Thank you for purchasing AGPtek MP3 Player. Please read the

manual carefully before using the product. Specifications are

subject to change without prior notice.

Buttons and Controls

Data Transfer

You can transfer music from your computer to the player using

the drag-and-drop method or using music management software

such as Windows Media Player. You can simply plug it into your

computer and copy over media files as if it were a hard drive.

Charge the Player

1. By connecting to a computer with the included USB cable

The USB cable can both be used for data transfer and charging

the player.

2. By connecting to a charger(Not included)

Please note: The specifications of the charger must meet the

following requirements or any accident or failure happened will

1.Power button

2.Play/Pause/Enter

3.Scroll up/Volume +

4.Scroll down/

Volume -

5.Previous/Rewind

6.Next/Fast forward

7.Back button

8.Menu button

9.USB port

10.Earphone jack

11.Card slot

12.Display

be regarded as man-made damage.

Input: AC110-240V 50/60Hz Max:100mA

Output: DC5.0-5.5V 500mA-800mA

Power On/Off

1. Power On: Slide the power switch to "On" position. If the switch

is already at "On" position, just press the play button for 3

seconds.

2. Power Off:

1) Slide the power switch to "Off" position.

2) Press play button for 3 seconds when the switch is at "On"

position.

Note:

1) Please put the power button to "Off" position if you won’t use it

for a long time.

2) If you cannot switch on the player, please make sure the slider

switch is on the right side.

3) When the player is on the music playing interface, if you hold

button to turn off it, next time you switch on the player, it

will start from the last position it left off.

Main interface

Each time you press the button ▲/▼/ / , it will bring you to

one of its 9 different functions, including Music, Radio, Folder,

Setting, Record, Tools, Pictures, EBook and Video.

While it’s on the main interface, press button to enter.

Play Music

Find "Music" on main menu, click button to access to its

function. Click button▲/▼to choose from the songs, click button

to play.

- All songs — play by name sequence

- Nowplaying — take you back to the song or audio file that you

are playing now.

- (Resume) — Choose "Resume" to start playing from where you

left off last time.

- Artists —Displays Tracks sorted by Artist

- Albums — Displays all Tracks sorted by Album

- Genres — Displays all Tracks sorted by Genre

- Playlists —3 playlists

- Update card data — Update local and card folder

- Local folder — Internal memory

- Card folder — External Micro SD memory card

Volume Adjustment

When it’s on music playing interface, press ▲/▼to

increase/decrease the volume.

Fast Rewind/ Forward

When it’s on music playing interface:

-Hold button / for fast backward/forward. Click to go to

previous/next song;

-Click button to play or pause.

Return

In any interfaces, click button to back to the previous menu;

hold to back to main interface.

Submenu

While it’s on music playing interface, press the button to

access to the submenu.

Then a related list will show, including:

"Home", go back to main interface.

"Repeat", choose to repeat 1, repeat all, and view playing or turn

off repeat function.

"Shuffle", choose to turn on/off shuffle mode.

"Play from…", choose to play songs from all

songs/artist/album/genre.

Please note: you can also find "Repeat"/"Shuffle"/"Play from…" in

"Setting">"Play mode", whether you make changes in "submenu"

or "settings", the setting will work in Music, but not in video.

"Equalizer", choose from the 7 sound effects, or choose "off" to

turn off equalizer

Please note: you can also find "Equalizer" in "Setting">"Sound

settings", whether you make changes in "submenu" under Music

or "settings", the setting will both work.

"Speed", adjust speed from -8(Slowest) to +8(Fastest).

"Language learning"(only available when the music is playing),

1) Choose the option "A-B Repeat", click button to confirm

the starting time A(A is flashing).

2) Then click button again to set the ending time B(B is

flashing). Click button again and the audio from time A to

B will be repeated automatically. The icon for A-B indication

will appear on the screen.

3) Click button again to back to normal playback.

Replay Times, choose to replay passage A-B for 1-10 times.

Replay Interval, choose to set the playing intervals for 1-10

seconds.

"Sleep timer", choose "Off" to turn off timer, or choose to set the

sleep timer in 1-99 minutes.

"Bookmarks", choose to add, delete or go to bookmark.

"Delete", choose to delete the song that is playing now.

"Add to playlist"/"Remove from Playlist", choose to add to or

remove from the 3 playlists.

• To shuffle your music

You can shuffle your songs from the music playing screen by

pressing the button > "Shuffle", and you can also Shuffle by

pressing "Setting"> "Play mode" > "Shuffle".

• To repeat your songs

You can repeat your songs from the music playing screen by

pressing the button > "Repeat", and you can also repeat by

pressing "Setting"> "Play mode" > "Repeat".

The player would only play the first 10 seconds of a track and

then skip if you select option "View playing" under "Repeat".

Please note: if you play songs through "Music", it will only repeat

in the folder which your songs is included.

Video

Find "Video" on main menu, click button to access to its

function. You will need to choose from local folder or card folder

if the card is inserted. In the video list, click button to go to its

submenu:

"Home", go back to main interface.

"Repeat", choose to repeat 1, repeat all or turn off repeat function.

"Delete video", choose to delete the video.

"Update Card Data", update the videos in the card.

Fast Rewind/Forward

When it’s on video playing interface:

-Press ▲/▼to increase/decrease the volume.

-Hold the button / for fast backward/forward. Click to the

previous/next video;

-Click button to play or pause.

-Click button to back to the previous menu; hold to back to

main interface.

Please note: This player can only support the .amv format in

160*128, you should convert video files by format conversion

software first.

Radio

Select "Radio" on main menu, click button to access to its

function. A related list will show including "Station list", "Manual

tune", "Auto tune" and "FM recording". Click ▲/▼to select.

Manual tune and Auto tune

You can adjust the radio by "Manual tune" or "Auto tune", Choose

"Manual tune", click button / to rewind or forward search

one by one, and hold button / to search automatically,

press the button to stop.

Choose "Auto tune" to search and save the radio stations

automatically.

Set the FM radio with the button

While on radio playing screen, press button to go to its

submenu, including "Start FM radio recording", "Save", "Clear

preset", "Auto tune", "Tuner region" and "FM recording".

- Choose the item "Home" to main interface(You can also

press continually or hold button to back to the

main interface.)

- Choose "Previous menu" to back to the last menu.

- Choose "Start FM radio recording" to save the radio you

want to record, find the saved recordings in the "FM recording".

Please note:

1. You can only listen to mono radio station on this player.

2. The saved recordings can be saved in WAV (in default)

/MP3/ACT format, choose to set the format in "Record" >

"Record Settings">"Record Format".

3. You can choose to store your radio in local folder or card folder

under "FM recording" when the card is inserted.

Pictures

-Click to enter and choose to play photos from local folder

or card folder;

-Click / to go to the previous/next picture.

Record

Select "Record" on main interface, click button to access to its

function, then a related list will show as "Start Voice Recording",

"Recordings library", "Storage"(only available with card inserted)

and "Record Settings".

-Select "Start Voice Recording" and click to start your

recording. Click and then choose "Yes" to save your recording;

-When it’s on recording interface, click the button to pause

or start;

-See your recording files in Recordings library. Click button

to play the recordings. Click / to go to the previous/next

recording.

-Storage (only available when an expandable card is inserted),

choose to store your recordings in internal or external memory.

Confirm your selection with button .

Record Settings

"Record Format", Select a format among MP3, WAV and ACT;

"Set rec bitrate", Select from 512/768/1024/1536kbps for WAV

format; 32/64/128/192 kbps for MP3 format; 8 kbps for ACT

format;

"Track AVR mode": Choose Normal/AVR mode;

Note: When it is in AVR mode and you choose to start recording,

the player will not record until sound is detected and stop

recording when no sound detected.

"Set recording scene", choose from different scenes.

Folder

Select "Folder" on main menu, click button to access to its

function. All of the files in the player will be listed. If the Micro SD

card is inserted, you can choose to go to Local folder or Card

folder. Click ▲/▼to select and choose to play.

Tools

Select "Tools" on main interface, click button to access to its

function. A related list will show "Calendar", "Stopwatch" and

"Alarm".

Select Stopwatch and click button to enter, click again to

start the timer, then click again to stop/resume. Press ▼to

start a new one. Click to go back.

Please note: the maximum Stopwatch list is 5.

Select Alarm and click button to enter, set the alarm

switch/time/cycle/music/volume you want.

EBook

Please note: Only "txt" format is supported for eBooks.

-Select "EBook " on main interface, click button to access to

its function.

-Press button ▲/▼to turn the page up/down.

-While on text playing interface, click button to play

automatically, click again to stop(click and choose

Playsetting to set the automatic playing interval).

Please note: if your player cannot read your txt document through

E book, connect it to the computer, and then choose the file for

the item "save as", select the code as "UTF-8" and save, then copy

the txt file to E-Book folder.

Settings

Find "Setting" on main menu, click button to access to its

function. Click ▲/▼to select. Click to back to the previous

menu; hold to back to main interface.

The related list will show as below:

Play mode: Choose to "Play music from"/"Repeat"/"Shuffle" the

songs in "Music".

Sound settings: Set the equalizer;

Power off: Shut off automatically when reaches the set time;

Sleep timer: Choose "Shut down sleep timer" to turn off this

function or set the sleep timer between 1-99(minutes), when it

reaches the sleep time you set, the player will power off

automatically;

Display settings: Set the Brightness, Backlight timer and

Screensaver of your player;

Backlight timer: set the time at 10(seconds)/20(seconds)/ 30

(seconds)/Always on.

Date and time: Set the Date and time according to your need;

Click button / to select year/month/day/ hour/minute.

Click ▲/▼to set the year/month/day/hour/minute. Click

button to save your settings.

Language: Choose your language;

Information: See Player information/Disk space/Supported file

type about your player;

Format device/Factory settings: Format the device or restore to

factory setting.

Trouble Shooting

Restart the player if it crashed or doesn’t work.

a.Can’t turn on the player

Please check whether the player is run out of battery, connect the

player to a adapter and try again after charging.

b. Heavy noise when playing music

Please make sure the plug is clean or this may cause noises;

Please check if the music file is damaged. Try to play other musics

to confirm. Damaged files may lead to heavy noise or skipping;

Autres manuels pour A29

Table des matières

Langues :

Autres manuels AGPtek Lecteur MP3

AGPtek

AGPtek A16 Manuel utilisateur

AGPtek

AGPtek A07 Manuel utilisateur

AGPtek

AGPtek a02 Manuel utilisateur

AGPtek

AGPtek G05S Manuel utilisateur

AGPtek

AGPtek H01 Manuel utilisateur

AGPtek

AGPtek R1SB Manuel utilisateur

AGPtek

AGPtek ROCKER MUSIC PLAYER Manuel utilisateur

AGPtek

AGPtek S66B Manuel utilisateur

AGPtek

AGPtek M07 Manuel utilisateur

AGPtek

AGPtek G15S Manuel utilisateur

AGPtek

AGPtek A02T Manuel utilisateur

AGPtek

AGPtek M3 Manuel utilisateur

AGPtek

AGPtek B03 Manuel utilisateur

AGPtek

AGPtek W2 Manuel utilisateur

AGPtek

AGPtek A29 Manuel utilisateur

AGPtek

AGPtek M28 Manuel utilisateur

AGPtek

AGPtek A20 Manuel utilisateur

AGPtek

AGPtek G05 Manuel utilisateur

AGPtek

AGPtek M6 Manuel utilisateur

AGPtek

AGPtek T03S Manuel utilisateur

AGPtek

AGPtek BHD01 Manuel utilisateur

AGPtek

AGPtek M30 Manuel utilisateur

AGPtek

AGPtek G15 Manuel utilisateur

AGPtek

AGPtek H3 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur

Kenwood

Kenwood M1GD50 Manuel utilisateur
