AEG CompuMaster 300 Manuel utilisateur

AEG

POWER

SUPPLY

SYSTEMS

Unterbrechungsfreie Stromversorgung

Uninterruptible Power Supply

CompuMaster

300

600

1000

Betriebsanleitung

Operating Manual

Hints concerning this manual

Responsibility of information

This manual will help you to install and to operate the

Uninterruptable

rower Supply (UPS) CompuMaster 300,

CompuMaster 600 or CompuMaster 1000

generally

simplified called CompuMaster in this manual

properly and

safe according to the assigned use. The manual includes im-

portant hints which will be helpful for a use without danger.

Please read this manual carefully before commissioning

This manual is a constituent part of the CompuMaster. The user

of this unit is obliged to provide this manual to all persons

handling the CompuMaster , e.g. transport, commissioning,

maintaining or other activity.

Validity

These operating instructions comply with the current technical

specifications of the CompuMaster at the moment of issue. The

contents do not constitute a subject of contract, but serve

information purposes only.

AEG reserves the right to make modifications with regard to

contents and technical data in these operating instructions

without prior notification.

AEG cannot be held liable for any inaccuracies or inapplicable

information in these operating instructions, as no obligation to

continuously update the data and maintain their validity has

been entered into.

Warranty

Our goods and services are subject to the general conditions of

supply for products of the electrical industry and our general

sales conditions. We reserve the right to alter any specifications

given in these operating instructions, especially with regard to

technical data, operation, weights and dimensions.

AEG will warrant for a period of one year after delivery of the

respective unit that all failures caused by faulty material or

-workmanship will be repaired accordingly, provided that the

products have been-used under normal conditions and by

appropriate operation. The a.m. warranty period will be also valid

for products being repaired according to this warranty conditions

during the time of one year. The warranty time will not be pro-

longed by repairs.

Claims in connection with supplied goods must be submitted

within one week of receipt along with the packing slip.

Subsequent

clai.ms

cannot be considered.

AEG will rescind all obligations such as warranty agreements,

service contracts etc. entered into by AEG or its representatives

without notice in the event of maintenance and repairs being

carried out with anything other than original AEG parts or spare

parts purchased by AEG as well as in case of unadequate

handling against instructions of this manual. AEG w-ill not be

responsible for damage outside the

used,product

caused by

internal failures.

Handling

The

realized

construction of the

CompuMaster

allows the user

ctiFy

out all necessary steps for erection, commissioning

and suitable operation without any internal manipulation.

Maintenance and repair of the unit should be performed by

qualified skilled personnel.

Illustrations are provided to elucidate and facilitate certain

work-

steps. If any work possibly involves danger to personnel and the

unit, it is highlighted accordingly by pictograms explained in

Chapter 2, Safety Instructions.

Hotline

Our service department is at your disposal for any questions on

the Hotline number given below:.

.Hotline”

1p’I

AEG Stromversorgungs-Systeme

GmbH

Emil-Siepmann-S

traRe

3 2

59581 Warstein

(0 29

02)

763

100

FAX

(0 29

02) 763

1203

No part of these operating instructions may

reproduced or

transmitted by any mechanical or electronic means without the

express prior written permission of AEG.

Table

contents

Notes on these operating instructions

Instruction obligation, validity

Handling, warranty

Hotline, copyright

System description 36

Safety 38

2.1

General safety hints

2.2

Safety hints for the

UPS CompWIaster 300

600

1000

Technical data 43

4Commissioning and operation 45

4.1

4.2

4.3

4.4

4.5

4.6

4.6.1

4.6.2

4.6.3

4.6.4

4.7

Uncasing

and testing

Site conditions

Principle sketch of connecting points

and operation/display elements

Initial start up

Operation

Danger signals

Normal operation

Battery operation

Overload conditions

Troubleshooting

Communication interface

UPS management- and shutdown software

CompuWatch

Storage, dismounting

and

scrapping 59

5.1

Storage

5.2

Dismounting

5.3

Scrapping

1 System description

The CompuMaster is an Uninterruptible Power Supply

(UPS) for essential loads like PC’s, IT systems and

similar device, consisting of

a rectifier (battery charging)

a battery as energy storage device during mains failure

(input supply for the inverter)

an inverter to supply the connected loads when a

mains failure occurs

a static stitch-over circuit to change AC-power supply

from mains to inverter as long as mains is not available

and

a filter circuit, situated on the mains input

cbzuger

1’1

iwerter

battery

load

Bloc diagram of a UPS

The UPS has to be connected between mains distribution

and the load via standard mains socket.

Under normal operating conditions, i.e. the

Compu-

Master is supplied by mains, the battery will be fully

charged by the rectifier. Loads connected to the Compu-

Master will be supplied with filtered mains voltage.

pm-.-

When mains is not available or in case of decreased mains

voltage to 85% of nominal value or less the inverter will take

over the supply of the connected loads.

The CompuMaster w-ill supply the load for a time according to the

battery capacity. This autarky time depends in general on the

load power. In case of restored mains supply the UPS will switch

over the load from inverter to mains operation, i.e. the load will

be supplied by mains again and the battery will be recharged.

In case of a mains blackout the mains input will be automatically

disconnected by a two-pole-switch to fulfil1 safety requirements of

german standards (VDE) and to avoid backfeeding from the

inver-

ter to the mains.

The availability of the following three protecting functions is

guaranteed:

Protection against mains blackout

Due to the type of CompuMaster the UPS will provide automati-

cally output power up to

3OOVA,

600VA oder

IZOOVA

for a time

being sufficient to shut down and switch off the system accor-

dingly via shut-down software. The effective autarky time differs

individually and depends in general on the power consumption of

your connected system load.

Protection against mains disturbance

In case of an input voltage change to less than 85% or more than

110% of nominal value, the CompuMaster initialises the change-

over to battery operation automatically and supplies the load with

AC-voltage to minimize the risk of data loss or damage.

Protection against electromagnetical disturbance

Disturbanc.es

and problems caused by HF will be reduced by the

use of an EMI filter network

2 Safety regulations

2.1 General safety instructions

Read these operating instructions carefully before initial

start-up of the

CompuMaster

and pay attention to the

safety instructions in any case

Use the unit only in a perfect technical state according

to the intended purpose and subject to the operating

instructions

Eliminate failures and any trouble which

can influence safety of personnel and goods.

The following symbols are used in these operating in-

structions to point at possible danger or for any other

reference:

CAUTION

This symbol identifies all working and operational

procedures requiring absolute compliance to avoid any

danger to personnel.

ATTENTION

This symbol identifies all working and operational

procedures requiring absolute compliance to prevent

danger of hurt to the personnel and any damage, irrepa-

rable or otherwise, to the

CompuMaster

or its

comnents.

NOTE

This symbol identifies technical requirements and

additional information requiring the operator’s attention.

2.2 Safety hints subject to

CompuMastcr

300/400/

1000

The contents of this chapter are important instructions

subject to the

CompuMaster

as well as the battery

concerning erection, operation and maintenance to be

complied with.

The UPS is connected to hazardous voltage.

Opening of

the unit is only allowed to qualified and authorized

personnel.

Repairs are only allowed to qualified service

personnel

Hazardous voltage may be applied to the output termi-

nals as well as mains is not connected, because the UPS

will be still running on it’s internal power supply

(battery)

/’

Duly earthing

of the unit is a must regarding the pro-

tection of the personnel

It is only allowed to connect to and operate the

Compu-

Master at AC-voltage 230V of a mains distribution with

protective earth by using a VDE-tested or equivalent

mains connection cable with protective earth contact

(enclosed).

Attention regarding burn (personnel) and fire

The ability of potential high

short-circuit currents

may

lead to melting connectors and firing with the result of

severe skin burns

The unit is provided with an acoustic signalling device to

warn in case of low battery voltage as well as if the UPS

does work in an abnormal state (see chapter 4.6, danger

signals).

To keep the UPS in good condition as well as for safe

working with, please pay attention to the following

safety instructions:

Don’t disassemble the UPS

The unit is provided for erection in

Don’t use the UPS near water or in

excessive humidity

heated interior.

environments with

Never connect mains input terminals to the UPS output

Please make safe, that no liquids or foreign matter can

enter the UPS

Don’t cover air inlet or outlet of the cabinet

Please make

safe, that children or other people don’t enter foreign

matter into this cooling openings

Don’t use the UPS as power supply for household

appliance, e.g. hair drier

Don’t erect the unit near heaters;

avoid direkt solar radiation

The mains wall plug should be situated near the unit:

Disconnecting should be possible without problems to

simplify maintaining of the UPS without input voltage

available

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels AEG UPS

AEG

AEG Protect C.3000 Manuel utilisateur

AEG

AEG Protect A. 1400 Manuel utilisateur

AEG

AEG MBS 6000 Manuel utilisateur

AEG

AEG Protect D Series Manuel utilisateur

AEG

AEG Protect Home Manuel utilisateur

AEG

AEG PROTECT 1 Series Manuel utilisateur

AEG

AEG PROTECT B. 2000 Manuel utilisateur

AEG

AEG Protect 5.31 Manuel utilisateur

AEG

AEG PROTECT A. 500 Manuel utilisateur

AEG

AEG Protect NAS Manuel du propriétaire

AEG

AEG PROTECT C. 1000 (S) Manuel utilisateur

AEG

AEG PROTECT C. 10000 Manuel utilisateur

AEG

AEG Protect B. 750 PRO Manuel utilisateur

AEG

AEG PDU 10-1 Manuel utilisateur

AEG

AEG Protect alpha. 1200 Manuel utilisateur

AEG

AEG Protect A. 1000 Manuel utilisateur

AEG

AEG Protect 2.33 2.0 Manuel utilisateur

AEG

AEG Protect alpha 450 Manuel utilisateur

AEG

AEG Protect Home. 600 Manuel utilisateur

AEG

AEG PROTECT C Series Manuel utilisateur

AEG

AEG UPS 10 kVA Manuel utilisateur

AEG

AEG Protect D. 6000 (BP) Manuel utilisateur

AEG

AEG Protect C.R Manuel utilisateur

AEG

AEG Fluxpower HE Series Manuel d'installation et d'exploitation

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
