Agilent Technologies LogicWave Manuel utilisateur

Agilent Technologies

LogicWave

Installation Guide

Publication number E9340-97002

December 2000

For Safety information, Warranties, and Regulatory information,

see the pages behind the index.

In This Book

This book:

• Shows how to install and care for the LogicWave logic analyzer.

• Describes the LogicWave specifications and characteristics.

See Also The online help for information on using LogicWave.

Contents

In This Book

1 Setting Up LogicWave

Installing LogicWave 6

Step 1. Connect the logic analyzer to a host computer (PC) 7

Step 2. Connect the power cable 8

Step 3. Turn on power 9

Step 4. Install software 10

Step 5. Start the LogicWave user interface 11

Step 6. Connect probe cables 13

Step 7. Probe the device under test 14

Step 8. Make measurements 15

Caring for LogicWave 16

To clean the instrument 16

2 Specifications and Characteristics

Specifications 19

Characteristics 20

General 20

Timing Analysis 20

State Analysis 21

Triggering 21

Probes 21

Operating Environment 22

Contents

Setting Up LogicWave

Shows how to install the Agilent Technologies LogicWave logic analyzer

and provides instructions on caring for the instrument.

Chapter 1: Setting Up LogicWave

Installing LogicWave

This section provides instructions for setting up the LogicWave logic

analyzer and connecting it to a device under test.

The logic analyzer user interface requires a host computer (PC) with

the following characteristics (or better):

•Pentium 90 MHz

•Windows 95/98/NT/2000

•16MB RAM

•10MB available space on the hard disk drive

•Available parallel port (no pass-through devices installed)

•Available LPT1 peripheral device designator

The host computer (PC) running the logic analyzer interface can be

either powered on or off. The interface software is installed on the PC.

Chapter 1: Setting Up LogicWave

Installing LogicWave

Step 1. Connect the logic analyzer to a host

computer (PC)

1Connect the small end of an HP C2946A parallel port printer

cable to the PARALLEL connector on the rear panel of the logic

analyzer

2Connect the large end of the printer cable to the PC’s parallel

port.

3Apply power to the PC if it is not turned on.

To ensure the PC’s parallel port is properly configured, interrupt the

PC’s boot process by pressing [ F2 ] on the keyboard. Scroll down to

the parallel port configuration and observe the current parallel port

data transfer mode. Ensure either Enhanced Capabilities Port (ECP),

Byte, or Nibble mode is selected (Enhanced Parallel Port (EPP) mode

will not work). If none of the correct transfer modes is selected, you

need to change the transfer mode according to the instructions for

your PC.

Chapter 1: Setting Up LogicWave

Installing LogicWave

Step 2. Connect the power cable

CAUTION: Use only the supplied power supply (HP F1044B) and cord. Failure to use the

proper power supply could result in equipment damage.

1Connect the power cord to the power supply input.

2Connect the power supply output cable to the power input

connector on the rear panel of the logic analyzer.

Chapter 1: Setting Up LogicWave

Installing LogicWave

Step 3. Turn on power

CAUTION: Do not block the air intake vents on the bottom of the logic analyzer.

1Turn the power switch to the on (“1”) position.

2Wait approximately 15 seconds for the logic analyzer to power up

and settle.

Chapter 1: Setting Up LogicWave

Installing LogicWave

Step 4. Install software

See Also Refer to the instructions on the installation CD.
