Agilent EPM and EPM-P Series

Power Meters

E-series Power Sensors

Configuration Guide

EPM Series Power Meters:

E4418B Power Meter (single channel)

E4419B Power Meter (dual channel)

EPM-P Series Power Meters:

E4416A Power Meter (single channel)

E4417A Power Meter (dual channel)

E-series Power Sensors:

E441XA C Power Sensors

(10 MHz to 26.5 GHz, sensor dependent)

E9300 Average Power Sensors

(9 kHz to 18 GHz, sensor dependent)

E9320 Peak and Average Power Sensors

(50 MHz to 18 GHz, sensor dependent)

Introduction

This configuration guide describes standard configurations, options

and compatible accessories. For full specifications, see EPM Series

Power Meters and E-Series Power Sensors Technical Specifications

(Agilent literature number 5965-6382E), or EPM-P Series Power

Meters and E9320 Power Sensors Technical Specifications

(Agilent literature number 5980-1469E). Contact your local

Agilent Technologies representative at the offices listed on the

back of this guide if you need more information.

Agilent Technologies

EPM-P series power meters

The EPM-P series power meters provide peak, peak-to-average ratio,

average and time-gated power measurements. For peak, peak-to-average

ratio and time-gated measurements, the EPM-P series must operate

with the E-series E9320 power sensors. For average power measure-

ments only, the EPM-P series power meters are compatible with all the

8480 series power sensors, the E-series C , the E-series E9300 average

power sensors, and the E-series E9320 power sensors.

The standard EPM-P series power meters include:

• Single-channel power meter, order E4416A

or dual-channel power meter, order E4417A

• Input sensor connector(s) on front panel

• Reference calibrator connector on front panel

• Hardcopy English-language Installations Guide

•CD- om, the English-language and localized User’s Guide,

the English-language Programming Guide and the

Agilent EPM-P analyzer software

• Supplied accessories:

Power sensor cable (1.5 meter (5 ft) E9288A)

One per E4416A and two per E4417A

Power cord (plug matches destination requirements)

EPM series power meters

The EPM series power meters provide average power measurements.

The standard E4418B and E4419B power meters include:

• Single-channel power meter, order E4418B

or Dual-channel power meter, order E4419B

• Input sensor connector(s) on front panel

• Reference calibrator connector on front panel

• English-language User’s Guide and Programming Guide

• Supplied Accessories:

Power sensor cable (1.5 meter (5 ft) 11730A).

One per E4418B and two per E4419B

Power cord (plug matches destination requirements)

E-series power sensors

The standard E4412A and E4413A C power sensors include:

• Power sensor 10 MHz to 18 GHz, order E4412A

Power sensor 50 MHz to 26.5 GHz, order E4413A

• English-language Operating and Service Manual

The standard E9300 average power sensors include:

+20 to –60 dBm:

• Power sensor 10 MHz to 18 GHz, order E9300A

• Power sensor 10 MHz to 6 GHz, order E9301A

• Power sensor 9 kHz to 6 GHz, order E9304A

+30 to –50 dBm:

• Power sensor 10 MHz to 18 GHz, order E9300

• Power sensor 10 MHz to 6 GHz, order E9301

+44 to –30 dBm:

• Power sensor 10 MHz to 18 GHz, order E9300B

• Power sensor 10 MHz to 6 GHz, order E9301B

•English-language Operating and Service Manual

(also available as Agilent part number E9300-90009)

The standard E9320 Peak and Average Power Sensors include:

• Power sensor, 50 MHz to 6 GHz, 300 kHz bandwidth, order E9321A

• Power sensor, 50 MHz to 6 GHz, 1.5 MHz bandwidth, order E9322A

• Power sensor, 50 MHz to 6 GHz, 5 MHz bandwidth, order E9323A

• Power sensor, 50 MHz to 18 GHz, 300 kHz bandwidth, order E9325A

• Power sensor, 50 MHz to 18 GHz, 1.5 MHz bandwidth, order E9326A

• Power sensor, 50 MHz to 18 GHz, 5 MHz bandwidth, order E9327A

• English-Language Operating and Service Manual

Compatibility

Power sensor compatibility

For compatibility of Power Meters, Power Sensors and Power Sensor

Cables please refer to the table below.

Firmware compatibility

The table below shows the required revision of firmware for operation

of the E9300 power sensors as well as the part number of the required

hardware upgrade kit.

Firmware upgrade information can be accessed from the orld ide

eb, free of charge. It can also be purchased as a firmware upgrade kit,

Agilent part number E4418-61035. The hardware upgrade is a simple

upgrade and the kit provides the parts required. The upgrade can be

performed at any local Service Center or at a customer site.

1. Please refer to the firmware compatibility table to ensure compatibility for this combination.

Power sensors Power meters Power sensor cables

EPM-P series EPM series 11730 E9288

power meters power meters sensor cables sensor cables

(grey) (blue)

E441X family Yes Yes Yes Yes

E9300 family Yes Yes1Yes Yes

E9320 family Yes No No Yes

8480 series Yes Yes Yes Yes

E4418A/E4419A E4418B/E4419B

Firmware Hardware Firmware

E9300A/01A/04A Rev A1.04.00/A2.04.00 E4418-60021 Rev A1.04.00/A2.04.00

E9300H/01H Rev A1.06.00/A2.06.00 E4418-60021 Rev A1.06.00/A2.06.00

E9300B/01B Rev A1.06.00/A2.06.00 E4418-60021 Rev A1.06.00/A2.06.00

Hardware options

The following options are available on the EPM and EPM-P power

meters.

Service and support options

Special options

Special options for EPM-P series power meters, EPM series power

meters, and E-series sensors are available. Contact your local Agilent

representative for more information.

Option Description EPM-P series EPM series

power meters power meters

001 Internal rechargeable battery No Yes

002 Rear panel sensor input(s)

(Power ref on front panel) Yes Yes

003 Rear panel sensor input(s)

(Power ref on rear panel) Yes Yes

004 Delete the power sensor cable Yes Yes

9081One instrument rackmount kit Yes Yes

9092 Two instrument rackmount kit Yes Yes

Option Description EPM-P series EPM series

power meters power meters

W30 3 years customer return repair service n/a3 n/a3

W32 3 years customer return

calibration service Yes Yes

W34 3 years customer return standards

compliance calibration service Yes Yes

W50 5 years customer return repair service Yes Yes

W52 5 years customer return

calibration service Yes Yes

W54 5 years customer return standards

compliance calibration service Yes Yes

1. Also available as Agilent part number 5063-9240.

2. Also available as Agilent part numbers 5063-9212 and 5061-9694.

3. The EPM and EPM-P series power meters are supplied with a 3-year customer return

repair service as standard.

Documentation

• The EPM power meters supply the standard documentation in

hard copy.

• The EPM-P power meters provide a hardcopy Installation Guide

which includes all languages and a CD-ROM which contains the

Agilent EPM-P analyzer software, User’s Guide and Programming

Guide. The localized versions of the Users Guide are included

on the CD.

Localization options

The following table supplies the option number as well as the Agilent

part number to order the documentation.

The following options provide a hardcopy of the localized User’s Guide.

For the EPM-P the localized manuals are all available on the CD-ROM

supplied with the product. The localized options for the EPM-P provide

a hardcopy of the localized User’s Guide and an English hardcopy of the

Programming Guide.

Calibration options

Supplies ANSI Z540 certificate of calibration with data, Option A6J

Note: Option A6J supercedes Options 1BN, 1BP and UK6.

Power sensors E4412A/13A E9300 E9320

User’s Guide E4412-90001 E9300-90016 E9321-90001

Add manual set Opt 0B1 Opt 0B1 Opt 0B1

Agilent part numbers

Option E4418B E4419B EPM-P series E4412/3A E9300

power meter power meter power meters sensors sensors

ABD - German E4418-90033 E4419-90007 E4416-90006 E4412-90003 E9300-90011

ABE - Spanish E4418-90036 E4419-90010 E4416-90007 E4412-90005 E9300-90013

ABF - French E4418-90034 E4419-90008 E4416-90008 E4412-90002 E9300-90010

ABJ - Japan E4418-90037 E4419-90013 E4416-90009 E4412-90006 E9300-90014

ABZ - Italian E4418-90035 E4419-90009 E4416-90010 E4412-90004 E9300-90012

AB1 - Korean E9300-90015

Power meters EPM-P series EPM series

power meters power meters

User’s Guide Opt 0BK (hard copy) Opt 916 (additional)

E4416-90004 E4418-90032 (E4418B)

E4419-90006 (E4419B)

Programming Guide Opt 0BK (hard copy) Opt 916 (additional)

E4416-90005 E4418-90029

Service Manual Opt 0B3 Opt 915

E4416-90014 E4418-90030

Component level Opt 0BV

Service documentation E4418-90031

Delete manual set Opt 0B0

Add manual set Opt 0BK Opt 916

Accessories available

•E9288A-C power sensor cables (refer to the compatibility section):

1.5 meters (5 ft) E9288A

3 meters (10 ft) E9288B

10 meters (31 ft) E9288C

•11730A-F power sensor cables: (refer to the compatibility section)

1.5 meters (5 ft) 11730A

3 meters (10 ft) 11730B

6.1 meters (20 ft) 11730C

15.2 meters (50 ft) 11730D

30.5 meters (100 ft) 11730E

61 meters (200 ft) 11730F

•Accessory pouch, 34161A

Holds accessories supplied or ordered

•Basic instrument transit case, 34131A

Protects the power meter during transit

•Soft carry/operating case, 34141A

Power meter with battery option can be operated in case

•Spare battery, E9287A

Extra battery for EPM series power meters with Option 001

Auxiliary equipment

The 11683A range calibrator verifies the accuracy and linearity of the

EPM-P and EPM series power meters. Outputs corresponding to meter

readings of 3, 10, 30, 100 and 300 µ and 1, 3, 10, 30 and 100 m are

provided. Calibration uncertainty is ±0.25% on all ranges.

Literature reference

EPM-P Series Power Meters and E9320 Sensors, Product Overview,

5980-1471E

EPM-P Series Power Meters and E9320 Sensors, Technical Specifications,

5980-1469E

EPM-P Series Single and Dual Channel Power Meters, Demo Guide,

5988-1605EN

EPM-P Series Power Meters, CD- OM,

E4416-90022

Choosing the ight Power Meter and Sensor, Product Note,

5968-7150E

EPM Series Power Meter and E-Series Power Sensors, Technical Specifications,

5965-6382E

EPM Series Power Meter and E-Series Power Sensors, Brochure,

5965-6380E

Fundamentals of F and Microwave Power Measurements,

Application Note 64-1,

5965-6630E

4 Steps for better Power Measurements, Application Note 64-4,

5965-8167E

E-Series E9300 Power Sensors, Product Overview,

5968-4960E

Agilent Technologies

By internet, phone, or fax, get assistance

with all your test & measurement needs

Online assistance:

www.agilent.com/find/assist

Phone or Fax

United States:

(tel) 1 800 452 4844

Canada:

(tel) 1 877 894 4414

(fax) (905) 282-6495

China:

(tel) 800-810-0189

(fax) 1-0800-650-0121

Europe:

(tel) (31 20) 547 2323

(fax) (31 20) 547 2390

Japan:

(tel) (81) 426 56 7832

(fax) (81) 426 56 7840

Korea:

(tel) (82-2) 2004-5004

(fax) (82-2) 2004-5115

Latin America:

(tel) (305) 269 7500

(fax) (305) 269 7599

Taiwan:

(tel) 080-004-7866

(fax) (886-2) 2545-6723

Other Asia Pacific Countries:

(tel) (65) 375-8100

(fax) (65) 836-0252

Email: [email protected]

Product specifications and descriptions in this

document subject to change without notice.

Printed in USA July 20, 2001

5965-6381E

Agilent Technologies’ Test and Measurement

Support, Services, and Assistance

Agilent Technologies aims to maximize the

value you receive, while minimizing your risk

and problems. We strive to ensure that you get

the test and measurement capabilities you

paid for and obtain the support you need. Our

extensive support resources and services can

help you choose the right Agilent products for

your applications and apply them successfully.

Every instrument and system we sell has a

global warranty. Support is available for at least

five years beyond the production life of the

product. Two concepts underlie Agilent’s overall

support policy: “Our Promise” and “Your

Advantage.”

Our Promise

Our Promise means your Agilent test and mea-

surement equipment will meet its advertised

performance and functionality. When you are

choosing new equipment, we will help you

with product information, including realistic

performance specifications and practical

recommendations from experienced test

engineers. When you use Agilent equipment,

we can verify that it works properly, help with

product operation, and provide basic measure-

ment assistance for the use of specified

capabilities, at no extra cost upon request.

Many self-help tools are available.

Your Advantage

Your Advantage means that Agilent offers a

wide range of additional expert test and mea-

surement services, which you can purchase

according to your unique technical and business

needs. Solve problems efficiently and gain a

competitive edge by contracting with us for

calibration, extra-cost upgrades, out-of-warranty

repairs, and on-site education and training, as

well as design, system integration, project man-

agement, and other professional engineering

services. Experienced Agilent engineers and

technicians worldwide can help you maximize

your productivity, optimize the return on invest-

ment of your Agilent instruments and systems,

and obtain dependable measurement accuracy

for the life of those products.

Microsoft®and Windows®are U.S. registered

copyrights of Microsoft Corporation.

Autres manuels pour E4418B

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Agilent Technologies Instrument de mesure

Agilent Technologies

Agilent Technologies 35670A Manuel utilisateur

Agilent Technologies

Agilent Technologies Agilent 4396B Manuel utilisateur

Agilent Technologies

Agilent Technologies EPM-P Series Mode d'emploi

Agilent Technologies

Agilent Technologies 86082A Manuel utilisateur

Agilent Technologies

Agilent Technologies FieldFox N9923AN Manuel utilisateur

Agilent Technologies

Agilent Technologies U1701A Manuel utilisateur

Agilent Technologies

Agilent Technologies K6460 Manuel d'installation et d'exploitation

Agilent Technologies

Agilent Technologies U2300A Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 85051B Manuel

Agilent Technologies

Agilent Technologies N2797A Manuel utilisateur

Agilent Technologies

Agilent Technologies 4288A Manuel du propriétaire

Agilent Technologies

Agilent Technologies 55B AA Manuel utilisateur

Agilent Technologies

Agilent Technologies ESA Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 16441A R-Box Manuel utilisateur

Agilent Technologies

Agilent Technologies E8362A Manuel utilisateur

Agilent Technologies

Agilent Technologies Twelfth 4287A RF LCR Manuel utilisateur

Agilent Technologies

Agilent Technologies WireScope 350 Manuel utilisateur

Agilent Technologies

Agilent Technologies E5071C Manuel utilisateur

Agilent Technologies

Agilent Technologies PSA Series Manuel utilisateur

Agilent Technologies

Agilent Technologies PSA Series Guide de démarrage rapide

Agilent Technologies

Agilent Technologies E444 AU Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 4418B Manuel utilisateur

Agilent Technologies

Agilent Technologies N1996A-503 Manuel de service

Agilent Technologies

Agilent Technologies Agilent 4396B Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
