advidia M-44-V-T-V2 Manuel utilisateur
Network Eyeball Cameras
Quick Guide
V1.00
M-44-V-T-V2
1
Waterproof Requirements
Please waterproof cables in accordance with the following instructions. User shall
assume all responsibility for device damage caused by water due to improper
waterproof measures.
NOTE!
⚫Before you start, connect all the needed cables and cut off the copper wires for
the cables that you don't use.
⚫Please use self-adhesive waterproof tape (supplied with some products) to
protect the cables.
⚫Use waterproof components to protect the network cable. Waterproof the
power cable separately if you don’t use it. The video cable does not need
waterproof treatment.
1. Use insulation tape (not included in the package) to insulate the connection part
of each cable.
2. Waterproof the cables with self-adhesive waterproof tape.
(1) Fully stretch the waterproof tape at both ends.
(2) Wrap the connection part and the cable ends tightly with waterproof tape.
Make sure the tape is fully stretched during the process.
(3) Tighten the tape at both ends to prevent water leakage.
Connection part
Insulation tape
2
3. Install the supplied waterproof components to the network cable in sequence.
CAUTION!
You need to mount the rubber ring onto the network cable interface first.
4. If your camera has a DC cable and you will not use it, insert the plug into the
interface.
5. (Optional) After the waterproof treatment is completed, put the cables into a
waterproof junction box (purchased separately).
CAUTION!
⚫The cable connector must not be exposed and must be kept away from water.
⚫Restore and fasten the device after dismounting.
⚫Place the power adapter in a power distribution box.
Wrap the unused cables together into a bundle
Tighten Tighten
Waterproof tape
Tighten
DC interface
Plug
3
1Packing List
Contact your local dealer if the package is damaged or incomplete. The attachments
may vary with models, please see the actual model for details.
No.
Name
Qty
Unit
1
Camera
1
PCS
2*
Waterproof components（1）
1
Set
3*
Screw components（2）
1
Set
4*
Mount accessory （3）
1
Set
5
User manual
1
Set
Remarks:
* means optional and supplied with certain models only.
(1)Including one or more waterproof components such as tape and plug.
(2)Including one or more accessories such as screws and hex key.
(3)Including one or more items from drilling template, bracket adapter, anti-static
gloves, etc.
2Safety Instructions
Installation and removal of the unit and its accessories must be carried out by
qualified personnel. You must read all of the safety instructions before installation
and operation.
2.1 Precautions
⚫Use a power adapter or a PoE device that meets requirements. Otherwise, the
device may be damaged.
⚫Be careful not to blur, scratch, damage the dome cover or leave fingerprints on
it because this could decrease image quality. Keep the protective film on the
dome cover until installation is complete.
⚫Make sure the length of the power cable between the power adapter and the
camera is not too long, otherwise the voltage of the camera is lowered, causing
the camera to work abnormally. If it is required to lengthen the power cable,
lengthen the cable between the power adapter and the mains.
4
⚫Do not overbend the cables during the installation, otherwise, poor cable contact
may cause malfunction.
⚫When connecting to an external interface, use an existing connection terminal,
and ensure that the cable terminal (latch or clamp) is in good condition and
properly fastened. Ensure that the cable is not tense during mounting, with a
proper margin reserved to avoid poor port contact or loosening caused by shock
or shake.
⚫During transportation, special attention is required to protect the transparent
dome cover from friction, scratch and stain, etc. Do not remove the protective
film from the cover until mounting is finished. Remove the protective film before
powering on the device.
⚫Make sure the wall or ceiling is strong enough to support the weight of the
camera. If dust falls during mounting, take off the dome cover and keep it away
from dust. Install the dome cover after the base is installed.
⚫Contact professionals for maintenance information. Do not attempt to dismantle
the device by yourself. We shall not assume any responsibility for problems
caused by unauthorized repair or maintenance.
2.2 Maintenance
⚫If there is dust on the front glass surface, remove the dust gently using an oil-
free brush or a rubber dust blowing ball.
⚫If there is grease or a dust stain on the front glass surface, clean the glass surface
gently from the center outward using anti-static gloves or an oil-free cloth. If the
grease or the stain still remains, use anti-static gloves or an oil-free cloth dipped
with detergent and clean the glass surface gently until it is clean.
⚫Do not use organic solvents (such as benzene and alcohol) to clean the
transparent dome cover.
3Appearance
3.1 Dimensions
The appearance and tail cable may vary with device model.
Type A
5
Type B
3.2 Cable Connection
The appearance and tail cable may vary with device model.
Type A
110mm
4.3"
129mm
5.1"
129mm
5.1''
111mm
4.4''
6
Type B
1. Bottom ring
2. Housing
3. Mic
4. Lens
5. Power interface(12 VDC)
6. Ethernet interface
IP
Network
1
2
3
5
6
4
IP
Network
1
2
3
5
6
4
7
NOTE!
Use a pin to press and hold the Reset button for about 15 seconds to restore factory
default settings. Perform this operation within 10 minutes after the device is
powered on or the reset will fail otherwise.
4Mount Your Camera
You can adopt ceiling mount or wall mount and purchase hardware accessories by
yourself. The following part takes ceiling mount as an example. Wall mount is similar
to ceiling mount and therefore is omitted here.
1. Attach the sticker to ceiling, and then drill 30-mm deep guide holes using a drill
bit (6mm or 6.5mm in diameter) according to the sticker.
2. Insert the plastic anchors.
(1) Drill a hole to lead cables out of the ceiling.
(2) Knock in plugs.
2
1
8
3. Loosen the fixing screw, then remove the housing. Loosen the fixing screw, then
turn the housing to the position shown in figure to remove it.
4. Connect the cable and then secure the bottom ring.
5. Mount the housing.
Adjust the housing to the position shown in figure above.Align the screw hole on the
1
Attach bottom ring to ceiling with
taping screws
Connect cable and protect it
with waterproof tape
(Optional) insert a
micro SD card
9
housing with the tail cable outlet on the base, attach the housing gently and then
rotate clock/counterclockwise at least 8 degrees to lock.To ensure proper image
display and illumination effects, make sure the mark (see figure above) is aligned
with the screw hole when installation is complete.
6. Adjust the monitoring direction. Adjust the monitoring direction, then tighten the
screw.
NOTE!
⚫Do not adjust monitoring direction by force with the screw fully tightened.
Loosen the screw first.
⚫For open installation, lead the tail cable out of the open slot on the base plate
first and then fasten the screw.
5Startup
After you have installed the device, connect one end of the power adapter
(purchased separately) to power supply, and then connect the other end to the
power interface to start up the device.
6Access Your Camera
1. Open your Web browser, enter the camera's IP address in the address bar, and then
press Enter. The default IP is 192.168.1.13.
