AGPtek A22 Manuel d'instructions

A22 Music Player

CONTENTS

01/06

07/13

14/20

21/27

28/34

35/40

English

Deutsch

Italiano

Español

Francais

日本語

Thank you for purchasing AGPTEK MP3 Player. Please read

the manual carefully before using the product.

Specifications are subject to change without prior notice.

Buttons & Controls

Charge the Player

1. Charge by solar energy

With the built-in solar charging battery, this player allows

to charge by the solar power with the solar panel on the

back of the player. If the sun light is strong enough, you

can charge it by placing the back side of player under the

sunlight. The charging time depends on the sunlight

intensity.

2.By connecting to a computer or charger(Not included)

1. Play/Pause/Enter/Po-

wer on/off

2. Menu

button/Screen

Lock/unlock

3. Previous/Rewind/Scr

oll up/Volume -

4. Next/Fast

forward/Scroll

down/Volume +

5. Back button

6. Volume button

7. USB port

8. Power slider

9. Earphone jack

10.Card slot

Please note: The specifications of the charger must meet

the following requirements or any accident or failure

happened will be regarded as man-made damage.

Input: AC110-240V 50/60Hz Max:100mA

Output: DC5.0-5.5V 500mA-800mA

Power On/Off

Slide the power switch to "Right" side to power on the

player. Repeat to power off.

Standby status: hold the play button for 3 seconds to

power on/off.

Screen Lock/unlock

In any interface, hold button M for 2 seconds to

lock/unlock screen.

Main interface

Each time you press the button / , it will bring you to

one of its 9 different functions, including Music, FM Radio,

Folder View, Settings, Recordings, Tools, Pictures, EBook

and Video.

Play Music

- Resume ~ take you back to the song or audio file that

you are playing now.

- Update playlist ~ update all songs in the external Mirco

SD card or the internal memory of the player

Volume Adjustment

Click the volume button(button 6), then press / to

decrease/increase the volume.

Return

In any interfaces, click button to back to the previous

menu; hold to back to main interface.

Submenu

While it’s on music playing interface, press the button M

to access to the submenu.

1.Play Mode >"Repeat settings", choose to set Repeat

Mode, Replay Times, Replay Interval.

"Repeat Mode"(only available when the music is playing)

1)Choose the option "Repeat Mode" with button to

confirm the starting time A(A is flashing).

2)Then click button again to set the ending time B(B is

flashing). Click button again and the passage from

time A to B will be repeated automatically. The icon for

A-B indication will appear on the screen.

3)Click button again to back to normal playback.

2.Shuffle: Choose to turn on/off shuffle mode.

3.Sound Settings: "Variable Speed Playback", adjust speed

from -8(Slowest) to +8(Fastest).

4.Bookmarks: Choose to add, delete or go to bookmark.

FM Radio

Select "FM Radio" on main menu, click button to

access to its function. A related list will show including

"Presets", "Manual tune", "Auto tune" and "FM recordings".

Click / to select. Press continually or hold

button to back to the main interface.

1.Choose "Start FM radio recording" to save the

radio you want to record, find the saved recordings in

the "FM recording".

2."Tuner Region", choose from Common /Japan /

European Band.

3. "FM Recordings", all saved recordings will be listed here.

Please note: You can only listen to mono radio station on

this player.

Settings

Sleep timer: Choose "Sleep Timer" to turn off this

function or set the sleep timer between 1-99(minutes).

Display Settings: Set the Brightness, Backlight time and

Screensaver of your player;

Date and Time: Click button M to switch. Click / to

set. Click button to save your settings.

Recordings

Select "Recordings" on main interface, click button to

access to its function, then a related list will show as "Start

Voice Recording", "Recordings library", "Storage"(only

available with card inserted), "Record Format" and "Record

Settings".

Tools

Select "Tools" on main interface, click button to access

to its function. A related list will show "Calendar",

"Stopwatch" and "Alarm".

Video

This player can only support the .amv format in 160*128,

you should convert video files by format conversion

software first.

Trouble Shooting

a.How to re-choose the language?

Find this icon in the main interface, and click button

to access to its menu, scroll down to the last

menu(the menu at the buttom is “Default settings” in

English). click button to enter and choose the

first(upper) option which means “Yes” , click button

again to confirm and restore to factory settings, the

player will power on automatically and then you can

choose language again.

b.Can’t turn on the player; the screen of player goes

blank/black; the player is crashed or has a firmware bug

1)Power off the player and try again.

2)Slide the power switch to the “Left” side to turn off the

player, then hold the play button for 10 seconds to

reset the player.

3)Update the firmware. Please visit

http://www.agptek.com/support/download.html/ or

www.agptek.com/blog to download the firmware and

update.

c.Disk error

If the screen says “Disk error”, please format the player.

Find it in“settings”>”Format device”.

d.Songs can’t be recognized by the player

Please check if the song is in a wrong format or has been

encrypted, or the song format is not supported by this

player. Find the supported audio format below:

MP3:

Bitrate: 8Kbps~320Kbps, Sampling rate:8MHz~48MHz;

WMA:

Bitrate:5Kbps~384Kbps, Sampling rate:8MHz~48MHz;

APE:

Bitrate:800Kbps~1000Kbps(FAST normal compressed),

Sampling rate:8MHz~48MHz;

WAV:

Bitrate:32Kbps~384Kbps, Sampling rate:8MHz~48MHz;

FLAC:

Bitrate:1000Kbps~1200Kbps(L0~L8),

Sampling rate:8MHz~48MHz;

Specifications

Screen 1.8" TFT screen

Weight 32g

Dimension 92*41*10mm

Flash memory 8G

Audio format MP3/WAV/APE/WMA/FLAC etc.

Video format 128*160 AMV(converted video)

Recording format MP3/WAV/ACT

Picture format JPG/JPEG/BMP

Recording distance 5-8 meters

Playing time Music 60 hours Video 18 hours

Battery 3.7V/460 mAh

Charging time 1.5-2 hours

SD card expansion Up to 128G

If you have any questions about this product, please feel

free to contact us at s[email protected].

For detailed user manual, please visit:

http://www.agptek.com/support/download.html

Vielen Dank für Ihren Einkauf bei AGPTEK. Lesen Sie bitte

die Bedienungsanleitung sorgfältig durch, bevor Sie das

Produkt benutzen.

Tasten und Bedienelemente

Aufladen

1.Mit der eingebauten Solaraufladungsbatterie erlaubt

dieser Spieler, durch die Sonnenenergie aufzuladen.

Wenn das Sonnenlicht stark genug ist, können Sie es mit

dem Solarpanel auf der Rückseite des Spielers aufladen.

Die Ladezeit hängt von der Sonneneinstrahlung ab.

2.Sie können das Gerät über Computer oder ein

Ladegerät per USB-Kabel aufladen. (Ladegerät nicht

1.Spielen/Pause/Besti

mmenTaste/

Ein&Ausschalten

2.MenüTaste/Bildschir

msperre

3.NachOben/Volume-

/Vorherig/Schnaller

Rücklauf

4.NachUnten/Volume

+/SchnellerVorlauf

/Nächst

5.Zurück Taste

6.Volumen Taste

7.USB-Anschluss

8.Ein/Ausschalter

9.Kopfhörerbuchse

10.Karte Buchse

enthalten)

Hinweis:Um Unfall oder Fehler zu vermeiden, die

Spezifikationen des Ladegerätes müssen die folgenden

Anforderungen erfüllen:

Eingang: AC110-240V 50 / 60Hz Max: 100mA

Ausgang: DC5.0-5.5V 500mA-800mA

Ein/Ausschalten

Schieben Sie bitte den Netzschalter auf „Rechts“ Seite um

das Gerät einzuschalten. Wiederholen Sie auf

„Links“ Seite um das Gerät auszuschalten.

Standby-Status: Halten Sie die Play-Taste für 3 Sekunden

zum Ein-/Ausschalten.

Bildschirmsperre

An jeder Schnittstelle drücken Sie die Taste M 2 Sekunden,

um den Bildschirm zu sperren. Und noch einmal die Taste

M 2 Sekunden drücken, wird es freigeben.

Hauptschnittstelle

Eine unter Liste wird mit 9 verschiedenen Funktionen

Musik, FM-Radio, Ordner, Einstellen, Aufnahme,

Werkzeug, Bilder, E-Buch und Video

angezeigt. Klicken Sie / um es zu wählen.

Musik Spielen

1. Resume: Wenn Sie auf dem „Musik“ Menü sind,

drücken Sie „Resume“,um zu der letzten Position zu sein,

wo Sie die Musik hörten.

2. Wiedergabelisten aktualisieren: aktualisieren Sie alle

Songs auf der externen Micro SD Karte oder den internen

Speicher des Players.
