AGPtek M07 Manuel utilisateur

Parts and controls

1. Display screen

2. “ ”:Play/Pause/Select

ion button

3. “ ”: Previous/Fast

backward

4. “ ”: Next/Fast

forward

5. “M”: Menu

button/VOL+ button

6. “VOL”: Volume/Return

button /VOL- button

7. Speaker hole

8. TF card slot

9. USB port

10. Power on/off button

11. Earphone port

Charge the Player

Use 5V/300mAh charger for charging.

Plug one end of the micro USB cable into the USB port of a computer, the other end to

the port on your device. While it is fully charged, disconnect the cable from your device

by pulling it straight outward.

Note: when you start charging, it will show two options: “Charge & Transfer” and

“Charge & Play”. An icon in the top right corner will show the charging status.

Power On/Off

1. Power On: Slide the power switch to “On” position. If the switch already at “On”

position, just press the play button “ ” for 3 seconds.

2. Power Off:

1) Slide the power switch to “Off” position.

2) Press play button “ ” for 3 seconds when the switch at “On” position.

Note:

1) Please put the power button to “Off” position if you won’t use it for a long time.

2)The player will power off automatically if inactive and no applications operate on

backstage for 1 min. And it will still work on backstage for 30 seconds under

“screensaver” with backlight goes out . You can press any button to light up the screen

within 1 minute..

Main interface

Each time you press the button “ ”/ “ ”, it will bring you to one of its 6 different

functions, including All songs,Artists,Albums,Playlists,Folder view, and Tools.

All songs: all songs listed here

Artists: all songs are classified by artists

Albums: all songs are classified by albums

Playlists: all your favorite songs can be added here

Folder view: all folders can be found here

Tools: There are four functions: FM radio, E-book, Recordings, Set.

While it’s on the main interface, press button “ ” to enter.

Submenu

While it’s on music playing interface, press the button “M” to access to the submenu.

Then a related list will show, including “Home”, “Shuffle”, “Repeat”, “Bookmarks”,

“Play music from…”, “Equalizer”, “Variable Speed Playback”, “Sleep timer”, “Delete”,

“Add to playlist” and “Remove from Playlist”.

1. Play mode

While playing, press button “M” > “Home” / “Shuffle” / “Repeat” / “Bookmarks” /

“Play music from…” / “Equalizer” / “Variable Speed Playback” / “Sleep timer” /

“Delete” / “Add to playlist” / “Remove from Playlist”. Select according to your need.

Under menu “Repeat”, you can set “Repeat Mode”(A-B repeat), “Repeat time” and

“Repeat interval”.

2. Sound settings

While playing, press button “M” >”Equalizer” > “Rock” / “Funk” / ”Hip hop” / “Jazz” /

“Classical” / “Techno” / “Custom”.

Rewind/Forward/VOL

While it’s on music playing interface

Hold the button “ ” to fast forward, short press to next music file; hold the button

“ ” to rewind, short press to the previous song files. Tap the button “ ” for

playing/pause.

Hold the button “VOL” to adjust the volume, short press to get back.

FM radio

Insert the earphone, then select FM frequency from 87.5 to 108.0MHz.

While in the FM radio interface, press button “M” to enter the submenu: Start FM radio

recording, Presets,Save to preset, Clear preset, Auto tune, Tuner region, FM recording.

E-book

Can read .txt format. While reading e-book, press button “M” to enter the submenu: Play

setting(Auto scroll time), Delete ebook, Bookmark Select, Delete bookmark, Add book

mark, Page select.

Recordings

There are 5 options available for you: Start voice recording, Storage, Recordings library,

Record format, Record settings.

Record format: MP3/WAV/ACT Rec

Record settings > “VOR(Voice Operated Recording)”

Settings

There are 10 different items for you to choose in this section, including: Play mode,

Sound settings, Sleep timer, Display settings, Date and time, Language, Information,

Format device, Factory settings, Create playlist.

Note: when you set “date and time”, use button “M” to switch to next one. For example,

“Set time”, after you set the hour, press button “M” to switch to set minute.

Help and Troubleshooting

● Can’t turn the player on

Please check whether the battery has been run out, maybe you can connect the player

with computer and try again after charging.

● Can’t hear the sound

-Please check if the volume is set to zero

-Check that the headset is inserted correctly.

● Can’t download file from computer

-Please confirm whether it’s connected properly

-Please check whether the storage space of the internal memory is full

-Please check whether the USB cable is damaged

Specifications

Music formats

MP3, WMA, DRM WMA, OGG, APE(Normal/Fast),

FLAC, WAV, AAC-LC, ACELP

Recording

formats

MP3, WMA, ACT

Video formats

AMV

Screen

1.8" OLED screen

Size

94*38*9mm, net weight: 79.2g

Capacity

8 GB; support up to 32 GB micro SD card(SD card not

included)

Case

Full zinc alloy case

Playing time

12 hours by earphone, 3.5 hours by loudspeaker

Charging time

1.5 hours

Standby time

520 days

Battery capacity

3.7V/260 mAh

Recording

distance

10-15 meters

Lyric format

LRC

Color

Silver/Gray
