B-5360 Hardware and Install Manual
Table of Contents
Precautions 4 -
Safety Instructions ........................................................................... 6 -
Introduction 7 -
Package Contents............................................................................. 7 -
Physical Description ........................................................................ 7 -
B-5360 ........................................................................................... 8 -
Mounting Options ............................................................................. 9 -
Installation Procedures 10 -
Step 1: Prepare for Installation...................................................... 10 -
Step 2: Open the Dome Cover ....................................................... 11 -
Step 3: Route the Cables ............................................................... 12 -
Step 4: Install the Camera.............................................................. 13 -
Step 5: Waterproof the Cable Connection .................................... 14 -
RJ-45 Ethernet Cable (B-5360).................................................... 14 -
Step 6: Connect to Network........................................................... 17 -
Step 7: Access the Camera Live View........................................... 17 -
Step 8: Close the Dome Cover....................................................... 18 -
Other Adjustments and Accessories 20 -
How to Install / Remove the Memory Card ................................... 20 -
How to Insert the Memory Card ................................................... 20 -
How to Remove the Memory Card............................................... 20 -
How to Adjust the Fisheye View Orientation [B-5360] .............. 21 -
How to Connect Audio In Device................................................... 22 -
How to Replace the Dome Cover ................................................... 23 -
Accessing the Camera 25 -
2
Available from A1 Security Cameras
B-5360 Hardware and Install Manual
Configure the IP Addresses........................................................... 25 -
Using DHCP Server to Assign IP Addresses................................ 25 -
Using the Default Camera IP Address.......................................... 27 -
Access the Camera......................................................................... 29 -
3
Available from A1 Security Cameras
B-5360 Hardware and Install Manual
Precautions
Read these instructions
Read all the safety and operating instructions before using this product.
Heed all warnings
Adhere to all the warnings on the product and in the instruction manual. Failure to follow the
safety instructions given may directly endanger people, cause damage to the system or to other
equipment.
Servicing
Do not attempt to service this product yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Trademarks
All names used in this manual are probably registered trademarks of respective companies.
Liability
Every reasonable care has been taken during the writing of this manual. Please inform your local
office if you find any inaccuracies or omissions. The manufacturer will not be held responsible for
any typographical or technical errors and reserves the right to make changes to the product and
manuals without prior notice.
4
Available from A1 Security Cameras
B-5360 Hardware and Install Manual
Federal Communications Commission Statement
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to the equipment that are not expressly approved by the
responsible party for compliance could void the user’s authority to operate the equipment.
European Community Compliance Statement
This product has been tested and found to comply with the limits for Class B -
Information Technology Equipment according to European Standard EN 55022
and EN 55024. In a domestic environment, this product may cause radio interference in which
cause the user may be required to take adequate measures.
5
Available from A1 Security Cameras
B-5360 Hardware and Install Manual
Safety Instructions
Cleaning
Disconnect this product from the power supply before cleaning.
Accessories and Repair Parts
Use only the accessories and repair parts recommended by the manufacturer. Using other
attachments not recommended by the manufacturer may cause hazards.
Installation
Install other devices (such as PoE injector, alarm, etc.) that will be used with the camera in a dry
place protected from weather,
Servicing
Do not attempt to service this product yourself. Refer all servicing to qualified service personnel.
Damage Requiring service
Disconnect this product from the power supply immediately and refer servicing to qualified
service personnel under the following conditions. -
1) When the power-supply cord or plug is damaged -
2) If liquid has been spilled, or objects have fallen into the product. -
3) If the inner parts of product have been directly exposed to rain or water. -
4) If the product does not operate normally even by following the operating instructions in this
manual. Adjust only those controls that are covered by the instruction manual, as improper
adjustment of other controls may result in damage, and will often require extensive work by a
qualified technician to restore the product to its normal operation.
Safety Check
Upon completion of any service or repairs to this product, ask the service technician to perform
safety checks to determine if the product is in proper operating condition.
6
Available from A1 Security Cameras
-
B-5360 Hardware and Install Manual
Introduction
Package Contents
Check if the camera package comes with the following items:
Camera
B 5360
Drill Template
Drill Template
Screw Kit Hexagon Screwdriver Dome Cover Tab
Quick Installation Guide
IMPORTANT: When the camera is taken out from the box, the lens cover is covered by a thin film.
DO NOT remove this film. It is used to protect the lens cover from scratches or fingerprint marks
which may happen during installation. Remove this film only after the camera is securely installed
and all connections are complete.
Physical Description
7
Available from A1 Security Cameras
B-5360 Hardware and Install Manual
B-5360 -
Item Description
1 System LEDs Indicates the camera status:
Amber LED: Blinks when network activity is in progress.
Blue LED: Lights up when the camera is powered up and
goes off again after the boot up process is complete.
Green LED: Lights up when the camera is connected to a
network.
2 Audio Input Connects to audio input devices, such as a microphone with
built-in amplifier, etc. See How to Connect Audio In Device on
page 22 for more information.
NOTE: The microphone must have a built-in amplifier.
Connecting an ordinary microphone will dwarf sounds and will
result in inaudible recording.
3 Ethernet Port
(RJ-45)
Connects to a network using an Ethernet cable with RJ-45
connector.
4 Reset Button Restores the factory default settings of the camera. To reset the
camera, while the power is on, press and hold the Reset Button
for at least 5 seconds or until the Blue LED lights up.
5 Memory Card Slot Insert a memory card (not included) into the slot for local
recording purposes. See How to Install / Remove the Memory
Card on page 20 for more information.
NOTE: Supports microSDHC and microSDXC cards.
8
Available from A1 Security Cameras
B-5360 Hardware and Install Manual
Mounting Options
Select the most suitable solution for your installation environment. The camera can be mounted
by either of the following methods:
Mount Types Accessories
Surface Mount Suitable when mounting the camera directly on walls or ceilings without
additional mounting accessories. See Installation Procedures
on page
10 for more information.
Gangbox Suitable when mounting the camera on a 4” Round or 4” Octagon
Gangbox. The use of gangbox is lawfully required in some areas in the
United States. A Gangbox Converter (purchased separately) is required
for this type of installation.
Wall Mount Suitable when mounting the camera on the wall with the camera facing
down as if installed on the ceiling. The Wall Mount (optional mounting
accessory) is required for this type of installation.
Pendant Mount Suitable when installing the camera on high ceilings where a straight
tube is used to lower the camera. The Pendant Mount with Mount Kit
(optional accessory set) is required for this type of installation.
NOTE:
Note that for Q91 people counting cameras, the surface mount on ceiling and pendant
mount are recommended.
For more information about the mounting solutions and accessories, please check our
website.
The above mounting accessories are not included in the package. Contact your sales
agents to purchase.
9
Available from A1 Security Cameras
-
B-5360 Hardware and Install Manual
Installation Procedures
This section describes procedures in mounting the camera on a flat surface. -
NOTE: The camera images on this documentation are for reference only and may be different -
from the actual camera.
Step 1: Prepare for Installation
1. - Before installing the camera, prepare the additional accessories required for installation.
B 5360
Exterior-grade Ethernet Cable with
RJ-45 connector (not included; can be
purchased from local stores)
Bundled Cable Gland
2. - Depending on the material of the surface where the camera will be installed, it may be
necessary to drill the three (3) screw holes and use the supplied screw tox. In this case,
attach the bundled drill template on the surface and drill the screw holes.
10
