MEGOHMMETER 6505

User ManualENGLISH

No part of this documentation may be reproduced in any form or by any means (including electronic

storage and retrieval or translation into any other language) without prior agreement and written consent

from Chauvin Arnoux®, Inc., as governed by United States and International copyright laws.

Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

15 Faraday Drive • Dover, NH 03820 USA

Tel: (800) 945-2362 or (603) 749-6434 • Fax: (603) 742-2346

This documentation is provided “as is,” without warranty of any kind, express, implied, or otherwise.

Chauvin Arnoux®󰀨

but does not warrant the accuracy or completeness of the text, graphics, or other information contained

in this documentation. Chauvin Arnoux®, Inc. shall not be liable for any damages, special, indirect,





user of the documentation has been advised of the possibility of such damages.

Statement of Compliance

Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments

certiﬁes that this instrument has been calibrated using

standards and instruments traceable to international

standards.

We guarantee that at the time of shipping your

instrument has met its published speciﬁcations.

An NIST traceable certiﬁcate may be requested at

the time of purchase, or obtained by returning the

instrument to our repair and calibration facility, for

a nominal charge.

The recommended calibration interval for this

instrument is 12 months and begins on the date of

receipt by the customer. For recalibration, please

use our calibration services. Refer to our repair and

calibration section at www.aemc.com.

Serial #:

Catalog #: 2130.18

Model #: 6505

Please ﬁll in the appropriate date as indicated:

Date Received:

Date Calibration Due:

Chauvin Arnoux®, Inc.

d.b.a AEMC®Instruments

www.aemc.com

TABLE OF CONTENTS

1. INTRODUCTION ................................................................................ 6

1.1 PRECAUTIONS FOR USE .................................................. 7

1.2 RECEIVING YOUR SHIPMENT................................................ 7

1.4 ORDERING INFORMATION ..................................................... 8

1.4.1 Accessories....................................................................................8

1.4.2 Replacement Parts.........................................................................8

2. PRODUCT FEATURES...................................................................... 9

2.1 DESCRIPTION ........................................................................... 9

2.2 CONTROL FEATURES............................................................ 10

2.3 SWITCH FUNCTIONS ............................................................. 11

2.4 BUTTON FUNCTIONS ............................................................ 11

2.5 DISPLAY ................................................................................... 12

2.5.1 Digital Display ..............................................................................12

2.5.2 Bargraph Display..........................................................................12

2.5.3 Display Symbols...........................................................................12

3. OPERATION ..................................................................................... 13

3.1 SERIAL NUMBER .................................................................... 13

3.2 SOFTWARE VERSION............................................................ 13

3.3 VOLTAGE MEASUREMENT ................................................... 13

3.4 INSULATION MEASUREMENT ............................................. 14

3.5 PI MEASUREMENT ................................................................. 16

3.5.1 Adjustments of the PI ...................................................................17

3.6 ADJUSTMENT OF THE VARIABLE TEST VOLTAGE........... 18

3.7 ADJUSTMENT OF THE MAXIMUM TEST VOLTAGE........... 18

3.8 ERROR MESSAGES ............................................................... 19

4. SPECIFICATIONS............................................................................ 20

4.1 REFERENCE CONDITIONS................................................... 20

4.2 VOLTAGE.................................................................................. 20

4.3 INSULATION RESISTANCE ................................................... 20

4.3.1 Accuracy in Variable Mode...........................................................21

4.3.2 Measurement of the Test Voltage after a Capacitive Insulation

Measurement ........................................................................................21

4.3.3 Calculation of Terms DAR and PI.................................................21

4.3.4 Typical Change Curve for Test Voltages according to Load.........22

4.4 CAPACITANCE......................................................................... 23

4.5 POWER SUPPLY ..................................................................... 23

4.6 ENVIRONMENTAL SPECIFICATIONS .................................. 23

4.7 MECHANICAL SPECIFICATIONS.......................................... 24

4.8 SAFETY SPECIFICATIONS.................................................... 24

4.9 VARIATIONS IN OPERATING RANGE .................................. 24

5. MAINTENANCE................................................................................ 25

5.1 RECHARGING THE BATTERY............................................... 25

5.2 FUSE REPLACEMENT............................................................ 25

5.3 CLEANING................................................................................ 25

5.4 STORAGE................................................................................. 26

5.5 REPAIR AND CALIBRATION .................................................. 26

5.6 TECHNICAL ASSISTANCE ..................................................... 26

5.7 LIMITED WARRANTY.............................................................. 27

5.8 WARRANTY REPAIRS ............................................................ 27

6 Megohmmeter Model 6505

1. INTRODUCTION

Thank you for purchasing a Megohmmeter Model 6505.

For best results from your instrument and for your safety, read the enclosed

operating instructions carefully and comply with the precautions for use. These



Symbols

Instrument is protected by double or reinforced insulation.

CAUTION - DANGER! Read the User Manual.

Risk of electric shock. The voltage at the parts marked with this

symbol may be dangerous.

Important instructions to read and to fully understand.

Useful information or tip to read.

Battery.

Fuse.

USB socket.

The CE Mark guarantees conformity with European directives and

with regulations covering EMC.





regarding Low-Voltage Safety, Electromagnetic Compatibility, and

the Restriction of Hazardous Substances.

The trash can with a line through it means that, in the European

Union, this product must undergo selective disposal for the recycling

of electric and electronic material in compliance with Directive

WEEE 2002/96/EC.



CAT IV corresponds to measurements taken at the primary electrical supply

(<1000V).

Example: primary overcurrent protection devices, ripple control units, and meters.

CAT III corresponds to measurements taken in building installations at the

distribution level.

Example: distribution panel, circuit-breakers, machines, and xed industrial

devices.

CAT II corresponds to measurements taken on circuits directly connected to low-

voltage installations.

Example: power supple to domestic electrical appliances and portable tools.

Megohmmeter Model 6505 7

1.1 PRECAUTIONS FOR USE

This instrument is protected against accidental voltages of not more than 1000V

with respect to earth in measurement Category III. The protection provided by



manufacturer, or improper ways.

■Make no measurements on conductors likely to be connected to a live source.

■Comply with the rated voltage, maximum current, and measurement category.

■

■Comply with the conditions for use: temperature, humidity, altitude, degree of

pollution, and place of use.

■Do not use the instrument or its accessories if they seem damaged.

■Use only the accessories delivered with the unit compliant with safety

standards (IEC/EN 61010-2-031 or BS EN 61010-2-031).

■Respect the value and type of the fuse (see §5.2) to avoid damaging the

instrument and voiding the warranty.

■Set the switch to OFF when the instrument is not in use.

■

personnel.

■Wear the appropriate protective gear (insulated boots & gloves).

1.2 RECEIVING YOUR SHIPMENT

Upon receiving your shipment, make sure that the contents are consistent with

the ordering information. Notify your distributor of any missing items. If the



notify your distributor at once with a detailed description of any damage. Save

the damaged packing container to substantiate your claim.

8 Megohmmeter Model 6505

1.4 ORDERING INFORMATION

Megohmmeter Model 6505............................................................. Cat. #2130.18

Includes extra-large tool bag, set of 3 color-coded 10ft leads with clips [5000V]

(red, blue, black), one blue guard terminal jumper lead, fuse 0.1A 380V,

rechargeable battery pack (installed), US 115V power cord, and user manual.



Lead – Set of 3, 25 ft (5kV) Safety with Clips................................... Cat. #2151.32

Megohmmeter Calibration Checker.................................................. Cat. #5000.66

1.4.2 Replacement Parts

Fuse – Set of 3, 0.1A, 380V, 5 x 20, 10kA.........................................Cat. #2119.84

Extra Large Tool Bag ........................................................................ Cat. #2133.73

Lead – Replacement set of 3, 10ft (5kV) Color-coded Safety

with Clips (JUMPER LEAD NOT INCLUDED).................................. Cat. #2151.30

Lead – Replacement 1ft Jumper Lead ............................................. Cat. #2151.31

9.6V rechargeable NiMH battery pack.............................................. Cat. #2960.21

Power Cord 115V US Plug ............................................................... Cat. #5000.14



Check our Storefront at www.aemc.com/store for availability

Megohmmeter Model 6505 9

2. PRODUCT FEATURES

2.1 DESCRIPTION



case and operates on battery or line power. It performs voltage, insulation, and

capacitance measurements. This instrument contributes to the safety of electrical

installations and equipment.

Features include automatic calculation and presentation of the Dielectric

Absorption Ratio (DAR) and Polarization Index (PI). The Model 6505 displays

the test voltage, insulation resistance, and leakage current during the test.

Capacitance of the sample and discharge voltage present at the test leads is

displayed at the test’s conclusion.

The Model 6505 is designed with the highest level of built-in safety features. This

meter incorporates test inhibit capabilities that will not allow test voltages to be

generated if a live sample is detected. The test terminals are recessed to ensure

operating safety.

Features:

■Test voltage combination of 500V, 1000V, 2500V, and 5000V.

■

■Adjustable and programmable test voltage (40 to 5100V).

■Automatic calculation of DAR and PI values.

■Direct measurement and display of capacitance and leakage current.

■Display of resistance, test voltage, and run time.

■Programmable test run times and PI ratio times.

■Automatic test inhibition if live sample >40% of test voltage.

■Automatic discharge and display of discharge voltage.

■Large dual-display with time, voltage, and measurements.

■

■Designed and built to IEC safety standards.

■EN 61010-1, 1000V CAT III.

10 Megohmmeter Model 6505

2.2 CONTROL FEATURES

Item 

1Access to the protective fuse and connection terminals “+”, “G”, and

“-”.

2 AC power plug (direct operation on AC and battery recharge).

3 Back-lit crystal display (see §2.5).

4 Serial interface male plug (9-pin) for calibration only.

5 Rotary selector switch with 8 positions (see §2.3).

6 START/STOP button.

7 Two function buttons (see §2.4).

( )

FF 0.1A

380V - 10kA

5x20mm

110 - 230V

50/60 Hz

20 VA max

CALIBRATION

MEGOHMMETER

MODEL 6505

1000V CAT III

2500V

DISPLAY

START/STOP

(>2s:DAR-PI )

32 4

OFF

Ω

-1000V

Ω

-2500V

Ω

- 5000V

Ω

50-5000V

SET V VAR

SET V LOCK

Ω

- 500V

Autres manuels pour 6505

Table des matières

Autres manuels AEMC instruments Instrument de mesure

AEMC instruments

AEMC instruments Measure Up PowerPad III Manuel utilisateur

AEMC instruments

AEMC instruments MN213 Manuel utilisateur

AEMC instruments

AEMC instruments 300-24-2-10 Manuel utilisateur

AEMC instruments

AEMC instruments 6292 Manuel utilisateur

AEMC instruments

AEMC instruments 6505 Manuel utilisateur

AEMC instruments

AEMC instruments SR701 Manuel utilisateur

AEMC instruments

AEMC instruments CA811 Manuel utilisateur

AEMC instruments

AEMC instruments MN134 Manuel utilisateur

AEMC instruments

AEMC instruments AmpFlex Manuel utilisateur

AEMC instruments

AEMC instruments OX5042 Manuel utilisateur

AEMC instruments

AEMC instruments MN375 Manuel utilisateur

AEMC instruments

AEMC instruments 6550 Manuel utilisateur

AEMC instruments

AEMC instruments MN312 Manuel utilisateur

AEMC instruments

AEMC instruments MN379T Manuel utilisateur

AEMC instruments

AEMC instruments 6526 Manuel utilisateur

AEMC instruments

AEMC instruments Simple Logger AmpFlex AL24-2500 Manuel utilisateur

AEMC instruments

AEMC instruments Digital FlexProbes 400D-10 Manuel utilisateur

AEMC instruments

AEMC instruments PEL 105 Manuel utilisateur

AEMC instruments

AEMC instruments DIGITAL FLEXPROBE 400D-6 Manuel utilisateur

AEMC instruments

AEMC instruments SR601 Manuel utilisateur

AEMC instruments

AEMC instruments AmpFlex Manuel utilisateur

AEMC instruments

AEMC instruments 6501 Manuel utilisateur

AEMC instruments

AEMC instruments K100 Manuel utilisateur

AEMC instruments

AEMC instruments MN185 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
