

Combining SONET/SDH resilience

and quality of service (QoS) with

the flexibility and ubiquity of

Ethernet helps the system deliver

carrier-grade Ethernet services in

point-to-point and multipoint

configurations.

Seamless Delivery of Traditional

Circuit and Advanced Data Services

Central-Office Consolidation Opportunities

The Alcatel-Lucent TransLAN®

card option offers efficient and flex-

ible bandwidth-assignment capabil-

ities, including virtual concatenation

and link capacity adjustment scheme

(LCAS), to enable voice and data

transport and to help avoid separate

overlay networks that are costly to

build and manage.

High fiber utilization is accom-

plished using granular STS-1/VC-4

and VT-1.5/VC-12 grooming, a

wide range of service interfaces, and

advanced data-transport capabilities.

Occupying very little floor space

because of their high density, two

complete Alcatel-Lucent 1675

LambdaUnite MSSs fit in one rack,

providing up to 1.2 Tb/s per bay.

As shown in Figure 1, the Alcatel-

Lucent 1675 LambdaUnite MSS

supports various types of traffic and

protection schemes — all in one

network element.

6 Alcatel-Lucent 1675 LambdaUnite MultiService Switch

The Alcatel-Lucent 1675

LambdaUnite MSS offers a full

set of interface rates, reaches and

colored optics to help provide your

network with greater flexibility and

efficiency. Simultaneous support

for both ring and mesh allows you

to evolve network architectures

when you are ready.

System Architecture

The system architecture is based

on a full non-blocking duplicated

switch matrix. Each of the 32 I/O

slots can be filled with a variety of

cards ranging from 45 Mb/s up to

Supported Protection Schemes

The Alcatel-Lucent 1675 LambdaUnite MSS supports a variety of

industry-standard protection schemes:

• Multiplex section shared protection ring (MS-SPRing)/bi-directional

line-switched ring (BLSR)

• Subnetwork connection protection (SNCP)/unidirectional

path-switched ring (UPSR)

• Transoceanic protocol

• Dual node interworking/Dual ring interworking (DNI/DRI)

• 1+1 multiple section protection (MSP)/linear automatic protection switching (APS)

• Mesh-based restoration

The Alcatel-Lucent 1675

LambdaUnite MSS is a global,

standards-compliant product that

leverages traditional SDH and

SONET networks. Extensive multi-

vendor interworking capabilities

enable quick deployments while

protecting your existing investments.

Designed with scalability and

ease of maintenance in mind, the

Alcatel-Lucent 1675 LambdaUnite

MSS can help you affordably meet

the market’s growing demand for

bandwidth.

Integrated management using

the Navis Optical Management

System helps support a wide range

of applications and services to

keep your network running cost-

effectively. Sharing a common

management system with other

Alcatel-Lucent optical products

facilitates support-staff knowledge

across multiple platforms.

Ready Integration with Embedded Infrastructure

Evolution to Meet Growing Network Needs

40 Gb/s, thus enabling a wide range

of configurations. The optical

circuit packs support expansion

port modules that may be inserted

and provisioned in-service. This

means that you only pay for the port

capacity you need, when you need it.

The Alcatel-Lucent 1675

LambdaUnite MSS offers dedi-

cated data interfaces such as Gigabit

Ethernet (SX/LX) and 10 Gigabit

Ethernet (WAN PHY). From small

to large offices, this highly flexible

architecture allows you to configure

the system to meet your needs.

7Alcatel-Lucent 1675 LambdaUnite MultiService Switch

Flexible Interworking

Designed to interwork with a variety of standards-compliant SONET/SDH

products, the Alcatel-Lucent 1675 LambdaUnite MSS can be part of your

solution, with seamless, end-to-end network management and a decreased

need for manual intervention.

The Alcatel-Lucent 1675 LambdaUnite MSS offers you

a complete central office system in a single platform.

Leveraging your infrastructure investments, the switch

provides flexible support for existing and new network

applications and eases evolution — all while maximizing

capacity and availability.

With operations in more than 130 countries worldwide,

Alcatel-Lucent has a world-leading position in triple

play and extensive experience providing optical,

broadband and wireless network products, applications

and services. An end-to-end portfolio of products and

recognized project management and support make

Alcatel-Lucent the vendor of choice for central-office

broadband and convergence solutions.

FEATURE

• Ultracompact high-capacity shelf, with innovative, flexible “any card in any slot” architecture

• Optical line system (OLS) direct and passive DWDM optics

• Interfaces from DS-3 to OC-768/STM-256

• Bandwidth-optimized sub-lambda grooming

• 15G low-order grooming capabilities

• Centralized non-blocking switch, with 160G, 320G and 640G capacity options

• Seamless integration with the Navis Optical Management System

• Full interoperability with the Alcatel-Lucent SONET/SDH portfolio

• End-to-end point-and-click provisioning using the Alcatel-Lucent network management portfolio

• Expansion port modules that may be inserted and provisioned in-service

• In-service capacity upgrade

• Simultaneous support of ring, mesh and hybrid network topologies

• Multiple class of service (CoS) levels

BENEFIT

• Cost-effectively provides multiservice support and

addresses a variety of network applications

• Converges traditional circuit and advanced packet

services

• Offers central office consolidation opportunities

• Readily integrates with your embedded infrastructure

• Meets the needs of your growing network

The Alcatel-Lucent Advantage

www.alcatel-lucent.com

Alcatel, Lucent, Alcatel-Lucent and Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other

trademarks are the property of their respective owners. The information presented is subject to

change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein.

Autres manuels pour LambdaUnite 1675

Autres manuels Alcatel-Lucent Changer

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-320 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent LambdaUnite 1675 Guide de l'utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850 Series Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent OmniSwitch Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent OmniStack LS 6224P Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1850 Guide de l'utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6250 Manuel de programmation

Alcatel-Lucent

Alcatel-Lucent 7210 SAS Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6350 Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850-48 Mode d’emploi

Alcatel-Lucent

Alcatel-Lucent OmniSwitch OS6850-P48L Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6400 Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7210 SAS-D Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6855-24 Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850 Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6800 Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch AOS Release 7 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1675 LambdaUnite Guide de l'utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850-48 Manuel d'installation

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-320 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-320 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7210 SAS E OS Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniAccess 4504 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850-48 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
