Advidia A-47 Guide de l'utilisateur

A-47 IR Network Mini Dome Camera

Quick Operation Guide

A-47 IR Mini Dome Camera •Quick Operation Guide

Thank you for purchasing the Advidia A-47 IR mini dome camera. If

there are any questions, or requests, please do not hesitate to

contact the dealer.

About This Document

This manual applies to the following models.

Model

A-47 IR

This manual may contain several technical incorrect places or

printing errors, and the content is subject to change without notice.

The updates will be added to the new version of this manual. We will

readily improve or update the products or procedures described in

the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the

performance or reliability of the security or signaling aspects of this

product. UL has only tested for fire, shock or casualty hazards as

outlined in UL’s Standard(s) for Safety, UL60950-1. UL Certification

does not cover the performance or reliability of the security or

signaling aspects of this product. UL MAKES NO REPRESENTATIONS,

WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE

PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING

RELATED FUNCTIONS OF THIS PRODUCT.

A-47 IR Mini Dome Camera •Quick Operation Guide

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to

comply with the limits for a digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference in which

case the user will be required to correct the interference at his own

expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized European

standards listed under the Low Voltage Directive 2006/95/EC, the

EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.

A-47 IR Mini Dome Camera •Quick Operation Guide

2012/19/EU (WEEE directive): Products marked

with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment,

or dispose of it at designated collection points. For more information

see: www.recyclethis.info.

2006/66/EC (battery directive): This product

contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union.

See the product documentation for specific battery

information. The battery is marked with this symbol,

which may include lettering to indicate cadmium (Cd), lead (Pb), or

mercury (Hg). For proper recycling, return the battery to your

supplier or to a designated collection point. For more information

see: www.recyclethis.info

A-47 IR Mini Dome Camera •Quick Operation Guide

Safety Instruction

These instructions are intended to ensure that user can use the

product correctly to avoid danger or property loss.

The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the warnings

are neglected.

Cautions: Injury or equipment damage may occur if any of the

cautions are neglected.

Warnings

●In the use of the product, you must be in strict compliance with

the electrical safety regulations of the nation and region. Please

refer to technical specifications for detailed information.

●Input voltage should meet both the SELV (Safety Extra Low

Voltage) and the Limited Power Source with 24 VAC or 12 VDC

according to the IEC60950-1 standard. Please refer to technical

Warnings Follow these

safeguards to prevent

serious injury or death.

Cautions Follow these

precautions to prevent

potential injury or material

damage.

A-47 IR Mini Dome Camera •Quick Operation Guide

specifications for detailed information.

●Do not connect several devices to one power adapter as

adapter overload may cause over-heating or a fire hazard.

●Please make sure that the plug is firmly connected to the power

socket. When the product is mounted on wall or ceiling, the

device shall be firmly fixed.

●If smoke, odor or noise rise from the device, turn off the power

at once and unplug the power cable, and then please contact

the service center.

Cautions

●Make sure the power supply voltage is correct before using the

camera.

●Do not drop the camera or subject it to physical shock.

●Do not touch sensor modules with fingers. If cleaning is

necessary, use clean cloth with a bit of ethanol and wipe it

gently. If the camera will not be used for an extended period,

please replace the lens cap to protect the sensor from dirt.

●Do not aim the camera at the sun or extra bright places.

Blooming or smearing may occur otherwise (which is not a

malfunction), and affect the endurance of sensor at the same

time.

●The sensor may be burned out by a laser beam, so when any

laser equipment is in using, make sure that the surface of

A-47 IR Mini Dome Camera •Quick Operation Guide

sensor will not be exposed to the laser beam.

●Do not place the camera in extremely hot, cold (the operating

temperature shall be-30℃~+60℃,or -40°C ~ 60°C if the camera

model has an “H” in its suffix), dusty or damp locations, and do

not expose it to high electromagnetic radiation.

●To avoid heat accumulation, good ventilation is required for

operating environment.

●Keep the camera away from liquid while in use.

●While in delivery, the camera shall be packed in its original

packing, or packing of the same texture.

●Regular part replacement: a few parts (e.g. electrolytic

capacitor) of the equipment shall be replaced regularly

according to their average enduring time. The average time

varies because of differences between operating environment

and using history, so regular checking is recommended for all

the users. Please contact with your dealer for more details.

●Improper use or replacement of the battery may result in

hazard of explosion. Replace with the same or equivalent type

only. Dispose of used batteries according to the instructions

provided by the battery manufacturer.

●If the product does not work properly, please contact your

dealer or the nearest service center. Never attempt to

disassemble the camera yourself. (We shall not assume any

responsibility for problems caused by unauthorized repair or

maintenance.)

A-47 IR Mini Dome Camera •Quick Operation Guide

Table of Contents

1 Appearance Description ................................................................. 8

2 Installation.................................................................................... 10

Ceiling Mounting........................................................... 112.1

Ceiling Mounting with a Gang Box ................................ 152.2

Pendant Mount Installation......................................... 177

2.3

Wall Mount Installation............................................... 2002.4

Install the Micro SD Card ............................................. 2222.5

3 Setting the Network Camera over the LAN ................................ 244

4 Accessing via Web Browser .......................................................... 29

A-47 IR Mini Dome Camera •Quick Operation Guide

1Appearance Description

Overview (1)Figure 1-1

A-47 IR Mini Dome Camera •Quick Operation Guide

Overview (2)Figure 1-2

Physical DescriptionTable 1-1

No.

Description

Housing

Camera Body

Micro SD Card Slot

Network Cable

Lens

IR LED

Power Cable

Audio/Alarm Cables- Not included on A-47 IR

Wi-Fi Antenna- Not included on A-47 IR

Serial Port Interface

Hex Screw

MIC- Not included on A-47 IR

RESET

Press RESET about 10s when the camera is powering on or

rebooting to restore the default settings, including the user

name, password, IP address, port No., etc.
